Masterbuilt MB10 Assembly And Operating Instructions Manual

Masterbuilt MB10 Assembly And Operating Instructions Manual

Outdoor lp gas turkey fryer
Hide thumbs Also See for MB10:

Advertisement

Quick Links

Download this manual See also: Manual
Enlarged version
Masterbuilt
Gas Cooker
STOP AND READ
WARNING
1. Do not store extra cooking
oil/grease in the vicinity of this
or any other cooking
appliance.
2. Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity or
within 25 feet (8 m) of this or
any other cooking appliances.
3. Do not store spare LP Gas
cylinder within 10 feet (3m) of
this or any other cooking gas
appliance.
4. Keep LP Gas cylinder up wind
when in use.
5. When cooking with oil/grease,
do not allow the oil/grease to
get hotter than 350° F (177° C).
6. 6. Do not leave the oil/grease
unattended while cooker is in
use.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Perform soapy water test
4. If odor continues, immediately
call your gas supplier or your
fire department.
5. Leaking gas may cause a fire
or explosion which can cause
serious injury or death, or
damage to property.
Failure to follow these instructions and warnings properly
could result in fire or explosion, which could cause property
damage, personal injury, or death.
If parts are missing Do Not Use Cooker. Call 800-489-1581 for
replacement parts. Do Not Return to dealer without contacting us first.
Tips and Recipes are inside the manual, so save this manual for future reference.
Outdoor LP Gas Turkey Fryer
ASSEMBLY AND OPERATING INSTRUCTIONS
WARNING AND SAFETY INFORMATION
Model:MB10
FOR YOUR SAFETY
1. Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
cooking appliance.
2. When cooking with oil or grease, do
not allow oil/grease to exceed 350° F
(177° C). One gallon of oil can reach
350° in 7 to 10 minutes. Use a
thermometer to check temperature.
When cooker is in operation, NEVER
LEAVE UNATTENDED. Oil will heat
up quickly and ignite at 550° to 700°.
(Use a Max of one gallon of oil in the
10qt to 12qt pots, and a Max of
Three gallons of oil in the 30qt pot.)
3. An LP cylinder not connected for
use shall not be stored in the
vicinity of this or any other
appliance.
LP Cylinder
Not Included
Rev 6/01

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB10 and is the answer not in the manual?

Questions and answers

Related Manuals for Masterbuilt MB10

Summary of Contents for Masterbuilt MB10

  • Page 1 Masterbuilt Outdoor LP Gas Turkey Fryer ASSEMBLY AND OPERATING INSTRUCTIONS Gas Cooker WARNING AND SAFETY INFORMATION STOP AND READ Model:MB10 WARNING 1. Do not store extra cooking oil/grease in the vicinity of this or any other cooking appliance. 2. Do not store or use gasoline...
  • Page 2 WARNINGS Read and follow ALL INSTRUCTIONS and WARNINGS carefully before operating. • The Masterbuilt 3010 Outdoor Gas Cooker is for OUTDOOR USE ONLY. Do not use inside an enclosed area such as Patios, Garage or overhang of a house or building.
  • Page 3 WARNINGS • Always perform the soapy water test every time you use this appliance. • Always disconnect your gas cylinder from your cooker stand when not in use. • Keep your hands, hair and face away from the burner. Do not lean over the cooker stand when lighting the burner when cooking.
  • Page 4 Outdoor LP Gas Fryer / Boiler Assembly Instructions READ ALL INSTRUCTIONS AND WARNINGS CAREFULLY BEFORE ASSEMBLY OR OPERATION OF YOUR COOKER. PLEASE CHECK CONTENTS OF BOX FOR ALL PARTS. Mounting Cooker Legs 1. Secure all 3 legs to the windshield first using 2- 1/4” nuts and bolts per leg.
  • Page 5 Asked Question When The Cast Iron Burner Burns Yellow or Not At All What Do I Do? If your burner does not burn, blows out, burns yellow, or there’s a flame inside the ventura, you need to check the burner ventura for any obstructions.
  • Page 6 REGULATOR TO GAS CYLINDER VALVE CONNECTION Your Cooker May Be Equipped with Either a Type 1 or POL Connection COUNTER COUNTER CLOCKWISE CLOCKWISE CLOCKWISE CLOCKWISE POL CONNECTION TO GAS CYLINDER Type 1 CONNECTION TO GAS CYLINDER USE A 7/8” WRENCH TO TIGHTEN.
  • Page 7 DURING ANY PORTION OF THE SOAPY WATER TEST, IF BUBBLES CONTINUE TO APPEAR, STOP, DO NOT USE AND CONTACT YOUR LOCAL PROPANE DEALER OR THE MASTERBUILT HOTLINE AT 800-489-1581 EXT. 101. NOTE: USE A 20 LB. CYLINDER OR SMALLER WITH YOUR OUTDOOR GAS COOKER!
  • Page 8 Gas Boiling, Frying, Lighting Instructions: 1. Check the regulator control valve to be certain it is in the OFF position and perform soapy water test before each use. 2. Open lid if applies and turn gas cylinder valve ON. Use a long match or spark ignitor through the burner lighting hole.

  • Page 9: For Your Safety

    Gas Cylinder Size, Storage, and Filling A) Do Not Store a Spare LP-Gas Cylinder Under or Near Appliance. B) Never Fill the Cylinder Beyond 80 Percent Full. If the Instructions in “(A)” or “(B)” are not Followed Exactly, a Fire Causing Death or Serious Injury May Occur.

  • Page 10: Warranty Information

    WARRANTY INFORMATION •One turkey Up To 20 Pound Max (whole bird) in 30 Qt Pot. Masterbuilt warrants the burner, regulator valve, hose, thermometer, cookware and stand of the •Inject turkey and season outside of the turkey with Masterbuilt’s Cajun Spices.

  • Page 11: Outdoor Use Only

    Optional Accessories • Choose steaks to your desired thickness. • Season the outside of the steak with Masterbuilt’s Sizzlin’ Steak seasoning rub. • The amount of oil needed is 2 gallons. (Use 30 Quart Pot) STEP 1 - Place each steak in basket STEP 2 - With each steak seasoned it’s time to heat up the cooking oil.
  • Page 12 Model # DGM newspaper in the middle of your table and enjoy. Send us your recipe We would love to try it. Marketing Dept. Masterbuilt Mfg. Inc. 450 Brown Ave Columbus, GA 31906 Call 1-800-489-1581 OUTDOOR USE ONLY NEVER LEAVE UNATTENDED...
