PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
www.moosesound.com
TL260Z
Multi-zone PA mixer/amplifier
6 independent zones
TL260Z
MULTI-ZONE PUBLIC ADDRESS AMPLIFIER
ZONE
1
2
3
4
5
6
VOLUME
EQUALIZER
MIC
MIC/LINE
TREBLE
BASS
MASTER VOLUME
1
2
3
4
DING
OUPUT LEVEL
DONG
POWER ON
VOLUME
0
10
-13
-8
-3
0dB
CLIP
USER'S MANUAL
MAN196_0
Advertisement
Table of Contents
Related Manuals for MOOSE TL260Z
Summary of Contents for MOOSE TL260Z
- Page 1 PROUDLY DEVELOPED AND MANUFACTURED IN PORTUGAL www.moosesound.com TL260Z Multi-zone PA mixer/amplifier 6 independent zones TL260Z MULTI-ZONE PUBLIC ADDRESS AMPLIFIER ZONE VOLUME EQUALIZER MIC/LINE TREBLE BASS MASTER VOLUME DING OUPUT LEVEL DONG POWER ON VOLUME CLIP USER’S MANUAL MAN196_0...
- Page 2 Dear customer, Thank for choosing MOOSE branded products! MOOSE is a brand of professional audio & lighting products, proudly developed and manufactured in PORTUGAL. In order to operate this product in a safe and reliable manner, please follow the instructions in this booklet and before operating the equipment read the instructions carefully and please note the technical information.
- Page 3 To prevent unneeded devices from consuming power in standby mode, disconnect the mains plug. EC DECLARATION OF CONFORMITY The equipment marketed by MOOSE complies (where applicable) with the essential requirements and other relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD). Additional information can be requested to info@profactor.pt.
- Page 4 TL260Z Multi-zone PA mixer/amplifier Connections and Controls Please refer to the following scheme and instructions: TL260Z MULTI-ZONE PUBLIC ADDRESS AMPLIFIER ZONE VOLUME EQUALIZER MIC/LINE TREBLE BASS MASTER VOLUME DING OUPUT LEVEL DONG POWER ON VOLUME CLIP OUTPUT INPUT 0-100V 4/16...
- Page 5 1 - Verify that all Volume Control Pots ( 2 - 8 ) are at their minimum value ( 0 ); 2 - Connect the Mains Supply Cable ( 25 ); 3 - Connect all signal sources and devices that will be working with TL260Z to their respective Inputs just like connection diagram below;...
-
Page 6: Connection Diagram
INDEPENDENT ZONES connection ( 100V ): OUTPUT 0-100V 4/16 IN ORDER TO HAVE THE TL260Z WORKING WITH DIFFERENT ZONES YOU JUST HAVE TO CONNECT COMMON terminal marked with “COM” AND THE RESPECTIVE ZONE TERMINAL TO THE SPEAKER ( + ) www.moosesound.com MAN196_0... -
Page 7: Technical Specifications
TL260Z Multi-zone PA mixer/amplifier Technical specifications MODEL TL260Z TYPE Public address mixer-amplifier POWER OUTPUT (RMS) 260W FREQUENCY RANGE 50Hz - 15kHz T.H.D. (20Hz - 20kHz) < 1% @ 1kHz S/N RATIO > 90dB @ 1kHz ZONES 6 zones CONTROLS Bass, Treble and Master, Volume for MIC/LINE in... - Page 8 PROUDLY DEVELOPED AND MANUFACTURED IN PORTUGAL MOOSE is a brand or PROFACTOR S.A. PROFACTOR S.A Rua do Padrão 52 4440-617 Valongo PORTUGAL Telf.: +351 224 119 160 Fax: +351 224 155 822 info@profactor.pt www.moosesound.com...
