- Page 1 PROUDLY DEVELOPED AND MANUFACTURED IN PORTUGAL www.moosesound.com TL6Z Multi-zone PA mixer/amplifier 6 independent zones TL6Z MULTI-ZONE PUBLIC ADDRESS AMPLIFIER POWER ON VOLUME USER’S MANUAL MAN195_0...
- Page 2 Dear customer, Thank for choosing MOOSE branded products! MOOSE is a brand of professional audio & lighting products, proudly developed and manufactured in PORTUGAL. In order to operate this product in a safe and reliable manner, please follow the instructions in this booklet and before operating the equipment read the instructions carefully and please note the technical information.
- Page 3 To prevent unneeded devices from consuming power in standby mode, disconnect the mains plug. EC DECLARATION OF CONFORMITY The equipment marketed by MOOSE complies (where applicable) with the essential requirements and other relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD). Additional information can be requested to info@profactor.pt.
- Page 4 TL6Z Multi-zone PA mixer/amplifier Connections and Controls Please refer to the following scheme and instructions: TL6Z MULTI-ZONE PUBLIC ADDRESS AMPLIFIER POWER ON VOLUME INPUT UNBALANCED moosesound.com OUTPUT FUSE F 8A 0-100V 0-100V 0-100V 0-100V WARNING RISK OF ELECTRIC SHOCK. DO NOT OPEN.
- Page 5 1 - Verify that all Volume Control Pots ( 2 - 7 ) are at their minimum value ( 0 ); 2 - Connect the Mains Supply Cable ( 11 ); 3 - Connect all signal sources and devices that will be working with TL6Z to their respective Inputs just like connection diagram below;...
- Page 6 TL6Z Multi-zone PA mixer/amplifier Technical specifications MODEL TL6Z TYPE Public address mixer-amplifier POWER OUTPUT (RMS) 6x 150W FREQUENCY RANGE 50Hz - 15kHz T.H.D. (20Hz - 20kHz) < 1% @ 1kHz S/N RATIO > 90dB @ 1kHz ZONES 6 zones CONTROLS...
- Page 7 PROUDLY DEVELOPED AND MANUFACTURED IN PORTUGAL MOOSE is a brand or PROFACTOR S.A. PROFACTOR S.A Rua do Padrão 52 4440-617 Valongo PORTUGAL Telf.: +351 224 119 160 Fax: +351 224 155 822 info@profactor.pt www.moosesound.com...
