  • Page 1 Users manual DP-220 Digital Piano 00027530/00027531 Version 01/2012...

  • Page 2: Precaution

    Precaution INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE...

  • Page 3: Important Safety Instructions

    Precaution IMPORTANT SAFETY INSTRUCTIONS WARNING - When using electric products, basic precaution should always be followed, including the following: Read all the instructions before using the product. To reduce the risk of injury, close supervision in necessary when a product is used near children.
  • Page 4 Precaution 13. Do not attempt to service the product beyond that described in the user maintenance instruction. All other servicing should be referred to qualified service personnel. 14. To clean the exterior surfaces, wipe lightly with a clean, dry cloth. Never use solvents such as benzine or paint thinners.

  • Page 5: Welcome

    Welcome Welcome Thank you and congratulations on your purchase of the SLIM DIGITAL PIANO. Your new SLIM DIGITAL PIANO is a state-of-the-art musical instrument which incorporates the latest electronics technology to make its operation as easy as possible. Your versatile DIGITAL PIANO is ideal for beginners or experienced musicians. In order to enjoy the features and functions of this unit to their fullest, be sure to carefully read this manual and follow the instructions contained herein.

  • Page 6: Table Of Contents

    Contents Contents 목 Precaution Welcome Contents Care of Your Digital Piano Unpacking (SLP-100/SLP-200/SLP-300) 7/11/15 Setting Up Your Piano (SLP-100/SLP-200/SLP-300) 8/12/16 External Appearance Panel Controls and Terminals Adjusting the Volume Using Pedals Selecting Voice Layer Split 3D (Spatial Effect) Twin Piano Reverb Effect Tune...

  • Page 7: Care Of Your Digital Piano

    Care of your Digital Piano Care of your Digital Piano ● Avoid heat, humidity or direct sunlight. ● Take care not to drop the unit and avoid strong impact. ● Keep the unit free from liquids, dust, etc... ● Never attempt to modify any parts of the unit.

  • Page 8: Unpacking (Slp-100/Slp-200/Slp-300)

    Unpacking (SLP-100) Unpacking (SLP-100) Carefully remove the Digital Piano and its accessories from the packing box. The Digital Piano set consists of the following items. Main Unit Right, Left Legs (a, b) Speaker Box (c) Music Desk (d) Pedal(e) AC Power Adapter (f) Four Bolts Eight Bolts for Speaker Box (h)
  • Page 9 Setting Up Your Piano (SLP-100) Setting Up Your Piano (SLP-100) 1. Attaching the both legs and speaker box assembly Securely combine both Legs(a,b) and Speaker Box(c) assembly using Eight Bolts (h). 2. Attaching the main unit and stand Set the stand upright and gently lower the Main Unit on the stand, then tighten the main unit with four Bolts (g) for main unit...
  • Page 10 Setting Up Your Piano (SLP-100) 3. Attaching the music desk on the main unit Attach the Music Desk (d) on the Main Unit as shown in illustration. 4. Connecting the pedal, speaker and AC adapter with main unit Plug Pedal Cord, AC AC adapter and Speaker Cord into the corresponding ports on the bottom of the main unit as shown in illustration.

  • Page 11: Turning On The Power

    Setting Up Your Piano (SLP-100) Turning on the Power ① Connect the AC POWER ADAPTER. Insert DC plug at the end of DC cord of the AC adapter into the piano and AC plug at end of AC cord of the AC adapter into a standard AC outlet.
  • Page 12 Unpacking (SLP-200) Unpacking (SLP-200) Carefully remove the Digital Piano and its accessories from the packing box. The Digital Piano set consists of the following items. [BOX 1] BODY Main Unit [BOX2] STAND Right, Left Legs (a, b) Pedal Box (c) Rear Plate (d) Four Bolts AC Power Adapter...

  • Page 13: Setting Up Your Piano (Slp-100/Slp-200/Slp-300)

    Setting Up Your Piano (SLP-200) Setting Up Your Piano (SLP-200 1. Attaching the both legs and pedal box assembly ① Securely combine both Legs(a,b) Pedal Box(c) assembly using four Bolts(f). ② For pedal stability, rotate the adjusters on the bottom of the pedal assembly unit they comes in firm, contact with the floor surface.
  • Page 14 Setting Up Your Piano (SLP-200) 3. Attaching the main unit and stand Set the stand upright and gently lower the main unit on the stand, then tighten the main unit with four Bolts (g) for main unit as shown in illustration.
  • Page 15 Setting Up Your Piano (SLP-200) Turning on the Power ① Connect the AC POWER ADAPTER. Insert DC plug at the end of DC cord of the AC adapter into the piano and AC plug at end of AC cord of the AC adapter into a standard AC outlet.
  • Page 16 Unpacking (SLP-300) Unpacking (SLP-300) Carefully remove the Digital Piano and its accessories from the packing box. The Digital Piano set consists of the following items. [BOX 1] BODY Main Unit [BOX2] STAND Right, Left Legs (a, b) Pedal Box (c) Speaker Box (d) Twelve Bolts AC Power Adapter...
  • Page 17 Setting Up Your Piano (SLP-300) Setting Up Your Piano (SLP-300 1. Attaching the both legs and pedal box assembly ① Securely combine both Legs(a,b) Pedal Box(c) assembly using four Bolts(f). ② For pedal stability, rotate the adjusters on the bottom of the pedal assembly unit they comes in firm, contact with the floor surface.
  • Page 18 Setting Up Your Piano (SLP-300) 3. Attaching the main unit and stand Set the stand upright and gently lower the main unit on the stand, then tighten the main unit with four Bolts (g) for main unit as shown in illustration.
  • Page 19 Setting Up Your Piano (SLP-300) Turning on the Power ① Connect the AC POWER ADAPTER. Insert DC plug at the end of DC cord of the AC adapter into the piano and AC plug at end of AC cord of the AC adapter into a standard AC outlet.

  • Page 20: External Appearance

    External Appearance External Appearance SLP-100 1. Music Desk 2. Control Panel 3. Keyboard 4. Pedal 5. Stand SLP-200 1. Keyboard Cover 2. Control Panel 3. Keyboard 4. Pedal 5. Stand SLP-300 1. Keyboard Cover 2. Control Panel 3. Keyboard 4. Pedal 5.

  • Page 21: Panel Controls And Terminals

    Panel Controls and Terminals Panel Controls and Terminals ⓟ ⓗ ⓙ ⓚ ⓛ ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓖ ⓥ ⓦ ⓞ ⓣ ⓘ VOLUME SECTION FUNCTION SECTION Page 22 ⓐ MASTER VOLUME ⓞ SETUP Button Page 29 ⓟ DEFAULT ALL Key VOICE SECTION Page 33 ⓠ...
  • Page 22 Panel Controls and Terminals ⓜ ⓝ ⓤ ⓠ ⓡ ⓢ ① ③ ② ④ POWER SLP-100/300 ⑤ ⑥ ⑦ ① POWER Page 10,14,18 TERMINAL SECTION ② MIDI IN/OUT Page 37 ③ USB IN Page 37 ⑩ ④ PHONES Page 10,14,18 ⑤...

  • Page 23: Adjusting The Volume

    Adjusting the Volume Adjusting the Volume The piano has one volume on the panel for adjusting the volume. MASTER VOLUME This determines the entire volume of the piano. ☞ This also determines the output level of the signal at the PHONES.

  • Page 24: Using The Pedals

    Using the Pedals Using the Pedals The piano has three pedals. SLP-100 SLP-200/SLP-300 ☞ SLP-100 has only one pedal, which is for damper. ① Damper Pedal (Right) The damper pedal performs the same function as the damper pedal on an actual acoustic piano, letting you sustain the sound of the voices even after releasing your fingers from the keys.

  • Page 25: Selecting Voice

    Selecting Voice Selecting Voice The piano features a wealth of rich, authentic voices, including piano, strings and brass instruments. It also features a keyboard percussion function that lets you play the realistic drum and percussion sounds directly from keyboard. There are 12 main voices, 2 split voices, 3 layered voices and 14 extra voices in this piano. ☞...
  • Page 26 Selecting Voice VOICE KEY MAP...

  • Page 27: Layer

    LAYER Layer The layer mode of the piano allows you to select and play two different voices simultaneously in a layer. This makes it easy to create exceptionally rich and thick tonal textures. The volume balance can be set for the two voices. PLAYING WITH THE LAYER VOICE ①...

  • Page 28: Split

    Split Split The split mode of the piano allows you to select and play two different voices with your left and right hands - For example, play bass with the left and piano with the right . PLAYING WITH THE SPLIT VOICE ①...

  • Page 29: Spatial Effect)

    3D (Spatial Effect) 3D(Spatial Effect) The 3D effects widen the stereo image and the listener through two speakers or stereo headphones feels like placed in 3 dimensional spaces. PLAYING WITH THE 3D EFFECT ① Press the 3D button. The 3D effect turns on and the lamp lights. ②...

  • Page 30: Twin Piano

    Twin Piano/Default All Twin Piano Splitting the Piano Keyboard into two sections for twin piano performance. The keyboard can be divided into two separate sections, allowing for two people to perform in the same octave. PLAYING WITH THE TWIN PIANO ①...

  • Page 31: Reverb

    Reverb Reverb Reverb is an effect that recreates the decaying reflections of a sound in a performance space, and reproduces the special ambience of a concert hall. ① Press the REVERB button. ☞ The reverb turns on and lamp lights. ☞...

  • Page 32: Effect

    Effect Effect The effect adds more breadth to the selected keyboard voice. ① Press the EFFECT button. ☞ The effect turns on and lamp lights. ☞ When turning on power, the effect is off. (Default is off.) ② To turn off the reverb press the EFFECT button again. The effect turns off and the lamp goes out.

  • Page 33: Tune

    Tune Tune The Tune function lets you make fine adjustments to the pitch, allowing you to accurately match the tuning with that of other instruments. ① Press and hold the SETUP button. ☞ The lamp is on. ② Adjust the pitch by pressing tune up and down keys. ☞...

  • Page 34: Transpose

    Transpose Transpose The Transpose function makes it possible to shift the pitch of the keyboard in semitone units, allowing you to match the pitch of the keyboard to the range of other instruments or singers, or letting you easily play in a different key without having to change your fingering.

  • Page 35: Touch

    Touch Touch Touch determines how your playing strength (velocity) affects the volume of the voices. Four(4) types are available for tailoring the keyboard response to the selected voice, type of song, or your own playing preference. ① Press and hold the SETUP button. ☞...

  • Page 36: Using Metronome

    Using Metronome Using Metronome The piano features a convenient metronome that is ideal for practicing. ① START/STOP of Metronome To start the metronome, simply press the METRONOME button. The lamp lights. Press the METRONOME button again to stop the metronome sound. The lamp goes off.

  • Page 37: Recording

    Recording Recording The piano features comprehensive song recording functions that allow you to record your own performance. ① Select Record mode. Press the RECORD button, the RECORD lamp lights. ② Start recording Start playing the keyboard or press the START/STOP button. The record lamp flashes and the Play/stop lamp lights.

  • Page 38: Midi & Usb Midi

    MIDI & USB MIDI MIDI & USB MIDI ⓐ ⓑ ⓐ Connecting the external MIDI devices (MIDI Terminals) Use the built-in MIDI terminals and standard MIDI cables to connect external MIDI devices. MIDI IN Receives MIDI messages from an external MIDI device. MIDI OUT Transmits MIDI messages generated by the instrument.

  • Page 39: Midi Implementation Chart

    MIDI Implementation Chart MIDI Implementation Chart Function Recognized Transmitted Remark Basic Channel Default 1 - 3 Mode Default OMNI OFF, POLY OMNI OFF, POLY Note ON/OFF 9nH kk vv #kk:note ON (0-127) #vv:velocity (1-127) Pitch Bender EnH bi bh Maximum swing +/- 1 tone 00 BnH 00H cc Bank Select 01 BnH 01H cc...

  • Page 40: Gm Voice & Drum Table

    GM Voice & Drum GM Voice & Drum Table GM # Voice GM # Voice 0 0 1 Piano1 0 6 5 Soprano Saxophone 0 0 2 Piano2 0 6 6 Alto Saxophone 0 0 3 Piano3 0 6 7 Tenor Saxophone 0 0 4 Honky Tonk...
  • Page 41 GM Voice & Drum Table Prog 1 Prog 9 Prog 17 Prog 25 Prog 26 Standard Drum Room Drum Power Drum Elec. Drum TR-808 27 - D#1 High Q 28 - E1 Slap 29 - F1 Scratch Push 30 - F#1 Scratch Pull 31 - G1 Sticks...
  • Page 42 GM Voice & Drum Table Prog 33 Prog 41 Prog 49 Remark Jazz Drum (7-6) Brush Drum Orchestra 27 - D#1 Closed Hi Hat 28 - E1 Pedal Hi-Hat 29 - F1 Open Hi Hat 30 - F#1 Ride Cymbal 31 - G1 32 - G#1 33 - A1...

  • Page 43: Troubleshooting

    Troubleshooting Troubleshooting ※ Be sure to check to following table whenever you encounter problems with the DIGITAL PIANO operation. PROBLEM CAUSE SOLUTION No sound 1. Power supply problem. 1. Check the power cord whether it’ s properly in AC outlet. 2.

  • Page 44: Specifications

    Specifications Specifications Section Contents PRODUCT SLIM DIGITAL PIANO KEYBOARD 88 KEYS (STANDARD) - 7 1/4 OCTAVES MAX. POLYPHONY 64 NOTES SOUND 25 Voices and 1 DRUM KIT FUNCTIONS LAYER SPLIT TWIN PIANO TUNE TRANSPOSE TOUCH (Off, Hard, Normal, Soft) 3D EFFECT REVERB with Adjustable Level Control EFFECT with Adjustable Level Control METRONOME...
