Service Manual
NR-BW414MN, NR-BW414SS, NR-BW414SN, NR-BW414SW
NR-BW414VS, NR-BW414XN / NR-BW464VS, NR-BW464XN
NR-BW414MN
NR-BW414SS
NR-BW414SN
CFCs have been used in refrigerant as refrigerator and the insulation materials for many years. But it is now
known that these compounds which once seemed so ideal for use as cleaning agents and in refrigeration
systems, destroy the earth's ozone layer as a result, an international body decided on a total worldwide ban of
harmful CFCs by the end of 1995.
The service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a
product. Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any
attempt to service or repair the product or products dealt within this service information by anyone else could result in serious
injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical
parts should be replaced with manufacturer's specified parts to prevent shock, fire or other hazards. Do not modify the
original design without permission of manufacturer.
NR-BW414SS
NR-BW414SW
(WG, AE)
IMPORTANT SAFETY NOTICE
NR-BW414VS
NR-BW414XN
WARNING
© Panasonic Appliances (Thailand) Co., Ltd. 2012.
All rights reserved. Unauthorized copying and
distribution is a violation of law.
Order No. PHAT090301C3
(Revision : Nov. 2012)
Singapore, India, Vietnam
RBD, Indonesia, Philippines
NR-BW464VS
NR-BW464XN
Refrigerator
Product Colour
Silver (SL)
Champagne (SN)
Stainless (ST)
Destination
Malaysia, Hong Kong
PGF, GULF (Gen)
in the
Advertisement
Table of Contents
Related Manuals for Panasonic NR-BW414MN
Summary of Contents for Panasonic NR-BW414MN
- Page 1 Do not modify the original design without permission of manufacturer. © Panasonic Appliances (Thailand) Co., Ltd. 2012. All rights reserved. Unauthorized copying and distribution is a violation of law.
-
Page 2: Table Of Contents
8.1 Not cool at all [ Both PC and FC (compressor does not operate) ] 8.2 Cool, not enought [ Both PC and FC (compressor operates) ] 14~15 9. Schematic Diagram 9.1 Wiring Connection : NR-BW414MN, NR-BW414SS, SN, SW 9.2 Wiring Connection : NR-BW414VS, NR-BW414XN, NR-BW464VS, NR-BW464XN 10. Disassembly Instruction 10.1 Cover Control 10.2 PAS Control... -
Page 3: Safety Cautions For Repairing
NR-BW414 / NR-BW464 1. SAFETY CAUTIONS FOR REPAIRING When you repair the refrigerator, please kindly take care for the following cautions. 1.1 Warning Before repairing unit, unplug supply cord • Before you repair the refrigerator, please unplug the supply cord. Use authentic parts when repairing •... -
Page 4: Specification And Components
NR-BW414 / NR-BW464 2. SPECIFICATION AND COMPONENTS 2.1 NR-BW414SS, NR-BW414MN, NR-BW414VS, NR-BW414XN MODEL NR-BW414SS NR-BW414SN NR-BW414SW NR-BW414MN NR-BW414VS NR-BW414XN Destination Malaysia Hong Kong India Vietnam RBD GULF Malaysia GULF Hong Kong Vietnam Malaysia Malaysia Philippines India Vietnam RBD Indonesia Malaysia Singapore Vietnam Indonesia... -
Page 5: Nr-Bw464Vs, Nr-Bw464Xn
NR-BW414 / NR-BW464 2.2 NR-BW464VS, NR-BW464XN MODEL NR-BW464VS NR-BW464XN Destination Malaysia Hong Kong India Vietnam Philippines Indonesia Malaysia Hong Kong Singapore Vietnam Indonisia Code Attached Model Material Spec. Stainless Plug Power Source 240V 220V 230V 220V 230V 240V 220V 230V 220~240V 220~240V 220~240V 220~240V... -
Page 6: Performance Data
NR-BW414 / NR-BW464 3. PERFORMANCE DATA 3.1 NR-BW414MN, NR-BW414SS, SN, SW Thermostat Dial Setting “ 3 ” “ 2 ” “ 1 ” Mean Fresh Food Compartment Temperature t3 (°C) 1.0 ± 2.5 4.0 ± 2.5 7.0 ± 2.5 -23.5 ± 2.5 -20.0 ±... -
Page 7: Self Protecting Function
NR-BW414 / NR-BW464 4. SELF PROTECTING FUNCTION 4.1 Protection for IC • Normal operating. Does IC receive IPM protect signal? IC orders to stop compressor for 10 min. • IC continues to stop compressor until 1 hour. After 10 min, does PCB check if IPM protect signal •... -
Page 8: Protection For Compressor Locked
NR-BW414 / NR-BW464 4.2 Protection for compressor locked • Normal operating. • After starting 2 sec., does IC detect rpm <5r/sec>? • After starting from 2 ~ 10 sec., does PCB detect rpm over 120r/sec? IC orders to stop compressor for 10 min. IC cancels to stop compressor after 10 min. -
Page 9: Protection For Power Supply Droping
NR-BW414 / NR-BW464 4.3 Protection for power supply droping • Normal operating. Does Power supply voltage drop as condition >0.1 sec., and <160V AC? IC orders to stop compressor for 10 min. After 10 min, does PCB check power supply voltage •... -
Page 10: Self Diagnosing Function
NR-BW414 / NR-BW464 5. SELF DIAGNOSING FUNCTION When abnormalist is cased in the refrigerator, the sign is display on LED as below chart. How to use “Self diagnosing function” 1. Opening PC door and FC door, push Energy Saving “Quick Freezing” bottom more than 5 sec. 2. -
Page 11: Temperature Control
NR-BW414 / NR-BW464 6. TEMPERATURE CONTROL 6.1 How to operate “QUICK FREEZING” (Quick cool button) If you want the refrigerator to freeze quickly in order to preserve the food, press the “Quick Freezing” button (Green light LED turns ON). The system will operate immediately and will stop operating automatically (Green light LED turns OFF), when it runs for 150 minutes. -
Page 12: Refrigerator Instruction Guidelines
NR-BW414 / NR-BW464 7. REFRIGERATOR INSTRUCTION GUIDELINES 1. Do not open the refrigerator frequently or leave it opened for a long time. This is to prevent water dipping inside the refrigerator which will cause the waste of coolness and consuming of energy. 2. -
Page 13: Troubleshooting Guide
NR-BW414 / NR-BW464 8. TROUBLESHOOTING GUIDE 8.1 Not cool at all. [Both PC and FC (compressor does not operate)] • Check power supply. Does room light turn on? ex. Connect Power cord in inlet. ex. Check ELCB • Defect of over load relay. ex. -
Page 14: Cool, Not Enought [ Both Pc And Fc (Compressor Operates) ] 14~15
NR-BW414 / NR-BW464 8.2 Cool, not enough. [Both PC and FC (compressor operates)] To confirm when compressor is operating. • Defect of FC fan motor. When FC door opens and FC door SW • Poor connection between FC fan pushes, does cold air spout out from motor and IC1 on PCB. - Page 15 NR-BW414 / NR-BW464 • Defect of communication circuit and Does “Energy Saving” and “Quick EEPROM circuit of control PCB. Freezing” blink? • Plug out and after 7 minute plug in again. • Gap of door. 10 Does frost adhere to evaporator much? •...
-
Page 16: Schematic Diagram
NR-BW414 / NR-BW464 9. SCHEMATIC DIAGRAM 9.1 Wiring Connection : NR-BW414MN, NR-BW414SS, SN, SW 220V - 240V / 50Hz - 16 -... -
Page 17: Wiring Connection : Nr-Bw414Vs, Nr-Bw414Xn, Nr-Bw464Vs, Nr-Bw464Xn
NR-BW414 / NR-BW464 9.2 Wiring Connection : NR-BW414VS, NR-BW414XN, NR-BW464VS, NR-BW464XN - 17 -... -
Page 18: Disassembly Instruction
NR-BW414 / NR-BW464 10. DISASSEMBLY INSTRUCTION 10.1 Cover Control Fig. 1 Fig. 2 - Take out by use screwdriver put at hole of lock between PC Dooor Complete with Cover Control and push it loose. (as Fig. 1) - Then use another hand lift it up slowly. (as Fig. 2) 10.2 PAS Control Fig. -
Page 19: Repairing Procedure
NR-BW414 / NR-BW464 11. REPAIRING PROCEDURE Solving FC door over lab Fig. 1 Fig. 2 - To check FC door protruded out with PC door. (Spec : Not more than 1.0 mm.) Fig. 3 Fig. 4 - To take off the 2 screws of hinge bottom. Fig. -
Page 20: Technical Information
NR-BW414 / NR-BW464 12. TECHNICAL INFORMATION 12.1 NR-BW414MN, NR-BW414SS, SN, SW (Non Inverter) • PC Cooling not enough / Ice forming 1. Symptom of the problem PC cooling not enough by ice forming. 2. Cause Fan motor does not work due to ice forming, stuck to fan motor area. - Page 21 NR-BW414 / NR-BW464 • Countermeasure No. 1 To add insulation plate 2 pcs on cover coil Insulation plate and inner liner as below instruction. Insulation plate Cover coil Coil EVP. Inner Liner 1.1 To add insulation on rear of cover coil. Cover coil Add insulation on rear of Cover coil 1.2 To add insulation on inner liner.
- Page 22 NR-BW414 / NR-BW464 • Countermeasure No. 2 2.1 To add one deflector Add deflector 1 pcs. DWG : Deflector have 1 pcs. • Countermeasure No. 3 3.1 Pas control CNRBG-166465 replace. New PCB control have circle marking on top of Capacitor spec 450V. 6.
-
Page 23: Nr-Bw414Vs, Nr-Bw414Xn, Nr-Bw464Vs, Nr-Bw464Xn (Inverter) 23~26
NR-BW414 / NR-BW464 12.2 NR-BW414VS, NR-BW414XN, NR-BW464VS, NR-BW464XN (Inverter) • PC Cooling not enough / Ice forming 1. Symptom of the problem PC less cooling. 2. Cause Fan motor does not work due to ice forming, stuck to fan motor area. Fan motor can’t blow cold air. - Page 24 NR-BW414 / NR-BW464 • Countermeasure No. 1 To addition insulation plate 2 pcs on cover coil and inner liner as below instruction. Insulation plate Insulation plate Cover coil Coil EVP. Inner Liner 1.1 To addition insulation plate on rear of cover coil. Cover coil F Add insulation plate 1.2 To addition insulation on inner liner.
- Page 25 NR-BW414 / NR-BW464 • Countermeasure No. 2 2.1 To add one deflector Ref.3 Addition deflector/Part no. BF161020 DWG : Deflector have 1 pcs. Note : Dimension not to be same master. Ref.3 Add deflector 1 pcs. • Countermeasure No. 3 3.1 Pas B41MV4 (Control) to replace Ref.4 Replace new PCB 1 pcs (Mark F05).
- Page 26 NR-BW414 / NR-BW464 • Defrost mode demo checking guide. a) Open PC & FC door. b) Push “Freezer Control” 1 time. Then release your finger c) Push “Quick Freezing” 1 time. Then release your finger. d) Push “Freezer Control” 1 time. Then release your finger. e) Push “Freezer Control”...
-
Page 27: Parts Exploded View And Replacement Parts List
NR-BW414 / NR-BW464 13. PARTS EXPLODED VIEW AND REPLACEMENT PARTS LIST 13.1 Parts Exploded View : Body (For NR-BW414MN, SS, SN, SW) 20.1 (For Inverter only) (For PGF, GULF) (EXCEPT SN MODEL) 45.1 (EXCEPT SN MODEL) - 27 -... -
Page 28: Parts Exploded View : Door
NR-BW414 / NR-BW464 13.2 Parts Exploded View : Door (For BW414SSWG, AE/SWWG, AE) - 28 -... -
Page 29: Parts Exploded View : Packing
NR-BW414 / NR-BW464 13.3 Parts Exploded View : Packing STICKER BARCODE PACKING BELT TOP PAD BACK TOP PAD FRONT FOAM TOP PAD L, R PROTECTOR FORM COVER CONTROL FOR - STAINLESS MODEL ( ALL COUNTRIES ) - HONG KONG MODEL PLASTIC COVER PAPER PROTECTOR FRONT (ONLY HONG KONG MODEL, INDIA MODEL) BOTTOM TRAY AS. -
Page 30: Replacement Parts List 30~34
Important safety notice : Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer’s specified part. 13.4 Replacement Part List : NR-BW414MN, SS, SN, SW / NR-BW414VS, XN / NR-BW464VS, XN Parts List MODEL / Q’TY... -
Page 31: Parts List
NR-BW414 / NR-BW464 Parts List MODEL / Q’TY REF. PART NAME PART NO. SAFETY BW414 BW414 BW414 BW414 BW414 BW414 BW464 BW464 REMARK DIAL CONTROL CNRAC-200643 CNRAH-290912 BIG HANDLE CASE SW. FC - W CNRAC-201540 HINGE CENTER CNRAE-137991 PIN HINGE CENTER CNRAE-136583 HINGE BOTTOM CNRAE-138003... - Page 32 NR-BW414 / NR-BW464 Parts List MODEL / Q’TY REF. PART NAME PART NO. SAFETY BW414 BW414 BW414 BW414 BW414 BW414 BW464 BW464 REMARK CNRBH-140930 FOR NR-BW414VSVN CNRAH-266780 FOR NR-BW414VSWA CNRAH-255540 FOR NR-BW414XNMY CNRAH-255550 FOR NR-BW414XNSG CNRBH-140940 FOR NR-BW414XNVN CNRAH-255460 FOR NR-BW464VSMY CNRAH-255500 FOR NR-BW464VSHK CNRAH-255940...
- Page 33 NR-BW414 / NR-BW464 Parts List MODEL / Q’TY REF. PART NAME PART NO. SAFETY BW414 BW414 BW414 BW414 BW414 BW414 BW464 BW464 REMARK PLATE DUCT PC CNRAH-229920 CNRAH-229910 ESCUTCHEON AG CLEAN CNRAG-252270 PLATE DUCT PCB CNRAH-246041 AG FILTER BIO CNRAH-245521 INS.
- Page 34 NR-BW414 / NR-BW464 Packing MODEL / Q’TY REF. PART NAME PART NO. SAFETY BW414 BW414 BW414 BW414 BW414 BW414 BW464 BW464 REMARK PACKING AS. CNRBK-118960 FOR NR-BW414MNMY CNRBK-116120 FOR NR-BW414MNHK CNRBK-116150 FOR NR-BW414MNVN CNRBK-116100 FOR NR-BW414SSMY CNRBK-116110 FOR NR-BW414SSHK CNRBK-116130 FOR NR-BW414SS1N CNRBK-131141 FOR NR-BW414SS2N...
-
Page 35: Detail Change Notice
NR-BW414 / NR-BW464 DETAIL CHANGE NOTICE REVISION ITEM NO. PAGE DETAIL REMARK DEC. 2009 COMPRESSOR NEW PART NO. CNR91-236420 CHANGE PART NO. WHICH COMMON CHINA JAN. 2010 ADD PICTURE AND MODEL OF NR-BW414SS- ADD MODEL OF PGF, GULF (GEN.) AND SW/WG, AE AND VSVN, XNVN VIETNAM ADD PRODUCT SPEC.
