Asotel Dynamix DW-0101/H User Manual

Fxs/fxo gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D
y
n
a
m
i
D
y
n
a
m
i
D
y
n
a
m
i
D
y
n
a
m
i
F
X
S
/
F
F
X
S
/
F
U
s
U
s
x
D
W
-
0
x
D
W
-
0
x
D
W
-
0
x
D
W
-
0
X
O
G
A
T
E
W
X
O
G
A
T
E
W
e
r
M
a
n
u
a
e
r
M
a
n
u
a
1
0
1
/
H
1
0
1
/
H
2
0
2
/
H
2
0
2
/
H
A
Y
A
Y
l
l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dynamix DW-0101/H and is the answer not in the manual?

Questions and answers

Related Manuals for Asotel Dynamix DW-0101/H

Summary of Contents for Asotel Dynamix DW-0101/H

  • Page 2: Table Of Contents

    STEPS IN CONFIGURATION ..........................3 1. START UP ................................4 1.1 I ...............................4 NTRODUCTION 1.2 F ........................5 EATURES AND SPECIFICATION 1.3 A ........................6 CCESSORIES AND EQUIP MENT 1.4 A ..............................6 PPEARANCE 1.4.1 1 FXS/1 FXO............................6 1.4.2 2 FXS/2 FXO............................7 2. HOW TO SETUP AND CONNECT BASIC ALLY................10 2.1 S ..........................10 YSTEM...
  • Page 3 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.15 V ........................52 ERSION AND NFORMATION 3.16 ROM U ............................53 PGRADE 3.17 F .............................57 LASH LEAN 3.18 C ..............................58 OMMIT 3.19 R ............................59 EBOOT YSTEM 3.20 T ..........................60 ONFIGURATION 3.21 R ............................61 OUTING...
  • Page 4 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4.2.24 [pt] ..............................107 4.2.25 [rom] ...............................108 4.2.26 [passwd] ............................110...

  • Page 5: Steps In Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Steps in configuration To check out the peripheral equipments and STEP 1 understand the feature of this gateway. Please Start Up read this step very carefully before starting the configuring.

  • Page 6: Start Up

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 1. Start Up 1.1 Introduction TheFXSO gateway provides voice/fax service over IP network with H.323 v3 protocol. By connecting to your existing ADSL or cable modem service, which allows the use of a single, network for voice and fax services with consequent saving in network infrastructure and greatly reduced telephone charges.

  • Page 7: Features And Specification

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 of the PBX 1.2 Features and specification Feature s ITU-T H.323 v4 compliance Automatically Gatekeeper Discovery Secondary GK support Peer-to-Peer mode (non-Gatekeeper) Support auto-attendant (2nddial Tone / Voice greeting) Dimensions : 221mm(W)*42mm(H)*217mm(L) Line hunting 1/2 RJ-11 FXS and FXO ports...

  • Page 8: Accessories And Equipment

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Management Features: Two easy ways for system configuration Console port: RS-232C port TELNET HTTP Brower (e.g. Internet Explorer) 1.3 Accessories and equipment u The voice gateway in FXSO ports models and only one RJ -45 connector (WAN).

  • Page 9: Fxs/2 Fxo

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 when it is set as Gatekeeper Mode. 3. Or when FXS/FXO is in downloading mode, LED should be flash as well. 4. Light off means FXS/FXO is in Peer -to -Peer Mode. Back panel: 1.4.2 2 FXS/2 FXO Front panel: The LED light provides system message of FXSO GateWay.
  • Page 10 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 1. Ethernet Port LAN/WAN: 10/100 Base-T; RJ-45 socket, complied with ETHERNET 10/100base-T. The pin-out is as following: PIN 1, 2: Transmit PIN 3, 6: Receive 2. COM: RS232 console port (DB-9pin male connector) Note: use straightforward cable to connect to your computer.
  • Page 11 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 RJ-11 connector, FXSO interface is for connecting the extension line of PABX or PSTN Line . 5. 12V DC: Input AC 100V~120V;output DC12V.

  • Page 12: How To Setup And Connect Basic Ally

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 2. How to Setup and connect basically 2.1 System Requirement 1. One PC (a) Pentium 100 or above, 64 RAM, Windows 98 or above. (b) Ethernet card or COM port 2.

  • Page 13: Ip Environment Setting

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 2.2 IP Environment Setting User must prepare a valid IP address, complied with IP Network, for Gateway’ s proper operation. For testing the validation of chosen IP address, using the same IP configuration in other PC or Notebook, and then try to connect to Public Internet (go to well-known website, receive Internet mail, or ping a specific public IP address).
  • Page 14 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 2.1: Network Configuration Select the Property of the LAN card. Setup the ip address, subnet mask and default gateway as below: Figure 2.2: Configure the network Click OK after you finished the network setup. The default ip address, netmask and default gateway address of the gateway is 10.1.1.3, 255.0.0.0, 10.1.1.254.

  • Page 15: Network Configurations In Your Gateway

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 2.3 Network configurations in your gateway Key in the ip address of the gateway (http://10.1.1.3) with the browser Figure 2.3: WEB Browser After key in the ip address, you have to enter the user name and password to enter the WEB configuration.
  • Page 16 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 2.3: Login the username and password You will enter the main page of the configuration after key in the login name and password correctly: Figure 2.4: The main WEB configuration Press the Network Interface to configure the networking of your gateway: Figure 2.5: The Network Interface...

  • Page 17: Static Ip Address

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 2.3.1 Static ip address Please get the correct ip address, netmask and default gateway address from your ISP first. Press the OK button if you finished. Figure 2.5: Configure the static ip address Press the commit if you finish the configuration.

  • Page 18: Dhcp Mode

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Press the reboot if you want the configuration executed. Figure 2.7: Reboot the system 2.3.2 DHCP mode Enable the DHCP if you are using the cable modem or DHCP server. Figure 2.8: Enable the DHCP function...

  • Page 19: Pppoe Mode

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Please commit the data and reboot the machine after you enable the DHCP function. 2.3.3 PPPoE mode Enable the PPPoE and press the info about PPPoE configuration in the correct table.

  • Page 20: Making A Voip Call

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 2.10: Configure the info about PPPoE Please commit the data and r e boot the machine after you finished the configuration of PPPoE. 2.4 Making a VoIP Call There are two modes that you could configure the gateway for making VoIP calls.
  • Page 21 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 2.11: Configure the Peer-to-Peer mode Press the OK button that is on the bottom of this page to save the configuration. Figure 2.12: The OK button Enter the Phone Book configuration table and configure the name, ip address and phone number of the destination.
  • Page 22 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 2.11: Phone Book 【Example】 Figure 2.12: The example of Phone Book configuration This is the first record of Phone Book. So the index is 1 The name of the destination: test The E164 number (phone number) of the destination: 123 The ip address of the destination: 10.1.1.100...

  • Page 23: Configure The Gateway Into The Gk Routed Mode

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Press the “Add Data” button when you finished, and the new table will display on the first index if you press the Phone Book configuration button. Figure 2.13: To show the Phone Book record Please Commit it and Reboot the system if the configuration is finished.
  • Page 24 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 2.14: Configure the GK info Press the OK button that is on the bottom of this page to save the configuration. Figure 2.15: Press OK to save the data Press the Commit Data and Reboot System buttons when you finished the configuration.

  • Page 25: The Type In Gk Routed Mode

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 2.4.2.1 The type in GK routed mode There are two types in the GK routed mode you could choose. One is Gateway type and another is Terminal type. There are some different functions, applications a nd configurations between the Gateway type and Terminal type.

  • Page 26: Advance Configurations

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3. Advance Configurations There are too many advanced commands for the advanced users. The following chapters are based on the application layer. Please get the info what you need. If you need the command, please watching the chapter of Command Line Interface.
  • Page 27 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 u Another IP Address for Gateway must be set as an fixed one in order for that IP Sharing device pass forwarding the relevant information from WAN to LAN. Besides, a valid IP Address meets the IP Sharing device (LAN site) is the element.
  • Page 28 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 3.2: Enable the ip sharing function Fixed IP – Please put the ip address of the ip sharing device in the IP Sharing Server Address table. Dynamic IP – Please enable the ip change function and leave the ip sharing server address.
  • Page 29 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 change is only support the GK from us. Please Commit it and Reboot the system if the configuration is finished. This chapter is focus on the DMZ function of the IP Sharing Device, Please get another application from our web site.

  • Page 30: Network Interface

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.2 Network Interface Users have to configure the Network configurations in this page. This gateway will be work while it is connecting with the internet network. Please get more info from the following descriptions.
  • Page 31 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 u DNS primary – To configure the first ip address for the DNS server. u DNS secondary – To configure the second ip address for the DNS server. u HTTP Port – To configure the HTTP port for access this unit from the remote side.
  • Page 32 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 The EMS function didn’t support this version as so far. This will be working if the EMS function and server get ready.

  • Page 33: H323 Information

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.3 H323 Information This WEB page will help user to configure the information about the dial mode, GK information and some TCP/IP port for the communication. Please get more info about this configuration from the below detail descriptions.
  • Page 34 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Gateway2 : Following the Cisco GK registration function. u Registered Prefix – The phone number for the GK registering. Support the GK mode only. u Line 1/ TEL 1 Number – Configure the number of the first port in this unit. u Line 2 / LINE1 Number –...
  • Page 35 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 u H225 RAS Port – The RAS port of this unit. Support the GK mode only. u H225 Call Signal Port – The Call Signal port of this unit. Support the GK mode only.

  • Page 36: Line Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.4 Line Configuration The Line configuration will show the status of the registrations and the ports. It includes the hunt group, hotline, and no answer forward configuration. Press the Line configuration button to enter configuration table (see figure 3.6) Figure 3.6: Line Information u Type –...

  • Page 37: Phone Book Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.5 Phone Book Configuration The Phone Book configuration is only support the gateway in Peer-to-Peer mode. Please refer the chapter 2 about the Peer-to-Peer mode. (see figure 3.7) Figure 3.7: Phone Book Configuration u Index –...
  • Page 38 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 u Add Data – Press this button if users fill the entire information table above. u Delete Date – If users want to delete the record from the table, enter the index number first and press this button.

  • Page 39: Support Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.6 Support Configuration This gateway supports the FAX over IP, fast start function and others function. Please enable or disable these in the Support WEB page. (see figure 3.8) Figure 3.8: Support Configuration u T.38 FAX –...

  • Page 40: How To Enable The H450 Function

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.6.1 How to enable the H450 function The H.450 function has to be work with the GK. So please make sure about that the GK could support the H.450 function before you want to use this function.

  • Page 41: System Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.7 System Configuration Figure 3.9: System Configuration u Inter Digit Time – The call will be sent out if user didn’ t enter the digits after this timer. u Forward time – It supports the No Answer Forward function. If users configure it for 10, the call will be forwarded when it rings about 10 seconds.
  • Page 42 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Master : Follow the result from the MasterSlaveDetermination. Caller : Follow the caller side. It’ s only for the special requirement. Please contact with your vendor before you configure this. u Reverse(FXS) –...
  • Page 43 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 u Ring Before Answer(FXO) – This will help the users to answer the calls from PSTN into this gateway quickly. The call will be connected by one time ring if users configure this for 1. (From 1 to 10) u Delay to add DTMF(FXO) –...

  • Page 44: Voice Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.8 Voice Configuration Users could configure the voice codec or gain level in this web page. Please get more detail info from the following description. (see figure 3.10) Figure 3.10: System Configuration u Codec Priority –...
  • Page 45 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 DTMF gain (DTMF) of the second FXO port. u G723 Silence Suppression – To enable the VAD and CNG function for the G.723 codec. u Echo Canceller – To enable or disable the echo cancellation function. u Jitter Buffer –...

  • Page 46: Phone Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.9 Phone Configuration This WEB will show the tone generation value from this unit. Please don’ t configure it if you got some correct value for sure. (see figure 3.11) Figure 3.11: Phone Configuration u Ring Cadence –...

  • Page 47: Rtp Pay Load Type Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.10 RTP Pay Load Type Configuration There are more types for the RTP Payload. This web page could support users define the Payload Type for some special payload. (see figure 3.12) Figure 3.12: Pay Load Type Configuration u RFC2833 Payload Type –...

  • Page 48: Ip Packet Tos

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.11 IP Packet ToS The Type of Service should be worked with the network router. The router will check all the packets if it supports the TOS function. There is a field in the packet for the TOS value.

  • Page 49: Ddns Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.12 DDNS Configuration This version of firmware supports DDNS function. Before using this function, please have a DDNS account and some info from your DDNS server. Press the DDNS Configuration button to configure it. (see figure 3.14) Figure 3.14: Phone Book u Status –...

  • Page 50: Prefix Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.13 Prefix Configuration The Prefix function is using the drop and inserts function (see figure 3.15). Figure 3.15: Prefix Configuration u Index – The list number of the Phone Book. u Prefix –...
  • Page 51 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Press the Prefix Configuration button to enter the configuration table (see figure 3.15) Enter the index number. Put the prefix numbers you will dial in the prefix table, enable (disable) the drop function and enter the numbers you want to insert (see figure 3.16) Figure 3.16: Configure the Prefix Table The usage is as same as the drop, insert function of the Phone Book.
  • Page 52 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Press the Prefix Configuration button to reload the configuration table (see figure 3.17) Figure 3.17: Configure the Prefix Table Please Commit it and Reboot the system if the configuration is finished.

  • Page 53: Password Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.14 Password Configuration There are two-login accounts in this unit. One is the account root another is administrator. The default setting for these two accounts are empty. Users could define the passwords for these two accounts. Please get more info from the following description.

  • Page 54: Version And Information

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.15 Version and Information Users could get more detail about the software version for all the parts in this web page. (see figure 3.19) Figure 3.19 Version and Information u Boot Rom –...

  • Page 55: Rom Upgrade

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.16 ROM Upgrade User could update the firmware just by the web configuration interface. There are two types for the upgrading procedure. One is using the TFTP server, another is using the FTP server. Please follow the step to update the gateway firmware version.
  • Page 56 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 【Updating the firmware by the FTP server】 Pick up the “Rom Upgrade” button to enter the upgrading web page and switch to the FTP method. (see figure 3.21) Figure 3.21 ROM Upgrade for FTP Key in the IP address, the login name, password of your FTP server and the correct file name, file type.
  • Page 57 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 3.22: FTP information Please pay more attentions about the red blank. The Target File Type has to be matched with the Target File name. Please put the correct info about the Target file in this table.
  • Page 58 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Key in the IP address of your TFTP server, pick up the file type for your upgrade file and the correct file name for upgrading. (see figure 3.23) Figure 3.24: TFTP information Press the OK button to start the upgrade procedure.

  • Page 59: Flash Clean

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.17 Flash Clean Users could make all the configurations back to the default setting by this button. The password of the account and the networking configuration couldn’ t be back to the default setting by this command. (see figure 3.25) Figure 3.25: Flash Command...

  • Page 60: Commit

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.18 Commit This web page could save the configurations if users change some configurations. This is necessary for users change the configurations. (see figure 3.26) Figure 3.26: Commit the data...

  • Page 61: Reboot System

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.19 Reboot System This web page will restart the whole system. This is the necessary step for the changing the configurations and makes it executed. (see figure 3.27) Figure 3.27: Reboot System...

  • Page 62: Tone Configuration

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.20 Tone Configuration Users could configure the tone pattern of the gate way in this page. If the disconnect tone from PSTN side is match the one of the Busy tone table, the call will be dropped.

  • Page 63: Routing Table

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.21 Routing Table Routing Table is a rule to define the destination of the calls you make. You could define the rules by the number you dial or by the ports. The Routing Table button will show you the configuration table.

  • Page 64: Change The Default Routing

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 u Default – For change the default setting. Users have to pick the direction for the default setting changed. u Prefix – The prefix number for the dialed digits. The call will be followed this route table if the prefix number was matched.
  • Page 65 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 3.30: Change the Default Setting The default setting is changed after you press the Change Default button. Please press the Routing Table button again to show the new setting. Figure 3.31: The Default Setting Changed Please Commit it and Reboot the system if the configuration is finished.

  • Page 66: Add A New Routing Table

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.21.2 Add a new Routing Table The default setting is changed after you press the Change Default button. Please press the Routing Table button again to show the new setting. Figure 3.32: Add a new routing table Press Add Data button to save the configuration and press the Routing Table button again to reload the configuration.
  • Page 67 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 The explanation of figure 3.33 is as below: When the user dial 8 with the first digit of the numbers from FXS or IP side. And the numbers you dial is between 1 and 8 digits. If this number matches the rule, it will be transferred to the FXO port whose E164 number is 1003.

  • Page 68: Fxo Password

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 3.22 FXO Password You will get the IVR if you make calls from PSTN side or from IP side. The IVR will ask you the password you set, and you could make other calls to IP side or PSTN side if the password you type is correct.

  • Page 69: Command List

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4. Command List 4.1 Hyper Terminal Setting A terminal emulator is needed when using RS-232 port to configure Gateway. There are kinds of terminal emulator software. Here, we use Microsoft HyperTerminal to depict how to set up terminal emulator: Execute the Hyper Terminal program, and then the following windows will pop-up on the screen.
  • Page 70 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 4.2: Edit the name for the connection After pressing OK button, the next window appear, and then choose COM1/2 Port, which you are going to use. Figure 4.3: Pick up the right interface to use Configure the COM Port Properties as following: u Bits per second: 9600 u Flow control: None...
  • Page 71 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Figure 4.4: Configure the right Bps and control Press ‘ OK’ button, and then start to configure Gateway.

  • Page 72: Command List

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4.2 Command List 4.2.1 [help] Type help or man or ? to list all the available command. usr/config$ ? help help/man/? [command] quit quit/exit/close debug show debug message reboot reboot local machine flash clean configuration from flash rom...

  • Page 73: Quit]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4.2.2 [quit] Type quit will quit the FXSO GateWay configuration mode. And turn back to login prompt. usr/config$ quit Disconnecting... login: Note: It is recommended that type the “quit” command before you leave the console.

  • Page 74: Reboot]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4.2.4 [reboot] After commit command, type reboot to reloadFXSO GateWay in new configuration. The procedure is as below: usr/config$ reboot ...Attached TCP/IP interface to cpm unit 0 Attaching interface lo0...done Hardware auto detect...

  • Page 75: Commit]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 root 4.2.6 [commit] Save changes after configuring theFXSO GateWay. ------------------------------------------------------------------------------------------------- usr/config$ commit This may take a few seconds, please wait..Commit to flash memory ok! usr/config$ Note: Users should use commit to save modified value, or they will not be activated after system reboot.
  • Page 76 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 -ipsharing Specify usage of an IP sharing device and specify IP address. -ipchange Replace IP address if the shared IP is changed (0=Disable, 1=Enable) PPPoE connection user name -pwd PPPoE connection password -reboot Reboot after remote host disconnection in PPPoE mode...

  • Page 77: Time]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 usr/config$ ifaddr -sntp 1 10.1.1.1 While 10.1.1.1 stands for SNTP server’ s IP address. -timezone set local time zone according to GMT -ipsharing Just put the static IP address for the WAN port of the IP sharing if the gateway is behind this IP sharing device.

  • Page 78: Ping]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4.2.9 [ping] Use ping to test whether a specific IP is reachable or not. For example: if 192.168.1.2 is not existing while 210.63.15.32 exists. Users will have the following results: usr/config$ ping 210.54.23.129 PING 210.54.23.129: 56 data bytes no answer from 210.54.23.129...
  • Page 79 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4 = R F C 2 8 3 3 . -prefixsw User defined local zone prefix switch (0=OFF, 1=ON). -prefixdisab Local zone prefix disable character (one character from 0~9, *, or NONE('-' key)). -usrdefprefix User defined local zone prefix (0 ~ 20 digits).
  • Page 80 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 this current call. For example, if user has set prefix as 100, and wants to dial out 100123, user can only press 123, to dial out 100123.However, if user wants to dial 123 without prefix, user can press prefix disable key, for example “*”, user can press “*”, then dial 123, gateway will dial out 123 without adding prefix.

  • Page 81: H323]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 gateway has incoming call 1001, after drop gateway prefix 100, it will search line number “1” . So line number must be set as “1”. -eod It will transfer the DTMF in “#” if users disable the end of dial function.
  • Page 82 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 H.323 stack information and configuration Usage: h323 [-print][-mode used][-gk IP address][-algk IP address][-gwtype used] [-dfgw IP address][-prefix number][-line number][-passwd number] [-alias h323id][-display information][-gkid ID][-gkdis used] -print Display H.323 stack information and configuration. -mode Configure as Gatekeeper mode or Peer -to-Peer mode (0=Gatekeeper, 1=Peer -to-Peer).
  • Page 83 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Range of IP address setting (0.0.0.0 ~ 255.255.255.255). Example: h323 -gk 210.59.163.171 -line1 70 -line2 71 -line3 72 -line4 73 h323 -alias Your_Alias_Name -gkid GK -gkdis 1 -passwd 1234 h323 -range start 1024 end 19999 pbook -add name Test ip 210.59.163.202 e164 1001...
  • Page 84 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 number on the Gatekeeper. -line1 assign Line1 number. -line2 assign Line2 number. -line3 assign Line3 number. -line4 assign Line4 number. Note: User can also set “x” in line number to disable the port. If the port is disabled, it can only receive calls but not calling out.

  • Page 85: Line]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 LAN Phone will multicast to search a GateKeeper on network with configured GateKeeper name (please refer to -gkid); if IP address of GateKeeper is set, before LAN Phone register to the assigned GateKeeper, it will send out GRQ(GateKeeper Request) message with configured GateKeeper name to GateKeeper first.
  • Page 86 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 hotline: Hot line configuration. Example: line -config 1 hunt 1 hotline 1003 usr/config$ Parameter Usages: -print print out all current settings of line -config determine which line to configure -hunt set hunting group flag of each line.

  • Page 87: Prefix]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Set gateway under P2P mode. Create phone book table with “pbook ” command. Create a Hotline table with “line ” command. usr/config$ pbook –add name test ip 10.1.1.1.e164 1001 usr/config$ line –config 1 hotline 1001 In this example means: if user calls inFXSO Line1, gateway will automatically dial out IP address of “1001”.

  • Page 88: Pbook]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 prefix -add prefix 100 drop 1 prefix -add prefix 100 drop 0 insert 200 prefix -modify 1 prefix 100 drop 0 insert 300 prefix -delete 1 usr/config$ Parameter Usages: -add add a rule to drop or insert prefix digits of incoming call.(prefix –add prefix “prefix number”...
  • Page 89 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 pbook -print Display phone book information and configuration. -add Add new phone book record. name : 1 ~ 10 character s. e164 : 1 ~ 10 digits. : I P a d r e s s . p o r t : 1 0 2 4 ~ 6 5 5 3 5 .

  • Page 90: Voice]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 sequence number as index. -add add a new record to phone book. When adding a record, users have to specify name, ip, and e164 number to complete the command. name name to represent callee.
  • Page 91 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 [-volume line [voice level][input level][dtmf level]] [-nscng [G711U used1][G711A used2][G723 used3]] [-echo used][-mindelay t1][-maxdelay t2] -print Display voice codec information and configuration. -s e n d Specify sending packet size. G.723 (30/60/90 ms) G.729...
  • Page 92 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Parameters Usage: -print print current voice information and configurations . -send define packet size for each codec. 20/40/60ms means to send a voice packet per 20/40/60 milliseconds. The smaller the packet size, the shorter the delay time.

  • Page 93: Support]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 -maxdelay the minimum jitter buffer size. (Default value= 150 ms) usr/config$ voice –mindelay 90 –maxdelay 150 Note: be sure to know well the application before you change voice parameters because this might cause incompatibility. 4.2.16 [support] This command provides some extra functions that might be needed by users.
  • Page 94 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 support -fstart 1 support -tunnel 1 support -h245fs 1 support -earlyh245 1 usr/config$ Parameter Usages: -print print current settings in support command. -t38 to switch ON/OFF (1 = ON; 0 = OFF) T.38 fax ability. When T.38 ability is ON, Gateway will automatically defer codec (G.723 or G.729 series) to T.38 when FAX signal is detected.

  • Page 95: Sysinfo]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Note: it is not recommended to change the value in this command, only if users do know well the application. This might cause incompatibility with other devices. 4.2.17 [sysinfo] Show the status of the port and registrations ------------------------------------------------------------------------------------------------- usr/config$ sysinfo...
  • Page 96 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 e164 Destination e164 number(when destination isFXSO). Max digits.(0 ~ 255) hunt Hunt method for busy forward(0=NONE, 1=GROUP, 2=ALL). -delete Delete routine table index record. -modify Modify routing table record. prefix The prefix of dialed number.

  • Page 97: Tone]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 create routing table for incoming call from IP side. (route –ip dst “destination port type” e164 “e.164 number of port”) -FXSO create routing table for incoming call fromFXSO Lines. (route –FXSO dst “destination port type”...
  • Page 98 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 usr/config$ tone Disconnect tone and remote ring back tone configuration Usage: tone [-print][[num][freqLo ][freqHi ][freqLoLev][freqHiLev] [Tone1ON][Tone1OFF][Tone2ON ][Tone2OFF ]] tone -print Display tone configuration. Tone index(1~4=Disconnect tone, 5~8=Remote ring back tone). freqLo Low frequency.

  • Page 99: Fxopwd]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 (If user doesn’ t know about the frequency of disconnect tone or ring back tone, please refer to [record] command to detect frequency.) For each tone may has 1 set or 2 sets (high and low) of frequencies.

  • Page 100: Record]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Parameter Usages: -print show al FXO password configuration -add add 1 set of FXO password -delete delete 1 specific set of FXO password -modify modify 1 specific set of FXO password passwd password direction the direction number which password implement.
  • Page 101 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Parameter Usages: -greeting record greeting file. User must assign a file name for greeting, once record is finished, file recorded will be display in rom –print. ----------------------------------------------------------------------------------------------- usr/config$ record -greeting greeting.test Please off hook the port 1 and press (N) for the next step...
  • Page 102 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 -askpin record askpin file. User must assign a file name for askpin file, once record is finished, file recorded will be display in rom –print. ----------------------------------------------------------------------------------------------- usr/config$ record -askpin askpin.test Please off hook the port 1 and press (N) for the next step...
  • Page 103 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 usr/config$ -tone analyze tone frequency. Gateway can analyze tone frequency as user provide tone inFXSO Line1. ----------------------------------------------------------------------------------------------- usr/config$ record –tone usr/config$ record -tone Press (R) to start record...........................................
  • Page 104 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 You will get another dial tone from the PSTN line which was connected with the Line 1 port. Answer the call and make sure the call is connected. Hang up the phone which is from the Line 2 port and you will get the disconnect tone from the Line 1 port.
  • Page 105 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 tone –print Disconnect tone 1 paramter Frequency high : 620 frequency low : 480 frequency high level frequency low level Tone1 on : 25 Tone1 off : 25 Tone2 on : 1023 Tone2 off : 1023...
  • Page 106 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Tone2 on : 50 Tone2 off : 50 (Confirm the values is correct or not) (Key in the commit and reboot command if you finish the procedures as above) 【Example -2】...

  • Page 107: Document Ver

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 frequency high level frequency low level Tone1 on : 25 Tone1 off : 25 Tone2 on : 1023 Tone2 off : 1023 Disconnect tone 2 paramter Frequency high : 450 frequency low frequency high level frequency low level...

  • Page 108: Tos]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 4.2.22 [tos] IP Packet ToS(type of Service)/Differentiated Service configuration. ----------------------------------------------------------------------------------------------- usr/configtos IP Packet ToS(type of Service)/Differentiated Service configuration Usage: tos [-rtptype dscp] tos [-sigtype dscp] tos -print [-rtpreliab mode] tos -print Example: tos -rtptype 7 -sigtype 0...
  • Page 109 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 -hostname Registered domain nam e. Registered account ID. -passwd Registered account password. -checkip Check the host current IP address(0=Disable, 1=Enabled). -checkipsrv1 Specify IP address check server. -checkipsrv2 Specify secondary IP address check server. -delay Setting the service delay time (1~59 minutes or 1~24 horus).

  • Page 110: Rom]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 Usage: pt [-print][-rfc2833 type][-dtmf type][-fax type][-faxbypass type] [-modembypass type][-redundancy type][-modemrelayp type] pt -print Display the RTP payload type information. -rfc2833 Configurate the DTMF RFC2833 payload type. -dtmf Configurate the DTMF payload type. -fax Configurate the FAX payload type.
  • Page 111 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 -greeting update Greetings PCM file(optional) -askpin update AskPin file(optional) IP address of TFTP/FTP server (mandatory) file name(mandatory) -method download via TFTP/FTP (TFTP: mode=0, FTP: mode=1) -ftp specify username and password for FTP Note: This command can run select one option in 'app', 'dsptest', 'dspcore', 'dspapp', and 'rbpcm'.

  • Page 112: Passwd]

    FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 ------------------------------------------------------------------------------------------------- -greeting The greeting file can be updated by users. The attributes of sound file should complied to: μ-law, 8000 Hz , 8 bit, Mono, 7 kb/s -askpin update ASKPIN sound file. This is the greeting sound that when asking for pincode.
  • Page 113 FXSO H.323 Gateway User Manual Document Ver.: 105 Release Dec, 2004 upgrade the firmware by 2m file.
