- Page 1 Installation Guide for Navigation Video Interface RGB MBCIRC designed for Mercedes-Benz WITH and WITHOUT Navigation Made in USA Watch video of this installation at www.youtube.com/navtool Copyright 2012 NavTool, Inc. All rights reserved.
- Page 2 RGB MBCIRC interface is compatible with: Mercedes-Benz B-CLASS 2003-2008 Mercedes-Benz C-CLASS 2005-2007 Mercedes-Benz CLK-CLASS 2005-2009 Mercedes-Benz G-CLASS 2007-2008 Mercedes-Benz GL-CLASS 2007-2008 Mercedes-Benz M-CLASS 2006-2008 Mercedes-Benz R-CLASS 2006-2008 The interface works on vehicles WITH and WITHOUT Navigation, if there is a screen installed.
- Page 3 Step 1 PREPARATION FOR THE INSTALALTION In order to prepare the Mercedes radio for the installation, open the front cover by pressing EJECT button. When the cover is open, disconnect the radio from power and turn the radio upside down. Shown above is the radio prepared for installation.
- Page 4 Do not use sharp objects for this operation. Step 4 CONNECTING NAVTOOL RIBBON CABLE Run the NavTool ribbon cable through the same slot as for original cable. Connect NavTool cable to the radio, and close the locks. Carefully reinstall the plastic cover (marked red) Do not use sharp objects and do not apply force on the locks.
- Page 5 Step 5 SECURING NAVTOOL RIBBON CABLE Place the NavTool ribbon cable into the compartment behind the slot, where the original cable is located. Leave suffi cient length of both NavTool and original cables for connecting them to NavTool board. Make sure there is at least 1.5” on both cables is loose.
- Page 6 86 of relay to reverse light, connect pin 30 of relay to accessory power, connect pin 87 of relay to Orange wire from NavTool Interface, you may also connect 87 of relay to accessory power for back up camera. If camera is desired to be...
-
Page 7: Testing The Operation
To check Camera in Motion press push button ones again. To switch back to Navigation press and hold the push button for three seconds. If all functions responded correctly – your installation of NavTool RGB MBC-IRC designed for Mercedes-Benz vehicles was done correctly.
