Banana Pi BPI-D1 Quick Start Manual

Banana Pi D1 Camera Quick Start Guide
1.How to record a video
In a fully charged or connecting micro - power USB cable, BPI-D1 will automatically start the default
set of video application. Start recording the video and sound and generate file storage to TF card.
Recorded 30 minutes to automatically generate and save for a video file. Click the "function key "
button, then manually stop recording the current task and generate a complete video file, start the next
record files after 10 seconds.
[Reminder]: Micro-USB interface supports USB flash disk connected through USB female port of
OTG cable, when there is no TF card, support recording videos directly to the external USB drive.
2.How to connect to the AP
Connect to the specified AP
The USB-WiFi module is connected to the USB interface of OTG. Press the BPI-D1 "primary key"
button, green LED will keep long bright after flashing about 8 seconds; it means BPI-D1 work in AP
mode.
1)Connect any mobile devices (e.g. Smartphone, tablet or computer) to the WiFi connection "SSID=
XXX_D1_A39XXX" and enter the default password "12345678".
2)In Internet Explorer, enter the FTP address "ftp://192.168.0.1". (user name: admin, password: admin)
3)Click "Ethernet", select one of the available WiFi. The SSID parameter will be displayed in the
above, click password blank and enter the known password, then click the "save". After flashing on the
screen, four parameters in the form disappeared that the connection is successful.
4)Click on the (39) Boot/WPS button, BPI-D1 switches to slave mode; you will see LED flashes from
fast into slow, which has been connected to the specified WiFi-AP.
