Eliet KS300 PRO Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M A N U A L
KS300 PRO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KS300 PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Eliet KS300 PRO

Summary of Contents for Eliet KS300 PRO

  • Page 1 M A N U A L KS300 PRO...
  • Page 2 Copyright 2009 ELIET. All rights reserved. All textual material, drawings, illustrations, diagrams, graphs, etc., included in this ELIET booklet are protected by copyright and also by other intellectual property rights. None of this information may be copied for commercial purposes or distribution and/or changed or reposted for other purposes. The copyright on the content included in...

  • Page 3: Introduction

    1. Introduction 1.1 Read this operating manual carefully ELIET machines are designed for safe and reliable use if they are operated in accordance with the instructions provided. Carefully read these operating instructions before using the machine. Failure to do so may result in personal injury or damage to the equipment.

  • Page 4: Welcome

    Welcome to the family of ELIET users. We thank you for the trust that you have placed in ELIET and we are convinced that you have purchased the very best machine. The operating life of your ELIET machine depends on how you care for your machine.

  • Page 5: Table Of Contents

    4. Table of Contents 1. Introduction ..........................3 1.1 Read this operating manual carefully ....................3 1.2 Identification data – ELIET KS300 PRO .................... 3 2. Warranty ........................... 3 2.1 Warranty card ............................3 3. Welcome ............................ 4 4. Table of Contents ........................5 5.
  • Page 6 9.5 Operating the machine ........................22 9.5.1 Prior to starting the work ......................22 9.5.2 Setting blade depth ........................23 9.5.3 Setting the angle of the blade ....................24 9.5.4 In the course of the work ......................24 9.6 Cleaning the machine .........................26 9.6.1 The importance of cleaning .......................26 9.6.2 What does cleaning entail? .......................27 9.7 Options ..............................28 9.7.1 Double front wheels ........................28...

  • Page 7: Operator Safety Warnings

    5. Operator safety warnings ELIET cannot anticipate every situation in which a risk or danger can occur. The warning symbols in this operating manual and the labels on the machine are therefore not comprehensive. Al- though minimal, a residual risk will always be present. If while operating the machine you apply a working method, operation or technique that is not explicitly recommended by ELIET, make sure that it does not represent a danger for bystanders.

  • Page 8: Main Machine Parts

    6. Main parts To fully understand the content of this operating manual you need to be fully conversant with the terminology used for the descriptions. This chapter refers to a broad range of machine parts and identifies their names. We recommend that you take the time to study the machine prior to its use for a better understanding of the descriptions provided in this operating manual.

  • Page 9: Engines

    (Find the closest dealer on www.eliet.eu). Caution: For your own safety, only genuine parts should be mounted on ELIET machines. For a list of original spare parts and their ordering codes please visit www.eliet.

  • Page 10: Safety Instructions

    7. Safety instructions 7.1 Safety messages The safety messages are clearly indicated on the machine with stickers or relief pictograms. Take good notice of the symbols and warning messages displayed. This sticker groups a number of key safety messages and infor- mation about the machine and the manufacturer: Some safety instructions are symbolised by icons: 1.

  • Page 11: Safety Features

    Safety stickers or parts that include safety information that are damaged due to use or cleaning, become illegible or have been removed must be immediately replaced. Stickers and parts can be obtained from any authorised ELIET dealer. 7.2 Safety features Belt shield: In order to guarantee your safety, the freewheeling part of the drive belt is covered.

  • Page 12: Safety Instructions

    • If the instructions stated in this manual are not clear to you, do not hesitate to contact your Eliet dealer for further explanation. In addition, the ELIET help desk is at your service during...

  • Page 13: Careful And Proper Use

    • After you purchase the machine, allow the dealer or a professional to give you some instruc- tions regarding correct use. • Carefully observe all safety instructions when using this ELIET machine! Carefully read all the instructions relating to the operation of the machine. All these instructions are important for your own personal safety.

  • Page 14: Personal Protective Equipment (Ppe)

    Children (under 16 years of age) and animals should be kept at a safe distance (2 m) from the machine. ELIET advises against lending the machine to others, but if this should occur, it should only be lent to persons who are familiar it. Always make sure that the user is aware of the potential hazards and ensure that he/she reads the manual before using the machine.

  • Page 15: Periodic Maintenance

    When parts must be replaced as a result of wear or failure, you must always request original ELIET replacement parts from your ELIET dealer. This is of key importance for your own safety. (Find an authorised ELIET dealer near you on www.eliet.eu).

  • Page 16: Assembly

    In case of damage to the machine a complaint to the shipping company must be submitted im- mediately after delivery. 8.1 Assembly When the machine has been removed from its packaging, it is still not completely assembled. The dealer must finish the assembly. Below we provide a few guidelines: You will find the machine in the box with the handlebar underneath it.
  • Page 17 The second part of the bar is also assembled. This is done by inserting the bar behind the hook. This part is fully secured in the following step, when the rotational knob for height regulation is installed. The rotational knob is installed. The order of installation is of utmost importance. The ‘dead man’s handle’...

  • Page 18: Other Duties

    At the back, the rotational knob is secured with a nut. The depth regulation lever is installed. The rod that comes in the box connects the operation lever on the steering rack with the lever arm on which the blades are mounted. The rod is affixed to the lever on top via a star lock fasten- er.

  • Page 19: Operating Instructions

    Every Eliet dealer warrants a long life span of Eliet machines. He will lubricate the hinges before delivering the machine to the client. The revolutions per minute will be set at 3,200 rpm. Finally, make sure that the warranty card is filled in completely and signed. The purpose is to avoid warranty disputes.

  • Page 20: Adding Fuel

    • Clean the area around the fuel cap (1) and remove it. Don’t fill the tank completely. Fill up to ap- proximately 20 millimetres from the brim. So never fill it up to the brim. • Always use a funnel or a spout for refuelling. Special funnels are available from your ELIET dealer.

  • Page 21: Preparing The Work Site

    9.3 Preparing the work site • Clean up the area where the machine will be operated prior to starting the work. Foreign objects are to be removed from the work area. The term ‘foreign objects’ is understood to mean: anything that is not organic or which breaches the maximum diameter given (e.g.

  • Page 22: Operating The Machine

    How to proceed? For your information: For placement of the parts, please check the engine manual or § 6.2. Open the throttle. b. Put the ignition to ‘ON’. c. Close the choke. d. Pull the starter cord to start the engine. e.

  • Page 23: Setting Blade Depth

    depth). There are 6 settings. The first two settings are for disengaging the clutch, the others are for setting the blade. The blade rises or falls by about 2 cm per setting. Now compare the desired cutting depth with the actual cutting depth. Set the depth regulation lever in its highest setting.

  • Page 24: Setting The Angle Of The Blade

    to the desired angle. The angle can be set at 0° - 25° - 45° • Set blade depth. (§ 9.5.2 Setting blade depth) If the ground is firm and has been finished well, it is preferable to cut the edges at an angle. This means that the ground will not be damaged and will retain its firmness.
  • Page 25 Warning: The blade will continue to turn for a while after the machine has been switched off. Always be careful. For your information: The ‘line’ that the blade follows is given by the indicator on the cover (see dia- gram below). For your information: A piece of string can be used to ensure that edges are straight.

  • Page 26: Cleaning The Machine

    Any necessary replacement and/or repair works must be undertaken immediately. Visit your authorised ELIET dealer to have them carried out (find an authorised ELIET dealer near you on...
  • Page 27 (Do not use a cleaning agent that will remove paint or stickers) If safety messages on stickers have become illegible, please replace. Original stickers can be pur- chased from your ELIET dealer. Compressed air can be used to easily blow out and clean some parts.

  • Page 28: Options

    9.7 Options 9.7.1 Double front wheels A double-wheel gives the machine extra stability and makes it easier to use, particular when cut- ting curved lawns. A. DISMANTLING SINGLE FRONT WHEEL B. ASSEMBLING DOUBLE FRONT WHEEL 9.7.2 Eight-tooth disc The standard machine is supplied with a classic straight blade. For more delicate work you can replace the standard blade with an eight-tooth disc.

  • Page 29: Transporting The Machine

    10. Transporting the machine • Only adults are permitted to move or transport the machine. During transport children, unauthorised people or animals must not be allowed within a 2 m radius of the machine. Leave all operational levers unchanged when moving the machine. The lawn edger can be pushed forwards.

  • Page 30: Maintenance

    (find an authorised ELIET dealer near you on www.eliet.eu). Your ELIET dealer is always at your service for maintenance and advice. He stocks genuine ELIET replacement parts and lubricants. His staff can always obtain advice and service from ELIET’s help desk in order to provide you with an impeccable after-sales service.

  • Page 31: A Routine Check Before Each Operation

    Caution: Always wear safety gloves when performing maintenance. Safety goggles may be required for certain operations. These are supplied standard with the machine. 1.2 A routine check before each operation Warning: For your own safety, always replace the safety guards after work. Removing the wheel guard At the back (angle setting side) •...

  • Page 32: Visual Check Of The State Of The Machine

    • Remove the hexagonal bolts. • Remove the cover. 11.2.1 Visual check of the state of the machine Check whether any parts have been deformed and check for torn welds and any excess play on parts. If problems are found, repairs must be carried out first. 11.2.2 Checking the engine’s oil level •...

  • Page 33: Cleaning The Air Filter

    11.2.3 Cleaning the air filter The type of air filter may differ slightly depending on the engine brand and type. • The air filter is located under the black protection cover, next to the fuel reservoir on the ma- chine. Loosen the black protection cover.

  • Page 34: Checking And Tightening The Blade Bolts

    (2) and fixed using a bolt (3). When removing the blade, note the order of the machine parts that have been removed; this will simplify reassembly. In order to sharpen the blade, you are advised to consult the ELIET dealer as they will have the...

  • Page 35: Checking After 50 Hours Of Use

    Empty the full contents (approx. 0.6 l) from the engine. Replace the bolt on the drain. Wipe away any spilled oil with a clean cloth. Refill the engine with fresh 4 stroke oil. ELIET recommends a top quality high-detergent oil: SUNOCO DENALUBE SAE 20W50 API SF / CC.

  • Page 36: Checking The Spark Plug

    11.3.3 Changing the air filter This procedure is exactly the same as for cleaning the air filter. (See § 11.2.3 Cleaning air filter). Contact your ELIET dealer or authorised engine service centre to purchase the proper air filter. 11.3.4 Lubricating For proper operation of the machine it is recommended to lubricate it at regular intervals.
  • Page 37 • Clean the nipple Push new lubricant through the nipple with a special lubricant pump. ELIET recommends Sunoco Multi Purpose Grease. One or two pump-fulls will suffice to redistribute the new grease. Remove the grease that protrudes via the seams.

  • Page 38: Belt Tension Adjustment

    11.3.5 Belt tension adjustment Caution: When adjusting the belt tension the engine must be turned off and the spark plug cap removed. The operation lever on the handlebar can be used to set depth as well as to engage the blade. You must ensure that the belt is not tensioned in the highest position.

  • Page 39: Storing The Machine

    Check all nuts and bolts and fasten them where necessary. To avoid rust on the machine, touch up all chipped areas or treat them with anti-rust grease. Original paints/enamels in the appropriate colours are available from your ELIET dealer.

  • Page 40: Equipment Specifications

    13. Equipment specifications Engine 4.0 hp Honda GX 120 5.5 hp Honda GX160 Blade Steel 6 mm Rpm blade 2,550 rpm Depth setting max 110 mm Angle setting 0° / 25° / 45° Chassis Steel 6 mm Transmission V-belt A 32.5 Adjustable steering height 7 Height settings Dimensions (LxWxH in mm)

  • Page 41: Appendices

    Neglecting to conduct routine maintenance may cause a machine to stop working effectively. Damage can be caused and the risk to the operator or third parties may be increased. ELIET EUROPE NV cannot be held liable for the consequences of neglecting to carry out maintenance. The warranty may also be...

  • Page 42: B2 List Of Torques

    B2 List of torques Bolt head according to DIN 931,912 etc. Thread strength 8.8 10.9 Normal thread M4 3.0 4.4 M5 5.9 8.7 M6 10 15 M8 25 36 M10 49 72 M12 85 125 M14 135 200 M16 210 310 M18 300 430 M20 425 610 M22 580 820...

  • Page 43: B3 Ec Declaration Of Conformity

    HELD LAWN TRIMMERS AND LAWN EDGE TRIMMERS - MECHANICAL SAFETY The ELIET machine factory hereby declares that after performing a hazard analysis, it is fully aware of the potential hazards and risks associated with the machine. In this knowledge, the necessary steps have been taken in line with Machine Directive 2006/42/EC in order to ensure absolute operator safety for the operator, when the machine is used correctly.

  • Page 44: B4 Warranty Conditions

    At ELIET, we have strict quality rules on designing and manufacturing products. The purpose of these rules is to guarantee a long service life and permanent safety. That is why ELIET is happy to repair any hidden defects or faults during the whole run-in period (i.e. the warranty period) free of charge, provided the prescribed procedure is followed.
  • Page 45 Step 2: In the event of a defect, the customer shall have it verified by the authorised ELIET dealer. If the dealer finds a manufacturing defect, he may invoke the warranty under the terms specified.
