Eliet KS240 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M A N U A L
KS240

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KS240 and is the answer not in the manual?

Questions and answers

Related Manuals for Eliet KS240

Summary of Contents for Eliet KS240

  • Page 1 M A N U A L KS240...
  • Page 2 Copyright 2009 ELIET. All rights reserved. All textual material, drawings, illustrations, diagrams, graphs, etc., included in this ELIET booklet are protected by copyright and also by other intellectual property rights. None of this information may be copied for commercial purposes or distribution and/or changed or reposted for other purposes. The copyright on the content included in...

  • Page 3: Introduction

    Introduction Read this operating manual carefully ELIET machines are designed for safe and reliable use if they are operated in accordance with the instructions provided. Carefully read these operating instructions before using the machine. Failure to do so may result in personal injury or damage to the equipment.

  • Page 4: Welcome

    Welcome to the family of ELIET users. We thank you for the trust that you have placed in ELIET and we are convinced that you have purchased the very best machine. The operating life of your ELIET machine depends on how you care for your machine.

  • Page 5: Table Of Contents

    Table of Contents 1. Introduction ..........................3 1.1 Read this operating manual carefully ....................3 1.2 Identification data – ELIET KS240 ....................... 3 2. Warranty ............................ 3 2.1 Warranty card ............................3 3. Welcome ............................. 4 4. Table of Contents ........................5 5.
  • Page 6 9.5 Operating the machine ......................... 21 9.5.1 Prior to starting the work ......................21 9.5.2 Setting blade depth ........................21 9.5.3 Setting the angle of the blade ....................22 9.5.4 During work ...........................23 9.6 Cleaning the machine ..........................24 9.6.1 The importance of cleaning ......................24 9.6.2 What does cleaning entail? ......................25 9.7 Options ..............................26 9.7.1 Double front wheels ........................26...

  • Page 7: Operator Safety Warnings

    5. Operator safety warnings ELIET cannot anticipate every situation in which a risk or danger can occur. The warning symbols in this operating manual and the labels on the machine are therefore not comprehensive. Al- though minimal, a residual risk will always be present. If while operating the machine you apply a working method, operation or technique that is not explicitly recommended by ELIET, make sure that it does not represent a danger for bystanders.

  • Page 8: Main Parts

    6. Main parts To fully understand the content of this operating manual you need to be fully conversant with the terminology used for the descriptions. This chapter refers to a broad range of machine parts and identifies their names. We recommend that you take the time to study the machine prior to its use for a better understanding of the descriptions provided in this operating manual.

  • Page 9: Engines

    Your ELIET dealer remains at your service for any maintenance or advice, ensur- ing your ELIET machine is always in perfect condition. You can contact him for original ELIET parts and lubricants at any time. These service parts are manu- factured according to the same strict rules and craftsmanship as the original equipment.

  • Page 10: Safety Instructions

    7.Safety instructions 7.1 Safety messages The safety messages are clearly indicated on the machine with stickers or relief pictograms. Take good notice of the symbols and warning messages displayed. This sticker groups a number of key safety messages and infor- mation about the machine and the manufacturer: Some safety instructions are symbolised by icons: 1.

  • Page 11: Safety Features

    Safety stickers or parts that include safety information that are damaged due to use or cleaning, become illegible or have been removed must be immediately replaced. Stickers and parts can be obtained from any authorised ELIET dealer. 7.2 Safety features...

  • Page 12: Safety Instructions

    • If the instructions stated in this manual are not clear to you, do not hesitate to contact your Eliet dealer for further explanation. In addition, the ELIET help desk is at your service during office hours to answer any questions you may have: (EU +32 56 77 70 88). • Be sure to read the chapter which is intended for the dealer (see chapter 8) and verify whether the machine was delivered in accordance with the instructions.

  • Page 13: Operator's Responsibilities

    • A disabled person may only operate the machine when under the supervision of an experi- enced operator. • Children (under 16 years of age) and animals should be kept at a safe distance (2 m) from the machine. • ELIET advises against lending the machine to others, but if this should occur, it should only be lent to persons who are familiar it. Always make sure that the user is aware of the potential hazards and ensure that he/she reads the manual before using the machine. • This machine must only be operated by persons who have a good physical condition. Take a rest if you become tired while operating the machine.

  • Page 14: Dangerzone

    This will prevent overheating and consequential damage to the machine. • When parts must be replaced as a result of wear or failure, you must always request original ELIET replacement parts from your ELIET dealer. This is of key importance for your own safety. (Find an authorised ELIET dealer near you on www.eliet.eu). • For a list of original spare parts and their ordering codes please visit www.eliet.eu.

  • Page 15: In Harmony With Nature

    8. Dealer’s duties Warning: As an ELIET dealer you must familiarize your customers with the operation of the machine and also point out the possible dangers while using it. You are expected to carefully go over the main- tenance points of the machine together with the new owner. Repeat these instructions until the new owner has fully understood everything.
  • Page 16 The upper half of the handlebar is then placed on the lower half. The operation lever remains on the side of the blade. Both blades are fixed to one another with two bolts (M6x45) and the nuts and locking rings (M6) supplied. The rod that comes in the box connects the operation lever on the steering rack with the lever arm on which the blades are mounted.

  • Page 17: Other Duties

    (or those pertaining to the engine manual). Every Eliet dealer warrants a long life span of Eliet machines. He will lubricate the hinges before delivering the machine to the client.

  • Page 18: Operating Instructions

    If you detect cracks or flaws in the blade, immediately install a new blade. 6. Check that the machine is running at the rpm given (an rpm counter can be obtained from your ELIET dealer). 7. Check that all safety provisions on the machine are still operating properly.

  • Page 19: Preparing The Work Site

    Under certain conditions, petrol is extremely flammable and highly explosive. Fire breakouts and petrol explosions can inflict severe burns and cause damage to personal property. • Never refuel while the engine is running. Always allow the engine to cool down for several minutes before refuelling. • Use fresh fuel only. • Given the limited shelf life of petrol, ELIET recommends purchasing small amounts. • Store the fuel in an approved tank. Keep it out of reach of children. • Store the petrol in a well-ventilated area, away from fire, sparks or heat sources. • Never refuel at the location where the machine will be operated. Keep a distance of at least 10 m from the selected work area in view of fire hazard. • Clean the area around the fuel cap (1) and remove it. Don’t fill the tank completely. Fill up to ap- proximately 20 millimetres from the brim.

  • Page 20: Starting The Petrol Engine

    9.4 Starting the petrol engine Caution: Please read the safety instructions under § 7.3. Caution: Never start the engine if the cooling fins are dirty. The engine would heat up too quickly, which would pose a fire risk. For your information: For more information, please check the engine manual.

  • Page 21: Operating The Machine

    How to proceed? For your information: For placement of the parts, please check the engine manual or § 6.2. Open the throttle. b. Put the ignition to ‘ON’. c. Close the choke. d. Pull the starter cord to start the engine. e.

  • Page 22: Setting The Angle Of The Blade

    • Push it downwards until it reaches the desired setting (or the setting that gives the required depth). There are 6 settings. The first two settings are for disengaging the clutch, the others are for set- ting the blade. The blade rises or falls by about 2 cm per setting. • Now compare the desired cutting depth with the actual cutting depth. • Set the depth regulation lever in its highest setting. • Pull the Beta pin (2) out and take the screw (3) out of the holder. • Turn the screw to the left to raise the blade or to the right to lower the blade. (A 1 cm move- ment of the screw gives approximately 2 cm movement of the blade).

  • Page 23: During Work

    • Set blade depth. (§ 9.5.2 Setting blade depth) If the ground is firm and has been finished well, it is preferable to cut the edges at an angle. This means that the ground will not be damaged and will retain its firmness. A right angle is better for unfinished edges as this will give them a nice finish and will keep sub- sequent work to a minimum.

  • Page 24: Cleaning The Machine

    9.6 Cleaning the machine 9.6.1 The importance of cleaning ELIET recommends cleaning the machine after each use. We recommend performing an inspec- tion each time you clean the machine to check component and machine integrity. It allows timely intervention and prevention of any defects, ensuring a longer service life of your machine.

  • Page 25: What Does Cleaning Entail

    Any necessary replacement and/or repair works must be undertaken immediately. Visit your authorised ELIET dealer to have them carried out (find an authorised ELIET dealer near you on www.eliet.eu). Cleaning the machine entails more than just cleaning the outside. Open all protective covers so that you can also clean the inside of your machine.

  • Page 26: Options

    • Pay particular attention to cleaning the engine. Cooling fins and air inlets are of key impor- tance to guarantee adequate cooling of the engine.  • A steamer may be used for cleaning, Do not spray excessive amounts of water on the bear- ings, electric contacts and filler caps. Water is the number one cause of rust and this must be avoided at all times. Allow the engine to cool down properly before treating it with water. Caution: Cleaning activities to the machine must always be carried out with the engine turned off.

  • Page 27: Eight-Tooth Disc

    9.7.2 Eight-tooth disc The standard machine is supplied with a classic straight blade. For more delicate work you can replace the standard blade with an eight-tooth disc. This further reduces the risk of damage to borders, stepping stones and path edges. The blade is mounted between two locking rings and fixed using a bolt.

  • Page 28: Maintenance

    (find an authorised ELIET dealer near you on www.eliet.eu). Your ELIET dealer is always at your service for maintenance and advice. He stocks genuine ELIET replacement parts and lubricants. His staff can always obtain advice and service from ELIET’s help desk in order to provide you with an impeccable after-sales service.

  • Page 29: A Routine Check Before Each Operation

    Caution: Always wear safety gloves when performing maintenance. Safety goggles may be required for certain operations. These are supplied standard with the machine. 11.2 A routine check before each operation Warning: For your own safety, replace all safeguards after maintenance work is complete. 11.2.1 Visual check of the state of the machine Check whether any parts have been deformed and check for torn welds and any excess play on parts.

  • Page 30: Adjusting Depth Regulator

    Caution: Should the machine have toppled over for some reason, you must set it upright again as soon as possible. The unusual position of the engine may have caused oil to seep from the crankcase via the carburettor onto the air filter. Oil on the filter paper obstructs the air passage and the filter must therefore be replaced.

  • Page 31: Checking The Blade

    The engine must be switched off and the height regulator must be put in the highest position. Caution: Wear gloves when turning the blade in order to avoid injury. • Turn the blade and check that there are no cracks in it. If there are, replace the blade immedi- ately. Always use original ELIET machine parts. • The blade must be undone in order to replace or sharpen it. Hold the blade fast and turn the M8 bolt anti-clockwise using a 13 ring spanner. • When removing the blade, note the order of the machine parts that have been removed; this will simplify reassembly.

  • Page 32: Checking After 50 Hours Of Use

    11.3 Checking after 50 hours of use 11.3.1 Removing the wheel guard At the back (angle setting side)  Unscrew the inner hexagon from the engine block.  Remove both hexagons. At the front (blade side)  Unscrew both hexagonal M5 bolts. ...

  • Page 33: Checking The Sparking Plug

    If it doesn’t, more oil must be added. Warning: Oil shortage inevitably causes severe engine damage. 11.3.3 Checking the sparking plug. ELIET suggests the following spark plugs: BPM 7 A CHAMPION BS 19 LM • Turn off the engine and pull the cable from the spark plug.

  • Page 34: Changing The Air Filter

    11.3.4 Changing the air filter • This procedure is exactly the same as for cleaning the air filter. (See § 11.2.3 Cleaning air filter). • Contact your ELIET dealer or authorised engine service centre to purchase the proper air filter. 11.3.5 Lubricating For proper operation of the machine it is recommended to lubricate it at regular intervals.  Lubricate hinges and friction points.  Lubrication nipples Caution: As for other maintenance, the engine must be switched off and the spark plug removed before performing any lubricating activities.

  • Page 35: Belt Tension Adjustment

    How to proceed? • Clean the nipple • Push new lubricant through the nipple with a special lubricant pump. • ELIET recommends Sunoco Multi Purpose Grease. • One or two pump-fulls will suffice to redistribute the new grease. • Remove the grease that protrudes via the seams. B. LUBRICATING WHEELS • Use a ring spanner 17 to loosen the bolts that hold the wheels on the axle. Remove the wheel from the axle. • Squirt penetrating oil on a basis of MOS2 onto the wheel axles and give it time to work in. Then clean the wheel axles with a clean cloth. Reapply grease (Sunoco Multi-purpose LR - EP2 grease) using a brush. Do this to the bearings in the wheel too.
  • Page 36 How to proceed? • Switch the engine off and remove the spark-plug cover. • Put the depth regulator in its penultimate setting. • Use you finger to press the centre of the belt. • This should move the belt by a maximum of 1 cm. If the movement exceeds this, the belt needs tightening. • Pull the Beta pin (1) out and take the screw (2) out of the holder. • Turn the screw in a clockwise direction to tension the belt. • Now place the screw back in the holder and replace the Beta pin. Check Once the connector has been replaced and fixed in place and the lever is put into the third posi- tion, you can check whether the tension is sufficient: hold the belt fast with one hand and try to turn the blade with the other hand.

  • Page 37: Storing The Machine

    • Store the machine out of the reach of children. • Never leave the machine connected to the mains when storing. • Never store the machine near heat sources or open flames. (Observe at least 2 m distance) • If the machine is stored outdoors, it must be properly covered with canvas. Avoid direct pre- cipitation on the machine. ELIET highly recommends a sheltered storage place. Storing • Always allow the engine to cool down before storage. • When storing the machine for an extended period, we recommend that you follow the steps below: • Check all nuts and bolts and fasten them where necessary. • To avoid rust on the machine, touch up all chipped areas or treat them with anti-rust grease. Original paints/enamels in the appropriate colours are available from your ELIET dealer.

  • Page 38: Equipment Specifications

    13. Equipment specifications Engine 4.0 hp Honda GC135 5.0 hp Honda GC160 Blade Steel dia. 240mm / 68 NiCrMo3 Rpm blade 2,550 rpm Depth setting max 80 mm Angle setting 0° / 25° / 45° Chassis Steel 6 mm Transmission V-belt A 32.5 Dimensions (LxWxH in mm) 1,270x460x920 mm...
  • Page 39 Neglecting to conduct routine maintenance may cause a machine to stop working effectively. Damage can be caused and the risk to the operator or third parties may be increased. ELIET EUROPE NV cannot be held liable for the consequences of neglecting to carry out maintenance. The warranty may also be...
  • Page 40 B2 List of torques Bolt head according to DIN 931,912 ed. Thread Strength 10.9 Normal thread 1050 1100 1550 1450 2100 Fine thread M8 x 1 M10 x 1.25 M12 x 1.5 M14 x 1.5 M16 x 1.5 M18 x 1.5 M20 x 1.5 M22 x 1.5 M24 x 2...
  • Page 41 HELD LAWN TRIMMERS AND LAWN EDGE TRIMMERS - MECHANICAL SAFETY The ELIET machine factory hereby declares that after performing a hazard analysis, it is fully aware of the potential hazards and risks associated with the machine. In this knowledge, the necessary steps have been taken in line with Machine Directive 2006/42/EC in order to ensure absolute operator safety for the operator, when the machine is used correctly.
  • Page 42 The first part of the card has to be returned to ELIET within one month. The customer is required to keep all remaining parts of the card along with the purchase invoice for the duration of the warranty period.
  • Page 43 • Step 6: ELIET sends the parts ordered to the dealer under the regular delivery and payment conditions. • Step 7: The defective part will be examined by ELIET’s technical department prior to approv- ing or rejecting the warranty. ELIET reserves the right to unilaterally decide whether or not the customer has complied with all the conditions applicable to the one year or two year warranty. Faulty components automatically become the property of ELIET.
