Summary of Contents for Elari CardPhone

  • Page 2: Table Of Contents

    Content 1. Getting started 1.1. Installation of SIM card 1.2. Charging method 2. Buttons 3. Introduction 3.1. Standby interface 3.2. Use of dialing function 4. Menu 4.1. Music player control 4.2. Sound recording 4.3. Bluetooth 4.4. Contacts 4.5. Short Messages 4.6.

  • Page 3: Getting Started

    Getting started 1.1. Installation of SIM card The SIM card slot is on the upper right side of the back of equipment. According to the instructions, first remove the cover of the slot, then carefully put the SIM card downward into the slot, only then close the cover of the slot.

  • Page 4: Charging Method

    1.2. Charging method The four hard contacts of the charging clip should cor- respond to the four hard contacts of the equipment. Press the charging clip to ensure that it is closely at- tached to the back part of equipment, and then use the USB cable to connect the charging clip to the computer or adapter for charging.

  • Page 5: Buttons

    Buttons Automatic screen lock key OFF ON Long press Bluetooth to access dialing button voice mail GSM dialing button In standby Select menu mode short item (up) press to access calcu- Select menu lator, in text item (down) input forms short press to Return button delete...

  • Page 6: Introduction

    Introduction 3.1. Standby interface In the stop mode of the equipment, long press of ON/ OFF key can turn the phone on, then you can enter the standby mode. Status bar of the standby interface shows the Internet signal, battery capacity, message notifica- tion icon if your short message is not read.

  • Page 7: Menu

    Menu 4.1. Music player control When the equipment and smartphone Bluetooth are con- nected, you can use the control function for playing music (please note that this function is only control one, it can con- trol the smartphone playing or stopping the music, has the function to play previous or next song).

  • Page 8: Bluetooth

    Play and delete the recording file In the interface of sound recording menu using the selec- tion button (up) and selection button (down) you can select the required function. Then select the record history menu, press OK key. The list or recording files can be popped out, using the selection button (up) and selection button (down) you can select the required file.

  • Page 9: Contacts

    4.4. Contacts In the main interface of contacts menu press OK key to access the list of contacts, using the selection button (up) and selec- tion button (down) you can select the contacts from this phone, synchronize the contacts via Bluetooth and add the contacts. Contacts from the Contacts main menu Bluetooth contacts...
  • Page 10 Find the contact Send message Call the contact Transfer the contacts between Edit the contact Delete the contact the phone and SIM card 4.4.3. Call the Bluetooth contacts In the list of Bluetooth contacts press OK key to access the contact view interface, then press OK button once more to enter the menu selection interface of these contacts.

  • Page 11: Short Messages

    4.5. Short messages In the interface of short message main menu press OK key to access the short message operational interface, press the up and down selection buttons to select the following func- tions: «Create new message», «Inbox», «Drafts», «Outbox». Short message main Create new message Outbox...
  • Page 12 Unread messages Read messages Reply Add the contact Delete Forward Call 4.5.3. Outbox Select «Outbox», then press OK key to access the list of sent messages, use the up and down selection buttons to se- lect the required message, press OK key to review sent text, press again OK key for the following functions: «Forward the message», «Delete».

  • Page 13: Call History

    4.6. Call history Press OK key to enter the call list, then press again OK key to review the details of the call history, then press OK key once again to perform the following functions: «Add the contact», «Call the contact», «Send message», «Delete call history». Call history main menu Received calls Dialed calls...
  • Page 14 4.7.2. Phone settings The phone settings include the following types: «Date set- tings», «Time settings», «Time zone settings», «Time format settings», «System language settings», «Volume settings», «Provider manual settings», «Screen brightness time set- tings». For information relating to the details of these func- tions, please refer to the following figures: Phone settings Date settings...
  • Page 15 4.7.3. Profiles There are the following profiles: «Standard mode», «Silent mode», «Conference mode», «Outdoors mode», «Airplane mode». Select the required used mode, press OK key to confirm the settings. Profiles Standard mode Silent mode Outdoors mode Airplane mode Conference mode 4.7.4.

  • Page 16: Calculator

    4.8. Calculator In the standby interface press long the calculator button to access the calculator interface, CardPhone will be trans- ferred to the calculator, input the numbers directly to per- form the calculation. CE zero clearing Calculator button Press long to enter or exit the...

  • Page 17: Shortkeys

    4.10. Shortkeys 1. In the interfaces for editing short messages, names and surnames of the contacts, etc. press # key to change the input method, press * key to enter the sym- bol selection interface. 2. In the conversation mode press OK key to activate or deactivate hands-free mode.
