IMPORTANT SAFETY INSTRUCTIONS

All the safety and operating instructions should be read before operating this

product. The safety and operating instructions should be retained for future reference.

All warnings on the product and the operating instructions should be adhered to.

All operating and usage instructions should be followed.

Unplug this product from the wall outlet before cleaning.

Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning and place

the receiver in well ventilated and no-heat environment. Do not use attachments

not recommended by the product manufacture as they may cause hazards.

Do not use this product near water for example, near a bath tub, wash bowl,

kitchen sink or laundry tub, in a wet basement, or near swimming pool, and

the like. Do not place this product on an unstable cart, stand, tripod, bracket, or table.

The product may fall, causing serious injury to a child or an adult and serious

damage to the product. Use only with a cart, stand tripod, bracket, or table

recommended by the manufacturer or sold with the product. Any mounting of the

Product should follow the manufacturer's instructions, and should use a mounting

accessory recommended by the manufacturer.

This apparatus shall not be exposed to dripping or splashing and that no object

filled with liquids, such as vases, shall be placed on the apparatus.

The main plug is used as the disconnect device. The disconnect device shall

remain operable.

0 1

Table of Contents

Need help?

Do you have a question about the SR-X7100USB and is the answer not in the manual?

Questions and answers

Summary of Contents for star sat SR-X7100USB

Page 1: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS All the safety and operating instructions should be read before operating this product. The safety and operating instructions should be retained for future reference. All warnings on the product and the operating instructions should be adhered to. All operating and usage instructions should be followed.
Page 2: Table Of Contents
CONTENTS 1. Introduction 1. Introduction 1-1 Main Features 1-2 Accessories 1-1 Main Features 2. Controls & Features 2-1 Front Panel 120 programmable satellites / 6,000 programmable channels 2-2 Rear Panel 950~2150 MHz IF range 2-3 Remote Control Unit(RCU) MCPC/SCPC, C/KU reception 3.
Page 3: Controls & Features
2. Controls & Features 2. Controls & Features 2-1 Front Panel 2-2 Rear Panel (SR-X7100USB titanium) (SR-X7100USB titanium 2 3 4 Power IF IN: Satellite dish input (F-connector) To put the receiver in and out of standby mode. IF OUT: IF loop-through output to second receiver...
Page 4 T.S. Key: you will be asked to "Do you want to time shift?" menu. GOTO key: Jump to input time program. key: will stop the recorded and want to stop play record. SR-X7100USB titanium key: will be asked to "Do you want to record?" Menu.
Page 5: Connection Diagram Of The Receiver
3. Connection Diagram of the Receiver 3. Connection Diagram of the Receiver " To receive high video quality, " To receive high video quality, please use either component or scart output only " please use either component or scart output only " 3-1 Connecting to a TV 3-2 Connecting to a HiFi System - Connect the SCART lead between the main SCART socket on the TV and the...
Page 6: Function Guide
4. Function Guide 4. Function Guide 4-1 Channel Information 4-4 Channel List for TV/Radio/Favorite Every time you change channels, program information will be displayed for a few When you press the OK key, you can directly see the channel list seconds.
Page 7 4. Function Guide 4. Function Guide 4) BLUE(Multi Pictures): If you press the Blue 4-6 Zoom key, you will be able to choose between a 4, 9, 13 or 16 pictures display. After making 1.The [Zoom] key allows you to magnify a you selection, the screen will be divided and certain area on the images and the current the current channel will be displayed in the first...
Page 8: Main Menu
4. Function Guide 5. Main Menu 4-9 Quick Scan 5-1 Installation 5-1-1 Installation (Antenna & Transponder Configuration) Press Scan button on RCU, and you will be able This mode will display the LNB Frequency, to fine the channel very easily. DiSEqC and transponder list of current satellite After selecting the satellite, if you start the Scan, and can adjust displayed information...
Page 9 5. Main Menu 5. Main Menu 5-1-4 PID Edit 5-1-7 Antenna Positioning When you want edit PID (Packet Identifier) value, Antenna Positioning (DiSEqC 1.2) press GREEN key in the Transponder which has This mode will allow you to set the antenna non-DVB standard channels and which only can position for each satellite.
Page 10 5. Main Menu 5. Main Menu 5-2 System Setting 5-2-1 Edit Channel The factory set password is 000000. Rename channels From these menus you can create and edit Within any of your favorite lists you can rename channel lists. You can create a favorite channel the channels.
Page 11 5. Main Menu 5. Main Menu 5-2-2 Parental Control 5-2-3 Time Adjustment Parental Control Automatic Update: This item is used to set the In the parental control menu, you can set the time by using the time signal from the satellite. censorship classification or change the PIN Press ◄/►...
Page 12 5. Main Menu 5. Main Menu 5-2-5 System Information 5-2-8 Automatic Standby This displays general information about which Low Power Consumption: At this option, you hardware and software version your receiver is could Enable / Disable the low power running on. consumption mode.
Page 13 5. Main Menu 5. Main Menu 5-3 User Preference 5-4 Advanced Utilit From here you can access the Menu Language, 5-4-1 DVR Management Select the Media List, Media Control and First Audio Lang, Second Audio Lang, Disk Information TV screen format, TV Type, Video Output. . Management.
Page 14 5. Main Menu 5. Main Menu Disk Information STB-STB Upgrade The screen displays data about the current This can be done from PC to receiver HDD. or from a master receiver to a slave HDD Model / HDD Size / Time Shift Size / receiver.
Page 15: New Features
5. Main Menu 6. New Features 6-1 A/V Selection 5-4-3 Smart Card Press Blue key in the viewing mode, and you can adjust the setting of Audio / Video. In this option, you can find information about Audio the conditional access system. If there is no Alternate Video: select the video channel in case that several video channels input.
Page 16: Troubleshooting
7. Troubleshooting 8. Technical Specifications There may be various reasons for abnormal operation of the unit. Therefore, if the unit dies not work properly, check the unit according to the procedures shown in the table below. A/V & Data In / Out Problem Possible causes What to do...
Page 17 8. Technical Specifications MEMO Tuner & Channel Input Connector: F-type, IEC 169 24, Female Frequency Range: 950MHz to 2150MHz Input Impedance: 750hm or 75 . Unbalanced Signal Level: -25 to -65dBm LNB Power & Polarization: Vertical ±13V / Horizontal ±1 8V Current: 500mA Max overload Protection 22KHz Tone: Frequency -22KHz ±...
