Ergänzung
Zusätzlich erforder-
Supplement
liche Unterlagen
für den
Komplettservice:
1
Additionally
required Service
Sach-Nr./Part No.
Manuals for the
72010-013.81
Complete Service:
D
Für diese Geräte gilt das Service Manual CUC 6310.
Diese Ergänzung dokumentiert die Unterschiede bzw. zusätzlichen
Bestückungen der Geräte.
Die Bausteinbestückung und die Sachnummern der einzelnen Bau-
steine entnehmen Sie bitte der Tabelle auf Seite 1.
Grundlage für den Service sind:
– Sicherheitsvorschriften (Sach-Nr. 72010-800.00)
– Service Manual CUC 6310 (Sach-Nr. 72010-013.80)
Inhaltsverzeichnis
Modulübersicht ................................................................................ 1
Technische Daten ............................................................................ 2
Abgleich ........................................................................................... 3
Bedieneinheit 29501-082.22 ............................................................ 4
Chassisplatte ................................................................................... 5
Gesamtschaltplan ............................................................................ 9
Oszillogramme Chassisplatte ........................................................ 13
Bildrohrplatte 29305-122.05 .......................................................... 17
Ersatzteillisten ................................................................................ 19
Modulübersicht / Module List
T 70-740 text
T 70-740/4 top
T 70-740 FT/GB
Änderungen vorbehalten
Subject to alteration
Service
Manual
CUC 6310
Sach-Nr./Part No.
72010-013.80
Seite
Gerät
Chassis
Unit
29701-084.03
29701-084.07
29701-084.08
Printed in Germany
SERVICE MANUAL
Service
Manual
Sicherheit
Safety
Sach-Nr./Part No.
72010-800.00
T 70-740 text
T 70-740/4 top
T 70-740 FT/GB
GB
For these TV sets the Service Manual CUC 6310 is applicable.
This Manual describes the differences and the additionally fitted
modules of the TV receivers.
The individual modules and the relevant part numbers are listed in the
table on page 1.
Basic instructions for servicing are given in the:
– Safety Instructions (Part No. 72010-800.00)
– Service Manual CUC 6310 (Part No. 72010-013.80)
Table of Contents
Module List ...................................................................................... 1
Technical Data ................................................................................. 2
Alignment ......................................................................................... 3
Control Unit 29501-082.22 .............................................................. 4
Chassis Board ................................................................................. 5
General Circuit Diagram .................................................................. 9
Oscillograms Chassis Board ......................................................... 13
CRT Panel 29305-122.05 .............................................................. 17
Spare Parts Lists ........................................................................... 19
BR-Platte
Tuner
CRT Panel
29504-201.01
29305-122.05
29504-201.01
29305-122.05
29504-201.01
29305-122.05
VK 24 0296
CUC 6310
(9.21426-01 / G.CA 3875)
(9.21426-02 / G.CC 4575)
(9.21426-64 / G.CC 7875 GB)
Fernbedienung
Remote Control
29642-059.06
29642-059.06
29642-059.06
Service Manual Sach-Nr.
Service Manual Part No. 72010-013.81
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUC 6310 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Grundig CUC 6310

  • Page 1 (9.21426-64 / G.CC 7875 GB) Für diese Geräte gilt das Service Manual CUC 6310. For these TV sets the Service Manual CUC 6310 is applicable. Diese Ergänzung dokumentiert die Unterschiede bzw. zusätzlichen This Manual describes the differences and the additionally fitted Bestückungen der Geräte.
  • Page 2: Technische Daten

    Allgemeiner Teil / General Section CUC 6310 Technische Daten / Technical Data T 70-740 text T 70-740/4 top T 70-740 FT/GB Bildröhre / Picture Tube Sichtbares Bild 66cm 66cm 66cm Visible picture Bildschirmdiagonale 70cm (28") 70cm (28") 70cm (28") Screen diagonale...
  • Page 3: Abgleich

    CUC 6310 Abgleich / Alignment Abgleich Alle nicht beschriebenen Einstellelemente sind werkseitig abgeglichen und dürfen im Servicefall nicht verstellt werden. Bildrohrplatte Meßgeräte: hochohmiges Voltmeter, Zweikanal-Oszilloskop mit Tastkopf 10:1 Servicearbeiten nach Austausch der Bildröhre, der Bildrohrplatte bzw. Reparatur der Bildrohrplatte: Abgleich...
  • Page 4 IC84001 R84001 TFMS5300 SCHALT SCHALT SCHALT SCHALT AUDIO C41001 5,6n (AU1B) FBAS FBAS R44001 AUDIO AUDIO BED.-EINHEIT 29501-082.22 CONTROL UNIT UNITA DE COMANDE UNITA DI COMANDO UNIDAD DE MANDO 201295 FEUR CUC 6310 T 70-740 TEXT DRUCK: 29304-702.94 GRUNDIG Service...
  • Page 5: Chassisplatte

    CUC 6310 Chassisplatte / Chassis Board CUC 6310 Chassisplatte / Chassis Board Chassisplatte / Chassis Board +5V/D +B´ +B´´ B´ B´ +F´ Bestückungsseite, Ansicht von oben L´ Component side, top view 30 29 GRUNDIG Service GRUNDIG Service...
  • Page 6 Chassisplatte / Chassis Board CUC 6310 CUC 6310 Chassisplatte / Chassis Board Lötseite, Ansicht von unten Chassisplatte / Chassis Board 30 29 L´ Solder side, bottom view +F´ B´ +B´´ +B´ +5V/D GRUNDIG Service GRUNDIG Service...
  • Page 7: Gesamtschaltplan

    CUC 6310 Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 6310 Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams Gesamtschaltplan / General Circuit Diagram GRUNDIG Service GRUNDIG Service...
  • Page 8 CUC 6310 Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 6310 Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams ca 26V Spannungsangaben Voltage Levels 152V +B'' 200V ca. 26V 16,5V GRUNDIG Service GRUNDIG Service...
  • Page 9: Chassis Board

    Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams CUC 6310 Chassisplatte / Chassis Board 500mV/cm, 2µs/cm 2V/cm, 2µs/cm 200mV/cm, 2µs/cm 100V/cm, 2µs/cm 500mV/cm, 20µs/cm 100V/cm, 2µs/cm 2,3V 3,5V 4,6V 100mV/cm, 20µs/cm 1V/cm, 20µs/cm 200mV/cm, 20µs/cm 2,2V 1V/cm, 20µs/cm 100mV/cm, 1µs/cm...
  • Page 10 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams CUC 6310 1V/cm, 20µs/cm 1V/cm, 20µs/cm 1V/cm, 20µs/cm 1V/cm, 20µs/cm 1V/cm, 20µs/cm 1V/cm, 5ms/cm 5V/cm, 5ms/cm 5V/cm, 5ms/cm 1V/cm, 5ms/cm 10V/cm, 5ms/cm 5V/cm, 5ms/cm 500mV/cm, 10µs/cm 5V/cm, 10µs/cm 500V/cm, 10µs/cm 5V/cm, 10µs/cm...
  • Page 11 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams CUC 6310 5V/cm, 10µs/cm 50V/cm, 10µs/cm 50V/cm, 10µs/cm 50V/cm, 10µs/cm 5V/cm, 10µs/cm 20V/cm, 10µs/cm 10V/cm, 10µs/cm 38A 50V/cm, 10µs/cm 50V/cm, 5ms/cm 500mV/cm, 10µs/cm 200mV/cm, 10µs/cm 2V/cm, 500µs/cm ohne VT-Einblendung without VT display 1V/cm, 10µs/cm...
  • Page 12 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams CUC 6310 2V/cm, 500µs/cm 1V/cm, 20µs/cm 1V/cm, 20µs/cm ohne VT-Einblendung bei VT-Betrieb bei Menü-Einblendung without VT display on VT operation on Menü display 2V/cm, 20µs/cm 2V/cm, 20µs/cm 2V/cm, 20µs/cm bei VT-Betrieb...
  • Page 14 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams CUC 6310 C793 R722 2 9 3 0 4 - 7 2 2 . 4 1 / 4 B ( 0 9 ) T721 R793A R721 C786 R793 R7XX R778...
  • Page 15: Spare Parts Lists

    INSTRUCTION MANUAL .64 72010-013.81 SERVICE MANUAL SERVICE MANUAL 72010-013.80 SERVICE MANUAL SERVICE MANUAL 29701-084.03 COLOR-EINBAUCHASSIS .01 COLOR TV CHASSIS .01 CUC 6310 CUC 6310 KEIN E-TEIL NO SPARE PART 29701-084.07 COLOR-EINBAUCHASSIS .02 COLOR TV CHASSIS .02 CUC 6310 CUC 6310 KEIN E-TEIL NO SPARE PART 29701-084.08...
  • Page 16 Service Manual "Sicherheit", valid as provided by the "Safety" Service Manual, Sach-Nummer 72010-800.00, sowie zusätzlich part number 72010-800.00, as well as the die eventuell abweichenden, landesspezifischen respective national deviations. Vorschriften! ÄNDERUNGEN VORBEHALTEN SUBJECT TO ALTERATION GRUNDIG Service...
  • Page 17 29701-084.03/.07/.08 Ersatzteilliste / Spare Parts List Ersatzteilliste Spare Parts List 9 / 93 CUC 6310 MONO SACH-NR. / PART NO.: 29701-084.03/.07/.08 POS. ABB. SACHNUMMER ANZ. DESCRIPTION BEZEICHNUNG POS. FIG. PART NUMBER QUA. 0001.000 29504-201.01 CHIP-TUNER/HYPERBAND SMD TUNER/HYPERBAND 0002.000 29303-119.06 PERIBUCHSE SCHWARZ PERI SOCKET BLACK 0004.000...
  • Page 18 ESTR.SK10-A 1,5 KOHM LIN IC 680 8305-205-705 IC MC 78 M 05 CT R 682 8705-329-321 MOW LI 0411 100 KOHM 10% IC 686 8305-205-703 IC MC 7805 CT IC 811 8305-684-655 IC ZC 88655 P ÄNDERUNGEN VORBEHALTEN ALTERATIONS RESERVED GRUNDIG Service...
  • Page 19 TRANS.BC 548 B T 936 8303-201-548 TRANS.BC 548 T 961 8303-201-558 TRANS.BC 558 T 962 8303-201-548 TRANS.BC 548 TR 526 29201-029.51 DIODEN-SPLIT TRAFO KPL TR 563 09246-863.04 TREIBERTRAFO TR 651 29201-455.02 SPERRWANDLERTRAFO KPL 29201-502.97 SPERRWANDLERTRAFO KPL ÄNDERUNGEN VORBEHALTEN ALTERATIONS RESERVED GRUNDIG Service...
  • Page 20: Subject To Alteration
