- Page 1 All instructions must be handed to user for safekeeping Revision A - 06/09 Country(s) of destination - GB/IE eko 2040 fuel effect gas fire...
- Page 2 INSTALLATION INSTRUCTIONS Eko 2040 Preliminary Notes Before Installation This appliance is an Inset Decorative Fuel Effect appliance which provides radi- ant warmth utilising the latest type burner technology. The fire is designed to fit into a purpose made builder’s opening, and use natu- ral draught flues as listed in the Installation Requirements.
-
Page 3: Table Of Contents
Section Page No. Contents Section Contents Page No. Important Notes 10.0 Operating the fire Appliance Data 10.1 Spark Failure Installation Requirements 10.2 Setting Pressure Site Requirements 10.3 Flue Spillage Monitoring System Ventilation 10.4 Testing for Spillage Unpacking the Appliance 10.5 Briefing the Customer Component Checklist 11.0... -
Page 4: Appliance Data
APPLIANCE DATA Gas Group G20 Natural Gas CAT I2H Inlet Pressure 20 mbar (+/- 2.0mbar) Max Energy Input (gross) 5.5 kW Min Energy Input (gross) 3.5 kW Pilot Energy Input (gross) 166 W Setting Pressure (cold) 12.2 mbar (+/- 1.5mbar) Main Injector Burner Stereo size 77 Gas Inlet Connection... -
Page 5: Site Requirements
INSTALLATION REQUIREMENTS (continued) The flue must be connected to only one fireplace, and the flue must not vent more than one appliance (i.e. not shared with a gas back boiler). There must be no opening in the flue apart from the one that the appli- ance is installed into, and the one venting the gases into the air. -
Page 6: Ventilation
SITE REQUIREMENTS (continued) A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. A non-combustible shelf may be fitted to within 10mm of the top edge of the fireplace opening. Maximum depth of shelf Minimum distance from finished hearth surface to underside of shelf... -
Page 7: Component Checklist
COMPONENT CHECKLIST QUANTITY DESCRIPTION Burner tray assembly. Stone effect body. Bag of granular burner medium. Individually packaged ceramic pebbles. Set of manufacturers instructions. Screw and rawlplug pack. Fitting template. INSTALLATION OF APPLIANCE Notes: Ensure that the gas supply is isolated before commencing installation of the appliance. Check that the thermocouple connection nut into the rear of the valve is secure. -
Page 8: Operating The Fire
10.0 OPERATING THE FIRE The pilot is visible at the rear of the fuel bed. The control knob is located on the right hand side of the appliance. Push in and turn the control knob to the SPARK position, and hold there for a few seconds. -
Page 9: Flue Spillage Monitoring System
10.3 FLUE SPILLAGE MONITORING SYSTEM This fire is fitted with a flue spillage safety device (ODS). If the fire shuts down during use for no apparent reason then several things may be suspected. If a door or window has been opened creating a draught, then pilot disturbance is the problem, and removal of the draught should resolve this. -
Page 10: Servicing
11.0 SERVICING Ensure that the fire is fully cold before attempting service. A suggested procedure for servicing is detailed below. 1. Lay out the dust sheet and tools. 2. Inspect the area around the top of the fireplace opening for signs of spillage. 3. -
Page 11: Troubleshooting Guide
12.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipework blockage, clean out. Air not fully purged, repurge supply or wait longer. Spark earthing to metal work, reset gap correctly. Check for spilled granular burner medium in pilot well. Blocked pilot, clean out internally. - Page 12 USER INSTRUCTIONS Section Contents Page No. Important Notes Clearances to Combustibles Ventilation Fuel bed layout Operating Instructions Servicing Flue Spillage Monitoring System Cleaning List of Spares IMPORTANT NOTES The installation of this fire MUST only be carried out by a competent person in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’...
-
Page 13: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. Maximum depth of shelf Minimum distance from finished hearth surface to underside of shelf 100mm (4in) 745mm (29 1/4 in) 150mm (6in) 845mm (33 1/4 in) -
Page 14: Fuel Bed Layout
FUEL BED LAYOUT (continued) 3. Next, place the pebbles marked ‘D’, ‘E’ and ‘F’ as shown. The letters are on the bottom of the pebbles and should face downwards. 3. Next, place the pebbles marked ‘G’ and ‘H’ as shown. The letters are on the bottom of the pebbles and should face down- wards. -
Page 15: Servicing
OPERATING THE FIRE The pilot is visible at the rear of the fuel bed. The control knob is located on the right hand side of the appliance. Push in and turn the control knob to the SPARK position, and hold there for a few seconds.
