WALL MOUNTED OR FREE-STANDING ELECTRIC FIRE GB IE MODELS COVERED BY THESE INSTRUCTIONS 1120 LED ELECTRIC FIRE Christchurch, Dorset BH23 2BT EF11-36 Tel: 01202 588 638 Fax: 01202 499 639 www.ekofires.co.uk e-mail: sales@ekofires.co.uk MPDEL SHOWN: EKO 1120 LED ELECTRIC FIRE...
I N S TA L L AT I O N & U S E R I N S T R U C T I O N S GB IE Section Contents Page No. Section Contents Page No. Important Notes Installation Wall Mounted Installation Requirements Installation Table Top Appliance Data...
1.0 IMPORTANT NOTES - CONTINUED GB IE • DO NOT cover or obstruct the heater in any way. Overheating will result if it is accidentally covered. • Never immerse the product in water or any other liquids. • DO NOT use the appliance outdoors. •...
5.0 COMPONENT CHECKLIST - CONTINUED GB IE 7.Table Top Base 8. Logs 9. Pebbles Dependent On Model 10. Crystals 11. Remote Control 6.0 SITE REQUIREMENTS It should be noted that the appliance creates warm convected air currents.These currents move heat from the room surroundings to, and up the wall surfaces adjacent to the heater.
8.0 INSTALLATION WALL MOUNTED GB IE CAUTION: DO NOT CONNECT THE APPLIANCE TO THE WARNING ELECTRICAL SUPPLY AT THIS TIME. Focal Point Fires plc. assumes absolutely no responsibility for injuries and damages The wall where the appliance is to be that may occur due to improper installation or handling.
Page 6
8.0 INSTALLATION WALL MOUNTED - CONTINUED GB IE 3. Find the optimal place to mount your wall-mounted Fire. Consider the proper position relative to your room, placement of furniture and windows. 4. Hold the mounting bracket up to the wall to verify the correct location and ensure that the mounting bracket is level. Use a pencil to mark the four mounting holes on the wall at the desired mounting location, using the mounting bracket as a template.
Page 7
8.0 INSTALLATION WALL MOUNTED - CONTINUED GB IE 8. Hang the firebox on the hooks at the bottom of the mounting bracket , and push the top of the firebox into the mounting bracket. As shown. 9. Ask a friend to hold the electric firebox into place and secure it to the mounting bracket by refitting the two small screws which were removed in step 2.
8.0 INSTALLATION WALL MOUNTED - CONTINUED GB IE 12. Lift the glass fascia into place, making sure the 2 hooks on the top back of the glass fascia fit securely into the slots on the top of the firebox. As shown. NOTE: It is recommended that you use two people at this stage to prevent damaging the glass fascia or the firebox.
Page 9
9.0 INSTALLATION TABLE TOP - CONTINUED GB IE Front brace Front brace Heat Deflector Table top support Table top base 3. Fasten the deflector to the front brace with two M4 x 8 mm Screws (1). As shown. 4. Slide the front brace assembly onto the table top support and rest it onto the table top base. As shown. Firebox Table top support Firebox...
9.0 INSTALLATION - TABLE TOP - CONTINUED GB IE 7. Repeat steps 10 and 11 on the installation wall mounted to change the log fuel bed to pebble. 8. Repeat steps 12 on the Wall Mounted configuration to install the glass fascia on the firebox. NOTE : Please use the handle when moving.
Page 11
10.0 OPERATING THE APPLIANCE - CONTINUED GB IE Remote Control The fire is supplied with an IR multifunction remote. Before the remote will operate the plastic insulating sheet needs to be removed. Battery Replacement Battery Requirements: 3V CR2025 1. Locate and remove the battery bracket. 2.The battery has two sides, one with a button feature, and the other is flat.
Page 12
10.0 OPERATING THE APPLIANCE - CONTINUED GB IE Using theTimer Control Button Pressing the timer control button (3) will set the timer. NOTE: If this product experiences exceptionally high temperature, it may automatically stop heating. If this occurs the product should be unplugged or isolated from the main supply for a period of 30 seconds before the power is then re-supplied.
11.0 SAFETY CUTOUT SYSTEM GB IE This product has one non-self-resetting overheat protection device (thermal cut-out) which will activate if the air inlets or outlets are obstructed. For safety reasons the fire will NOT switch on again automatically, the following procedure must be carried out before the fire can be operated.
14.0 TROUBLESHOOTING GUIDE GB IE Fire is not switching on Ensure mains switch is on Replace the fuse in the plug Fire is not emitting any heat The fire is fitted with an energy saving thermostat. If the temperature in the room is higher than the temperature selected on the fire, then the thermostat will stop the heater from turning on.
