Burley Surefire FCC 16 User, Installation & Servicing Instructions

Inset coal effect

Advertisement

Quick Links

SUREFIRE
Fuel Effect Options:
Coal Effect
Control Options:
Slide Control with Convection Fan
Model No: FCC 16 Inset Coal Effect
For use on Natural Gas only (G20) at a supply pressure of 20mbar GB and IE
Users, Installation &
Servicing Instructions
MUST BE LEFT WITH THE USER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Surefire FCC 16 and is the answer not in the manual?

Questions and answers

Summary of Contents for Burley Surefire FCC 16

  • Page 1 SUREFIRE Fuel Effect Options: Coal Effect Control Options: Slide Control with Convection Fan Model No: FCC 16 Inset Coal Effect For use on Natural Gas only (G20) at a supply pressure of 20mbar GB and IE Users, Installation & Servicing Instructions MUST BE LEFT WITH THE USER...
  • Page 2 Any claims under this warranty must be made through the retailer from whom the product was purchased. As the purchaser’s contract of sale is with the retailer, Burley Magiglo are unable to enter into discussions with the purchaser until the retailer has inspected any claim and deemed it to be valid.
  • Page 3: Table Of Contents

    Contents 1. I ....................2 NNOVATION NOT IMITATION 2. G ...................... 4 ENERAL NFORMATION 2.1. Important Note About ODS Pilot ................5 2.2. Fire Fret Dimensions ....................6 3. U ......................7 NSTRUCTIONS 3.1. Lighting Procedure ....................7 3.2. Electric Fan ......................7 3.3.
  • Page 4: Innovation Not Imitation

    To ensure you get the most from your fire and to understand its operation, please read the information below. It has taken Burley Magiglo nearly four years to develop the numerous unique features used in this fire, the technology is so advanced that this fire is the subject of five pending patents, so it is not the same as fires you may have previously owned.
  • Page 5 The fan is powered by a small adapter (provided) which plugs into a conventional wall socket. The adapter has a variable output from 3 to 12 watts so you can select your preferred speed. On the higher settings there will inevitably be a little noise from the fan, so if you are sitting reading you may wish to choose one of the lower speeds.
  • Page 6: General Information

    Only approved imitation fuel, available from Burley Magiglo., should be used with this appliance. 3. It is recommended that a fire guard complying with BS 8423 be fitted for the protection of young children, the elderly or infirm.
  • Page 7: Important Note About Ods Pilot

    Under no circumstances should it be adjusted or put out of action by the installer or the user. If the pilot needs replacing, only the approved part (available from your supplier or Burley Magiglo.) should be fitted. Note: if any part of the pilot assembly becomes faulty the complete assembly will need replacing.
  • Page 8: Fire Fret Dimensions

    2.2. Fire Fret Dimensions All models can be used with the Burley Magiglo range of frets or any other fire frets that falls within the dimensions shown below Minimum opening (free air) in fire fret Minimum opening (free air) in ash pan cover...
  • Page 9: User Instructions

    3. U NSTRUCTIONS 3.1. Lighting Procedure The pilot can be viewed by looking downwards over the front ceramic between the first and second coals from the right hand side. Press the control lever firmly down to the bottom of its travel and listen for the spark generator clicking which should light the pilot.
  • Page 10: Hot Surfaces

    3.4. Hot Surfaces Certain parts of this appliance get very hot during normal use. It is therefore recommended that a suitable fireguard (to BS8428:2010) be used for the protection of young children and the infirm. The shaded parts in the illustration below show the ‘Working Surfaces’ on the appliance.
  • Page 11: Coal Effect Layout

    3.5.1. Coal Effect Layout The fire is supplied with a set of ceramic fuel bed components as follows: A three piece set of: lining boards, one left hand side, one right hand side and a rear board. One Moulded Front Ceramic, Moulded Rear Ceramic, Moulded Coal Matrix, Coal with round peg and one Coal with square peg.
  • Page 12: Fitting The Trim

    3.7. Fitting the Trim 1. Fix the infill frame onto the front of the appliance using the four screws provided 2. Most trims are coated with a protective film. This must be removed by peeling off before fitting the trim. 3.
  • Page 13: Cleaning And Care Instructions

    3.9. Cleaning and Care Instructions CAUTION: Ensure that the appliance is off (including the pilot light) and has completely cooled (off for at least 2 hours) before carrying out any cleaning or maintenance. RCF Advice: This product may use Components Coals, containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.
  • Page 14: Painted Metal Surfaces

    The very high temperatures produced within the appliance will cause the paint to bubble and/or burn off rendering the fireback looking unsightly. Minor surface scuffs may be treated using a water based touch up stain available at Burley Magiglo fire retailers.
  • Page 15: Nstallation Nstructions

    It is important for correct combustion of this fire that the imitation fuel is placed in accordance with the instructions given in this and associated booklets. Only approved imitation fuel, available from Burley Magiglo, should be used with this appliance. Combustible shelves or materials must only be fitted above the fire in accordance with the instructions given in this and associated booklets.
  • Page 16: Flue Requirements

    4.2. Flue Requirements This appliance may be installed in fireplaces served by the following types of flue; Class 1 Masonry Flue - A flue having no cross sectional dimension less than 175mm (7”) e.g. 225mm (9”) by 225mm (9”) Masonry chimney or 175mm (7”) diameter clay liner. Due to the high efficiency of this appliance consideration should be given to lining any unlined masonry flue with a flexible flue liner to prevent problems with condensation.
  • Page 17: General Dimensions

    4.3. General Dimensions Page 15...
  • Page 18: Technical Data

    4.4. Technical Data Natural Gas Nominal maximum heat input 2.5kW (gross) Minimum heat Input 1.5 kW (gross) Inlet Pressure 20 mbar ±1mbar I2H (Natural Gas) Injector Type No.180 Gas inlet connection Control valve Teddington TESA 3173/0014/A Pilot Seagas P441 4.5. Mantels &...
  • Page 19: Floor Level And Raised Fireplace Openings

    4.6.1. Floor Level and Raised Fireplace Openings Floor Level Openings 560mm 405mm 235mm (min) Raised Installation HD + HF Height of Hearth from Floor = at least 225mm Table 1 50mm Figure 3 50mm Figure 4 Hearth Construction: The hearth material must be non-combustible and a minimum of 12mm thick, when laid on the floor.
  • Page 20: Ventilation

    4.7. Ventilation For this model additional ventilation is not normally required in the room that the fire is fitted. However, if spillage is detected during spillage test additional ventilation may be required. In GB reference should be made to BS 5871:Part 2, and in IE, reference should be made to the current edition of I.S.813 which makes clear the conditions that must be met to demonstrate that sufficient ventilation is available.
  • Page 21: Installation Procedure

    General Information on Pages 2 and 5. The Burley Magiglo FCC 16 is designed to be inset into a 16” fireplace opening. Any surround that is to be installed with this appliance must be rated at 150oC.
  • Page 22 Page 20...
  • Page 23: Connecting The Gas Supply

    4.9.3. Connecting the Gas Supply The gas supply to the fire must be carried out using rigid or semi-rigid metal tubing. A service cock must be incorporated near the appliance to facilitate isolation of the fire during servicing. An isolating valve (with a pressure test point) has been supplied with this fire. The gas supply must be fed into the firebox through the aperture on the left hand side.
  • Page 24: Fitting The Glass Panel

    Place the moulded coal matrix on top of the base ceramic so that the front rests on the front ceramic. Push it back so that it touches the rear lining board. Place the two pegged coals in position. 4.9.6. Fitting the glass panel Refit the glass panel by seating it centrally behind the lower clamp and securing by fixing the upper clamp in position with the four screws previously removed.
  • Page 25: Commissioning

    4.9.7. Commissioning 1. Turn on the gas supply to the fire and c) Restriction at the appliance isolation purge the gas line. Check all the gas valve. joints for gas soundness. 6. Turn the fire off and replace the pressure 2.
  • Page 26: Adjusting The Flue Exit Restrictor And Checking For Spillage

    4.9.8. Adjusting the Flue Exit Restrictor and Checking for Spillage from the upper hole to the lower hole in its bracket. Before screwing the limit screw home push the thermostat arm down so that it is under the limit screw’s new position.
  • Page 27: Servicing Instructions

    5. S ERVICING NSTRUCTIONS 5.1. General Requirements All repairs and servicing must be carried out by a qualified registered gas installer (e.g. member of Gas Safe in GB) in accordance with the current Gas Safety (Installation and Use) Regulations and these instructions. Before any servicing is carried out ensure that the gas and electrical supply / transformer is unplugged.
  • Page 28: Replacing Parts

    5.3. Replacing Parts For any spare parts that are required, please contact either your supplier or the manufacturer directly. You will either need the serial number or: a) model name; b) the gas type; c) the imitation fuel type; d) the type of control. Only approved parts should be used.
  • Page 29: Installation & Operational Troubleshooting

    5.5. Installation & Operational Troubleshooting The table below is intended for problems related to the fire and its gas controls. It is a guide only and does not take into account every eventuality. Servicing must be carried out in accordance with the current Gas Safety (Installation and Use) Regulations, by a competent person.
  • Page 30: Parts List

    Warning: If you are in any doubt about the clearance of fumes, you must stop using the appliance immediately and seek expert advice. Do not use appliance until the fault has been rectified. Installation & Operational Troubleshooting – cont. NOTE: If any part of the pilot assembly (i.e. thermocouple, electrode, jet or burner) becomes faulty the whole pilot assembly will need changing.
  • Page 31: Customer & Installation Notes

    5.6. Customer & Installation Notes Date of Installation: Gas Safe Installer Name & contact details Serviced Date Notes: Page 29...
  • Page 32 Magiglo fires are protected by UK patents 2193802, 2240620 and 2256920 Other Patents Pending Magiglo is a registered trademark of Burley Appliances Ltd. 0558 Burley Magiglo, Lands End Way, Oakham; Rutland,LE15 6RB Tel: 01572 725570 Fax: 01572 724390 www.magiglo.co.uk Email: info@magiglo.co.uk...
