Operating & Installation
Instructions
570-R & 590-R Series
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICEABLE PARTS INSIDE
Burley Appliances Limited
Lands End Way, Oakham, Rutland, LE15 6RB, U.K.
Telephone +44 (0)1572 756956. Fax +44 (0)1572 724390.
E-mail info@burley.co.uk
Web www.burley.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 570-R Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Burley 570-R Series

  • Page 1 Instructions 570-R & 590-R Series CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN NO USER-SERVICEABLE PARTS INSIDE Burley Appliances Limited Lands End Way, Oakham, Rutland, LE15 6RB, U.K. Telephone +44 (0)1572 756956. Fax +44 (0)1572 724390. E-mail info@burley.co.uk Web www.burley.co.uk...
  • Page 2: Important Safety Instructions

    INSTRUCTIONS Thank you very much for purchasing a Burley electric fire. Please spend a couple of minutes reading these instructions before using the appliance, they are to ensure your safety and convenience. IMPORTANT SAFETY INSTRUCTIONS 1. To disconnect heater, turn controls to off, then remove plug from outlet.
  • Page 3: Tools Required

    TOOLS REQUIRED PRODUCT TESTING & APPROVALS This product range has been independantly tested and meets the requirements of the Low Voltage Directive. In addition to the safety testing the product has been tested and passed the EMC requirements. The product has been tested by TUV—SUD in the UK, to EN60335-2-30:2009 in conjunction with EN60335-1:2002+15:2001 product safety standards.
  • Page 4: Product Contents

    PRODUCT CONTENTS X6 570 EURO X4 X4 590 X6 X1 WALL BRACKET X1 Trim for 570 or 590 X1 Fire 570 or 590...
  • Page 5: Installation Information

    INSTALLATION INFORMATION Both the 570 & 590 series fires can be either inset into a cavity or mounted directly onto a flat Wall. CHASSIS DIMENSIONS H - mm MODEL CAVITY OPENING MODEL H - mm ELECTRICAL CONNECTION UNDERNEATH D - mm Note : The sizes allow for clearance at the sides of the fire of 15mm,clearance at the top of 20mm and 5mm at the back.
  • Page 6 WALL CAVITY INSTALLATION INSTRUCTIONS Refer to P.3 for cavity sizes X4 - 570 X6 - 590 X4 - 570 X6 - 590 WALL FIXINGS For plasterboard and cavity wall type construction additional fixings will be required. Nylon wall plugs supplied suitable for masonry and aerated concrete only.
  • Page 7 X4 - 570 X6 - 590...
  • Page 8 Locate trim fixings into the four key hole slots and push down the trim to secure. Note : The trim can be adjusted if required to give a tighter fit on the key hole slots. 1. Ensure the nut is finger tight. 2.
  • Page 9 SURFACE WALL MOUNTED INSTALLATION INSTRUCTIONS X 4 MIN - 570 X 6 MIN - 590...
  • Page 10 X 4 MIN - 570 X 6 MIN - 590...
  • Page 11 X 2 POSITIONS LOCKING SCREWS...
  • Page 12 Remove the four nuts and spacers from the rear of the trim Locate the trim onto the four slots. Fit the four plastic spacers and then nuts to secure the trim. Finger tight is sufficient. Installation Complete. Refer to P.11 for user instructions...
  • Page 13 USER INSTRUCTIONS P.13 THERMOSTAT P12. & 13. Place the optional white chippings onto the glass fuelbed if desired.
  • Page 14: Remote Control Handset

    REMOTE CONTROL HANDSET Batteries - 2 x AAA INFRARED TRANSMITTER RED LED LIGHT CONTROL BUTTON REMOTE CONTROL OPERATION PRESS CONTROL BUTTON ONCE FOR THE FLAME EFFECT. PRESS A FURTHER TWO TIMES FOR THE FLAME EFFECT AND HEATER. PRESS ONCE MORE TO TURN OFF THE FLAME EFFECT AND HEATER.
  • Page 15: Thermostat Operation

    3 METRES MAXIMUM 120º Remote Control a. The fire can only be operated by remote control. b. Be vigilant and keep the handset out of reach of children or other potential risks. c. Due to the location of the infrared sensor, the remote control works best from a position predomi- nantly in front of the appliance.
  • Page 16: Troubleshooting Guide

    REPLACE 13A FUSE WITH SAME TYPE TROUBLE SHOOTING GUIDE The following instructions should solve any questions or problems which you may have. To find the cause of an operational fault, plug the fire into the wall socket, turn on the on/off switch and turn the thermostat up to maximum. Symptoms.
