LG 29FS2ALX Service Manual page 29

Hide thumbs

Advertisement

Table of Contents
LOCA. NO
PART NO
R902
0RD2200F609
RD-96T1J220R 220OHM 5% 1/6W 3.2X1.8MM
R903
0RD2200F609
RD-96T1J220R 220OHM 5% 1/6W 3.2X1.8MM
R906
0RD1201A609
RDM92T1J1K20 1.2KOHM 5% 1/2W 6.5X2.3MM
R907
0RD1201A609
RDM92T1J1K20 1.2KOHM 5% 1/2W 6.5X2.3MM
R908
0RD1201A609
RDM92T1J1K20 1.2KOHM 5% 1/2W 6.5X2.3MM
R909
0RS2201H609
RSD92T1J2K20 2.2KOHM 5% 1/2W 6.5X2.3MM
R910
0RS2201H609
RSD92T1J2K20 2.2KOHM 5% 1/2W 6.5X2.3MM
R911
0RS2201H609
RSD92T1J2K20 2.2KOHM 5% 1/2W 6.5X2.3MM
R912
0RD2204A609
RDM92T1J2M20 2.2MOHM 5% 1/2W 6.5X2.3MM
R920
0RD4703A609
RDM92T1J470K 470KOHM 5% 1/2W 6.5X2.3MM
R925
0RD2200F609
RD-96T1J220R 220OHM 5% 1/6W 3.2X1.8MM
SW1101
140-315A
THVH472GBC 1C1P 12VDC 0.05A VERTICAL
SW1102
140-315A
THVH472GBC 1C1P 12VDC 0.05A VERTICAL
SW1103
140-315A
THVH472GBC 1C1P 12VDC 0.05A VERTICAL
SW1104
140-315A
THVH472GBC 1C1P 12VDC 0.05A VERTICAL
SW1105
140-315A
THVH472GBC 1C1P 12VDC 0.05A VERTICAL
SW1106
140-315A
THVH472GBC 1C1P 12VDC 0.05A VERTICAL
SW1111
6600VM2002A
SDKEA3012A AC 250VAC 8A 1PCS 2C1P
SPARK GAP, AXIAL
SG201
6918VAX002E
WSP-351M AXIAL 350V 350V - 7.5MM TP
SG901
165-004A
152F-L3N/S-23 RADIAL 1.5KV 1.5KV - 5MM BK
SG902
165-004A
152F-L3N/S-23 RADIAL 1.5KV 1.5KV - 5MM BK
SG903
165-004A
152F-L3N/S-23 RADIAL 1.5KV 1.5KV - 5MM BK
SG904
6918VAX002H
WSP-122N AXIAL 1.2KV 1.2KV - - TP
SG911
6918VAX002E
WSP-351M AXIAL 350V 350V - 7.5MM TP
SG912
6918VAX002E
WSP-351M AXIAL 350V 350V - 7.5MM TP
SG913
6918VAX002E
WSP-351M AXIAL 350V 350V - 7.5MM TP
FILTER & CRYSTAL
FB401
125-022K
125-022K 20OHM 3.5X6MM AXIAL TP
FB802
125-022K
125-022K 20OHM 3.5X6MM AXIAL TP
FB803
125-022K
125-022K 20OHM 3.5X6MM AXIAL TP
FB833
125-022K
125-022K 20OHM 3.5X6MM AXIAL TP
FB844
125-022K
125-022K 20OHM 3.5X6MM AXIAL TP
FB845
125-022K
125-022K 20OHM 3.5X6MM AXIAL TP
FB846
125-022K
125-022K 20OHM 3.5X6MM AXIAL TP
T1111
6200JB8012T
6200JB8012T 10MH 31X31X25MM SQE2828S
T803
150-F06T
150-F06T 20MH 38X26X43MM SQE3535
X01
156-A01Z
HC-49/U 24.576MHZ 50PPM 24.576MHZ 50PPM
Z101
166-A01B
K3953M 33.90MHZ 38.90MHZ 17X3.9X8.7MM
Z102
6200QL3003G
K9650M(B39389-K9650-M100) 33.90_38.90MHZ
JK1203
6613V00004Q
PJ6054Q 14.0MM 3RX1C ANGLE TR
JK201
6612M00005A
UPJ-R1-027 21P 21P/1C 3.81MM ANGLE
JK202
6613V00025A
PSC002-01 24P SCART/RCA 14MM
MISCELLANEOUS
F1111
0FS5001B51D
Fuse,Time Delay, 0218 005. GLASS 250V 5A
DESCRIPTION
SWITCH
JACK
For Capacitor & Resistors,
the characters at 2nd and 3rd
digit in the P/No. means as
follows;
LOCA. NO
PART NO
LD1101
0DD000000BA
PA1101
6712R1538GH
R855
6322TA080AB
SK901
6620VBC003A
SW
SAA30042202
TH301
6322A90004A
TH801
163-058D
TU101
6700MF0018A
VD1111
164-003G
B1
3890900097C
B2
3890V00067F
B3
3890900100B
B4
3890900096C
B5
3890V01828B
B6
MAY30423501
3890900172U
A1
38289U0479L
38289U0479M
38289U0479N
38289U0479Q
38289U0479V
38289U0579L
MFL32905222
MFL32370210
A2
MKJ30036802
6710V00124V
A3
450-018C
? W & @ @ @ @ ) X ? g
W 2 @ @ 6 X h
? O 2 @ 6 K h
@ ( M ? I ' @ ? g
? 7 ( M ? I ' @ 1 ? g
? J @ H e ? N @ L g
? @ H ? e N @ @ ? g
? 7 @ ? f @ 1 g
? @ f ? @ @ ? g
? @ @ ? g
? @ @ ? f @ @ g
? @ @ ? f @ @ g
@ @ @ @ @ @ @ @ @ @ f
J @ 5 ? g
? 3 @ L e ? J @ @ g
@ @ @ @ @ @ @ @ @ @ f
7 ( Y ? g
? V 4 ) K ? O & @ 5 g
W . Y ? h
? J ( Y h
? I 4 @ @ @ @ H g
? @ @ ? g
? W . Y h e
J @ 5 ? g
W . Y ? e @ ? g
? W & ( Y ? g
? W & Y f @ ? g
W & @ @ @ @ @ @ @ ? g
? O & 0 Y ? h
W & ( Y h
& @ @ @ @ @ @ @ @ ? g
? @ @ 0 M ? h e
CC, CX, CK, CN : Ceramic
CQ : Polyester
CE : Electrolytic
DESCRIPTION
LED,DIP SA5711-B DL-1LO(S)
Receiver Module, TSOP2438 4.5TO5.5V 1.5MA
Thermistor,NTC TP8D15LKBESMNR 8OHM
Socket,CRT PCS030A 8P STRAIGHT 15.24MM
S/W,Firmware 3.14 407C
Thermistor,NTC KC5B130L 300OHM 15% 2.671V
Thermistor,PTC J503P83D070M290X 14OHM 20%
Tuner,Analog TAEA-G011D PAL-B/G+I+M+D/K
Varistor, TVR14621 620V 10% 250pF 14MM
BOX DW2 1080 1124 100 1 COLOR MC049A
BOX SW 0 0 0 1 COLOR PC-63A 29"" SW
Box C/SKD 21"" DWR2 332*484*300"
BOX DW2 1060 1104 1080 1 COLOR MAIN
BOX SWR2 703 372 312 1 COLOR
BOX DW 836 454 642 2 COLOR TDR
BOX DWR2 856 468 680 2 COLOR
ACCESSORIES
Manual, HU/BU/EN 124U/V/W/X TX 051A
Manual, 124U/V/W/X TX 017B
Manual, RO 124U/V/W/X TX
Manual, CZ/SK 124U/V/W/X TX
Manual, BALTIC ES/LV/LT 124V-TX
Manual, USER UKR/BZ03 RU/EN 112 TX
Manual,Owners EN/SE/HU/BU/LV/LT/ES/SK/CZ
Manual,Owners AK/ME28 KA/RU/EN
Remote Controller MOLD HIPS 60HR
Remote Controller, W/O PIP W/ TXT
Connector,RF BS901 - STRAIGHT RF
RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RF : Fusible
