Grayns TORC 1.9 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TORC 1.9 and is the answer not in the manual?

Questions and answers

Related Manuals for Grayns TORC 1.9

Summary of Contents for Grayns TORC 1.9

  • Page 2: About Grayns

    ABOUT GRAYNS™ The GRAYNS™ Rice Cooker is an amazing invention that redefi nes healthy living by cooking rice in the traditional way along with the convenience of smart modern living. Rice cooked in GRAYNS™, undergoes an intelligent 4-stage cooking process that...

  • Page 3: Table Of Contents

    INDEX ABOUT GRAYNS FAMILIARIZING YOURSELF WITH THE GRAYNS RICE COOKER WHAT’S INSIDE YOUR GRAYNS BOX IMPORTANT USER GRAYNS OVERVIEW INFORMATION & CONTROL PANEL - Navigation Trackball DIGITAL CONTROL INTERFACE - Screen Display INSTRUCTION PREPARING YOUR GRAYNS RICE COOKER PREPARATION TO COOK...

  • Page 4: Familiarizing Yourself With The Grayns Rice Cooker

    FAMILIARIZING YOURSELF WITH THE GRAYNS RICE COOKER WHAT’S INSIDE YOUR GRAYNS BOX Strainer Basket Made from stainless steel to hold your rice and let the water drain perfectly Steel ball marble sized stainless steel ball allows the water to drain...
  • Page 5 Power cable connect the cooker to a power source Measuring cup Allows you to measure the amount of cook Scoop Use to fl uff and scoop the rice from the strainer basket Spare Steel ball PAGE 4 GRAYNS™ - INSTRUCTION MANUAL...

  • Page 6: Grayns Overview

    FAMILIARIZING YOURSELF WITH THE GRAYNS RICE COOKER GRAYNS OVERVIEW Steam vent Steam cover Lid slot Holder Screen display Navigation trackball Collector cap Starch collector Exhaust Infomation label air outlet Ventilation Power in Wire slot GRAYNS™ - INSTRUCTION MANUAL PAGE 5...

  • Page 7: Control Panel - Navigation Trackball

    FAMILIARIZING YOURSELF WITH THE GRAYNS RICE COOKER CONTROL PANEL - Navigation Trackball Navigation Trackball How to Operate Scroll up / down - Move option / next / previous Single click - To confi rm / select / ok / yes / no Press &...

  • Page 8: Digital Control Interface- Screen Display

    FAMILIARIZING YOURSELF WITH THE GRAYNS RICE COOKER DIGITAL CONTROL INTERFACE- Screen Display WELCOME SCREEN Screen Display MAIN MENU Selection bar Features option & number Command Current cooking setting / next setting TIMING SELECTION Command option Time Option ‘HOUR’ Time Option ‘MINUTE’...
  • Page 9 COOKING SETTING Setting Option Selection Bar Description Setting option Command Current setting by number Current setting bar COOKING PROGRESS Current Features Current Process Progress Timing Progress Percentage Progress Bar ERROR SCREEN PAGE 8 GRAYNS™ - INSTRUCTION MANUAL...

  • Page 10: Preparing Your Grayns Rice Cooker

    PREPARING YOUR GRAYNS RICE COOKER Please ensure the Steel Ball and the Inner Container is in the right position and fi rmly placed to avoid any leakage or failure to perform. Place Cap (5) and Collector (6), Strainer Basket (1), Inner Container (3) and Steel Ball (2) into the cooker in the right position.

  • Page 11: Preparation To Cook

    PREPARING YOUR GRAYNS RICE COOKER PREPARATION TO COOK Take the strainer basket & collector out of the rice cooker. Take out the collector tray, and put the strainer basket into the collector. Refer to the cooking instruction for the ideal ratio to get a satisfactory...
  • Page 12 Please refer to become relatively clear. the marking on the strainer basket. Refer to the cooking instruction on the next page (14) for the ideal ratio to get a satisfactory cooking results. GRAYNS™ - INSTRUCTION MANUAL PAGE 11...

  • Page 13: Making Grayns Rice

    PREPARING YOUR GRAYNS RICE COOKER MAKING GRAYNS RICE Maximum water level Water = Maximum Rice Approx 1.9L @9 cups 3 cups 2 cups 1 cup MAXIMUM *use 180ml (6 oz) measuring cup To facilitate the release of starch from the rice, fi ll the container with water up to the mark indicated regardless of the amount of rice you used.
  • Page 14 Close the Lid properly Make sure the steam cover is in place especially after washing. Press the top to ensure that it is properly closed to avoid any spillover steam. GRAYNS™ - INSTRUCTION MANUAL PAGE 13...
  • Page 15 Plug in to the wall socket cooker in vertical position and turn it on. Wait until the welcome menu appears. Please proceed menu selection. Check the screen for any ERROR! if there is a message follow the instruction indicated. PAGE 14 GRAYNS™ - INSTRUCTION MANUAL...

  • Page 16: How To Cook Grayns Rice

    HOW TO COOK GRAYNS RICE - Select Type of Rice (DEFAULT) The default settings is set for most kind of rice; Long grain, medium grain and short grain Scroll down - fi nd menu Click! - select customize Click! - select default Scroll down - make a selection Click! - confi...
  • Page 17 HOW TO COOK GRAYNS RICE - Cooking (DEFAULT) current setting Click! - confi rm menu - continue cooking Make sure the setting is correct & continue cooking. The setting is save as your default setting PAGE 16 GRAYNS™ - INSTRUCTION MANUAL...
  • Page 18 HOW TO COOK GRAYNS RICE - Customize Your Rice Customize the settings according to your preference and taste. At default the setting is 0.5 for both softness and moisture. For softness the higher the number the softer is the rice. Conversely the lower the Click! - select customize number the harder the rice.

  • Page 19: Cooking (Default)

    HOW TO COOK GRAYNS RICE - Customize Your Rice Once the setting is done, it will be saved as your default. The following cooking process will remain your own setting with just a click of the Scroll down - make a selection button.
  • Page 20 HOW TO COOK GRAYNS RICE - Cooking (CUSTOMIZE) current setting Click! - confi rm menu - continue cooking Make sure the setting is correct. The setting is saved as your default setting GRAYNS™ - INSTRUCTION MANUAL PAGE 19...
  • Page 21 HOW TO COOK GRAYNS RICE - Cooking Process Please wait until the cooking process is ‘completed’ or the lights indicator on the trackball turns to green. Press the trackball to return Wait..to main menu. Then switch off the power.

  • Page 22: How To Soak

    HOW TO SOAK Rince the rice, repeat the same method of PREPARING YOUR GRAYNS RICE COOKER in page 10. Make sure the rice does not exceed the maximum level. Put the rice and strainer basket into the rice cooker, then add the exact amount of water.
  • Page 23 HOW TO SOAK You can use the SOAK function with GRAYNS rice cooker. Set the time in hours or minutes as you require. Scroll down - make a selection Click! - select soak Scroll up/down - increase/reduce the time setting (hour) Click! - confi...
  • Page 24 Soak & Cook Wait..If you wish to soak & cook please continue the process as shown in page 24. Done! Press - to return Return to the main menu GRAYNS™ - INSTRUCTION MANUAL PAGE 23...

  • Page 25: How To Soak & Cook

    Click! - confi rm setting - proceed to minute Scroll up/down - increase/reduce the time setting (minute) Click! - confi rm setting Click! - confi rm setting - select start * select back to return for time setting PAGE 24 GRAYNS™ - INSTRUCTION MANUAL...
  • Page 26 Press the trackball to return to main menu. Wait..The heat on the trackball is normal due to the heat transfer from the cooking process. Wait..Wait..Done! Press - to return Return to the main menu GRAYNS™ - INSTRUCTION MANUAL PAGE 25...

  • Page 27: How To Cancel Progress

    Press & Hold the Trackball for a moment to cancel the cooking/ soaking progress. Wait until the screen return to the welcome screen and the main menu. Press & hold Wait..Return to the main menu PAGE 26 GRAYNS™ - INSTRUCTION MANUAL...

  • Page 28: Serving

    Be careful with the hot steam coming out of the steam vent. If you open the lid during the cooking process, the screen will shows error! Please close the lid to resume the process. GRAYNS™ - INSTRUCTION MANUAL PAGE 27...
  • Page 29 Scoop your rice for serving. You may also remove the basket if you wish to scoop all the rice into a container/plate. PAGE 28 GRAYNS™ - INSTRUCTION MANUAL...
  • Page 30 Any impurities and defects may cause malfunction. DO NOT USE ANY ABRASIVE CLEANER OR SCOURING PAD TO CLEAN THE NON- STICK INNER POT. Do not use the inner container if the coating is scratched or peel off GRAYNS™ - INSTRUCTION MANUAL PAGE 29...

  • Page 31: Wet Wipe Only

    Allow to dry completely before re-using. You must keep the heating plate Body and thermocontrol plate free from any foreign objects. Wipe clean - to clear from any strach collected Starch collecting area PAGE 30 GRAYNS™ - INSTRUCTION MANUAL...
  • Page 32 MAINTENANCE - Cleaning The Steam Vent Take out the Steam Cover. Wipe with a dimp cloth the cover and the top of the steam ventilation lid to remove dirt and stratch. Top Lid Steam Vent GRAYNS™ - INSTRUCTION MANUAL PAGE 31...

  • Page 33: Cleaning The Starch Collector

    Take out the Drain Cap and dispose the starch collected. Handle with care, heat content may cause injury. Starch collected in this container is not for consumption. It is to be disposed PAGE 32 GRAYNS™ - INSTRUCTION MANUAL...
