- Page 1 UCHW-H 09, 12, 18, 24 AF2 UCHW-H 09,12, 18, 24 CF2 UCHW-H09AF2 UCHW-H12AF2 UCHW-H18AF2 UCHW-H24AF2 UCHW-H09CF2 UCHW-H12CF2 UCHW-H24CF2...
-
Page 3: Selection Of Installation Positions For Indoor Unit
INSTALLATION & REPAIR GUIDE Split Wall-Mounted Air Conditioner *Selection of installation positions for indoor unit* * To be installed at the position where the air delivered from the unit can reach every corner of the room; * To avoid being affected by the outdoor air; * To avoid blockage to the air inlet or outlet of the unit;... -
Page 4: Selection Of Installation Positions For Outdoor Unit
INSTALLATION & REPAIR GUIDE Split Wall-Mounted air conditioner *Selection of installation positions for outdoor unit* * To install the outdoor unit at the places which can stand the load of the machine weight and will not cause big vibrations and noises; * To install the unit at the places not to be exposed to rain or direct sunshine, and the places with good ventilation;... -
Page 5: Installation Of Indoor Unit
INSTALLATION & REPAIR GUIDE Split Wall-Mounted air conditioner Installation fixture of indoor unit 1.Installation of wall-mounting plate Fix the wall-mounting plate firmly on the wall with screws. Make sure of the leveling of the plate. Slanted wall-mounting plate might jeopardize the smooth discharge of the condensed water. -
Page 6: Installation Fixture Of Outdoor Unit
INSTALLATION & REPAIR GUIDE Split Wall-Mounted air conditioner Inspections: Fig.5 a. Check if the hooks at the top and bottom are firmly fixed. Connecting pipe b. Check if the position of the master unit is Connecting wires Wall pipe properly leveled. c. - Page 7 9,000 BTU /12,000 BTU MODEL 18,000 BTU /24,000 BTU MODEL 9,000 BTU / 12,000 BTU MODEL:...
- Page 8 INSTALLATION & REPAIR GUIDE Split Wall-Mounted air conditioner 18,000 BTU / 24000 BTU Model...
- Page 9 INSTALLATION & REPAIR GUIDE Split Wall-Mounted Air Conditioner Pipelines connection *Ordinary pipelines connection (it is suitable for non-quick coupler) No dust ,foreign articles,air or moisture should be allowed to enter the air conditioning system.Careful attention should be paid when pipeline connection for outdoor unit is made.Try to avoid repeated curves as much as possible,otherwise hardening or cracks might be caused to the copper pipes.Suitable wrenches should be used when the pipeline connection is done so as to ensure appropriate torque(refer to following torque Table 1).Excessive torque might damage the joints while too little torque might...
- Page 10 Air Purging Air purging With Vacuum Pump...
-
Page 13: Test Running
INSTALLATION & REPAIR GUIDE Split Wall-Mounted air conditioner Connection of power cable Fig.7 1.Remove the drawer of the outdoor unit. wire pressing plate 2.Connect the indoor power and control wires with the matched outdoor wires in accordance with the electric schematic diagram and make sure that the connection is firmly done(Fig.7) Drawer screw... -
Page 14: Self Diagnosis Functions
INSTALLATION & REPAIR GUIDE Split Wall-Mounted air conditioner *Choose the place where hot air and operation noise from the outlet of the outdoor unit do not annoy the neighborhood . *Things left near the outlet and inlet of the outdoor unit cause malfunction or increased operation noise .
