THANK YOU Thank you for choosing this innovative Amcor air conditioner. We suggest that you keep this manual in a safe place for future reference. It describes the many benefits and advanced features this unique product has to offer. Before you use your new air conditioner you should carefully read these instructions to maximise this product’s performance.
Do not use your air conditioner when: the power cord is there is a chance there is a risk of it a close to a heat This air conditioner damaged. of liquids falling on interference from source. is not made for DIY the unit.
REMOTE CONTROL LCD display: temperature timer setting timer on/off fan speed louvre setting indication of active mode or selected option Buttons: 1. Temperature setting 2. ON/OFF 3. Swing 4. Air flow 5. Sleep 6. Mode 7. Fan speed 8. Timer 9.
OPERATION General • Turn the unit on with the [2]. The last used operating mode is OFF BUTTON selected. • The turns the appliance off; the operating mode active at this OFF BUTTON moment is stored in memory and will be used when the air conditioner is switched back on again.
Page 6
Fan mode 1. Press the [6] until the symbol appears next to MODE BUTTON 2. Use the [7] to set the fan speed. FAN SPEED BUTTON 3. Use the [3] and the [4] to adjust the air flow direction. SWING BUTTON AIR FLOW BUTTON Sleep button Press the...
Page 7
Press the [10] to lock or to unlock the keys of the remote control. The HOLD BUTTON symbol on the right hand side of the display next to indicates locked keys. HOLD Left/right air flow direction Method 1: Manually adjust Turn the air conditioner off.
Page 8
Emergency start In the event of a problem, or when the remote control is missing, the air conditioner can be operated using the emergency button under the panel in the indoor unit. Open the front panel and press the button to switch on (in the mode last set) or to switch off. FILTERS Turn the air conditioner off and remove the plug from the mains outlet.
Page 9
CLEANING Turn the air conditioner off and remove the plug from the mains outlet. Indoor unit Dust regularly with a dry cloth or slightly damp paper towel. Never use chemicals or solvents. Never spray a liquid in or over the appliance. Outdoor unit Remove dirt and keep the air intake and exhaust openings free of leaves, etc.
Page 10
INSTALLATION GUIDE In case of a non quick coupling unit, make sure to have the professional after-sales service person or authorized dealer to install the units. • The units may not be installed in places where there might be leakage of combustible gases: fire hazard.
SAFETY ASPECTS Check the network voltage. Make sure that the existing network voltage corresponds to the value specified on the type tag on the appliance. Keep the work area tidy. Carelessness in the work area can lead to accidents. Use the right tools. Do not use tools that are not sturdy enough for heavy work.
Page 12
SAFETY Read the section on safety aspects and these instructions before you start. Stick to the work sequence and working method shown here. For technical or commercial reasons, the manufacturer may make changes to the appliance or component parts, without general notification. You can consult your supplier about this.
Page 13
Ceiling At least 10 cm For operational convenience and At least At least 15 cm for safety, ensure there is enough 15 cm space between the unit and walls, windows and ceiling. At least 230 cm Wall-mounting plate Floor Pipe lines can be connected in the directions 1, 2, 3, 4 or 5 as indicated in Figure 3.
Page 14
Inspections: • See if the hooks at the top and bottom are firmly fixed. • See if the position of the master unit is properly levelled. • The drain pipe must not curve upward (Figure). Connecting Connecting pipe wires • The drain pipe must be at the lower part of the Wall pipe wall pipes (Figure) to avoid possible restriction to the water flow.
• use expansion bolts to fix the mounting supports on the wall • use bolts and nuts to fix the outdoor unit firmly on the supports and keep on the same level • if the unit is installed on the wall or at the roof top, the supports have to be firmly fixed to resist earthquake or strong wind.
multiple gauge EXHAUST AIR high pressure side gauge pressure vacual mercury column Only applicable for non-quick coupler. hand regulation main regulation valve closed valve closed from high pressure side maintenance point R410A: use pump vacuum to exhaust the air. to outdoor unit R407C/R410A industrial pipe container (brown)
Page 17
PARTS Indoor unit Air filter Room temperature detecting probe Emergency start/stop Air outlet • • Air flow direction TIMER adjusting Drain tube Electric connection Refrigerant piping Air inlet connection side and rear Outdoor unit Air discharge...
TECHNICAL DATA Model HW-9EZ HW-12EZ HW-18EZ BTU/h 9200 12000 16500 Cooling capacity measured conform EN 14511 3.51 4.82 BTU/h 9500 12300 17400 Heating capacity Power supply 220 – 240 V • 50 Hz • 1Ph Power consumption 840/780 1100/1000 1600/1580 Current 3.9/3.7...
Page 19
ELECTRIC CONNECTION (UK ONLY) For your safety please read the following information. Warning: This appliance must be earthed. The appliance must be connected to a 220-240 volts 50 cycle AC supply by means of a three pin socket, suitably earthed and should be protected by a 13 amp fuse in the plug. The appliance is supplied with a moulded 13 amp 3 pin mains plug fitted with a 13 amp fuse.
Page 20
Hong Kong Amcor Ltd Suite 1010–1011, 10/F, Ocean Centre, Harbour City, 5 Canton Road, Tsim Sha Tsui, Kowloon, Hong Kong Tel: +852 2997 6865 Fax: +852 2997 6091 Email: amcorhk@amcorgroup.com United Kingdom Amcor Ltd 9 Ryan Drive, West Cross Centre, Great West Road, Brentford, Middlesex, TW8 9ER, United Kingdom...
