OPERATOR'S MANUAL
0
1
5
4
5
7
7
E
N
0154577en
1102
Vibroplate
VPR 1330
001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPR 1330 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wacker Neuson VPR 1330

Summary of Contents for Wacker Neuson VPR 1330

  • Page 1 0154577en 1102 Vibroplate VPR 1330 OPERATOR’S MANUAL...
  • Page 2 BELGIE 1730 ASSE-MOLLEM ASSESTEENWEG 17 Tel. (32) 02-4528509+07 4040 Herstal 4 Avenue 9800 Deinze Kortrijkse Steenweg 400 Tel. (09)-386 8529 B - 6041 Gosselies Rue Adrienne Bolland s/n Tel. 071-372450 ÇESKÁ REPUBLIKA 19402 PRAHA 9-HLOUBETIN KOLBENOVA 259 Tel. (0042) 2 862165 DANMARK 2690 KARLSLUNDE RØRGANGEN 6...

  • Page 3: Table Of Contents

    VPR1330 Table of Contents Foreword Safety Information Laws Pertaining to Spark Arresters ............4 Operating Safety .................. 5 Operator Safety while using Internal Combustion Engines ....6 Service Safety ..................7 Label Locations ..................8 Warning and Informational Labels ............9 Operating Labels ................
  • Page 4 Table of Contents VPR1330 Maintenance Periodic Maintenance Schedule ............20 Cleaning Plate ..................20 Drive Belt .....................21 Exciter Lubrication ................22 Spark Plug ...................23 Engine Oil ....................24 Air Cleaner ..................25 Cleaning Fuel Strainer .................26 Throttle Adjustment ................26 5.10 Adjusting Idle Speed ................27 5.11 Troubleshooting ...................28 5.12 Storage ....................28...

  • Page 5: Foreword

    Foreword CALIFORNIA Proposition 65 Warning: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California WARNING to cause cancer and birth defects or other reproductive harm. Foreword This manual provides information and procedures to safely operate and maintain this Wacker model.

  • Page 6: Safety Information

    Safety Information VPR 1330 Safety Information This manual contains DANGER, WARNING, CAUTION, and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 7: Operating Safety

    VPR 1330 Safety Information Operating Safety Familiarity and proper training are required for the safe operation of equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions contained in both WARNING this manual and the engine manual and familiarize yourself with the location and proper use of all controls.

  • Page 8: Operator Safety While Using Internal Combustion Engines

    Safety Information VPR 1330 Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling! Read and follow warning instructions in engine owner's manual and safety guidelines below. Failure to follow warnings and DANGER safety guidelines could result in severe injury or death.

  • Page 9: Service Safety

    VPR 1330 Safety Information Service Safety Poorly maintained equipment can become a safety hazard! In order for the equipment to operate safely and properly over a long period of WARNING time, periodic maintenance and occasional repairs are necessary. 2.4.1 DO NOT attempt to clean or service machine while it is running.

  • Page 10: Label Locations

    Safety Information VPR 1330 Label Locations WARNING WARNUNG ADVERTENCIA 10 W 30 AVERTISSEMENT wc_gr000182 wc_si000031gb.fm...

  • Page 11: Warning And Informational Labels

    VPR 1330 Safety Information Warning and Informational Labels Wacker machines use international pictorial labels where needed. These labels are described below: Label Meaning To prevent hearing loss, wear hearing protec- tion when operating this machine. Read the operator's manual for machine infor- mation.
  • Page 12 Safety Information VPR 1330 Label Meaning WARNING! Hand injury if caught in moving belt. Always replace belt guard. CAUTION! Read and understand the supplied operator's manual before operating this machine. Failure to do so increases the risk of injury to yourself or others.
  • Page 13 VPR 1330 Safety Information Label Meaning This machine may be covered by one or more patents. wc_si000031gb.fm...

  • Page 14: Operating Labels

    Safety Information VPR 1330 Operating Labels Wacker machines use international pictorial labels where needed. These labels are described below: Label Meaning Open fuel flow valve. Push or turn engine switch to ON position. Close choke. Place throttle in the IDLE position.
  • Page 15 VPR 1330 Safety Information Label Meaning Push or turn engine switch to OFF position. Open choke. Place throttle in the FAST position. Throttle control lever: Turtle = Idle or Slow Rabbit = Full or Fast wc_si000031gb.fm...

  • Page 16: Technical Data

    Technical Data VPR 1330 Technical Data Engine Data VPR 1330 VPR 1330 0006512 0006512 Rev. 102 and lower Rev. 103 and higher Engine Engine Make Robin Engine Model EY15 (W1-145) EH122 (YD 4020) Rated Power kW (Hp) 2.6 (3.5) 2.9 (4.0) Engine Speed - full load 3500 ±...

  • Page 17: Machine Data

    VPR 1330 Technical Data Machine Data VPR 1330 VPR 1330 0006512 0006512 Rev. 102 and lower Rev. 103 and higher Plate Operating weight kg (lbs.) 76 (167) Exciter Speed 5800 ± 100 Exciter Lubrication ml (oz.) 800 (27) SAE 30W Sound and Vibration Specifications The required sound specification, Paragraph 1.7.4.f of 89/392/EEC...

  • Page 18: Dimensions

    Technical Data VPR 1330 Dimensions mm (in.) 8 8 4 ( 3 5 ) 6 0 1 ( 2 3 . 5 ) 6 5 9 ( 2 6 ) 1 0 7 8 ( 4 2 . 5 ) 3 0 0 ( 1 3 .

  • Page 19: Operation

    VPR 1330 Operation Operation Recommended Fuel The engine requires regular grade unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Consult engine owner’s manual for complete fuel specifications. Before Starting 4.2.1 Read and understand safety and operating instructions at beginning of this manual.

  • Page 20: To Stop

    Operation VPR 1330 To Stop See Graphic: wc_gr000183 4.4.1 Reduce engine RPM to idle by moving throttle completely to the left (d1). 4.4.2 Turn engine switch to "OFF" (b2). 4.4.3 Close fuel valve (a2). Application This plate is designed for compacting loose, granular soils, gravel, and paving stones.

  • Page 21: Operation

    VPR 1330 Operation Operation Run the engine at full throttle and allow the plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist the plate by pushing it forward slightly. When operating downhill hold the plate back slightly, if it begins to pick up speed.

  • Page 22: Maintenance

    Maintenance VPR 1330 Maintenance Periodic Maintenance Schedule The chart below lists basic engine maintenance. Refer to engine manufacturer’s Operation Manual for additional information on engine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs.

  • Page 23: Drive Belt

    VPR 1330 Maintenance Drive Belt See Graphic: wc_gr000185 On new machines or after installing a new belt, check belt tension after first 20 hours of operation. Check and adjust belt every 50 hours thereafter. To adjust belt: 5.3.1 Remove the two screws (b) at the bottom of the guard and the two nuts (a) located behind the guard.

  • Page 24: Exciter Lubrication

    Maintenance VPR 1330 Exciter Lubrication See Graphic: wc_gr000184 The bearings in the exciter assembly are splash lubricated and rotate at very high speed. It is important to maintain the exciter oil at the correct level and change it regularly. Check oil level in exciter each day, before running plate.

  • Page 25: Spark Plug

    VPR 1330 Maintenance Spark Plug See Graphic: wc_gr000028 Clean or replace spark plug as needed to ensure proper operation. Refer to the engine Owner’s Manual. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot.

  • Page 26: Engine Oil

    Maintenance VPR 1330 Engine Oil See Graphic: wc_gr000087 5.6.1 Drain oil while engine is still warm. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid which drains off. Dispose of this liquid in accordance with environmental protection legislation.

  • Page 27: Air Cleaner

    VPR 1330 Maintenance Air Cleaner See Graphic: wc_gr000088 The engine is equipped with a dual element air cleaner. Service the air cleaner frequently to prevent a carburetor malfunction. CAUTION: NEVER run the engine without the air cleaner. Severe engine damage will occur.

  • Page 28: Cleaning Fuel Strainer

    Maintenance VPR 1330 Cleaning Fuel Strainer See Graphic: wc_gr000089 5.8.1 Turn fuel valve off. 5.8.2 Remove bowl (a) gasket (b) and screen (c). 5.8.3 Wash them thoroughly in a nonflammable solvent. Dry them and reinstall. 5.8.4 Turn fuel valve on and check for leaks.

  • Page 29: Adjusting Idle Speed

    VPR 1330 Maintenance 5.10 Adjusting Idle Speed See Graphic: wc_gr000186 Adjust the idle when the engine is warm. 5.10.1 Start the engine and allow it to warm up for a minute. 5.10.2 With the throttle in lowest (slowest) position, adjust the idle speed screw (a) to obtain the correct idle speed.

  • Page 30: Troubleshooting

    Maintenance VPR 1330 5.11 Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting.

  • Page 31: Lifting Machine

    VPR 1330 Maintenance 5.13 Lifting Machine See Graphic: wc_gr000359 See Technical Data for the weight of the machine. To lift machine manually: 5.13.1 Stop the engine. 5.13.2 Obtain help from a partner and plan the lift. 5.13.3 Grasp the machine by its cage (a) and lifting handle (b).

  • Page 32: Transporting Machine

    Maintenance VPR 1330 5.14 Transporting Machine See Graphic: wc_gr000356 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 5.14.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling.
  • Page 33 1. Category / Art / Categoría / Catégorie Vibrationsplatte Plancha Vibradora Patin Vibrant VPR 1330 2. Type - Typ - Tipo - Type 3. Item number of equipment / Gerätetypnummer / Número de referencia de la máquina / Numéro de référence du matériel : 0006512 4.
  • Page 35 UNITED KINGDOM LONDON LEA ROAD Tel. (44)(01992) 707200 WALTHAM CROSS, HERTS EN9 1AW Washington Washington/Tyne N37 1LH Tel. (0191) 4 16 63 92 Warrington Winwick Quay, Warrington WA2 8RE Tel. (01925) 57 39 55 Worksop Worksop S81 7BE Tel. (01909) 48 45 06 Redditch Washford, Redditch B98 0DQ Tel.
  • Page 36 www.wackergroup.com UNITED STATES CORPORATE OFFICE MENOMONEE FALLS, WI 53052 N92 W15000 ANTHONY AVE. Tel. (262) 255-0500 CANADA MISSISSAUGA, ONT. L5T 2N6 160 ADMIRAL BLVD. Tel. (905) 795-1661 Calgary, Alta. T2H 2H9 #11, 6115-4 St. S.E. Tel. (403) 255-3336 St. Laurent, Quebec H4R 2C1 3526 Rue Ashby Tel.
