- Page 1 www.wackergroup.com 0200071en 11.2005 Electrik-hammer EHB 10/... Operator´s Manual...
-
Page 3: Foreword
Wacker Construction Equipment AG. Any type of reproduction, distribution or saving on data carriers of any type or method not authorized by Wacker represents an infringement of valid copyrights and will be prosecuted. -
Page 4: Table Of Contents
TABLE OF CONTENTS FOREWORD SAFETY INSTRUCTIONS General instructions Operation Safety checks Maintenance Transport Maintenance checks TECHNICAL DATA DESCRIPTION Application Putting into operation During operation Disassembly Assembly MAINTENANCE Maintenance schedule Maintenance and lubrication BREAKING TOOLS DRILLING TOOLS REFORGING OF TOOLS DIAGRAM WIRING DIAGRAM EC - CONFORMITY-CERTIFICATE... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS FOR THE USE OF DRILLING AND BREAKING HAMMERS WITH ELECTRIC DRIVE General instructions Drilling and breaking hammers may only be operated by persons who * are at least 18 years of age, * are physically and mentally fit for this job * have been instructed in operating drilling and breaking hammers and proven their ability for the job to the employer * may be expected to carry out the job they are charged with carefully. -
Page 6: Safety Checks
Maintenance Only use original spare parts. Modifications to this machine, including the adjustment of the maximum engine speed set by the manufacturer, are subject to the express approval of Wacker. In case of non- observance all liabilities shall be refused. -
Page 7: Technical Data
TECHNICAL DATA EHB 10/230 EHB 10/240 EHB 10/230 THW EHB 10/240 GB EHB 10/230 DBP EHB 10/230 SEV EHB 10/230 BW Item no. 0006943 ... 0007084 ... 0007082 ... 0007085 ... 0007081 ... 0007083 ... 0007087 ... Length x width x height (without tool) 545 x 105 x 245 Operating weight (mass) without tool Voltage... -
Page 8: Description
DESCRIPTION Application This versatile breaking and drilling hammer is used in civil engineering and building industry, in concrete works, cast stone plants, foundries, by plumbing installation firms and communities. It is particularly suited for use on natural and cast stone, as well as for all kinds of brickwork and concrete. A wide selection of easily interchange- able tools is available for drilling holes from 12 to 125 mm, for breaking, chiselling, digging, puddling, hammer- ing ramming and deburring. -
Page 9: Disassembly
DESCRIPTION Disassembly 1. Tool holder/Cylinder housing Remove pin. Remove supplementary handle with holder spring from tool holder. Remove cheese head screw. Remove tool holder, tool holder bushing, intermediate gear and intermediate plate. Remove cylinder housing with drive shaft from crankcase. Remove percussion piston. 2. -
Page 10: Maintenance
MAINTENANCE Maintenance schedule Check all external screw connections for tight fit approx. 8 hours after first operation. Component Maintenance work Maintenance interval Feed line Check for perfect condition - if cable daily defective, replace. Miscellaneous Fan slits dirt - free - clean if necessary. Tools Check the shafts and cutting edges - if necessary, sharpen, reforge or replace. -
Page 11: Breaking Tools
BREAKING TOOLS Shank for breaking: Hexagonal, spanner Ref. - No. Type opening SW 19x82,5 For breaking: Effective length Moil point 230 mm 0022763 430 mm 0032860 Flat chisel, wide 24 mm Effective length 230 mm 0022764 Wedge flat chisel, wide 25 mm Effective length 190 mm 0109320... -
Page 12: Drilling Tools
65 mm WI 0124277 Adapter 200 mm WI 0124278 300 mm WI 0124279 460 mm WI 0124280 Adapter with WACKER-connection 330 mm WI 0124281 Conveyor spiral for concrete and 80 mm Whole natural stone length 0124282 ø 33 mm 0124283 ø... - Page 13 DRILLING TOOLS Shank for drilling tools: Hexagonal, spanner Type Ref. - No. opening SW 19x80 (82,5) Cone adapter 1:10 55 mm WI 0037105 Machine adapter 0124275 Adapter for Hilti tools 0063747 Cross drill crown type G ø 65 mm 0124289 ø...
-
Page 14: Reforging Of Tools
REFORGING OF TOOLS ATTENTION! Use safety glasses when doing this job. When reforging of the tools becomes necessary, care should be taken that only that part of the tool that needs reforging is heated. Moreover, it is important that the heat is increased slowly and that it is constantly watched, otherwise heat cracks are likely to occur on hardened tools. -
Page 15: Diagram
DIAGRAM Selection of required cross section for extension of cables and power lines This procedure takes into consideration: The ohmic and inductive resistance of the line with an admissible loss of voltage of 5% and cos phi = 0,8 as per voltage-frequency-curves. The admissible warming-up of the lines as per VDE standard (table of required minimum cross section). -
Page 16: Wiring Diagram
WIRING DIAGRAM Handle Plug Conducting Switch Screw union Capacitor Plug-blue Plug-red white/yellow white/yellow white/red Engine white/green white/green white white/red Electronic black SK00012GB... -
Page 17: Ec - Conformity-Certificate
EC - CONFORMITY-CERTIFICATE Wacker Construction Equipment AG , Preußenstraße 41, 80809 München hereby certify that the construction equipment specified hereunder: 1. Category: Breaking / Drilling hammer 2. Type: EHB 10/230 EHB 10/240 3. Equipment item number: 0006943 ... 0007084 ... - Page 19 DIN EN ISO 9001 CERTIFICATE...
- Page 20 Wacker Corporation - P.O. Box 9007 - Menomonee Falls, WI 53052-9007 - Tel.: +1-(1)(262)-255-0500 - Fax: +1-(1)(262)-255-0550 - Tel.: (800)770-0957 Wacker Asia Pacific Operations-Skyline Tower, Suite 2303, 23/F, 39 Wang Kwong Road, Kowloon Bay, Hong Kong-Tel.: +852 2406 6032-Fax: +852 2406 6021...
