N6123 NVR
IMPORTANT SAFETY INSTRUCTIONS
DO NOT DISCARD, READ BEFORE OPERATING
Please read the safety precautions carefully before
using this product. Ensure that you use the product
correctly according to the procedures described in
these instructions.
The following safety precautions are intended to
instruct you in the safe and correct operation of the
product and its accessories to prevent injuries or damage
to yourself, other persons, and property. Please read and ensure that you understand them before you
proceed to the other sections of these instructions.
• Do not operate this device in a wet environment.
• Refer servicing to qualified service personnel only.
• Please read the Operating Manual carefully before operating. Follow all operating and other instructions
carefully.
• This device should only be operated with the accompanying power adapter.
• Do not use this product near heat sources such as radiators, air ducts, areas subject to direct, intense
sunlight, or other products that produce heat.
• Do not use this product near devices that produce extreme magnetics fields.
Disclaimer
• While every effort has been made to ensure that the information contained in these instructions is
accurate and complete, no liability can be accepted for any errors or omissions. SVSi reserves the right
to change the specifications of the hardware and software described herein at any time without prior
notice.
• SVSi makes no warranties for damages resulting from corrupted or lost data due to mistaken operation
or malfunction of the SVSi hardware, software, or accessories.
Product Overview
The SVSi N6123 is a network video recorder capable of recording up to 20 hours of high-resolution, HD
content over an Ethernet LAN. This rack-mount DVR is compatible with all SVSi video-over-IP products
and attaches to the video network at any point to record up to 20-hrs of 1080p video. Each video stream
is recorded and played back at its original resolution. The N6123 acts as a receiver during recording and
as a transmitter during playback. The N6123's 2RU form-factor is stackable for a high density of recorded
video streams in a small footprint.
USER MANUAL
Advertisement
Table of Contents
Related Manuals for SVSi N6123
Summary of Contents for SVSi N6123
- Page 1 SVSi hardware, software, or accessories. Product Overview The SVSi N6123 is a network video recorder capable of recording up to 20 hours of high-resolution, HD content over an Ethernet LAN. This rack-mount DVR is compatible with all SVSi video-over-IP products and attaches to the video network at any point to record up to 20-hrs of 1080p video.
- Page 2 Accessing the NVR The NVR is discoverable using our Conductor Netlite Software (found here: http://svsiav.com/support/resources/software/), just as any other SVSi device is. The NVR ships with Auto IP as the default IP mode for the network card. This means that it will automatically configure an IP address in the range of 169.254.X.X with a netmask of 255.255.0.0.
- Page 3 Default username and password: Username: admin Password: password Configuring the NVR Once the NVR is discovered, double-click on its name to bring up its settings page. On the basic settings tab, you can assign its output and record stream numbers, change its IP configuration, enable a dual-sync recording (N-2000 and V-Series) and enable/disable audio.
- Page 4 Recording Sources The N-6123 can record and playback 1 x N-1000 stream, 2 x N-2000 streams (in sync), or 20 x N-3000 streams (N-3000 available late 2013). Transport controls are available on the DVR window of Netlite. To start a recording of a source: 1.
- Page 5 Playback of Recordings Within the Matrix view, you will notice that the NVR shows up across the top as a source (for playback operation) and in the left-hand column as a display (for recording purposes). To playback a recorded file: 1.
- Page 6 Downloading Converted MPEG Files Enter the NVR’s IP address into your web browser. Use the default login information mentioned at the beginning of this manual. Once logged into the NVR, simply right-click and “Save As” on any file you wish to download. For technical support, contact support@svsiav.com or call (256) 461-7143.
-
Page 7: Specifications
Distribution | Switching | Recording | Windowing | Wall Processing | Control 360B Quality Circle Suite 200, Huntsville, AL 35806 • 256.461.7143 • www.svsiav.com © Southern Vision Systems, Inc. SVSi and voLANte are trademarks of Southern Vision Systems, Inc. in the United States and other countries. Made in the U.S.A 800DOCN6123MNREV1.1...
