It's in closed status for UPS normal operation.
WARNING: The EPO, RS-232 and USB circuits are IEC 60950 safety extra low voltage (SELV) circuits. This circuit must be
separated from any hazardous voltage circuits by reinforced insulation.

System single line diagram

System single line diagram is demonstrated as picture below:
