IFC-BOX4000 User Manual
1
IFC-BOX4000
Fanless Embedded Box PC
Intel® Haswell™ Celeron® Processor 2957U Processor
Intel Haswell Core4 I3-4030U-1.9GHz CPU
Intel Haswell Core4 I5-4278U-3.1GHz CPU
Intel Haswell Core4 I7-4578U-3.5GHz CPU
SODIMM DDR3 Socket
Intel® HD Graphics Integrated Graphic Card
DVI-I/HDMI/DP Display
4 x Intel®I210 GbE LAN
2 x RS-232/ Isolation RS-485, 4 x RS-232
4 x USB2.0, 2 x USB3.0
+9V~+30V Extended Voltage Input
User Manual
Ver 2.0
Advertisement
Table of Contents
Related Manuals for IFC IFC-BOX4000
Summary of Contents for IFC IFC-BOX4000
- Page 1 Intel Haswell Core4 I7-4578U-3.5GHz CPU SODIMM DDR3 Socket Intel® HD Graphics Integrated Graphic Card DVI-I/HDMI/DP Display 4 x Intel®I210 GbE LAN 2 x RS-232/ Isolation RS-485, 4 x RS-232 4 x USB2.0, 2 x USB3.0 +9V~+30V Extended Voltage Input IFC-BOX4000 User Manual...
- Page 2 Copyright The documentation and the software included with this product are copyrighted 2013 By IFC. All rights are reserved. IFC reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced/ copied/ translated or transmitted in any form or by any means without the prior written permission of IFC.
-
Page 3: Declaration Of Conformity
Because of IFC’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an IFC product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. -
Page 4: Technical Support And Assistance
Technical Support and Assistance 1. Visit the IFC web site at www.ifc-ipc.cn where you can find the latest information about the product. 2. Contact your distributor, sales representative, or IFC's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –... -
Page 5: Safety Instructions
Caution: The computer is provided with a battery-powered real-time clock circuit. There is a danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacture. Discard used batteries according to the manufacturer’s instructions. IFC-BOX4000 User Manual ver 2.0... -
Page 6: Packing List
IEC 704-1:1982 is no more than 70 dB (A). Disclaimer: This set of instructions is given according to IEC 704-1. IFC disclaims all responsibility for the accuracy of any statements contained herein. -
Page 7: Table Of Contents
ATCHDOG PROGRAM EXAMPLE GPIO ...................... 36 PROGRAM EXAMPLE INDEX: A ............................37 А.1 I/O P ........................ 38 YSTEM ORTS А.2 MB M ......................38 EMORY А.3 DMA C ....................39 HANNEL SSIGNMENTS А.4 ....................... 39 NTERRUPT SSIGNMENTS IFC-BOX4000 User Manual ver 2.0... -
Page 8: General Introduction
Chapter General Introduction This chapter gives background information on IFC-BOX4000 series. IFC-BOX4000 User Manual... -
Page 9: Introduction
IFC-BOX4000 is designed as a palm-size fanless embedded system and occupies only 260 x 176 x 49 mm 260 x 176, The rugged, cast aluminum case not only provides great protection from EMI, shock/vibration, cold and heat, but also provides passive cooling for quiet, fanless operation. -
Page 10: Electrical Specifications
Power Input: DC +9V ~ +30 V Power On Type: AT / ATX Jumper selection APM: ACPI 3.0, APM Power Adapter: AC ~ DC 12V/3A , 36W Power consumption: 2957U-1.4GHz (Fanless) Voltage Current Power Idle mode +12V IFC-BOX4000 User Manual ver 2.0... -
Page 11: Os Support
It supports Support Win7, Win8, Win CE 6.0, and Linux Ubuntu 10.04 UP. 1.5 Other Power switch, power indicator 1 -255 sec. watchdog 12 bits, support routine, self-define I/O, 3.3V@24mA IFC-BOX4000 User Manual 1.6 Environmental Specifications Operating temperature: -20 ~ 60° C (extended temp. SSD/mSATA device) 0 ~ 40°... -
Page 12: Mechanical Specifications
1.7 Mechanical Specifications IFC-BOX4000 User Manual ver 2.0... - Page 13 Figure 1.7 IFC-BOX4000 mechanical dimension drawing IFC-BOX4000 User Manual ver 2.0...
-
Page 14: H/W Installation
H/W Installation This chapter explains the setup procedures of the IFC-BOX4000 hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. IFC-BOX4000 User Manual ver 2.0... -
Page 15: Jumpers
1. Please check the M/B carefully, where there is a mark of “1” or white thick line, there is Pin1. 2. Look into the pad on the back side of the M/B, generally the square side of the pad is Pin1. IFC-BOX4000 User Manual ver 2.0... - Page 16 8 M2.5, remove the lower cover of the computer case can be carried out from the bottom, hard disk, M-SATA, memory, Mini-PCIe equipment installation. And can be set up to the corresponding functional jumper IFC-BOX4000 User Manual ver 2.0...
-
Page 17: Jumper Setting
2.1.3 Jumper Setting JCMOS CMOS Clear/AT & ATX Power Mode Select Part Number Description Pin Header 1x3Pin 2.54mm DIP & Jumper 2.54mm Setting Function 1-2 On (Default) Normal 2-3 On Clear BIOS IFC-BOX4000 User Manual ver 2.0... - Page 18 2.1.4 IFC-BOX4000 I/O Indication Figure 2.1.4 IFC-BOX4000 mechanical dimension drawing IFC-BOX4000 User Manual ver 2.0...
-
Page 19: External I/O Connectors & Pin Assignments
+12V/5V power output is connected to the supply of external equipment. COM1 Part Number Description COM Port D-Sub 9Pin Male DIP Signal Signal 9 Wire RS232 Interface , Support a maximum 115200bps Rate , Support 4000V Surge protection. COM2-COM4 Part Number IFC-BOX4000 User Manual ver 2.0... - Page 20 GPIO9 GPIO10 GPIO11 GPIO12 V3.3S Free programming is defined as the input or output, the driving power of 3.3V@24mA DVI Port Part Number Description DVI-D 24Pin Fe male DIP Signal Signal TX2- TX2+ SHLD24 TX4- IFC-BOX4000 User Manual ver 2.0...
- Page 21 Signal Signal LANE_0P LANE_0N LANE_1P 6 LANE_1N 7 LANE_2P LANE_2N LANE_3P LANE_3N MODE AUXP AUXN PWR_RET DP support max. resolution 3200X2000@60HZ, support DP Dangle device. Power Input Connector (DC_IN1) Part Number Description DC-Jack 3Pin DIP IFC-BOX4000 User Manual ver 2.0...
- Page 22 Signal Signal IFC-BOX4000 with a 9-30V support DC external power input of the phoenix head jack. The ACC signal is connected with a vehicle ACC signal support. Power ON/OFF Button (PWR_SW1) Part Number Description Power Button LED PTCT-07-A 5P 7Pin DIP IFC-BOX4000 has a power button with LED indicator.
- Page 23 Receive Data- Bi-directional Data+ Bi-directional Data- IFC-BOX4000 provides 4 POE RJ45 LAN port, in full compliance with the IEEE 802.3u 10/100/1000 Base-T CSMA/CD standard. RJ-45 connector using standard Ethernet port, support 48V@500mA POE power output, Link/Speed LED lights, for indicating transmission / connection state and speed condition.
-
Page 24: Bios Settings
Chapter BIOS Settings IFC-BOX4000 User Manual ver 2.0... -
Page 25: Bios Overview
Please use internal default value of BIOS to restore the system. Our company is constantly updating BIOS, so the setup interface may varies sometimes. The default options bellow are just for reference only. IFC-BOX4000 User Manual ver 2.0... -
Page 26: Main Menu
BIOS Information (read only): To display BIOS info, including Project Name, Build Date ect. Processor Information: To display the basic Processor Information Total Memory: To display the Total Memory Memory Frequency: To display the Frequency Memory is running IFC-BOX4000 User Manual ver 2.0... -
Page 27: Advanced Menu
3.3 Advanced Menu ACPI Settings. CPU Configuration. SATA Configuration. USB Configuration. Super IO Configuration. H/W Monitor. IFC-BOX4000 User Manual ver 2.0... -
Page 28: Acpi Settings
Enable Hibernation: Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS.. ACPI Sleep State: Select the ACPI state used for system suspend.(S3 state). 3.3.2 CPU Configuration IFC-BOX4000 User Manual ver 2.0... - Page 29 Show the detail information of the processor and setting for it. IFC-BOX4000 User Manual ver 2.0...
-
Page 30: Sata Configuration
SATA Mode Selection: Determines how SATA controller(s) operate. SATA Controller Speed: Indicates the maximum speed the SATA controller can support. Serial ATA Port X(0-3): Show the sata device information detected on this port Port X(0-3) : Enable or Disable this sata port IFC-BOX4000 User Manual ver 2.0... -
Page 31: Usb Configuration
USB transfer time-out: The time-out value for Control, Bulk, and Interrupt transfers. Device reset time-out :USB mass storage device Start Unit command time-out. Device power-up delay: Maximum time the device will take before it properly reports itself to the Host Controller. IFC-BOX4000 User Manual ver 2.0... -
Page 32: Super Io Configuration
(G3 state).. Power on: System will always power on when restore AC power Power Off: System will not power on when restore AC power Last State: whether power on depend on the state when Power Loss IFC-BOX4000 User Manual ver 2.0... - Page 33 3.3.6 H/W Monitor PC Health Status: read only, including CPU/System temperature, Fan Speed, VCORE, VDIMM, +3.3V, +5V, +12V, VBAT. IFC-BOX4000 User Manual ver 2.0...
-
Page 34: Chipset
3.4 Chipset PCH-IO Configuration: PCH Parameters System Agent (SA) Configuration: System Agent (SA) Parameters IFC-BOX4000 User Manual ver 2.0... - Page 35 3.4.1 PCH-IO Configuration PCI Express configuration: PCI Express Root Port 1-6 Setting IFC-BOX4000 User Manual ver 2.0...
- Page 36 IFC-BOX4000 User Manual ver 2.0...
- Page 37 3.4.2 System Agent (SA) Configuration Graphics Configuration : Graphics Device Settings. IFC-BOX4000 User Manual ver 2.0...
- Page 38 DVMT Pre-Allocated: Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. DVMT Total Gfx Mem: Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. IFC-BOX4000 User Manual ver 2.0...
-
Page 39: Boot Menu
Note: When pressing <F7> while booting it is possible manually to select boot device. Boot Option #1: Setting first boot device. Boot Option #2: Setting second boot device. Hard Drive BBS Priorities: Setting the boot priority of Hard Disk IFC-BOX4000 User Manual ver 2.0... -
Page 40: Security Menu
3.6 Security Menu Change Administrator / User Password: IFC-BOX4000 User Manual ver 2.0... -
Page 41: Save Changes And Exit
Save as User Defaults This item allows you to save the changes done so far as user defaults. Restore User Defaults This item allows you to restore the user defaults to all the options. Boot Override IFC-BOX4000 User Manual ver 2.0... -
Page 42: S/W Introduction & Installation
Chapter S/W Introduction & Installation IFC-BOX4000 User Manual ver 2.0... -
Page 43: S/W Service Introduction
GPIO -OL Gpio Num : Set GPIO Port output Low Example: GPIO -I 1 : Set GPIO 1 as input GPIO -OH 1 : Set GPIO 1 output high GPIO -OL 1 : Set GPIO 1 output Low IFC-BOX4000 User Manual ver 2.0... -
Page 44: Index: A
Chapter Index: A IFC-BOX4000 User Manual ver 2.0... -
Page 45: А.1 System I/O Ports
FEC00000h - FEC00FFFh Motherboard resources FED00000h - FED003FFh High precision event timer FED14000h - FED19FFFh System board FED1C000h - FEE00FFFh Motherboard resources FF000000h - FFFFFFFFh Intel 82802 firmware Hub Device Table 5.2: 1st MB Memory Map IFC-BOX4000 User Manual ver 2.0... -
Page 46: А.3 Dma Channel Assignments
Standard 101/102-Key or Microsoft Natural PS/2 Keyboard IRQ3 COM2 IRQ4 COM1 IRQ8 System CMOS/real time clock IRQ9 Microsoft ACPI-Compliant System IRQ11 SMBUS Controller IRQ16 Network /USB IRQ17 Network IRQ18 IRQ19 SATA IRQ22 IRQ23 Table 5.4: Interrupt Assignments IFC-BOX4000 User Manual ver 2.0... - Page 47 Made in China www.IFC-ipc.cn IFC-BOX4000 User Manual ver 2.0...
