Troubleshooting
Check the LED displays on the StorEdge S1 periodically to make sure that the
enclosure and disk drives are running properly.
Front Panel LEDs
The front panel LEDs indicate system power, system faults, hard drive activity, and
SCSI ID assignments.
and
show the location of the front panel
FIGURE 5-1
FIGURE 5-2
LEDs and
shows their meanings and gives corrective actions. There is also
TABLE 5-1
a quick-reference card attached to the system which explains what the SCSI ID LEDs
mean.
System Power LED System Summary Fault LED
Drive activity LEDs
Front Panel LEDs With Bezel
FIGURE 5-1
Chapter 5 Maintenance Tasks
67
