Summary of Contents for PurePro JA-303
-
Page 1: Table Of Contents
Water Ionizer JA-303 User's Manual CONTENT Package contents Applications & uses of ionized water Preparation Control panel Installation Filter replacement procedure How to test the pH / chlorine Trouble shooting Limited warranty Specification Safety information... -
Page 2: Package Contents
PACKAGE CONTENTS All accessories that come with the water ionizer You should have the following items included with your water ionizer 3/8" flexible hose Screw x 3 Stainless steel outlet hose PH & Chlorine testing kit Hole template Tap adapter wall-mounting Chlorine Hose clip x 3... -
Page 3: Applications & Uses Of Ionized Water
APPLICATIONS & USES OF IONIZED WATER ALKALINE WATER: Drinking alkaline water Useful in improving the constitution, and regulates physical condition. Unlike tap water, you can drink large quantities of alkaline water without the risk of stomach upset. a. Unusual gastrointestinal fermentation: drinking alkaline water on an empty stomach is effective. - Page 4 APPLICATIONS & USES OF IONIZED WATER Other uses of alkaline water a. Animals and pets: Can be used as drinking water to maintain their health Bathe in acidic water Healthier coat of fur Less odor in feces Helps prevent skin disease and itching b.
- Page 5 APPLICATIONS & USES OF IONIZED WATER Home remedies of acidic water Due to its slight disinfecting and sterilizing action, acidic water has disinfecting, sterilizing and analgesic effects on skin wounds. Also kills bad breath.. a. Gargling water: prevents infection by germs including the microbes that cause colds and tonsillitis.
-
Page 6: Preparation
PREPARATION PH function select button LCD panel + Adjust pH SET button - Filter life reset button Acidic water output port Tap water input port Alkaline water output... -
Page 7: Control Panel
CONTROL PANEL Working Use purified water when taking medicine. Alkaline: Acidic: 2 level acidic 3 level alkaline water selection water selection #1 Low pH level: Minor alkaline; good for initial drinking; after drinking for 1 week, you can drink higher level alkaline water. #2 Cooking level: For cooking and making beverages #3 Drinking level: Best level for drinking... -
Page 8: Installation
INSTALLATION A. Installation for Euro-faucet First, remove original Euro-faucet aerator. This is usually done without tools by rotating counter-clockwise. And then slip on quick fitting pad, two- way screw, quick fitting in turn. Connect the house to the water input. - Page 9 INSTALLATION B. Flexible Hose Simply cut a sufficient length of house to reach "acidic water output" port. Allow some extra length in the event acidic water to be collected for external or plant use. Power Cord Tap water input port Acidic water output port Output port for connection...
- Page 10 INSTALLATION C. Base Unit a. Do not wind the hose, and extend the hose to a sufficient length, using a sharp pair of scissors to cut the hose straight across in a single cut. b. The best length of the acidic water hose is around 16.5 inches. c.
- Page 11 INSTALLATION D. Illustration Stainless steel outlet hose for alkaline water Faucet Controls panel Hose clamp Flexible hose for connection Quick fitting Acidic water hose Plug Power cord connection (Length: 1.5M)
- Page 12 INSTALLATION E. Hole template for wall-mounting Remove template, find suitable location for installation. Drill 3 holes, and fix the template with screws. Hook the unit on the template.
-
Page 13: Filter Replacement Procedure
FILTER REPLACEMENT PROCEDURE When to replace filter How to replace the filter is indicated by the LCD display. Filter service life to be 9,000 liters in original setting. The number of liters reduces after each time of water use. Replace the old filter when the number of liters reduced to 0. Working Warning: If the following events happened, you must replace the old filter immediately. - Page 14 FILTER REPLACEMENT PROCEDURE To replace the filter, turn off the water and switch off the ionizer unit by the mains and unplug it. Then remove the unit from the wall where it is attached. 1. Open the cover of the filter. 2.
-
Page 15: How To Test The Ph / Chlorine
HOW TO TEST THE PH / CHLORINE 1. Add 2 Drops of the PH / Chlorine testing solution to sample. 2. Compare the resultant hue to the ph inspection chart. It will tell you the ph level. 3. The chlorine testing result should be yellow in your tap water, the ionized water should colorless. -
Page 16: Trouble Shooting
TROUBLE-SHOOTING Phenomenon Water production Filter clogged Replace new filter is decreasing water flow less water pressure less Flexible hose winding Straighten the hose 1. The filter expired 1. Replace new filter Unpleasant smell 2. Over-ionized 2. Try lower PH or ORP Something solid Let ionizer make Alkaline mineral solidify... -
Page 17: Faq
Q1: What is white powder which sticks to the cup or kettle? A1: Alkaline-forming minerals. Which contains Calcium, Magnesium, and Sodium, Potassium, lron and Manganese. The white power will appear after boiling the alkaline water. It's all right for drinking. Q2: What kind of water should be used? A2: Normal city tap water is preferred. -
Page 18: Limited Warranty
LIMITED WARRANTY A. What the warranty covers: We warrant this product to be free from defects. B. How long the warranty is effective: The warranty is one year for all parts. (Filter excluded) C. What the warranty does not cover: I. -
Page 19: Specification
SPECIFICATION Model number JA303 Voltage AC-110V / AC-220V Electricity DC-2A~6A Power consumption 100~200 W Dimensions 315 x 275 x 140 mm ORP level +500MV ~ -400MV Electronic wire 1.5M Fuse protected Filtration capacity 16,000L ORP constant outlet & continue electrolysis Method Chlorine removal <... -
Page 20: Safety Information
SAFETY INFORMATION Read manual prior to installation and operation Verify with your health practitioner that prescribed medications or existing conditions will not be affected by alkalinity. Your new unit is intended as a point-of-use appliance only. Serious damage may result from misuse of your unit. Never attach any plumbing or tubing to flexible dispensing hose.
