Page 1: User Manual
User Manual Ceramic Cooktop Model : CRSF745 Please read this instruction manual carefully before using your new ceramic cooktop and keep the manual in a safe place for future reference. - Page 2 Dear customer, You will have many years of cooking enjoyment with your new cooktop. Please read this manual carefully and keep in a safe place for future reference. Please pay particular attention to the Safety and Maintenance section on page 8. Safety The installation and connection of the cooktop must only be carried out by qualified personnel.
-
Page 3: Installation
Safety Residual heat indicators After using the hob, waste heat remains in the heating area. The power nixie tube shows the code “H”, warning to be away from the heating area. Auto shut down protection During the hob working, it is shut off automatically when the default timing reach by the program if without operating. - Page 4 Under any circumstances, make sure the ceramic hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic hob is in good work state. As shown in Figure (2) Air exit mini 5 cm mini 5 mm mini 2 cm Air intake Figure (2)
-
Page 5: Power Line Connection
Cautions The ceramic hob must be installed by qualified personnel or technicians. Please never conduct the operation by yourself. The ceramic hob shall not be mounted to cooling equipment, dishwashers and rotary dryers. The ceramic hob shall be installed such that better heat radiation can be ensured to enhance its reliability. -
Page 6: Instructions For Use
The ceramic hob appearance Glass plate Power cord Control panel ON/OFF Schematic diagram of the control panel Timer Double loop key Power/Timer ON/OFF regulating key Lock key Instructions for Use Put the pot in the center of the heating zone. Preparation before using After turning on, the buzzer will beep once. -
Page 7: Operation Instructions
Operation Instructions: After the " ON/OFF "key is pressed,all the indicators show " - ".Then you can set the heat setting of corresponding heating zone ON/OFF Note: 1. In standby working mode, touch the “ON/OFF” symbol the heating zone will restore to the standby working mode if there is no heat setting within 2 minutes. - Page 8 Childproof lock: To ensure the safety of children, the hob is provided with the function of childproof lock. Activating the childproof lock: When the lock is deactivated, touch the “childproof lock” symbol to activate Child safety the childproof lock. However when in the locked position, the "stop"...
- Page 9 Safety Reminding and Maintenance A dedicated power protection Never use the ceramic cooktop Do not put any detergents or air swith protection air switch in high temperature flammable materials in the must be incorporated in the environments such as near a equipment installed under the fixed wiring in accordance gas stove or kerosene stove.
- Page 10 DISPOSAL: Do not dispose this Indoor use only. Clean the ceramic cooktop product as unsorted municipal on a regular basis to prevent foreign matters from entering waste. Collection of such waste the fan thus influencing the separately for special treatment normal operation.
-
Page 11: Maintenance Service Warranty
Maintenance Service Warranty For any failure of the product, please contact the special maintenance department or the customer service center. 1. There is a year’s guarantee with the our brand ceramic cooker hob. 2. The period of warranty shall start from the date on which the invoice is issued.
