- Page 1 Instruction Manual for Induction Cooktop MODEL: IDSF608 Thank you for purchasing the induction cooktop, please read this instructions manual carefully before using and keep it in a safe place for your future reference.
-
Page 2: Product Introduction
Product Introduction The induction cooktop can meet various of cuisine demands by electromagnetic heating, with micro-computerized control and multi- functions, really the optimal choice for modern families. The induction cooktop centers on customers and adopts personalized design. Made of imported materials and through advanced process, the unit has safe and reliable performances, making your life comfortable and enabling you to fully enjoy the pleasures of life. - Page 3 Safety We have designed this cooktop for private use in home. With a view to constantly improving our products, we reserve the right to make any changes to their technical, program or aesthetic features connected with their technical evolution. Over- Temperature Protection A temperature sensor equipped can monitor the temperature inside the hotplate.
-
Page 4: Installation
Installation Selection of installation equipment Drill holes on the table surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50 mm space shall be preserved around the hole. Be sure the thickness of the table surface is at least 30mm. Please select heat-resistant table material to avoid larger deformation caused by the heat radiation from the hotplate. - Page 5 Fix the hob on the table by screw four brackets on the bottom of hob (see picture) after installation. Adjust the bracket position to suit for different table top thickness. Cautions The induction cooktop must be installed by a qualified, licensed electrician. Please never conduct the operation by yourself.
- Page 6 If the cable is damaged or to be replaced, the operation must be carried out the by after-sale agent with dedicated tools to avoid any accidents. If the appliance is being connected directly to the mains an omnipolar circuit-breaker must be installed with a minimum opening of 3mm between contacts.
-
Page 7: Instructions For Use
Instructions for Use Preparation before using: After power on, the buzzer beep once, all the indicators light up for 1 second then go out, indicating the induction hotplate enters the state of standby. Put the pot in the center of the heating zone. Operation Instructions After the “ON/OFF”... - Page 8 Cancellation of “BOOST” function Select the corresponding cooking zone and press the "Boost" key or "-" to cancel the Boost mode, then the cooking zone will revert to its original setting. Timing function Press the "+"or"-" key of that zone, the corresponding indicator will be flashing.
- Page 9 The max. power of each heating zone are as follows: Max. power (W) Heating zone Boost Normal 2600 2000 2000 1500 2600 2000 2000 1500 The above power may vary if the material or the size of pot is different. Selection of heating appliances Iron oil frying pan Iron pan...
- Page 10 Never have the induction For sealed food such as After being used for a long cooktop to work without food canned goods, please do not time, the corresponding i n s i d e , o t h e r w i s e i t s heat them before opening their heating zone of the induction...
- Page 11 DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Cleanness and Maintenance You can easily clean the surface of the induction cooktop if following the methods given in the table. Articles used for Type of contam- Method of cleaning...
-
Page 12: Failure Display And Inspection
Failure Display and Inspection If an abnormality comes up, the induction cooktop will enter the protective state automatically and display corresponding protective codes: Display Code Possible reasons Solutions Please contact the Fan failure F0/F1/F2 supplier Temperature Please contact the sensor failure supplier.
