- Page 1 SR 2000 IEM SR 2050 IEM Notice d emploi Instruction manual Instruction manual...
- Page 2 Tastensymbole / Button icons / Icônes de touches / Simboli dei tasti / Símbolos de las teclas / Toetssymbolen / Символы кнопок 按键图标 Símbolos dos botões / Taste STANDBY STANDBY button / Touche STANDBY Tasto STANDBY / Tecla STANDBY / Toets STANDBY / Кнопка...
-
Page 3: Table Of Contents
Contents Contents Important safety instructions ...............................2 The SR 2000 IEM and SR 2050 IEM transmitters ........................4 The frequency bank system ................................4 Areas of application .....................................5 Delivery includes .....................................5 Product overview ....................................6 Overview of the SR 2000 IEM/SR 2050 IEM transmitter ......................6 Overview of the displays ..................................7... -
Page 4: Important Safety Instructions
10.Protect the power cord from being walked on or pinched, particularly at plugs, conve- nience receptacles, and the point where they exit from the apparatus. 11.Only use attachments, accessories or spare parts specified by Sennheiser 12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. - Page 5 Intended use Intended use of the SR 2000 IEM and SR 2050 IEM transmitters includes: • having read these instructions, especially the chapter “Important safety instructions”, • using the device within the operating conditions and limitations described in this instruc- tion manual.
-
Page 6: The Sr 2000 Iem And Sr 2050 Iem Transmitters
The SR 2000 IEM and SR 2050 IEM transmitters The SR 2000 IEM and SR 2050 IEM transmitters With the SR 2000 IEM and SR 2050 IEM 2-channel/stereo monitoring transmitters, musi- cians, video and sound amateurs, reporters/broadcasters, etc. can directly monitor the received sound signals without troublesome cables or monitor speakers being required. -
Page 7: Areas Of Application
1 SR 2000 IEM transmitter or 1 SR 2050 IEM twin transmitter 3 mains cables (with EU, UK and US plug) 1 rod antenna (SR 2000 IEM) or 2 rod antennas (SR 2050 IEM) 1 instruction manual 1 frequency information sheet... -
Page 8: Product Overview
Product overview Overview of the SR 2000 IEM/SR 2050 IEM transmitter The SR 2050 IEM twin transmitter has the same operating elements as the SR 2000 IEM transmitter. All informa- tion contained in this instruction manual refers to both transmitters. -
Page 9: Overview Of The Displays
Product overview Overview of the displays After switch-on, the transmitter displays the standard display. PEAK PEAK B.Ch: 5.14 **2050** 552.300 Standard -18dB AF I AF II Display Meaning Audio level Modulation of the left I) and right “AF I” and “AF II”... -
Page 10: Putting The Transmitter Into Operation
You have the following options: • For professional use, we recommend connecting a remote antenna and, if necessary, using Sennheiser antenna accessories (see next section and the chapter “Connecting several transmitters to a remote antenna” on page 9). • If the transmitter is to be put into operation without a large amount of installation work, you can: –... - Page 11 Putting the transmitter into operation • A 2003 UHF passive directional broadband antenna • A 1031 passive omni-directional broadband antenna Use a low-attenuation 50-Ω cable to connect the antenna to the transmitter. If possible, use a short antenna cable and as little connections as possible, since long cables and many connectors lead to an attenuation of the antenna signal.
- Page 12 Putting the transmitter into operation Guide the BNC connector of the BNC extension cable through the hole in the rack mount “ear” ³. Connect the BNC connector to the antenna output ³ Screw the antenna holder to the BNC socket using the supplied washer ³...
-
Page 13: Connecting An Audio Source To The Input Sockets
To do so, proceed as follows: Route a signal from the mixing console to the input socket (in this example: BAL AF IN R of transmitter A. Stereo Transmitter SR 2000 IEM PUSH PUSH PUSH... -
Page 14: Connecting Devices To The Output Sockets
ART NO 503841 DESIGNED AND MADE IN GERMANY DESIGNED AND MADE IN GERMANY SER NO 251810043 SER NO 2518100095 additional SR 2000 IEM or SR 2050 IEM) to the output socket LOOP OUT BAL L(I) and/ Loop Out A ANT B LOOP OUT BAL R(II) (see preceding chapter). -
Page 15: Using The Transmitter
Using the transmitter Using the transmitter To establish a transmission link, proceed as follows: 1. Switch the transmitter on (see below). 2. Switch the EK 2000 IEM receiver on (see the instruction manual of the receiver). The transmission link is established. It is vital to observe the notes on frequency selection on page 22. -
Page 16: Deactivating The Lock Mode Temporarily
Using the transmitter Deactivating the lock mode temporarily You can activate or deactivate the automatic lock mode via the “Auto Lock” menu item. If the lock mode is activated, you have to temporarily deactivate it In order to be able to operate the transmitter: Press the jog dial. -
Page 17: Monitoring The Audio Signal Via Headphones
» Set the headphone volume control to the minimum position. Stereo Transmitter SR 2000 IEM ·. Connect headphones with a ¼” (6.3 mm) stereo jack plug to the headphone output Gradually increase the volume and monitor the audio signal with the lowest possible volume. - Page 18 Using the transmitter Carrying out an Easy Setup Sync or a Sync function The following assumes that you are using the Easy Setup Sync function for setting up a multi- channel system. You can also you the Easy Setup Sync function for establishing a transmis- sion link between one transmitter and one EK 2000 IEM receiver.
- Page 19 Using the transmitter Easy Setup Sync Sync Store the frequency bank and channel – setting by pressing the jog dial on your transmitters. You can carry out the Sync function (see right-hand column) at a later time to establish a transmission link between transmitters and receivers.
-
Page 20: Using The Operating Menu
Overview of the operating menu For more detailed information on the operating menu, refer to the instruction manual of the SR 2000 IEM/SR 2050 IEM which can be downloaded from the SR 2000 IEM/SR 2050 IEM product page at www.sennheiser.com. - Page 21 Using the operating menu Display Function of the menu item Main menu “Menu” Sensitivity Adjusts the input sensitivity Easy Setup Deactivates the RF signal and activates Easy Setup Sync (see page 15) Mode Selects mono or stereo operation Frequency Preset Changes the frequency bank and the channel Name Enters the transmitter name...
-
Page 22: Working With The Operating Menu
Using the operating menu Working with the operating menu If the lock mode is activated, you have to deactivate it In order to be able to work with the operating menu (see page 14). By way of example of the “Frequency Preset”... - Page 23 Using the operating menu To return to the last edited menu item: Press the jog dial repeatedly until the last edited menu item appears. Exiting a menu item Menu Sensitivity Change to the “Exit” menu item. Mode Easy Setup Confirm your selection. Frequency Preset You return to the next higher menu level.
-
Page 24: Synchronizing The Transmitter With An Ek 2000 Iem Receiver
Synchronizing the transmitter with an EK 2000 IEM receiver Synchronizing the transmitter with an EK 2000 IEM receiver When synchronizing your transmitter with an EK 2000 IEM receiver, please observe the following: Only use a transmitter and a receiver from the same frequency range (see the type plate on the transmitter and the receiver). -
Page 25: Cleaning The Transmitter
To ensure that the desired frequencies are intermodulation-free: Contact your Sennheiser partner (see www.sennheiser.com). Set each transmitter to the same frequency bank. On one of the transmitters, select a channel within this frequency bank (see page 19). -
Page 26: If A Problem Occurs
If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”. -
Page 27: Specifications
RF output power at 50 Ω typ. 10/30/50 mW (Low/Standard/High), switchable AF characteristics Modulation wideband FM stereo (MPX pilot tone) Compander system Sennheiser Nominal/peak deviation ±24 kHz/±48 kHz MPX pilot tone (frequency/deviation) 19 kHz/±5 kHz AF frequency response 25 Hz to 15 kHz... -
Page 28: Manufacturer Declarations
Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our web site at www.sennheiser.com or contact your Sennheiser partner. In compliance with the following requirements •... - Page 29 • Consult the dealer or an experienced radio/TV technician for help. This class B digital device complies with the Canadian ICES-003. Changes or modifications made to this equipment not expressly approved by Sennheiser electronic Corp. may void the FCC authorization to operate this equipment.
- Page 30 Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Publ. 07/14, 529682/A03...
