Sharp SMD2470AS Installation Manual page 6

This drawing represents a typical standard cabinet. If installed in custom
cabinets with extended counter tops, take into account visibility and access
to controls. See Figure 7.
B
E
C
D
A
G
F
6
Move oven location downward for
extended countertops
Extended countertops
Figure 7
A. 25"
B. 1/2"
C. 15-7/8"
D. 36"
E. Control panel shown in open position
F. 24"
G. 34-1/2"
