Sharp SMD2470AS Installation Manual page 5

B
M
G
I
J
L
O
Figure 5
F
Figure 6
C
D
F
K
P
I
B
A
C
J
E
A
Cutout Dimension 28
E
A. 6"
B. Suggested electrical outlet location*
C. Anti-Tip block
H
D. 5"
E. 3-1/2"
F. 4"
G. 28-7/16" opening
H. 14-13/16" to bottom of Anti-Tip block
N
I. Allow 3/4" overlap
J. 23-1/2" minimum depth
K. Allow 3/16" overlap
L. 36" countertop height
M. Allow 7/16" overlap
N. Floor must support 100 lb
O. 30" cabinet minimum
P. 15-9/16" opening
G
D
H
5
/ " x 15 / "
7 9
16 16
A. 21-5/8"
B. 4-11/16"
C. 1-3/4"
D. 21-7/8"
E. 29-7/8"
I
F. 15-7/8"
G. 14-19/32"
H. 1-9/64" door thickness
I. 15" auto drawer opening
J. 4"
