Magellan MiVue 5 series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MiVue 5 Series
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MiVue 5 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Magellan MiVue 5 series

Summary of Contents for Magellan MiVue 5 series

  • Page 1 MiVue 5 Series User Manual...
  • Page 3 Connect with us @MagellanGPS Magellan Take-Back Program Magellan’s Take-Back Program provides a way for consumers to recycle certain Magellan equipment. As part of this program, all Magellan GPS models will be accepted. Visit magellanGPS.com for more information.
  • Page 4 The driver should enter data or program the centimeters between the radiator and your body. Magellan receiver only when the vehicle is stopped. Only a vehicle passenger should enter data or Wi-Fi 5G Band 1 is for indoor use only.

  • Page 5: Getting To Know The Recorder

    Getting to know the recorder Device mount socket For the device mount. Mini-USB connector Connects to the charger. HD OUT connector* Connects to an external device. LCD screen Buttons Navigate menu settings LED indicator 1 Indicates the system status of the recorder.

  • Page 6: Power Key

    Power key Once the vehicle engine is started, the recorder automatically turns on. By default, the recording will start right after the recorder turns on. You can do the following using the Power key: ƒ To manually turn the recorder on and off, press and hold the Power key for 2 seconds.

  • Page 7: Using The Function Keys

    Using the Function keys The device provides four function keys to control the corresponding icons displayed at the bottom of the LCD screen. The key’s function may vary on different screens. For example, the device will display four icons as shown below while continuous recording is in progress. Example Button Description...

  • Page 8: Inserting A Memory Card

    ƒ Use a Class 10 memory card with at least 8GB capacity. The recorder supports memory cards with up to 32GB capacity. ƒ Magellan does not guarantee the product’s compatibility with memory cards from all manufacturers. ƒ Before you start recording, please format the memory card to avoid malfunction caused by files not created by the recorder.

  • Page 9: Using Your Recorder In A Vehicle

    Using your recorder in a vehicle 1. Make sure that your car is parked on a level ground. 2. Follow the instruction below to mount your recorder in a vehicle securely. 3. Connect the car charger to the vehicle power plug. Route the cables through the top ceiling and the A-pillar so that it does not interfere with driving.
  • Page 10 4. When adjusting the angle of mounting, make sure that the camera’s view is parallel with the level ground, and you see the entire road on the screen. 5. When not using the recorder, follow the instruction below to remove the recorder from the holder.

  • Page 11: Connecting To External Devices

    Connecting to external devices Connecting to your computer You can connect the recorder to your computer to access data on the memory card. The Mini-USB connector is located on the right side of the device. Follow the instruction below to connect the recorder to the computer via the USB cable (not supplied).

  • Page 12: Operating Basics

    Operating basics Turning the recorder ON and OFF Complete the installation according to the instructions in the “Using your recorder in a vehicle” section. ƒ Once the vehicle engine is started, the recorder automatically turns on. By default, the recording will automatically start in a few seconds after start-up. ƒ...

  • Page 13: Recording In Driving Mode

    the step until all fields have been changed. When completed, press Recording in driving mode NOTE: ƒ DO NOT remove the memory card while recording. ƒ If the recording (including continuous recording, event recording and parking recording) is ongoing but there is not enough space on your memory card, the system will display a warning message on the screen.

  • Page 14: Camera Mode

    To stop event recording and resume continuous recording, press ƒ The event recordings can be found in the “Emergency” category for playback. Recording in Parking mode Your recorder supports parking recording function. Depending on how long the car is parked, you may need an external power source (e.g. a power bank) to record the video while the device's power cable is disconnected.

  • Page 15: Playback Mode

    ƒ If the recording is in progress, press to take a photo. ƒ The photos can be found in the “Photo” category for playback. Playback mode To select a video or photo for playback: 1. Press to access the Settings Menu. 2.

  • Page 16: System Settings

    System settings Settings Menu To customise the system settings, press Item Description File Playback Plays the recorded videos and photos. For more information on playback, see the "Playback mode" section. Record Voice Sets if you want to include sounds in the recordings. The default setting is On.
  • Page 17 (1 min, 3 min, or 5 min). - EV: Sets the proper exposure level (-1 ~ +1) to adjust the brightness of the image. The default setting is 0. - HDR: Select On or Off to enable or disable High Dynamic Range function of the device.

  • Page 18: Installing Mivue Manager

    MiVue Manager MiVue Manager is a tool for you to view the videos recorded on a MiVue recorder. Not all features are available for every model. IMPORTANT! Your computer needs MOV and AVI codecs to play the recording files. Please visit www.MagellanGPS.com to install the required codecs. Installing MiVue Manager Download the Setup file from www.MagellanGPS.com.
  • Page 19 NOTE: ƒ The Map screen may not appear when the computer is not connected to the Internet or when your MiVue model records without the GPS function. ƒ G sensor chart displays data in 3-axis waveform about the car’s shift forward/backward (X), to the right/left (Y) and upward/downward (Z).
  • Page 20 6. The playback controls are described as follows: 6-1. Skips to the previous / next file on the list. 6-2. Starts or pauses the playback. 6-3. Changes the playback speed to 1/4x, 1/2x, 1x (default), 1.5x, or 2x. 6-4. Mutes or unmutes the volume. 6-5.
  • Page 21 8-3. Saves the selected files to the specified location on your computer. 8-4. Captures and saves the current video image to the specified location on your computer. 8-5. Opens the Settings Menu. The Settings items are described as follows: - Change Language: Sets the display language of MiVue Manager. - Change Skin: Sets the color scheme of MiVue Manager.

  • Page 22: Caring For Your Device

    For more information Caring for your device Taking good care of your device will ensure trouble-free operation and reduce the risk of damage. ƒ Keep your device away from excessive moisture and extreme temperatures. ƒ Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time.

  • Page 23: Precautions And Notices

    ƒ Overheating may damage the device. Precautions and notices ƒ For your own safety, do not operate the controls of the product while driving. ƒ A window mount is needed when using the recorder in a car. Make sure that you place the recorder in an appropriate place, so as not to obstruct the driver’s view or deployment of airbags.
  • Page 24 ƒ Do not attempt to service the unit. There are no serviceable parts inside. Replace the unit if it is damaged or exposed to excess moisture. About the battery CAUTION! This unit contains a non-replaceable internal Lithium Ion battery. The battery can burst or explode, releasing hazardous chemicals.
  • Page 25 CONSUMER PURCHASER OF THIS PRODUCT. The purchaser must return the product postpaid with (b) In the event of a defect, Magellan will, at its a copy of the original sales receipt, purchaser’s return discretion, repair or replace the hardware product with...
  • Page 26 VARY FROM LOCALITY TO LOCALITY AND CERTAIN the receiver that may be required due to any change LIMITATIONS CONTAINED IN THIS WARRANTY MAY in the GPS. (Note: Magellan GPS receivers use GPS NOT APPLY TO YOU. or GPS+GLONASS to obtain position, velocity and time (b) If any part of this limited warranty is held to be information.
  • Page 27 Need Technical Support? If you need technical support for your Magellan receiver you should first go to www.magellangps.com/support for answers to most questions. If you can’t find a solution there, you can contact Magellan Technical Support directly by e-mail at support.us@cs.magellangps.com...
