Page 1 Introduction Welcome to the worldwide family of Volvo owners. We hope that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
Page 2 2005 Volvo S40 Your Volvo is designed to meet all applicable safety and emission standards, as indicated by the certification labels attached to the driver's door opening, and on the underside of the hood. For further information please contact your retailer, or:...
Page 3 Volvo and the environment Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact. Volvo's environmental activities are based on a holistic view, which means we consider the overall environmental impact of a product throughout its complete life cycle.
Page 4: Table Of Contents
Properly dispose of any vehicle-related waste such as used motor oil, used batteries, brake pads, etc. When cleaning your car, use Volvo's own car care products, all of which have systematically been adapted to the environment.
Page 5 2005 Volvo S40 Top of Page http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_00.htm (5 of 5)8/12/07 12:11 AM...
Page 6: Instrument Overview
2005 Volvo S40 2 0 0 5 VOLVO Chapter 1 - Instrument overview pg. 8 Instrument overview pg. 9 Instrument overview 1. Steering wheel adjustment 2. Hood opener 3. Controls in driver's door 4. Turn signals, high beams, trip computer 5.
Page 7 2005 Volvo S40 9. Cruise control 10. Horn, airbag 11. Main instrument panel 12. Audio controls (option) 13. Windshield wipers and washers, headlight washers (certain models) 14. Ignition key 15. Rear-view mirror and optional compass 16. Seat belt reminder 17. Driver's side reading light 18.
Page 8 2005 Volvo S40 Contents Top of Page http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_01a.htm (3 of 3)8/12/07 12:12 AM...
Page 9 Occupant safety Volvo's concern for safety Safety is Volvo's cornerstone. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
Page 10: Safety
However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1- 800-424-9393 (or 202-366-0123 in Washington, D.C. area) or write to: NHTSA, U.
Page 11 Using seat belts Not wearing a seat belt is like believing "It'll never happen to me!" Volvo, the inventor of the three-point seat belt, urges you and all occupants of your vehicle to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
Page 12 Tightening the lap belt WARNING! Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
Page 13 2005 Volvo S40 Child seats Please refer to page 35 for information on securing child seats with the seat belts. Seat belt use during pregnancy Pregnant women should always wear seat belts. Remember that the belt should be positioned in such a way as to avoid any possible pressure on the abdomen.
Page 14 Components in the SRS system Front airbags Your Volvo is equipped with a Supplemental Restraint System (SRS), which consists of front airbags that enhance the three-point seat belt system. The Volvo SRS system includes gas generators (1) surrounded by the airbags (2) and front seat belt tensioners for both of the front seats. To deploy the system, the sensor (3) activates the gas generators causing the airbags to be inflated with nitrogen gas.
Page 15 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the vehicle.
Page 16 2005 Volvo S40 Occupant Weight Sensor (OWS) indicator light Disabling the passenger's side front airbag The passenger's side front airbag is automatically enabled/disabled by the Occupant Weight Sensor (OWS), a system that monitors the weight of the person or object in the front passenger's seat. The...
Page 17 In this case, the safety systems and Occupant Weight Sensor should be inspected by an authorized Volvo retailer as soon as possible. pg. 20 Front airbags (Supplemental Restraint System - SRS)
Page 18 2005 Volvo S40 WARNING! Never try to open, remove, or repair any components in the OWS system. This could result in system malfunction. Maintenance or repairs should only be carried out by an authorized Volvo service technician. WARNING! Keep the following points in mind with respect to the OWS system. Failure to follow these...
Page 19 If the airbags have been deployed, we recommend the following: Have the vehicle towed to an authorized Volvo retailer. Never drive with the airbags deployed. Have an authorized Volvo retailer replace the SRS system components.
Page 20 If the safety system warning light stays on after the engine has started or if it comes on while you are driving, drive the vehicle to the nearest authorized Volvo retailer for inspection as soon as possible. There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of airbags and seat belt tensioners.
Page 21 23 Front airbags (Supplemental Restraint System - SRS) SRS text on passenger's dash Should you have any questions about the SRS system, please contact your authorized Volvo retailer or Volvo Customer Support: In the USA In Canada Volvo Cars of North America, LLC Volvo Cars of Canada Ltd.
Page 22 SRS text on inside of both sun visors WARNING! Children must never be allowed in the front passenger's seat. Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the back seat of any vehicle with a passenger-side front airbag.
Page 23 Never try to open the SRS cover on the steering wheel or the passenger's side dashboard. This should only be done by an authorized Volvo service technician. Failure to follow these instructions can result in injury to the vehicle occupants.
Page 24 2005 Volvo S40 2 0 0 5 VOLVO pg. 25 Side impact protection (SIPS) airbags Side impact (SIPS) airbag Side impact airbags - front seats only As an enhancement to the structural side impact protection built into your car, the car is also equipped with Side Impact Protection System (SIPS) airbags.
Page 25 Failure to follow these instructions can result in injury to the occupants of the vehicle in the event of an accident. pg. 26 Volvo Inflatable Curtain (VIC) The Volvo Inflatable Curtain system This system consists of inflatable curtains located along the sides of the roof liners, stretching from the center of both front side windows to the rear edge of the rear side door windows.
Page 26 The VIC system is a supplement to the Side Impact Protection System. It is not designed to deploy during collisions from the front or rear of the car or in rollover situations. Never try to open or repair any components of the VIC system. This should be done only by an authorized Volvo service technician.
Page 27 2005 Volvo S40 pg. 29 WHIPS WARNING! If the rear seat backrests are folded down, cargo must be secured to prevent it from sliding forward against the front seat backrests in the event of a collision from the rear. This could interfere with the action of the WHIPS system.
Page 28 Even if the car appears to be drivable after COLLISION STATUS has been set, it should not be driven or towed (pulled by another vehicle). There may be concealed damage that could make it difficult or impossible to control. The car should be transported on a flatbed tow truck to an authorized Volvo workshop for inspection/ repairs.
Page 29 2005 Volvo S40 pg. 31 Inspecting safety system components Inspection date 1. Driver's side airbag 2. Passenger's side airbag 3. Side airbag on the driver's side 4. Side airbag on the passenger's side 5. Driver's side inflatable curtain 6. Passenger's side inflatable curtain This is a sample of the decal located in the left rear door opening.
Page 30 2005 Volvo S40 Children should be seated safely Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car. Your car is also equipped with ISOFIX/ LATCH attachments, which make it more convenient to install child seats.
Page 31 33 Child safety A specially designed and tested booster cushion (not available in Canada) can be obtained from your Volvo retailer for children weighing 33 - 80 lb. (15 - 36 kg) and 38-54 inches (97 - 137 cm) in height.
Page 32 2005 Volvo S40 Integrated booster cushion Volvo's optional integrated booster cushions are located in the outboard seating positions. These booster cushions have been specially designed to help safeguard a child seated in the rear seat. These seats should be stowed (folded down into the seat cushion) before installing accessory child seats.
Page 33 2. Push the cushion forward/downward. NOTE: Canada only: This cushion may be referred to as a built-in booster cushion. WARNING! The booster cushion should be cleaned while in place in the vehicle if possible. If not, please consult your Volvo retailer. WARNING! DEATH or SERIOUS INJURY can occur Follow all instructions on the booster cushion and in the vehicle's owner's manual.
Page 34 2005 Volvo S40 Child restraint anchorages Volvo cars are equipped with child restraint top tether anchorages in the rear seat. Refer to the child seat manufacturer's instructions for information on securing the child seat. WARNING! Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints.
Page 35 2005 Volvo S40 Why does Volvo believe that no child should sit in the front seat of a car? It's quite simple really. A front airbag is a very powerful device designed, by law, to help protect an adult. Because of the size of the airbag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly belted or strapped into a child safety seat.
Page 36: Instruments And Controls
2005 Volvo S40 2 0 0 5 VOLVO Chapter 3 - Instruments and controls pg. 37 Instruments and controls Instrument panel 38 Indicator and warning symbols 39 Symbols on the left side of the instrument panel 40 Symbols on the right side of the instrument panel 41...
Page 37 2005 Volvo S40 Home Link® Universal Transceiver (option) 63 pg. 38 Instrument panel 1. Speedometer 2. Turn signal, left 3. Warning symbol See the next page for additional information. 4. Information display The display presents information and warning messages, the ambient temperature, and the clock, etc.
Page 38 2005 Volvo S40 8. Indicator and warning symbols 9. Fuel gauge The fuel tank holds approximately 15.9 US gallons (60 liters) . When a warning light in the gauge comes on, there are approximately 2.1 US gallons (8 liters) of fuel remaining in the tank.
Page 39 1. Stop the car as soon as possible in a suitable location. 2. Read the message in the information display. 3. Follow the instructions provided, or contact an authorized Volvo Retailer or workshop. Information symbol The yellow information symbol lights up to alert the driver to a message in the information display. This symbol may also light up in combination with other indicator or warning symbols.
Page 40 2. Anti-lock brake system (ABS) If the warning light comes on, there is a malfunction of the ABS system (the standard braking system will still function). The vehicle should be driven to a Volvo retailer for inspection. See page 113 for additional information.
Page 41 2005 Volvo S40 This indicator symbol flashes when the STC (Stability and Traction control system) or the DSTC (Dynamic Stability and Traction control system) is actively working to stabilize the car. See page 116 for more detailed information. 5. Not in use 6.
Page 42 If this light comes on while the car is being driven, or remains on for longer than approximately 10 seconds after the car has been started, the safety system's diagnostic functions have detected a fault in a seat belt lock, SRS, SIPS, and/or VIC system. Drive to an authorized Volvo retailer to have the system (s) inspected.
Page 43 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the information display: DO NOT DRIVE. Have the car towed to an authorized Volvo retailer and have the brake system inspected. pg. 42 Symbols on the right side of the instrument panel If the BRAKE and ABS warning lights come on at the same time, this could indicate a fault in the brake system.
Page 44 Stop and switch off the engine to help prevent the risk of serious STOP ENGINE damage. Take your car to an authorized Volvo retailer for inspection as SERVICE URGENT soon as possible. Refer to your owner's manual. For additional information, please SEE MANUAL contact your Volvo retailer.
Page 45 I (or higher) for the auxiliary socket to function. The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. NOTE: The cover should be kept on when the auxiliary socket is not in use.
Page 46 NOTE:The anti-spin function will be automatically reactivated when the engine is started Auxiliary equipment The button to the right of the STC/DSTC button can be used for Volvo-installed optional or auxiliary equipment. pg. 45 Lighting panel 1. Headlights and parking lights All lighting off.
Page 47 2005 Volvo S40 darkness, the daytime running lights will switch off and the Bi-Xenon headlights will switch on. Parking lights When the switch is in this position, the front and rear parking lights, license plate lights, and instrument panel lighting will be on. The parking lights should be switched off when you leave the car to help avoid battery drain.
Page 48 2005 Volvo S40 Manually releasing the fuel filler door If it should be necessary, the fuel filler door can be opened manually from the inside the trunk. To do so: 1. Move the cover panel to one side. 2. This exposes a handle, located near the fuel filler door locking mechanism.
Page 49 2005 Volvo S40 Move the lever toward the steering wheel and release it to switch between high and low beams. With the headlights off: headlight flasher (3) With the headlights switched off (the switch on the lighting panel in position 0), move the lever toward the steering wheel.
Page 50 2005 Volvo S40 pg. 48 Left-side steering wheel lever NOTE: Warning messages from the car's monitoring systems will override the trip computer function. If a warning message is shown in the information display while you are using the trip computer, you must acknowledge the message by pressing the READ button (A).
Page 51 2005 Volvo S40 pg. 49 Cruise control (option) Cruise control The cruise control buttons are located on the left side of the steering wheel hub. Engaging the cruise control function 1. Press the CRUISE button. CRUISE will appear in the function display in the center of the instrument panel.
Page 52 2005 Volvo S40 Increasing or decreasing speed Use + or - in the following ways to increase or decrease the vehicle's speed: Press and hold down + or - until the vehicle reaches the desired speed. This will become the set speed when the button is released.
Page 53 2005 Volvo S40 Press the button to resume the previously set speed. (contd. on next page) pg. 50 Cruise control (option) Disengaging cruise control Cruise control can also be disengaged by: Pressing the CRUISE button (CRUISE ON will no longer be shown in the function display.
Page 54 2005 Volvo S40 Windshield wipers off The windshield wipers are off when the lever is in position 0 Manual wiper function From position 0, move the lever upward. The windshield wipers will sweep one stroke at a time for as long as the lever is held up.
Page 55 2005 Volvo S40 Optional Bi-Xenon headlights will be washed once for every five times the windshield is washed. Normal halogen headlights will not be washed. Headlights off Optional Bi-Xenon headlights will be washed once for every five times the windshield is washed.
Page 56 2005 Volvo S40 Pressing button (B). Moving the windshield wiper lever down. If the lever is moved up, the rain sensor function will remain activated. CAUTION! The rain sensor should be deactivated when washing the car in an automatic car wash, etc. If the rain sensor function is left on, the wipers will start inadvertently in the car wash and could be damaged.
Page 57 2005 Volvo S40 2 0 0 5 VOLVO pg. 53 Steering wheel adjustment, Hazard warning flashers Steering wheel adjustment Both the height and the reach of the steering wheel can be adjusted to a comfortable position for the driver. 1. Pull down the lever on the steering column to release the steering wheel.
Page 58 2005 Volvo S40 Hazard warning flashers Check that the steering wheel is locked in the new position. WARNING! Never adjust the steering wheel while driving. Hazard warning flashers The four-way flasher should be used to indicate that the vehicle has become a traffic hazard. To activate the flashers, press the triangular button in the center dash.
Page 59 2005 Volvo S40 Parking brake (hand brake) The parking brake lever is located between the front seats. The parking brake is applied to the rear wheels. The indicator light in the instrument panel lights up when the brake is applied.
Page 60 Maximum current from the sockets is 10A. Ashtrays/cigarette lighter The auxiliary sockets can also be used for cigarette lighters. Ashtrays and lighters are available as accessories. Please contact your Volvo retailer. pg. 55 Power windows A. Front door windows, B. Rear door windows Operation The power windows are controlled by buttons in the arm rests.
Page 61 2005 Volvo S40 Press the front part of any of the buttons (A or B) as far down as possible and release it to automatically open the window completely. To stop the window at any time, pull the button up.
Page 62 2005 Volvo S40 Power window control - front passenger's side The control for the power window in the front passenger's door operates that window only. Power windows in the rear doors The rear door windows can be operated with the control on each door and with the switch on the driver's door.
Page 63 2005 Volvo S40 Rearview mirror Night position Use control (1) to switch between the normal and night-driving positions. 2. Normal position 3. Night position, reduces glare from following traffic Auto-dim function (option) An optional sensor (4) at the lower edge of the mirror, reacts to headlights from following traffic and automatically reduces glare.
Page 64 2005 Volvo S40 direction toward which the car is pointing. Eight different directions can be displayed: N, NE, E, SE, S, SW, W and NW. The display shows your car's orientation with respect to true north. Calibrating the compass The compass may need to be calibrated in certain cases. If calibration is required, the character C appears in the mirror's display.
Page 65 2005 Volvo S40 Magnetic zones Adjusting the zone The earth is divided into 15 magnetic zones. The compass is adjusted for the zone to which the car was delivered. Select a different zone as follows: 1. Turn on the ignition.
Page 66 2005 Volvo S40 Power door mirrors The mirror control switches are located on the driver's door armrest. To adjust the mirrors: Driver's door mirror: Press the L button (a light in the switch will go on) to activate the adjustment control.
Page 67 2005 Volvo S40 Moonroof control in the ceiling console 1. Auto open 2. Manual open 3. Manual close 4. Auto close 5. Tilt open 6. Tilt close Tilt position Open: Press the rear edge of the control upward to position 5.
Page 68 2005 Volvo S40 WARNING! If the moonroof is obstructed during autoclose operation, it will automatically reverse direction and return to its starting position. During manual closing, if the moonroof is obstructed, immediately open it again. pg. 60 Power moonroof (option) NOTE: If the moonroof is repeatedly obstructed during auto-close operation, an overload circuit breaker will temporarily halt moonroof function.
Page 69: Climate
2005 Volvo S40 is opened, and must be closed manually. pg. 61 Personal settings Control panel Control panel A - Display B - Menu button C - Exit button D - Enter button E - Menu navigation controls Personal settings can be made for some of the car's functions, such as the central locking system, climate control, and the audio system.
Page 70 2005 Volvo S40 pg. 62 Personal settings Possible settings Lock confirmation light When the car is locked/unlocked with the remote control, the direction indicators can be selected to flash to confirm the action. The alternatives On/Off are available for both locking and unlocking.
Page 71 2005 Volvo S40 depending on the ambient temperature. Select On/Off depending on whether the recirculation timer is to be active or not. Reset to factory settings Use this alternative to return to the default climate system settings. pg. 63 Home Link® Universal Transceiver (option)
Page 72 2005 Volvo S40 tollfree 1-800-355-3515 (Internet: www.HomeLink.com). 4. Using two hands, push and hold both your hand-held transmitter's button and the transceiver button you wish to program. The indicator light will flash first slowly, then rapidly. Rapid flashing indicates that the HomeLink button has been successfully programmed. Release both buttons.
Page 73 2005 Volvo S40 To train a rolling code garage door opener, follow these instructions after programming the desired transceiver button according to "Programming the transceiver." The help of a second person may make training easier. 1. Locate the training button on the garage door opener motor head unit. The location and color of the training button may vary.
Page 74 2005 Volvo S40 held transmitter 2 to 5 in. (5 to 12 cm) away from the HomeLink surface. 3. Press and hold the hand-held transmitter button. The HomeLink indicator light will flash first slowly, then rapidly. When the indicator light flashes rapidly, release both buttons.
Page 75 Climate control maintenance Your Volvo retailer has the tools and equipment required to maintain and carry out any necessary repairs on the climate system. Work of this type should only be done by an authorized Volvo service technician. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free...
Page 76 Replace the cabin air filter with a new one at the recommended intervals. Please refer to your Warranty and Service Records Information booklet, or consult your Volvo retailer for these intervals. The filter should be replaced more often when driving under dirty and dusty conditions. The filter cannot be cleaned and therefore should always be replaced with a new one.
Page 77 2005 Volvo S40 Air vents in the dashboard A. Open B. Closed C. Horizontal air flow D. Vertical air flow Direct the outer air vents toward the side windows to defrost. pg. 70 Manual climate control Climate system control panel 1.
Page 78 2005 Volvo S40 7. Heated front passenger's seat 8. Rear window and door mirror defrosters 9. Temperature selector Manual climate system functions 1. Blower speed The blower speed can be increased or decreased by turning the knob. If the knob is turned counterclockwise and the indicator light in the display goes out, the blower and the air conditioning are switched off.
Page 79 2005 Volvo S40 4. Airflow controls Press one of the three buttons in the illustration to activate the selected airflow. A symbol in the display above the climate control panel and a lit LED in the selected button indicate that the manual function has been selected.
Page 80 2005 Volvo S40 passenger's sides of the car. pg. 72 Electronic climate control (ECC) 1. Auto - On/Off 2. Blower speed 3. Recirculation 4. Defroster 5. Airflow controls 6. A/C - ON/OFF 7. Heated driver's seat 8. Heated front passenger's seat 9.
Page 81 2005 Volvo S40 automatically. All manual settings are switched off when AUTO is switched on. AUTO CLIMATE is shown in the display. 2. Blower speed The blower speed can be increased or decreased by turning the knob. The blower speed is regulated automatically if AUTO is selected.
Page 82 2005 Volvo S40 Directs airflow to the windshield and side windows and increases blower speed. The LED in the defroster button lights up when this function is activated. The air conditioning system is controlled to provide maximum air dehumidification. The air is not recirculated.
Page 83 2005 Volvo S40 Press to defrost the rear window and door mirrors. The rear window and door mirrors are defrosted simultaneously if the switch is pressed once. The function is active if one LED is lit in the switch. The door mirrors are deactivated automatically after approximately 6 minutes.
Page 84 2005 Volvo S40 Defroster. Air is not recirculated in this mode. Defrost/de-fog the windshield and front Air conditioning is always engaged. side windows. There is a certain amount of airflow to the panel air vents. Air to windshield and front side Prevents fogging in cold or humid weather windows.
Page 85 2005 Volvo S40 pg. 76 This page intentionally left blank Contents Top of Page http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_04a.htm (11 of 11)8/12/07 12:16 AM...
Page 86: Interior
2005 Volvo S40 2 0 0 5 VOLVO Chapter 5 - Interior pg. 77 Interior Front seats 78 Interior lighting 81 Storage compartments Rear seat 84 Trunk 86 pg. 78 Front seats Manual seat adjustment The driver's and passenger's seats can be adjusted in a number of ways to provide a comfortable driving...
Page 87 2005 Volvo S40 and sitting position. 1. Forward-rearward: Pull the lever up and slide the seat to the position of your choice. 2. Use this control to raise or lower the front edge of the seat cushion. 3. Use this control to raise or lower the rear edge of the seat cushion.
Page 88 2005 Volvo S40 pg. 79 Front seats Power seats The power driver's seat can be adjusted: If the ignition key is in position I or II. During a 10 minute period after the doors have been unlocked if the door remains open.
Page 89 2005 Volvo S40 The following example explains how button 1 can be programmed. Buttons 2 and 3 can be programmed in the same way. To program (store) a seat position in button 1: 1. Use controls 5, 6, and 7 to adjust the seat to the desired position.
Page 90 2005 Volvo S40 Vanity mirror Raise the cover to switch on the light. pg. 81 Interior lighting A - Driver's side reading light, B - Courtesy lighting, C - Passenger's side reading light Interior lighting The reading lights can be switched on and off by pressing buttons A or C. The function selector (B) can be set to three positions: Press the left side of the switch: the interior courtesy lighting is always on.
Page 91 2005 Volvo S40 a dimmer when the door is closed. Press the right side of the switch: the interior courtesy lighting is always off. Courtesy lighting - automatic function The interior lighting has a built-in automatic function that switches on the courtesy lighting for 30...
Page 92 2005 Volvo S40 pg. 83 Storage compartments 1. Storage pocket (also on front side of seat cushion) 2. Compartment in door panel 3. Ticket clip 4. Glove compartment 5. Waste bin (accessory), located behind the center instrument panel 6. Storage compartment and cup holders 7.
Page 93: Locks And Alarm
2005 Volvo S40 Glove compartment The owners manual and maps can be stored here. There are also holders for coins, pens and fuel cards. The glove compartment can only be locked and unlocked using the detachable key blade from the central locking system's remote control.
Page 94 2005 Volvo S40 To lower: Press the catch at the base of the right support and press the head restraint down. To remove: Pull the head restraint up far as possible. Press the catch at the base of the right support and pull the head restraint out of the its holders.
Page 95 2005 Volvo S40 3. Fold the backrest down partially and remove the outer head restraints. Press the center head restraint down completely or remove it. pg. 85 Rear seat 4. Place the head restraints in the plastic tubes, which are now accessible on the under side of the seat cushions.
Page 96 2005 Volvo S40 Auxiliary 12 volt socket (option) Fold down the lid to use the socket. Using the 12 volt socket while the engine is not running drains the vehicle's battery. If the ignition is switched off and a device drawing more that 0.1A is connected to a socket, a battery alert will be shown in the driver information display.
Page 97 2005 Volvo S40 Contents Top of Page http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_05a.htm (12 of 12)8/12/07 12:16 AM...
Page 98 2005 Volvo S40 2 0 0 5 VOLVO Chapter 6 - Locks and alarm pg. 87 Locks and alarm Remote control and key blade 88 Locking and unlocking 92 Locking the glove compartment, Child safety locks Alarm 94 pg. 88 Remote control and key blade Remote controls Two remote controls that also function as ignition keys are provided with your car.
Page 99 Loss of a remote control If either of the remote controls is lost, the other must be taken with the car to a Volvo retailer. As an anti- theft measure, the code of the lost remote control must be erased from the system.
Page 100 2005 Volvo S40 Remote control functions 1. Lock - Press the Lock button on the remote once to lock all doors and the trunk. The turn signals will flash once to confirm locking. 2. Unlock - Press the Unlock button on the remote once to unlock the driver's door. The turn signals will flash twice to confirm unlocking.
Page 101 2005 Volvo S40 pg. 90 Remote control and key blade Removing the key blade Key blade The key blade can be removed from the remote control. When removed, the key blade can be used as follows: To lock/unlock the driver's door...
Page 102 2005 Volvo S40 Reinserting the key blade in the remote control Hold the remote control with the pointed end down. Carefully slide the key blade into its groove. Gently press the key blade in the groove until it clicks into place.
Page 103 6. Press the cover back into place and tighten the screw. 7. Reinsert the key blade in the remote control. NOTE: The old battery should be disposed of properly at a recycling center or at your Volvo retailer. pg. 92 Locking and unlocking...
Page 104 2005 Volvo S40 Locking/unlocking the car from the inside The switches near the door opening handles on the driver's and front passenger's doors can be used to lock or unlock all doors and the trunk, and to set the alarm.
Page 105 2005 Volvo S40 Opening the trunk from the inside U.S. models only The car is equipped with a florescent handle on the inside of the trunk lid, which can be used in an emergency situation to open the trunk from the inside.
Page 106 2005 Volvo S40 Manual child safety locks, rear doors The controls are located on the rear inside edges of the doors, and are only accessible when the doors are open. Use the ignition key blade or a screwdriver to turn the control.
Page 107 The message "ALARM TRIGGERED, CHECK CAR" will also be displayed. Fault in the alarm system: If a fault has been detected in the alarm system, a message will be shown in the information display. Contact your Volvo retailer to have the alarm system inspected and repaired if necessary.
Page 108 2005 Volvo S40 approximately 5 minutes. Temporarily turning off the accessory alarm sensor(s) In certain situations it may be desirable to turn off the accessory inclination and movement alarm sensors if, for example, you drive your vehicle onto a ferry where the rocking of the boat could trigger the alarm or if a pet is left in the vehicle with the doors locked.
Page 109: Starting And Driving
2005 Volvo S40 2 0 0 5 VOLVO Chapter 7 - Starting and driving pg. 97 Starting and driving General information 98 Fuel requirements 101 Starting the vehicle 104 Manual transmission 107 Automatic transmission - Geartronic 108 All Wheel Drive (option) 110...
Page 110 2005 Volvo S40 pg. 98 General information Economical driving conserves natural resources Better driving economy may be obtained by thinking ahead, avoiding rapid starts and stops and adjusting the speed of your vehicle to immediate traffic conditions. Observe the following rules: Bring the engine to normal operating temperature as soon as possible by driving with a light foot on the accelerator pedal for the first few minutes of operation.
Page 111 It is therefore advisable to check the state of charge more frequently and spray an anti-rust oil on the battery posts. Volvo recommends the use of snow tires on all four wheels for winter driving - see the chapter http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_07a.htm (3 of 16)8/12/07 12:17 AM...
Page 112: Wheels And Tires
An LED in the button will light up to indicate that W is engaged. This mode may be selected for starting/moving off on slippery roads. Before a long distance trip It is always worthwhile to have your vehicle checked at a Volvo retailer before driving long distances. http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_07a.htm (4 of 16)8/12/07 12:17 AM...
Page 113 Check all lights, including high beams. Reflective warning triangles are legally required in some states/provinces. Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel. Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.
Page 114 (MMT). If such fuels are used, your Emission Control System performance may be affected, and the Check Engine Light (malfunction indicator lamp) located on your instrument panel may light. If this occurs, please return your vehicle to an authorized Volvo retailer for maintenance.
Page 115 2005 Volvo S40 Use of Additives With the exception of fuel line antifreeze during winter months, do not add solvents, thickeners, or other store-bought additives to your vehicle's fuel, cooling, or lubricating systems. Overuse may damage your engine, and some of these additives contain organically volatile chemicals. Do not needlessly expose yourself to these chemicals.
Page 116 If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 104 Starting the vehicle...
Page 117 WARNING! Volvo's floor mats are specially manufactured for your car. They must be firmly secured in the clips on the floor so that they cannot slide and become trapped under the pedals on the driver's side.
Page 118 2005 Volvo S40 WARNING! Always place the gear selector in Park and apply the parking brake before leaving the vehicle. Never leave the vehicle unattended with the engine running. Always open garage doors fully before starting the engine inside a garage to ensure adequate ventilation.
Page 119 2005 Volvo S40 III - Start position Release the key when the engine starts. The key returns automatically to the Drive position. A chime will sound if the key is left in the ignition and the driver's door is opened.
Page 120 2005 Volvo S40 5-speed manual transmission (option on certain models) Depress the clutch pedal completely when changing gears Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy.
Page 121 2005 Volvo S40 WARNING! An extra mat on the driver's floor can cause the accelerator pedal and/or the clutch pedal to catch. Check that the movement of these pedals is not impeded. Not more than one protective floor covering may be used at one time.
Page 122 2005 Volvo S40 Shift gate positions Depress the button on the front of the gear selector knob to move the selector between the R, N, D, and P positions. The gear selector can be moved freely between the Geartronic (manual shifting) and (D)rive positions while driving.
Page 123 2005 Volvo S40 Manual shifting - Geartronic The manual shifting mode (Geartronic) can be selected at any time, including while the car is moving. To access the (M)anual shifting position from (D)rive, move the gear selector to the right to M.
Page 124 2005 Volvo S40 accelerator pedal slightly. Kickdown can be used for maximum acceleration or when passing at highway speeds. NOTE: The gear selector must be in the D (Drive) position for kickdown to function. Shiftlock override Shiftlock prevents the gear selector from being moved out of Park unless the ignition key is in position II and the brake pedal is depressed.
Page 125 110 All Wheel Drive (option) All Wheel Drive (AWD) - general information Your Volvo can be equipped with permanent All Wheel Drive (option), which means that power is distributed automatically between the front and rear wheels. Under normal driving conditions, most of the engine's power is directed to the front wheels.
Page 126 If the fluid level is below the MIN mark in the reservoir or if a brake system message is shown in the information display: DO NOT DRIVE. Have the vehicle towed to a Volvo retailer and have the brake system inspected.
Page 127 If the BRAKE and ABS warning symbols light at the same time, there may be a problem in the brake system. If the brake fluid level is normal in these circumstances, drive carefully to the nearest Volvo workshop to have the brake system checked.
Page 128 2005 Volvo S40 This function cannot be disabled. Spin control - SC The spin control function is designed to help prevent the drive wheels from spinning while the vehicle is accelerating. This is done by temporarily reducing engine torque to the drive wheels, which helps improve tractive force.
Page 129 The STC or DSTC system has been switched off because of faults. 1. Stop the car in a safe place and switch off the engine. 2. Restart the engine. If the warning symbol remains lit, drive to a Volvo workshop to have the system checked. http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_07b.htm (5 of 15)8/12/07 12:17 AM...
Page 130 2005 Volvo S40 WARNING! The car's handling and stability characteristics will be altered if the STC or DSTC system functions have been disabled. pg. 115 Rear park assist General description The rear park assist system is designed to assist you when backing into parking spaces, garages, etc. It utilizes ultrasound sensors located in the rear bumper to gauge distance, and provides an audible signal when the vehicle is being backed close to another vehicle, object, or a person.
Page 131 2005 Volvo S40 Reactivating park assist Press the Enter button in the center control panel to reactivate the system. The text PARK ASSIST ACTIVATED, EXIT TO DEACTIVATE will be shown in the display in the center console. NOTE: Towing a trailer, carrying bicycles in a rear-mounted carrier, etc, could trigger the rear park assist system's sensors.
Page 132 Towing a vehicle with all four wheels on the ground WARNING! Volvo does not recommend towing a disabled vehicle behind another vehicle. Significant difficulty in steering and braking, combined with unfavorable weather, traffic, and road conditions may make it impossible to maintain vehicle control.
Page 133 2005 Volvo S40 4. Place the gear selector in neutral. For vehicles with automatic transmissions, follow instruction on page 109, "Shiftlock override" to allow the gear selector to be moved from the Park position. 5. Keep firm pressure on the brake pedal while releasing the parking brake.
Page 134 2005 Volvo S40 Towing vehicles with front wheel drive Volvo recommends the use of flat bed equipment for towing vehicles with front wheel drive. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the vehicle.
Page 135 2005 Volvo S40 Follow these instructions to jump start your vehicle's dead battery or to jump start another vehicle's dead battery using your vehicle. If the 12-volt auxiliary battery to be used is in another vehicle, check that the vehicles are not touching to prevent premature completion of a circuit. Be sure to follow jump starting instructions provided for the other vehicle.
Page 136 More frequent vehicle maintenance is required. Remove the ball and drawbar assembly when the hitch is not being used Volvo recommends the use of synthetic engine oil when towing a trailer over long distances or in http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_07b.htm (12 of 15)8/12/07 12:17 AM...
Page 137 Never connect a trailer's hydraulic brake system directly to the vehicle brake system, nor a trailer's lighting system directly to the vehicle lighting system. Consult your nearest authorized Volvo retailer for correct installation. When towing a trailer, the trailer's safety wire must be correctly fastened to the hole or hook provided in the trailer hitch on the vehicle.
Page 138 2005 Volvo S40 A - ball holder (1 7/8" ball), B - locking bolt, C - cotter pin, D - hitch assembly, E - safety wire attachment Installing the ball holder 1. If necessary, remove the cotter pin from the locking bolt and slide the locking bolt out of the hitch assembly.
Page 139 Volvo-approved removable roof racks are designed to carry the maximum allowable roof load for this vehicle: 165 lbs (75 kg). For Non-Volvo roof racks, check the manufacturer's weight limits for the rack. Never exceed the rack manufacturer's weigh limits and never exceed the maximum rated roof load of 165 lbs (75 kg).
Page 140 2005 Volvo S40 2 0 0 5 VOLVO Chapter 8 - Volvo Service pg. 123 Wheels and tires General information 124 Tire inflation 125 Tire inflation pressure tables 127 Tire designations 128 Glossary of tire terminology 129 Vehicle loading 130...
Page 141 2005 Volvo S40 surfaces. Certain models are equipped with "all-season" tires, which provide a somewhat higher degree of road holding on slippery surfaces than tires without the "all-season" rating. However, for optimum road holding on icy or snow-covered roads, we recommend suitable winter tires on all four wheels.
Page 142 2005 Volvo S40 2002). Improving tire economy: Maintain correct tire pressure. See the tire pressure table on page 127. Drive smoothly: avoid fast starts, hard braking and tire screeching. Tire wear increases with speed. Correct front wheel alignment is very important.
Page 143 2005 Volvo S40 Tire inflation placard on Canadian models NOTE: The placards shown indicate inflation pressure for the tires installed on the car at the factory only. Use a tire gauge to check the tire inflation pressure, including the spare, at least once a month and before long trips.
Page 144 127 Tire inflation pressure tables Tire pressures recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed on your vehicle at the factory. Cold tire pressure for vehicle loads up to 800 lbs (365 kg)
Page 145 2005 Volvo S40 36 (250) 36 (250) 195/65R15 205/55R16 91V 36 (250) 36 (250) 205/50R17 93V Extra load 36 (250) 36 (250) 215/45R18 93W 36 (250) 36 (250) Temporary spare tire T125/85R16 99M 61 (420) 61 (420) a. These weights include the weight of all occupants of the car plus cargo.
Page 146 2005 Volvo S40 Tire designations Federal law mandates that tire manufacturers place standardized information on the sidewall of all tires (see the illustration). The following information is listed on the tire sidewall: The tire designation (the following figures are examples of a tire designation): 1.
Page 147 2005 Volvo S40 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters "DOT" and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 148 This limit is set by the tire manufacturer. Recommended tire inflation pressure: inflation pressure, established by Volvo, which is based on the type of tires that are mounted on a vehicle at the factory. This inflation pressure is affected by the number of occupants in the car, the amount of cargo, and the speed at which the vehicle will be driven for a prolonged period.
Page 149 2005 Volvo S40 on each axle must never exceed its maximum permissible weight. Gross vehicle weight (GVW) The vehicle's curb weight + cargo + passengers. NOTE: The location of the various labels in your vehicle can be found on page 184.
Page 150 Snow chains can be used on your Volvo with the following restrictions: Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. If accessory, aftermarket or "custom" tires and wheels are installed and are of a size different than the original tires and wheels, chains in some cases CANNOT be used.
Page 151 All Wheel Drive models: Snow chains should only be installed on the front wheels. Only chains adapted for AWD models should be used. Consult your Volvo retailer for additional snow chain information. CAUTION! Check local regulations regarding the use of snow chains before installing.
Page 152 Recommended tire pressure (see the placard on the B-pillar or on the fuel filler door) should be maintained irrespective of which position on the car the temporary spare tire is used on. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING! Current legislation prohibits the use of the "temporary spare"...
Page 153 The tires with the most tread should always be at the rear (to reduce the risk of skidding) Wheels should be stored hanging up or on their sides, never standing. Contact a Volvo workshop if you are unsure about the tread depth. http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_08a.htm (14 of 17)8/12/07 12:18 AM...
Page 154 2005 Volvo S40 pg. 136 Removing a wheel Removing a wheel The spare tire, jack, and crank are located under the carpet on the floor of the trunk. To change a tire: 1. Engage the parking brake. 2. Put the gear selector in (P)ark.
Page 155 2005 Volvo S40 6. There are two jack attachment points on each side of the car. Position the jack correctly in the attachment (see illustration above) and crank while simultaneously guiding the base of the jack to the ground. The base of the jack must be flat on a level, firm, non-slippery surface. Before raising the car, check that the jack is still correctly positioned in the attachment.
Page 156 2005 Volvo S40 5. Install the wheel cap (where applicable). Returning the jack and spare wheel to the storage space 1. Crank the jack (1) down approximately halfway until the mark on the washer (2) aligns with the mark on the jack's arm (3).
Page 157: Vehicle Care
2005 Volvo S40 2 0 0 5 VOLVO Chapter 9 - Vehicle care pg. 139 Vehicle care Washing and cleaning the Paint touch up 143 pg. 140 Washing and cleaning the car Washing and cleaning the car Washing the car...
Page 158 2005 Volvo S40 cleaning improves visibility considerably. Wash off the dirt from the underside (wheel housings, fenders, etc). In areas of high industrial fallout, more frequent washing is recommended. After cleaning the engine, the spark plug wells should be inspected for water and blown dry if necessary.
Page 159 Volvo does not recommend the use of long-life or durable paint protection coatings, some of which may claim to prevent pitting, fading, oxidation, etc. These coatings have not been tested by Volvo for compatibility with your vehicle's clear coat. Some of them may cause the clear coat to soften, crack, or cloud.
Page 160 Volvo also offers a special leather softener that should be applied after the cleaner and protectant. It leaves leather soft and smooth, and reduces friction between leather and other finishes in the vehicle.
Page 161 2005 Volvo S40 Material: Primer - can Paint - touch-up pen Brush Masking tape NOTE: When touching up the vehicle, it should be clean and dry. The surface temperature should be above 60° F (15° C). If the stone chip has not penetrated down to the metal and an undamaged layer of paint remains, the touch-up paint can be applied as soon as the spot has been cleaned.
Page 162 2005 Volvo S40 pg. 144 This page intentionally left blank Contents Top of Page http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_09a.htm (6 of 6)8/12/07 12:18 AM...
Page 163: Maintenance And Servicing
Fuses 161 pg. 146 Volvo maintenance Volvo maintenance Volvo advises you to follow the maintenance program outlined in the Warranty and Service Records Information booklet. This maintenance program contains inspections and services necessary for the http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_10a.htm (1 of 14)8/12/07 12:19 AM...
Page 164 The maintenance services contain several checks that require special tools and training, and therefore must be performed by a qualified technician. To keep your Volvo in top condition, specify time-tested and proven Genuine Volvo Parts and Accessories.
Page 165 Wipe driver information displays with a soft cloth. Visually inspect battery terminals for corrosion. Corrosion may indicate a loose terminal connector, or a battery near the end of its useful service life. Consult your Volvo retailer for additional information. As needed: Wash the car, including the undercarriage, to reduce wear that can be caused by a buildup of dirt, and corrosion that can be caused by salt residues.
Page 166 2005 Volvo S40 Opening the hood To open the hood: Pull the lever located under the left side of the dash to release the hood lock. Lift the hood slightly. Press up the release control located under the front edge of the hood (at the center) up to the right, and lift the hood.
Page 167 Volvo does not recommend the use of oil additives. Synthetic oil is not used when the oil is changed at the normal maintenance intervals except at owner request and at additional charge. Please consult your Volvo retailer. Checking and adding oil The oil level should be checked every time the vehicle is refueled.
Page 168 2005 Volvo S40 Location of dipstick and oil filler cap If the engine is warm, wait for at least 10-15 minutes after the engine has been switched off before checking the oil. Checking the oil 1. Pull out the dipstick and wipe it with a lint-free rag.
Page 169 2005 Volvo S40 CAUTION! Never fill oil above the MAX mark. This could cause an increase in oil consumption. WARNING! Do not allow oil to spill onto or come into contact with hot exhaust pipe surfaces. pg. 150 Oils and fluids...
Page 170 2005 Volvo S40 Coolant reservoir Coolant Normally, the coolant does not need to be changed. If the system must be drained, consult your Volvo retailer. NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point.
Page 171 Replace: The fluid should be replaced according to the intervals specified in the Warranty and Service Records Information booklet. When driving under extremely hard conditions (mountain driving, etc), it may be necessary to replace the fluid more often. Consult your Volvo retailer. Always entrust brake fluid changing to an authorized Volvo retailer.
Page 172 2005 Volvo S40 Fluid type: Volvo power steering fluid or equivalent. Replace: No fluid change required WARNING! If a problem should occur in the power steering system or if the vehicle has no electrical current and must be towed, it is still possible to steer the vehicle.
Page 173 2005 Volvo S40 pg. 153 Battery http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_10a.htm (11 of 14)8/12/07 12:19 AM...
Page 174 2005 Volvo S40 Battery maintenance Driving habits and conditions, climate, the number of starts, etc. all affect the service life and function of the battery. In order for your battery to perform satisfactorily, keep the following in mind: Check the fluid level in each cell in the battery every 24 months or every 15,000 miles (24,000 km), whichever is sooner.
Page 175 2005 Volvo S40 pg. 154 Battery Battery replacement 1. Switch off the ignition and remove the key. 2. Unscrew the cover over the battery. 3. Wait at least 5 minutes after switching off the ignition before disconnecting the battery so that all information in the vehicle's electrical system can be stored in the control modules.
Page 176 2005 Volvo S40 WARNING! Never expose the battery to open flame or electric spark. Do not smoke near the battery. Battery fluid contains sulfuric acid. Do not allow battery fluid to contact eyes, skin, fabrics or painted surfaces. If contact occurs, flush the affected area immediately with water. Obtain medical help immediately if eyes are affected.
Page 177 2005 Volvo S40 2 0 0 5 VOLVO pg. 155 Bulbs Bulbs used in the car 1. Low beam headlight 2. Bi-Xenon headlight (option) 35W D2S 3. High beam headlight 55W HB3 4. Brake light, Rear fog light P21/W5 5. Turn signal, front/rear (amber bulb) PY21W 6.
Page 178 The optional Bi-Xenon headlight bulbs contain trace amounts of mercury. These bulbs should always be disposed of by an authorized Volvo retailer. Certain bulbs not listed here should only be replaced by an authorized Volvo service technician. pg. 156 Replacing front bulbs...
Page 179 2005 Volvo S40 Cover with retaining clamps Low beam bulb 1. Open the hood. 2. Remove the headlight housing. 3. Press the retaining clamps to the sides. 4. Release the bulb's retaining spring by pressing it to the right, and then moving it outward and downward.
Page 180 2005 Volvo S40 5. Press the retaining clamps back into place. 6. Reinstall the headlight housing. High beam bulb High beam bulb 1. Open the hood. 2. Remove the headlight housing. 3. Turn the bulb holder counterclockwise and pull it out. Replace the bulb. Note how the bulb holder is positioned.
Page 181 2005 Volvo S40 Turn signal 1. Turn the bulb holder counterclockwise and remove it. 2. Remove the bulb from the holder by pressing it in and twisting it counterclockwise. 3. Insert a new bulb and reinstall the bulb holder in the headlight housing.
Page 182 2005 Volvo S40 Front fog light (option) 1. Switch off all lights and turn the key to position 0. 2. Remove the panel around the fog light housing. 3. Unscrew both torx screws in the fog light housing and remove it.
Page 183 3. Turn signal 4. Fog light (driver's side only) 5. Back-up light High-level brake light These bulbs are of a special type. It is recommended that they be replaced by an authorized Volvo service technician. License plate lighting Replacing the bulb...
Page 184 2005 Volvo S40 1. Switch off all lights and turn the key to position 0. 2. Remove the screw with a screw driver. 3. Detach the entire bulb housing and carefully pull it out. Turn the connector counterclockwise and pull out the bulb.
Page 185 Fuse box in the engine compartment The fuse box in the engine compartment has positions for 36 fuses. Fuses 1-18 are relays/circuit breakers and should only be removed or replaced by an authorized Volvo service technician. Fuses 19-36 may be changed at any time when necessary.
Page 186: Audio
2005 Volvo S40 Fuses in the engine compartment 1. Coolant fan (radiator), 50A 2. Power steering, 80A 3. Feed to passenger compartment fuse box, 60A 4. Feed to passenger compartment fuse box, 60A 5. Element, climate unit, 80A 6. Not in use 7.
Page 187 2005 Volvo S40 29. Front fog lights (option), 15A 30. Engine control module (ECM), 3A 31.Generator voltage regulator, 10A 32. Fuel injectors, 10A 33. Heating element - heated oxygen sensor, vacuum pump, 20A 34. Ignition coils, engine control module, 10A 35.
Page 188 2005 Volvo S40 Fuses in the passenger compartment 37. Not in use 38. Not in use 39. Not in use 40. Not in use 41. Not in use 42. Not in use 43. Audio system, 15A 44. Supplemental Restrain System (SRS), 10A 45.
Page 189 2005 Volvo S40 65. Volvo Navigation system (option), Audio system, 5A 66. Audio system control module (ICM), audio system relay coil, 10A 67. Not in use 68. Cruise control, 5A 69. Climate system, rain sensor (option), 5A 70. Not in use 71.
Page 190 2005 Volvo S40 2 0 0 5 VOLVO Chapter 11 - Audio pg. 167 Audio Audio system - introduction 168 Audio system overview 169 Audio functions 171 Radio functions 174 CD player 177 CD changer (certain audio systems only) Audio menu settings and selections 181 pg.
Page 191 (bass, mid-range and treble speakers in the front doors, bass and treble speakers in the rear doors, and bass and treble in the dashboard's center speaker). A subwoofer mounted under the floor in the trunk is available as an accessory. Consult your Volvo retailer.
Page 192 2005 Volvo S40 4. CD - switch to the CD player or CD changer (certain audio systems only) 5. AM/FM - switch between AM, FM1, and FM2 6. MENU - press to access the audio and car settings menu 7. ENTER - press to make or confirm a menu selection 8.
Page 193 2005 Volvo S40 Daytime/twilight display In daylight the information is displayed against a light background. In darkness it is displayed against a dark background. Clean the display with a soft, dry cloth. Do not use cleaning agents. Using the audio system menus Press MENU to access the main audio system menu.
Page 194 2005 Volvo S40 Volume control Turn the volume knob clockwise or counterclockwise to increase or lower the volume. The volume can also be increased (+) or lowered (-) using the optional steering wheel keypad. Pause mode When the volume is turned all the way down, the CD player switches to pause mode. Reactivate the player by turning up the volume.
Page 195 2005 Volvo S40 The level for the subwoofer can only be set if SUBWOOFER is activated in the menu. 3-channel mode is recommended for AM/FM radio broadcasts. Dolby Surround Pro Logic II Dolby Surround Pro Logic II together with a center speaker in the dashboard offers you a sound experience very close to a live performance.
Page 196 2005 Volvo S40 To adjust the equalizer settings: 1. Press MENU. 2. Select the menu for the current sound source and press ENTER. 3. Select Audio settings in the menu and press ENTER. 4. Select Equalizer front/rear and press ENTER.
Page 197 2005 Volvo S40 Manual station search There are two ways to manually tune a radio station: Turn the TUNING knob to obtain the desired frequency. Press the left or right arrow key on the MENU NAVIGATION control and hold it down. The radio scans slowly in the selected direction and will increase the scanning speed after a few seconds.
Page 198 The RBDS or Radio Broadcast Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information.
Page 199 2005 Volvo S40 4. Select SHOW PTY and press ENTER. The PTY (program type) of the selected station is now shown in the display. NOTE: Not all RBDS radio stations have PTY designations. pg. 176 Radio functions Station formats Switch off/deactivate (Clear all PTY)
Page 200 2005 Volvo S40 types, select EXIT to exit the PTY list. 6. Select SEARCH PTY and press ENTER. If the radio finds a station with the selected format, it will tune to this station. If you would like to continue searching, press the left or right arrow on the MENU NAVIGATION control.
Page 201 2005 Volvo S40 track. NOTE: The track number is shown in the display. The TUNING knob or the arrow keys in the optional keypad in the steering wheel can also be used for this purpose. Fast forward/back Press and hold down the left or right arrows keys in the MENU NAVIGATION control (or the corresponding keys on the optional steering wheel keypad) to search within a track or the whole disc.
Page 202 Do not put tape or labels on the disc itself. They could become stuck in the player. Volvo does not recommend the use of plastic outer rings on the disc. Condensation may occur on discs/optical components of the changer in cold winter weather. The disc can be dried with a clean, lint-free cloth.
Page 203 2005 Volvo S40 Fast forward/back Press and hold down the left or right arrows keys in the MENU NAVIGATION control (or the corresponding keys on the optional steering wheel keypad) to search within a track or the whole disc. The search continues for as long as the buttons are held in.
Page 204 Do not put tape or labels on the disc itself. They could become stuck in the player. Volvo does not recommend the use of plastic outer rings on the disc. Condensation may occur on discs/optical components of the changer in cold winter weather. The disc can be dried with a clean, lint-free cloth.
Page 205 2005 Volvo S40 3.1. AF ON/OFF (default)* 3.2. RESET All 4. AUDIO SETTINGS 4.1. SURROUND AM/FM (Premium sound system only) 4.1.1. Dolby Pro Logic II* 4.1.2.3 Channel* 4.1.3. OFF (default)* 4.2. SURROUND CD 4.2.1. Dolby Pro Logic II (default)* 4.2.2.3 Channel* 4.2.3.
Page 206 2005 Volvo S40 2.1.1. Dolby Pro Logic II* 2.1.2. 3 Channel* 2.1.3. Off (default)* 2.2. SURROUND CD (Premium sound system only) 2.2.1. Dolby Pro Logic II (default)* 2.2.2. 3 Channel* 2.2.3. Off* pg. 182 Audio menu settings and selections 2.3. SUBWOOFER ON (default)/OFF* (accessory) 2.4.
Page 207 2005 Volvo S40 Contents Top of Page http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_11a.htm (18 of 18)8/12/07 12:20 AM...
Page 208: Specifications
2005 Volvo S40 2 0 0 5 VOLVO Chapter 12 - Specifications pg. 183 Specifications Label information 184 Dimensions and weights 185 Fuel, oils, and fluids 186 Engine oil 187 Engine specifications 188 Electrical system 189 Three-way catalytic converter Volvo programs 191 pg.
Page 209 5. Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.
Page 210 2005 Volvo S40 8. Vehicle Emission Control Information Your Volvo is designed to meet all applicable emission standards, as evidenced by the certification label on the underside of the hood. For further information regarding these regulations, please consult your Volvo retailer.
Page 211 SJ/Energy Conserving. Your Volvo has been certified to standards using ILSAC oil specification GF-2 5W-30. Volvo recommends use of oil with a quality rating equal to or higher than ILSAC GF-2. Equivalent and better oils include ACEA A1, API SJ, SJ/CF, and SJ/Energy conserving. Lower quality oils may not offer the same fuel economy, engine performance, or engine protection.
Page 212 Oil viscosity (stable ambient temperatures) Operation in hot climates When temperatures exceed 86° F (30° C) in your area, Volvo recommends, for the protection of your engine, that you use a heavier weight oil, such as SAE 10W-30. See the viscosity chart.
Page 213 93.2/3.67 Compression ratio 10.3:1 10.3:1 9.0:1 Spark plugs Volvo kit no. Volvo kit no. type Volvo kit no. 30650379 30650843 30650843 (3x) 0.024 ± 0.004 (3x) 0.024 ± 0.004 gap inches/mm 0.027in./0.7mm in./0.6 ± 0.1mm in./0.6 ± 0.1mm tightening torque ft. lbs./Nm 22.5 ft.
Page 214 If the battery must be replaced, replace it with one with the same cold start capacity and reserve capacity as the original (see the decal on the battery). * Cars equipped with the High Performance audio system ** Cars equipped with the Premium Sound audio system and/or the Volvo Navigation system maximum current 120/150 A Generator Starter motor output 1.4/1.9 kW...
Page 215 191 Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional information, features, and benefits are described in a separate information package in your glove compartment. If you have misplaced your package, dial: In the U.S.A.
Page 216 2005 Volvo S40 Fuel tank Octane rating: Unleaded premium 15.9 US gallons (60 liters) gasoline with an octane rating AKI Models with All Wheel Drive of 91, or above. The minimum have a tank volume of 15 US octane requirement is AKI 87 gallons (57 liters).
Page 217 2005 Volvo S40 2 0 0 5 VOLVO Index pg. 193-196 Index Numerics 12 volt socket, in trunk 12 volt socket, rear seat 12 volt sockets ABS (anti-lock brake system) Active yaw control - AYC Airbag deployment Alarm All Wheel Drive...
Page 218 2005 Volvo S40 Backrests, rear seat Battery drain - avoiding Battery maintenance Battery replacement Battery replacement, remote control Battery, conserving electrical current Battery, specifications Bi-Xenon headlights Booster cushion Brake fluid Bulbs Capacities, fluids Catalytic converter, three-way CD changer CD player...
Page 219 2005 Volvo S40 Dimensions Disabling the passenger's side front airbag Display, instrument panel Dolby Surround Pro Logic II Door mirrors Door open warning Driving after a collision DSTC Economical driving Electrical current - conserving Electrical system Electronic Brake Force Distribution (EBD)
Page 220 2005 Volvo S40 Fuel requirements Fuel system Fuel tank capacity Fuse box in the passenger compartment, accessing Fuses Fuses in the engine compartment Fuses in the passenger compartment Gasoline Geartronic (manual shifting) Generator Generator warning light Glossary of tire terminology...
Page 221 2005 Volvo S40 Indicator and warning symbols Inflatable Curtain Inflation pressure tables Information display Information display, messages in 38, 39 Information symbol Instrument overview Instrument panel Instrument panel lighting Interior lighting ISOFIX/LATCH anchors Jack, positioning correctly Jump starting Key blade...
Page 222: Occupant Safety
2005 Volvo S40 Manual transmission Mirror, rearview Mirrors, door-mounted Moonroof Occupant safety Occupant Weight Sensor (OWS), disabling front passenger's side airbag Octane rating Oil pressure warning light Oil, changing On Call Roadside Assistance Opening the hood Paint touch up Panic alarm, central locking system remote control...
Page 223: Seat Belts
2005 Volvo S40 PROPOSITION 65 WARNING Radio Broadcast Data System - RBDS Radio functions Radio station formats Radio text Rain sensor Reading lights, rear Rear fog light Rear park assist Rear reading lights Rear seat backrests, folding down Rear seat head restraints...
Page 224: Side Impact Protection (Sips) Airbags
2005 Volvo S40 SERVICE REQUIRED Shiftlock Side impact protection (SIPS) airbags Side marker light, replacing Speedometer Spin control - SC SRS warning light Stability Stability system Stability system STC or DSTC Start inhibitor (immobilizer) Starting the vehicle Station formats Steering wheel adjustment...
Page 225 Vanity mirror Vanity mirror lighting, replacing Vehicle Event Data Vehicle Identification Number Vehicle loading Volvo and the environment Volvo Customer Care Center, contacting Volvo Inflatable Curtain Volvo maintenance Volvo On Call Roadside Assistance W Winter/Wet driving mode Warning flashers Warning light, safety systems...
Page 226: Whips
2005 Volvo S40 Washing the car Waxing Weight distribution Weights Wheel nuts Wheels, removing Whiplash Protection System (WHIPS) Windshield washer fluid Windshield wiper blades Windshield wipers Wiper blades SUPPLEMENT - VALET OR SERVICE LOCKING At the time of printing for your All New S40 owner's manual, information about seat back locking was not available.
Page 227: Child Safety
The tables below show recommended tire inflation pressures for 18-inch tires you may have purchased as an accessory from your authorized Volvo retailer. If your vehicle is equipped with factory-installed tires, see your vehicle's tire inflation placard located on the driver's door pillar. See additional guidance in your owner's manual.
Page 228 2005 Volvo S40 Contents Top of Page http://new.volvocars.com/ownersdocs/2005/2005_S40/05s40_13.htm (12 of 12)8/12/07 12:20 AM...
