Interface
Description
Restore the default settings. Usage:
Turn on the router. Press the button and
keep for more than 6 seconds. Then the
router will restart with the factory
default configuration.
WAN
Connector for accessing the Internet.
LAN 1- 4
Connecters for local network devices
(LAN).
PWR: Connecter for a power adapter.
Connecter for a USB device (for 3G
USB Modem or printer or storage
disk).
ON/OFF: Power switch.
Vigor2120 Series Quick Start Guide
3
