7" DIGITAL VIDEO WIRELESS SYSTEM
Instruction Manual
DW-703W
(CM-703DW + DVWS-100W)
Thank you for purchasing this product.
For proper usages and application,
please read this instruction manual thoroughly.
* The design and specifi cations of this product in order to improve its quality
ver. 1.0
may be changed without notice.
PRINTED IN KOREA
Advertisement
Table of Contents
Related Manuals for Camos DW-703W
Summary of Contents for Camos DW-703W
- Page 1 7” DIGITAL VIDEO WIRELESS SYSTEM Instruction Manual DW-703W (CM-703DW + DVWS-100W) Thank you for purchasing this product. For proper usages and application, please read this instruction manual thoroughly. * The design and specifi cations of this product in order to improve its quality ver.
-
Page 2: Table Of Contents
CONTENTS SAFEGUARD INSTRUCTIONS -------------------------------------- 3 FEATURE ----------------------------------------------------------------- 5 BOX CONTENTS ------------------------------------------------------- 5 FUNCTION OF EACH PART ---------------------------------------- 6 FUNCTIONS ------------------------------------------------------------- 8 CONNECTIONS ------------------------------------------------------- 14 INSTALLATION -------------------------------------------------------- 16 CHANGING REMOTE CONTROL BATTERY -------------------- 17 SPECIFICATION ------------------------------------------------------ 18... -
Page 3: Safeguard Instructions
SAFEGUARD INSTRUCTIONS 7” DIGITAL VIDEO WIRELESS SYSTEM Please read the “Safety Rules” carefully before using this product. Following the safety rules prevents users from damages related with the misuse of the product. It is very important to follow these safety rules. We state “Caution” and “Warning”... - Page 4 WARNING Do not put the product in place where sudden temperature increasing and should use on optimum voltage, temperature and humidity --- It may cause to electronic shock or malfunction. Do not get product wet and operate with wet hands. --- It may cause to electronic shock or malfunction.
-
Page 5: Feature
FEATURE 7” DIGITAL VIDEO WIRELESS SYSTEM [CM-703DW] • 8bit MICRO controller • TFT LCD with high resolution and low reflection • All functions are displayed on screen (OSD function) • PWM volume control • Mode selection function • Low energy consuming rate •... -
Page 6: Function Of Each Part
FUNCTION OF EACH PART 7” DIGITAL VIDEO WIRELESS SYSTEM [ MONITOR ] ① ② ③ ④ ⑤ ⑥ ① IR-SENSOR Button to Setup Screen and Function ② MENU Button to Select Menu ③ SELECT ④ POWER Power ON/OFF button ⑤ VOLUME < > SOUND/MENU level control DVWS/CAM1/CAM2 selection function ⑥... - Page 7 [ REMOTE CONTROLLER (Option) ] Power ON/OFF button ① POWER ② MODE Selecting DVWS/CAM1/CAM2 ③ MENU Selecting MENU and changing functions ④ VOL ◀▶(VOL+-) Changing volume or MENU level ⑤ CH ▲▼ Moving Up/Down on MENU ⑥ MUTE Mute mode On/Off Displaying the current channel and volume level ⑦...
-
Page 8: Functions
FUNCTIONS 7” DIGITAL VIDEO WIRELESS SYSTEM ** Remote controller is an option. POWER 1) Press [POWER] button to the power. (STAND BY state is OFF) 2) Press [POWER] button again to off the power. (STAND BY state is ON) MODE •... - Page 9 UP/DOWN VOLUME VOLUME 1) Press VOLUME < > button on monitor to adjust volume. MENU • It is a function to select MAIN MENU (SETUP/PICTURE/CAMERA) 1) Press [MENU] button to select MAIN MENU, changed color in red when it is selected. 2) Press [MODE] button to select SUB MENU, button to change SUB MENU.
- Page 10 [ 1. SETUP ] • DIMMER • LANGUAGE ENGLISH DEUTSCH ITALIANO FRANCAIS 한국어 ESPAnOL 日本語 • DIRECTION DIMMER LANGUAGE ENGLISH DIRECTION 0˚ DISPLAY WIDE RESET ▶ • DISPLAY WIDE NORMAL CINEMA FULL • RESET ▶ A factory default reset will clear all of OSD information.
- Page 11 [ 2. PICTURE USER ] • When press the [AUTO PIC] button on remote control, PICTURE SETUP menu is displayed on screen. CONTRAST BRIGHTNESS COLOR TINT 1) MODE button to select CONTRAST, BRIGHTNESS, COLOR, TINT MENU. (Selected menu in red) 2) Press VOLUME <...
- Page 12 [ 3. CAMERA ] * CAMERA SETUP menu is displayed when the [MENU] button is pressed in CAM1/CAM2. And in the SETUP, NORMAL/MIRROR of CAM1/CAM2 or Output mode(CAM1/DVWS) of the trigger input in CAM1 could be selected. CAM1 MIRROR CAM2 MIRROR TRIGGER1 DVWS...
- Page 13 ※ This function can be operated by the remote control. MUTE 1) Press [MUTE] button to mute sound and display mute icon. RECALL DVWS VOLUME 1) Press [RECALL] button to check the MODE and Vol- ume.
-
Page 14: Connections
CONNECTIONS 7” DIGITAL VIDEO WIRELESS SYSTEM DVWS Receiver module is built-in monitor, when you use fi rstly just connect antenna and cigar jack. Then it works properly without additional work. * In case of using normal monitor, disassemble or fold the antenna. And purchase and connect mon- itor cable for rearview camera connecting. -
Page 16: Installation
INSTALLATION 7” DIGITAL VIDEO WIRELESS SYSTEM (1) Please set the place for Monitor installation. Clean the place where to install stand and install stand firmly after removing protect tape of stand bottom. (2) Fix the stand with enclosed screws. (3) Assemble the monitor to stand and fix it in the right angle. (4) Connect cable as follows. -
Page 17: Changing Remote Control Battery
CHANGING REMOTE CONTROL BATTERY 7” DIGITAL VIDEO WIRELESS SYSTEM 1. Pull the battery cover to the direc- tion of the arrow. 2. Place a battery with the (+) sign upward. (No. CR2025) 3. Put the battery case back into the remote control in the direction of the arrow. -
Page 18: Specification
SPECIFICATION 7” DIGITAL VIDEO WIRELESS SYSTEM [ CM-703DW ] SPECIFICATION ITEM NTSC SCREEN SIZE 17.78 cm (7.0 inch) DISPLAY FOMAT 480(H) x 3(RGB) x 234(V) LCD PANEL DOT PITCH 0.107(W) x 0.370(H) mm BRIGHTNESS 500 cd/m VIEW ANGLE 60˚(H) / 50˚(U) / 40˚(D) VOLTAGE DC 12V - 24V POWER SUPPLY... - Page 19 MEMO...
- Page 20 MEMO...
