606i(G) cover_cover.qxp 2011-05-12 오전 9:37 페이지 1
OPERATING INSTRUCTIONS
RD-606i
NETWORK AV RECEIVER
NETZWERK AV RECEIVER
RED RECEPTEUR AV
RESEAU RECEPTOR DE AV
АУДИО/ВИДЕО СЕТИ РЕСИВЕР

Advertisement

Table of Contents
loading

Related Manuals for Sherwood RD-606i

Summary of Contents for Sherwood RD-606i

  • Page 1 606i(G) cover_cover.qxp 2011-05-12 오전 9:37 페이지 1 OPERATING INSTRUCTIONS RD-606i NETWORK AV RECEIVER NETZWERK AV RECEIVER RED RECEPTEUR AV RESEAU RECEPTOR DE AV АУДИО/ВИДЕО СЕТИ РЕСИВЕР...

  • Page 2: Introduction

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 2 Introduction READ THIS BEFORE OPERATING YOUR UNIT This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 3: Table Of Contents

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 3 CONTENTS Introduction • READ THIS BEFORE OPERATING YOUR UNIT System Connections Front Panel Controls Remote Controls • REMOTE CONTROL OPERATION RANGE • LOADING BATTERIES Operations • LISTENING TO A PROGRAM SOURCE • SURROUND SOUND •...

  • Page 4: System Connections

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 4 System Connections • Please be certain that this unit is unplugged from the AC outlet before making any connections. • Since different components often have different terminal names, carefully read the operating instructions of the component connected.
  • Page 5 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 5 . CONNECTING VIDEO COMPONENTS • The jacks of VIDEO 1 may also be connected to a DVD recorder or other digital video recording component. For details, refer to the operating instructions of the component to be connected.
  • Page 6 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 6 Continued ■HDMI (High Definition Multimedia Interface) connection : (*) • You can connect the source component (DVD player, etc.) to the display component (TV, projector, etc.) through this receiver with using a commercially available HDMI cord.
  • Page 7 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 7 CONNECTING DIGITAL INS • The OPTICAL and the COAXIAL DIGITAL OUTs of the components that are connected to CD, VIDEO 1 and VIDEO 2 of COAX 1 this unit can be connected to these DIGITAL INs.
  • Page 8 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 8 CONNECTING SPEAKERS • Be sure to connect speakers firmly and correctly according to the channel(left and right) and the polarity (+ and -). If the connections are faulty, no sound will be heard from the speakers, and if the polarity of the speaker connection is incorrect, the sound will be unnatural and lack bass.
  • Page 9 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 9 Speaker placement Ideal speaker placement varies depending on the size of your room and the wall coverings, etc. The typical example of speaker placement and recommendations are as follows : ■ Front left and right speakers and center speaker •...

  • Page 10: Front Panel Controls

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 10 Front Panel Controls RD-606i NETWORK AV RECEIVER MASTER VOLUME STANDBY SOUND INPUT POWER ON / STANDBY AUTO / MANUAL SURROUND STEREO VIDEO AUDIO VIDEO 3 VIDEO AUDIO PHONES SPEAKER AUDIO ASSIGN TONE CH.LEVEL SETUP...
  • Page 11 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 11 ■AUX 1, 2 IN JACKS • The AUX 1, 2 IN jacks can be connected to additional audio components such as an MP3 player, etc. ■ Note : • When connecting these jacks to an MP3 player, etc., you should use the stereo mini cord, not a mono mini cord.

  • Page 12: Remote Controls

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 12 Remote Controls SELECT CURSOR CONTROL( , , , ), ENTER </SEARCH MODE, SELECT / > buttons The functions in “< >” are regional option for Europe, etc. NETWORK CONTROL(NETWORK, PAUSE( ), PLAY( ), STOP(...

  • Page 13: Remote Control Operation Range

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 13 REMOTE CONTROL OPERATION RANGE RD-606i NETWORK AV RECEIVER MASTER VOLUME STANDBY SOUND INPUT POWER ON / STANDBY AUTO / MANUAL SURROUND STEREO VIDEO AUDIO VIDEO 3 VIDEO AUDIO PHONES AUX 1 AUX 2 SPEAKER...

  • Page 14: Operations

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 14 Operations ■Note : Before operating this receiver, first set this unit as desired for optimum performance, doing the system setup procedures. (For details, refer to "System Setup" on page 37.) LISTENING TO A PROGRAM SOURCE •...
  • Page 15 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 15 Adjusting the tone (bass and treble) Operate the selected component for playback. • When playing back the program sources with surround Enter the tone mode. sound, refer to “ENJOYING SURROUND SOUND” on page 17.

  • Page 16: Surround Sound

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 16 SURROUND SOUND • This receiver incorporates a sophisticated Digital Signal Processor that allows you to create optimum sound quality and sound atmosphere in your personal Home Theater. Surround modes ■DTS Digital Surround • The following modes apply conventional 2-channel...

  • Page 17: Enjoying Surround Sound

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 17 ENJOYING SURROUND SOUND ■Note: Before surround playback, first perform the speaker setup procedure, etc. on the SETUP menu for optimum performance. (For details, refer to "SETTING THE SPEAKER SETUP" on page 42.) Depending on how to select a surround mode, select the auto surround mode or the manual surround mode.
  • Page 18 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 18 When adjusting the sound parameters • While playing digital signals form Dolby Digital program source or listening in Dolby Pro Logic II Music mode, you can adjust their parameters for optimum surround effects. Press the SOUND PARAMETER button.
  • Page 19 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 19 Adjusting each channel level with test tone • The volume level of each channel can be adjusted easily with the test tone function. ■Note : When the SPEAKER button is set to off, the test tone function does not work.
  • Page 20 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 20 Adjusting the current channel level • After adjusting each channel level with test tone, adjust the channel levels either according to the program sources or to suit your tastes. • You can adjust the current channel levels as desired. These adjusted levels are just memorized into user’s memory ("CAL"), not into preset memory("REF 1", "REF 2").
  • Page 21 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 21 Memorizing the adjusted channel levels Recalling the memorized channel levels • You can memorize the adjusted channel levels into preset memory("REF 1", "REF 2") and recall the memorized Press the CHANNEL LEVEL button. whenever you want.

  • Page 22: Listening To Radio Broadcasts

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 22 LISTENING TO RADIO BROADCASTS Auto tuning Manual tuning • Manual tuning is useful when you already know the Select the desired band. frequency of the desired station. • After selecting the desired band, press the TUNING UP(+) / DOWN(-) buttons repeatedly until the right frequency has been reached.
  • Page 23 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 23 Manual presetting Tuning to preset stations • You can store up to 30 preferred stations in the memory. • After selecting the tuner as an input source, select the desired preset number. Tune in the desired station with auto or manual tuning.

  • Page 24: Listening To Rds Broadcasts(Fm Only)

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 24 RDS Tuner (Regional Option for some countries in Europe, etc.) LISTENING TO RDS BROADCASTS(FM ONLY) RDS(Radio Data System) is a method for sending information signals together with the transmitter signals. Your tuner is capable of translating these signals and putting the information on the display. These codes contain the following information.
  • Page 25 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 25 Displaying RDS information In the FM mode, • Each time this button is pressed, the display mode changes as follows: Program Signal Surround → → → Service name input mode (PS) Program ← ←...

  • Page 26: Listening To Internet Radio Broadcasts, Music Files

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 26 LISTENING TO INTERNET RADIO BROADCASTS, MUSIC FILES • You can listen to Internet radio broadcasts or music files stored on a USB memory device or a computer (media server). ■Internet Radio ■DLNA (Digital Living Network Alliance) media server •...
  • Page 27 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 27 Basic Operation Select the desired item, then press the ENTER button. Make the necessary preparations. ENTER/MEMO PRESET ① Check the network environment, then turn on this unit. (See “CONNECTING TO NETWORK” on page 7.) ②...
  • Page 28 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 28 ◆To pause playback ◆To play repeatedly During playback, press the PAUSE( ) button. During playback of the desired music file, press the REPEAT( ) button. • Then “ ” lights up and the music files on the folder are •...
  • Page 29 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 29 When selecting “Now Playing” When selecting “Internet Radio” • You can display the information on the Internet radio • You can listen to Internet radio broadcasts provided by broadcast or music file being played.
  • Page 30 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 30 When selecting “USB” When selecting “DLNA” • You can listen to music files stored on a computer(media • You can listen to music files stored on a USB memory server) connected to this unit via your home network.
  • Page 31 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 31 ■Configuring the Windows Media Player ver. 11. Run the Windows Media Player ver. 11 on your • You can listen to Internet radio stations or music files computer. registered in the “Favorites” list or delete them.
  • Page 32 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 32 ◆When selecting “Modes” When selecting “Settings” Press the CURSOR UP(▲)/DOWN(▼) buttons to • When listening to Internet radio broadcasts or music files select “DHCP” or “STATIC”, then press the for the first time, first make settings for network, etc. for ENTER button.
  • Page 33 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 33 ◆When selecting “Factory Settings” ⑦ Press the AUDIO ASSIGN(/RETURN) button to return to previous status. Press the CURSOR UP(▲)/DOWN(▼) buttons to select “OK” or “CANCEL”, then press the AUDIO ASSIGN ENTER button. RETURN • When “OK” is selected, they are reset to the factory default.

  • Page 34: Recording

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 34 RECORDING • The digital signals from the “NET/USB”, coaxial, optical digital input or HDMI IN can be heard but cannot be recorded. • When recording the analog signals from CD, VIDEO 1~2, be sure to select the analog input.

  • Page 35: Other Functions

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 35 OTHER FUNCTIONS Operating the sleep timer • The sleep timer allows the system to continue to operate for a specified period of time before automatically shutting off. • To set the receiver to automatically turn off after the specified period of time.

  • Page 36: Confirming The Hdmi Function

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 36 CONFIRMING THE HDMI FUNCTION To use the HDMI control functions properly, it is recommend to confirm the HDMI control functions usable with each connected component by performing the following operations. ■Note : • Some HDMI control functions may not work with certain components and TV that are not compatible with them.

  • Page 37: System Setup

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 37 System Setup SETUP ENTER / MEMO PRESET TUNE MAIN MENU Turn the setup menu on. Confirm your selection. MENU T EM S • When selecting "SYSTEM SETUP", see "SETTING THE • The setup menu will be shown.
  • Page 38 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 38 ■Setup menu flow • The setup menu flow is as follows : SW MODE : NORM / SW + SYSTEM SETUP TONE : OFF / ON BASS : 0 dB / - 10 ~ + 10 A.P.S : OFF / 2HOUR / 4HOUR / 6HOUR...

  • Page 39: Setting The System Setup

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 39 SETTING THE SYSTEM SETUP SW MODE : NORM / SW + SYSTEM SETUP TONE : OFF / ON BASS : 0 dB / - 10 ~ + 10 A.P.S : OFF / 2HOUR / 4HOUR / 6HOUR...
  • Page 40 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 40 When selecting the TONE OFF : To listen to a program source without the tone effect. ("DIR" lights up.) ↕ ON : To adjust the tone for your taste. ("DIR" goes off.) ■When the TONE is set to ON to adjust the tone (bass and treble) ①...

  • Page 41: Setting The Input Setup

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 41 SETTING THE INPUT SETUP INPUT SETUP VIDEO 1 CONFIG D.IN : OPT / COX 1 / COX 2 / - - - AUTO : ON / OFF RETURN VIDEO 2 CONFIG D.IN : OPT / COX 1 / COX 2 / - - -...

  • Page 42: Setting The Speaker Setup

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 42 SETTING THE SPEAKER SETUP • After you have installed this receiver and connected all the components, you should adjust the speaker settings for the optimum sound acoustics according to your environment and speaker layout.
  • Page 43 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 43 Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to set the selected speaker as desired. • Depending on your speaker type, you can select one of these following speaker types. • Front, Center and Surround speakers : LARGE : Select this when connecting speakers that can fully reproduce sounds below crossover frequency.
  • Page 44 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 44 When selecting the CROSSOVER • When speakers are set to "SMALL", be sure to set their crossover frequency correctly according to their frequency characteristics. Press the CURSOR UP(▲)/DOWN(▼) buttons to select the "CROSSOVER", then press the ENTER button.
  • Page 45 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 45 When selecting the SPEAKER DISTANCE Press the CURSOR UP(▲)/DOWN(▼) buttons to select the “SPK DISTANCE”, then press the ENTER button. N I T : E ERS Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired item.

  • Page 46: Setting The Ch Level Setup

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 46 SETTING THE CH LEVEL SETUP CH LVL SETUP MODE : CAL / REF 1 / REF 2 LEFT : 0 dB / -15 ~ + 15 CENTER : 0 dB / -15 ~ + 15...
  • Page 47 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 47 Memorizing the adjusted channel levels Recalling the memorized channel levels • You can memorize the adjusted channel levels into preset Press the CURSOR UP(▲)/DOWN(▼) buttons memory("REF 1", "REF 2") and recall the memorized whenever you want.

  • Page 48: Setting The Parameter Setup

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 48 SETTING THE PARAMETER SETUP PARAMTER SETUP PANORAMA : OFF / ON C.WIDTH : 3 / 0 ~ 7 DIMENSION : 0 / -3 ~ +3 DRC DD DRC : OFF / MID / MAX...
  • Page 49 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 49 When selecting “DRC DD” • This function compresses the dynamic range of previously specified parts of the Dolby Digital sound track (with extremely high volume) to minimize the difference in volume between the specified and non-specified parts.

  • Page 50: Setting The Hdmi Setup

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 50 SETTING THE HDMI SETUP HDMI SETUP HDMI : AMP / THROUGH CEC : OFF / ON POWER : OFF / ON RETURN • HDMI(HDMI AUDIO OUT) : To output the digital audio signals from the HDMI MONITOR OUT connector.
  • Page 51 RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 51 When selecting the POWER CONTROL • The power control function allows the power status of this unit to be interlocked with the power ON/OFF and start of playback of the connected components. OFF : Not to use the POWER CONTROL function.

  • Page 52: Troubleshooting Guide

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 52 Troubleshooting Guide If a fault occurs, run through the table below before taking your receiver for repair. If the fault persists, attempt to solve it by switching the receiver off and on again. If this fails to resolve the situation, consult your dealer.

  • Page 53: Specifications

    RD-606i(G)_ENG_110511_RD-606i(G)_ENG 2011-05-13 오전 9:57 페이지 53 Specifications ■ AMPLIFIER SECTION • Power output, stereo mode, 6 Ω, THD 0.7%, 40 Hz~20 kHz 2x100 W • Total harmonic distortion, 6 Ω, 100 W, 1 kHz 0.05 % • Intermodulation distortion 60 Hz : 7 kHz= 4 : 1 SMPTE, 6 Ω, 100 W 0.1 %...
  • Page 54 606i(G) cover_cover.qxp 2011-05-12 오전 9:37 페이지 2 RD-606i NETWORK AV RECEIVER NETZWERK AV RECEIVER RED RECEPTEUR AV RESEAU RECEPTOR DE AV АУДИО/ВИДЕО СЕТИ РЕСИВЕР 5707-00000-576-0S...
