Page 1: User Manual
DDR-E04AB DDR-D04AB User Manual 2015 Mar V1.0... -
Page 2: Safety Precautions
DDR-E04AB / DDR-D04AB User Manual About this user manual Before installing and using this DVR unit, please read this user manual carefully. Be sure to keep it handy for later reference Package of contents Unpack carefully. This is electronic equipment and should be handled carefully. Check to ensure that the following items are included 1.DVR unit... - Page 3 DDR-E04AB / DDR-D04AB User Manual Do not remove cover No user serviceable parts inside Refer servicing to qualified service personnel. Warning To reduce risk of fire or electric shock. Do not expose this appliance to rain or moisture. Safety Precautions...
-
Page 4: Important Safeguards
DDR-E04AB / DDR-D04AB User Manual The exclamation point within an equilateral triangle is intended to alert the user to presence of Important operating and maintenance (servicing) instructions in the literature accompanying the appliance. Warning Electrostatic-sensitive device. Use proper CMOS/MOSFET handing precautions to avoid electrostatic discharge. - Page 5 DDR-E04AB / DDR-D04AB User Manual Read instruction All the safety and operating instructions should be read before the unit is operated. Retain instructions The safety and operating instructions should be retained for future reference. Heed Warnings All warnings on the unit and in the operating instructions should be adhered to.
-
Page 6: Table Of Contents
DDR-E04AB / DDR-D04AB User Manual 目錄 Chapter 1 Introduction ................... 1 Overview ............................ 1 Product Components ........................3 Front Panel ..........................3 Rear Panel ..........................3 Chapter 2 Installation ..................4 HDD Installation ........................4 Hardware connection ......................... 5 Setup DVR ..........................5 2.3-1 Power On ............................ -
Page 7: Chapter 1 Introduction
Chapter 1 Introduction 1.1 Overview DDR-E04AB / DDR-D04AB, is a ccHDtv standard with 4 channels DVR recorder; powered by Embedded LINUX decoding technologies with superior stability and performance. It can support most of today's off-the-shelf DTV cameras for up to 4 channels video recording and let you access your recordings quickly and reliably. - Page 8 DDR-E04AB / DDR-D04AB User Manual Standard Dual stream 1080p / D1, (25~30fps), Output 1 HDMI Display Display Split Resolution 1080p @ 30 fps per channel Camera title, date, time, video loss, motion detection and recording Recording Video / Audio H.264 / G711, G726, PCM...
-
Page 9: Product Components
DDR-E04AB / DDR-D04AB User Manual 1.2 Product Components The package contains the main unit and its accessary as specified below. When you purchase the DVR, please check to ensure the components specified below are included. The DVR unit Screws for HDD ... -
Page 10: Chapter 2 Installation
DDR-E04AB / DDR-D04AB User Manual DDR-D04AB Alarm OUT Alarm IN BNC 1 or 4 connector eSATA port HDMI Port WAN Port USB Port x 2 DC 12V power connector Power switch Chapter 2 Installation 2.1 HDD Installation 1. Loosen the four screws to open the cover 2. -
Page 11: Hardware Connection
DDR-E04AB / DDR-D04AB User Manual 2.2 Hardware connection 1. Connect one end of the network cable into the WAN port. 2. Connect the power adapter to the power source. 3. Connect the power adapter to the rear panel of the DVR unit. -
Page 12: Login Screen
DDR-E04AB / DDR-D04AB User Manual A. Press the right button of mouse in the grid to show the following screen. B. Press ”Login” ,the following screen appears 2.3-2 Login Screen Press to show a Virtual keyboard on the right side. -
Page 13: Camera Installation
A. Connect coaxial cable and power cable step by step. DC 12V NOTE: Power input follows DC12V DDR-E04AB to follow the following diagram to connect cameras (up to 4) DDR-D04AB to follow the following diagram to connect cameras (up to 4) - Page 14 DDR-E04AB / DDR-D04AB User Manual B. Press the right mouse in a grid will appear the following screen. C. Press "Select Camera" to set the camera’s channel & frequency. Note1: Each camera’s frequency is predefined and labeled on its own body.
- Page 15 DDR-E04AB / DDR-D04AB User Manual 1. Enter the camera’s name. 2. OSD 0FF or ON (display camera’s name, date and time). 3. Mirror Mode: vertical and horizontal flip. 4. Flicker Control: Flicker frequency is set to be 50Hz or 60Hz. (according to the local power soured) 5.
- Page 16 DDR-E04AB / DDR-D04AB User Manual 1 Set motion area with the red line 2. IN the motion area, by using mouse right-click button to display the adjustment windows of Sensitivity and Threshold (0-100). 3. If there are something moved into the motion area, display will show “.
- Page 17 DDR-E04AB / DDR-D04AB User Manual Press the "Camera Settings" and then "Private Settings" by using the mouse (lower right to upper left) to release the private area. H. Press ”About Camera” to display the following screen To show the Manufacturer, Model, Camera FW, FFT, Code Rate, Guard Interval, Quality, Strength, BER, Abort Count, Frequency.
-
Page 18: Chapter 3 Getting Start
DDR-E04AB / DDR-D04AB User Manual Chapter 3 Getting Start 3.1 Live Display Screen The following screen will appear after four cameras being installed Press the left mouse button to display the following screen... -
Page 19: Account Setting
DDR-E04AB / DDR-D04AB User Manual 3.2 Account setting Press , the following window is displayed 1. Account: Only the "admin" and "guest". 2. Set a new password and confirm password. 3. Remote Access: ON or OFF. 4. Press the "Save" to confirm setting or press "Revert" to revert again. -
Page 20: Streaming
DDR-E04AB / DDR-D04AB User Manual 3.3 Streaming Press , the following window is displayed 1. Show external IPv4 address.(show automatically) 2. Show Internal IPv4 address. (show automatically) 3. Setting HTTP Port. 4. Setting Streaming Port. 5. Press the "Save" to confirm setting or press "Revert" to revert again. -
Page 21: Ftp
DDR-E04AB / DDR-D04AB User Manual Status :Link Up or Link Down Using DHCP: OFF or ON(Automatically obtain IP Address) Specify the DNS:0FF or ON(Setting Preferred & Alternate DNS Server) Press the "Save" to confirm setting or press "Revert" to revert again. -
Page 22: Email
DDR-E04AB / DDR-D04AB User Manual B. Select Connection Mode: Active or Passive. C. Setup FTP Port. D. Setup Username. E. Setup Password. F. Setup Upload Path. G. Press the "Test" or "Save" to appear set-up successfully, press "Revert" to revert again. -
Page 23: Mylinks
DDR-E04AB / DDR-D04AB User Manual 3.7 MyLinks Press the following window is displayed 1. Enter the name and press "Save" to show the registration is completed successfully. 2. From external site to search this machine, enter the canonical name is: my-ndr.net 3.8 Sensor... -
Page 24: Date & Time Setting
DDR-E04AB / DDR-D04AB User Manual 3.9 Date & Time Setting Press , the following window is displayed 1. Manual adjustment: NTP “OFF” and choose the adjusted item, then press to adjust up or down. 2. Network adjustment time: NTP “ON” (Synchronize the server’s right time) 3. -
Page 25: Playback
DDR-E04AB / DDR-D04AB User Manual 1. Video schedule is one week and 24Hrs every day. 2. Each cell is 30 minutes 3. General Schedule is red and Motion Schedule is yellow and I / O alarm is blue 4. Choose the setting time or date line and then entire column or each grid can be set. - Page 26 DDR-E04AB / DDR-D04AB User Manual 2 Press "Play" to perform playback 3. Press the "Forward" to play forward, press "Backward" to play backward. Press the "Fast" to play accelerate (It is able to always press "Fast" to play accelerate). "Slow" to play decelerated (It is able to always press "Slow" to play decelerated).
-
Page 27: Language
DDR-E04AB / DDR-D04AB User Manual 4 .Backup: press "Backup" to set the date ,start time, end time( USB storage device or SD card must be inserted) 5. Press the right mouse button to display the following screen Press "Live Mode" to go back the real-time screen. - Page 28 DDR-E04AB / DDR-D04AB User Manual 1. Select the date or today (Move the mouse wheel up and down to exit the page) 2. Select "Filter" and” cameras or Sensor” There are those items in “Filter “: All, Authentication, Record , System ,Playback, Setup ,Backup ,Storage ,Remote, Alarm.
-
Page 29: Notification
DDR-E04AB / DDR-D04AB User Manual 3.14 Notification Press , the following window is displayed A. Video Loss Detection, Motion Detection and Alarm Input can select “Email” and” FTP” to notice. B. Hard Disk Drive Detection select Email to notice. C. Press the "Save" to confirm setting or press "Revert" to revert again. -
Page 30: Pause, Replay And Backup In Live Mode
DDR-E04AB / DDR-D04AB User Manual If there is software to update, the following screen will appear. Press the "Update now", the following screen will appear after finishing the update. Press “Reboot now” then reboot. 3.16 Pause, Replay and Backup in Live mode Put the Mouse on top of the screen to appear the following screen. -
Page 31: Quick Menu In Live Mode
DDR-E04AB / DDR-D04AB User Manual C. Press the "Replay" to replay screen within 15 seconds, press the "Fast" or "Slow" to speed up or slow down the replay. D. Press “Live” to resume live screen. E. Press "Backup" ( USB storage device or SD card must be inserted) 3.17 Quick Menu in Live mode... -
Page 32: Chapter 4 Windows® Remote Client
DDR-E04AB / DDR-D04AB User Manual Chapter 4 Windows® Remote Client You can also operate the DVR unit via Windows® remote client to monitor, playback the connected DTV cameras and manage the functions of the DVR system. 4.1 Login Click the Start button -> DVR Client -> DVR Remote Client at your Windows® desktop. When the client is entered, you will see the following login window. -
Page 33: Chapter 5 Iphone / Ipad Users & Android Users
DDR-E04AB / DDR-D04AB User Manual Chapter 5 iPhone / iPad users & Android users For iPhone / iPad users & Android users, please visit APP Store or Google Play to download “ ccHDtv Mobile” for remote mobile device access This screen appears... - Page 34 Contact Information: Ubiquity Smart Technology (UST Taiwan) TEL: +886-3-5777-368 FAX: +886-3-5777-339 Mail: sales@ubiquitysmaet.com...
