- Page 1 DDR-E04AA Hardware User Manual 2015 FEB V1.0...
-
Page 2: Table Of Contents
DDR-E04AA Hardware User Manual Contents CAUTION .............................. 1 Introduction ............................2 1. Product Overview ........................2 2. Main functions ........................... 2 Unpacking ............................4 1. Accessories ..........................4 2. Unpacking ........................... 4 Installation ............................4 Product appearance ......................... 6 1. Front Panel ..........................6 2. -
Page 3: Caution
DDR-E04AA Hardware User Manual A. CAUTION To our dear customers! Thank you for using our products. If you encounter any problems when using, please do not hesitate to contact our resellers. We will provide excellent services to you via our resellers. -
Page 4: Introduction
DDR-E04AA Hardware User Manual direct sunlight or near heat sources. Do not install this equipment in a humid environment Do not expose this equipment in smoky, dusty environments; Avoid strong collision, do not drop the machine Keep the installation level, install in a stable place, avoid the product falling;... - Page 5 DDR-E04AA Hardware User Manual Advanced H.264 compress technology provides the best HDD space usage. Embedded Linux system, to eliminate the threat from virus and hacking. Support 4CHs of Dtv Camera (1080P) video. Support HD output. Support CAMERA position layout and editable user definition.
-
Page 6: Unpacking
DDR-E04AA Hardware User Manual C. Unpacking Accessories ★ Power cable and adaptor AC100-240V/DC12V 3A x 1PCS ★ HDD screws x 4pcs ★ Mouse (optional) Unpacking When you receive the product, check first whether the packing of the equipment has obvious damage. The protective material used for the package during transport can cope with most of the accidental impact;... - Page 7 DDR-E04AA Hardware User Manual 3、Chassis installation starts from bottom to up 4、With multiple components in the chassis, take precautions to avoid overloading to the power outlet.
-
Page 8: Product Appearance
DDR-E04AA Hardware User Manual E. Product appearance Front Panel Under the live viewing mode, press MENU to enter the MENU MENU main menu. Exit the current menu. Under the live mode, press the REC button to enter recording menu. STOP Stop the playback under the playback mode. - Page 9 DDR-E04AA Hardware User Manual Indicator Recording Recording Indicator Indicator...
-
Page 10: Rear Panel
DDR-E04AA Hardware User Manual Rear Panel 4ch DVR illustration 1~4 CH Video Input (BNC) Video Output HD digital output VGA output LAN Port USB Mouse Port DC12 Power Input Alarm IN Alarm OUT Alarm In/Alarm Out DC12V ... -
Page 11: Installation Illustration
DDR-E04AA Hardware User Manual Installation Illustration Video input Input interface is BVC type; input signal is PAL/NTSC BNC（1.0VP-P，75Ω）. The Video signal should comply with national standards, a higher signal to noise ratio, low distortion, low-interference; clear images, no deformation, nature color and appropriate brightness. -
Page 12: Connections For Video Outputs
DDR-E04AA Hardware User Manual Connections for video outputs The video outputs include PAL/NTSC BNC(1.0VP-P，75Ω), VGA and HDMI interfaces. Pay attention to the following when you select a PC display instead of a monitor. Do not remain switched on for a long time to extend the life of the equipment;... -
Page 13: Q & A And Maintenance
DDR-E04AA Hardware User Manual F. Q & A and Maintenance 1. Q & A Q 1. After power on, DVR doesn’t work. A: The possible causes: 1. Wrong power input 2. bad connection of power cable 3. Power error 4. Firmware update error 5. - Page 14 DDR-E04AA Hardware User Manual 3. No signal input or signal too weak 4. Mask used 5. DVR hardware error Q 5. Live video problems: Such as bad colors, brightness error, image blink… A : The possible causes: 1. When using BNC as output, wrong NTSC/PAL matching will result in B/W image.
- Page 15 DDR-E04AA Hardware User Manual 3. Bad frequency oscillator Q 9. Motion detection not function A : The possible causes: 1. Wrong schedule setting 2. Wrong area setting 3. Low sensitivity 4. Hardware limitation for different version Q 10. Fail to login by using client software or Web browsers A : The possible causes: 1.
- Page 16 DDR-E04AA Hardware User Manual 2. Device not compatible 3. Backup device error Q 14. Alarms cannot be stopped A : The possible causes: 1. Wrong alarm settings 2. AlarmOut turned on manually 3. Input equipment error or wrong connections. 4. Wrong firmware problem; Upgrade firmware to fix it.
-
Page 17: Maintenance
DDR-E04AA Hardware User Manual Please contact local customer service staff or call the customer service phone headquarters, we will guide you how to solve by the machine type and version of the program. 2. Maintenance Damped dust on the PCB board will cause a short circuit and will do ... -
Page 18: Appendix : Specifications
DDR-E04AA Hardware User Manual G. Appendix : Specifications System CPU: Hisilicon SoC Operating system：Linux Storage Device/ Build in SATA interface x 1，compatible SATA/SATAII Interface HDD( Max. 4TB) User Interface DVR IR remote control Video And Other I/O Alarm OUT x1 / Alarm IN x4 (optional) - Page 19 DDR-E04AA Hardware User Manual Systems operation records, record login time, IP and selected video. Browser: MS IE7-IE11 Support Equipment Support megapixel DTV Camera video Power DC12V / 3A Operating Temperature 0-45 ℃ ★Product specifications are subject to change without notice; please contact us for the latest...
- Page 20 Contact Information: Ubiquity Smart Technology (UST Taiwan) TEL: +886-3-5777-368 FAX: +886-3-5777-339 Mail: sales@ubiquitysmaet.com...
