Page 1 2016 SUPER DUTY Owner’s Manual fordowner.com ford.ca April 2015 First Printing Owner’s Manual Super Duty Litho in U.S.A. GC3J 19A321 AA...
Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2015 All rights reserved. Part Number: 20150323155431...
Page 4: Table Of Contents
About This Manual...........7 Symbols Glossary..........7 Keys and Remote Controls Data Recording..........9 General Information on Radio California Proposition 65......11 Frequencies..........47 Perchlorate............11 Remote Control..........47 Ford Credit............11 Replacing a Lost Key or Remote Replacement Parts Control............50 Recommendation........11 Special Notices..........12 MyKey Mobile Communications Principle of Operation........51 Equipment.............13...
Page 5 Table of Contents Hints on Controlling the Interior Pedals Climate............112 Adjusting the Pedals........69 Heated Windows and Mirrors....115 Remote Start..........116 Wipers and Washers Windshield Wipers.........70 Seats Windshield Washers........70 Sitting in the Correct Position....117 Head Restraints..........117 Lighting Manual Seats..........119 General Information........71 Power Seats...........120 Lighting Control..........71 Memory Function.........120 Autolamps............72...
Page 6 Table of Contents Fuel Consumption........147 Driving Aids Emission Control System......148 Steering............184 Transmission Load Carrying Automatic Transmission......151 Load Limit............185 Power Take-Off..........156 Towing Four-Wheel Drive Towing a Trailer..........192 Using Four-Wheel Drive......158 Trailer Sway Control........193 Recommended Towing Weights....193 Rear Axle Essential Towing Checks......196 Limited Slip Differential......167 Towing Points..........204 Electronic Locking Differential....167...
Page 7 Table of Contents Reporting Safety Defects (U.S. Cleaning the Windows and Wiper Only)..............221 Blades............258 Reporting Safety Defects (Canada Cleaning the Interior........258 Only).............222 Cleaning the Instrument Panel and Instrument Cluster Lens.......259 Fuses Cleaning Leather Seats......259 Fuse Specification Chart......223 Repairing Minor Paint Damage....261 Changing a Fuse..........231 Cleaning the Alloy Wheels......261 Vehicle Storage..........261...
Page 8 Table of Contents SYNC General Information........329 Using Voice Recognition......331 Using SYNC With Your Phone....334 SYNC Applications and Services..346 SYNC AppLink ........354 Using SYNC With Your Media Player............355 SYNC Troubleshooting......365 MyFord Touch General Information........374 Settings............382 Entertainment..........395 Phone..............411 Information.............418 Climate............428 Navigation............431 MyFord Touch Troubleshooting..440 Accessories Accessories............447...
Page 9 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 10: Introduction
Introduction Note: Either Ford Motor Company or an ABOUT THIS MANUAL authorized Ford dealer may have originally sold this incomplete vehicle to a vehicle Thank you for choosing Ford. We modifier who upfitted it. As a result, some recommend that you take some time to...
Page 11 Introduction Avoid smoking, flames or sparks Engine oil Battery Explosive gas Fan warning Battery acid Fasten safety belt Brake fluid - non petroleum based Front airbag Brake system Front fog lamps Cabin air filter Fuel pump reset Check fuel cap Fuse compartment Child safety door lock or unlock Hazard warning flashers...
Page 12: Data Recording
Panic alarm as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair Parking aid facilities may access or share among them vehicle diagnostic information received...
Page 13 Other parties may seek to were operating; access the information independently • Whether or not the driver and of Ford Motor Company and Ford of passenger safety belts were Canada. buckled/fastened; Note: Including to the extent that any •...
Page 14: California Proposition 65
Ford replacement collision parts meet our stringent requirements for fit, finish, (U.S. Only) structural integrity, corrosion protection Ford Credit offers a full range of financing and dent resistance. During vehicle and lease plans to help you acquire your development we validate these parts vehicle.
Page 15: Special Notices
Using your Vehicle as an provided to you along with your Owner’s Ambulance Manual. If your light truck is equipped with the Ford Special Instructions Ambulance Preparation Package, it may be utilized as an ambulance. Ford urges For your added safety, your vehicle is fitted ambulance manufacturers to follow the with sophisticated electronic controls.
Page 16: Mobile Communications Equipment
Introduction If your vehicle is equipped with the Ford WARNING Ambulance Preparation Package, it will be Driving while distracted can result in indicated on the Safety Compliance loss of vehicle control, crash and Certification Label. The label is located on injury.
Page 17: Environment
Environment PROTECTING THE ENVIRONMENT You must play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 18: Child Safety
Ford recommends Exposure of people or animals to these checking with a NHTSA Certified Child high temperatures for even a short time...
Page 19: Installing Child Seats
Child Safety Recommendations for Safety Restraints for Children Child Child size, height, weight, or age Recommended restraint type Infants or Children weighing 40 lb (18 kg) or less Use a child safety seat toddlers (generally age four or younger). (sometimes called an infant carrier, convertible seat, or toddler seat).
Page 20 Child Safety Use a child safety seat (sometimes called • Place the vehicle seat upon which the an infant carrier, convertible seat, or child seat will be installed in the upright toddler seat) for infants, toddlers, or position. children weighing 40 pounds (18 •...
Page 21 Child Safety E142530 E142875 3. While holding the shoulder and lap belt 5. To put the retractor in the automatic portions together, route the tongue locking mode, grasp the shoulder through the child seat according to the portion of the belt and pull downward child seat manufacturer's instructions.
Page 22 There should be no more than 1 inch (2.5 centimeters) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child E142528 restraint is properly installed.
Page 23 Child Safety 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 24: Using Tether Straps
Ford recommends checking with a NHTSA The passenger seats of your vehicle may Certified Child Passenger Safety be equipped with built-in tether strap...
Page 25: Tether Strap Attachment
Child Safety F-Series Regular Cab E162710 F-Series SuperCab E162711 Note: For vehicles with adjustable head F-Series Crew Cab restraints, route the tether strap under the Attach the tether strap only to the head restraint and between the head appropriate tether anchor as shown. The restraint posts, otherwise route the tether tether strap may not work properly if strap over the top of the seat back.
Page 26 If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. E162715 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 27: Booster Seats
Child Safety 2. Attach the strap hook onto the loop 80 pounds (36 kilograms) and upward to behind an adjacent seating position. 100 pounds (45 kilograms) if recommended by your child restraint manufacturer). Many state and provincial laws require that children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms).
Page 28: Types Of Booster Seats
Child Safety Types of Booster Seats E70710 • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child's head, a high back E68924 booster seat would be a better choice. •...
Page 29: Child Seat Positioning
Child Safety E142596 E142597 WARNINGS If the booster seat slides on the vehicle the way back. When possible, all children seat upon which it is being used, placing a age 12 and under should be properly rubberized mesh sold as shelf or carpet restrained in a rear seating position.
Page 30: Child Safety Locks
Child Safety WARNINGS WARNINGS manufacturer. A safety seat that is Always restrain an unoccupied child improperly installed or utilized, is seat or booster seat. These objects inappropriate for your child's height, age, may become projectiles in a crash or or weight or does not properly fit the child sudden stop, which may increase the risk may increase the risk of serious injury or of serious injury.
Page 31 Child Safety E162719 The childproof locks are located on the rear edge of each rear door. You must set the lock separately for each door. Move the lock control up or down to engage or disengage the childproof lock. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 32: Safety Belts
Safety Belts PRINCIPLE OF OPERATION WARNINGS When possible, all children 12 years old and under should be properly WARNINGS restrained in a rear seating position. Always drive and ride with the Failure to follow this could seriously seatback upright and the lap belt increase the risk of injury or death.
Page 33: Fastening The Safety Belts
Safety Belts The safety belt pretensioners at the front seating positions are designed to tighten the safety belts when activated. In frontal and near-frontal crashes, side crashes and rollovers, the safety belt pretensioners may be activated alone or, if the crash is of sufficient severity, together with the front airbags.
Page 34: Using Safety Belts During Pregnancy
Safety Belts While you are fastened in the safety belt, the lap and shoulder belt with a cinch tongue adjusts to your movement. However, if you brake hard, turn hard, or if your vehicle receives an impact of 5.0 mph (8 km/h) or more, the safety belt will become locked and help reduce your forward movement.
Page 35 Safety Belts Safety Belt Locking Modes Automatic Locking Mode In this mode, the shoulder belt is WARNINGS automatically pre-locked. The belt will still After any vehicle crash, the safety retract to remove any slack in the shoulder belt system at all passenger seating belt.
Page 36: Safety Belt Height Adjustment
Safety Belts How to Disengage the Automatic Locking Mode Unbuckle the combination lap and shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. Safety Belt Extension Assembly WARNING Do not use extensions to change the E145664...
Page 37: Safety Belt Minder
Safety Belts Conditions of operation If... Then... The driver's safety belt is not buckled The safety belt warning light illuminates 1- before the ignition switch is turned to the 2 minutes and the warning chime sounds on position... 4-8 seconds. The driver's safety belt is buckled while the The safety belt warning light and warning indicator light is illuminated and the...
Page 38 Safety Belts If... Then... The driver's safety belt is buckled before The Belt-Minder feature will not activate. the ignition switch is turned to the on posi- tion or less than 1-2 minutes have elapsed since the ignition switch has been turned to on...
Page 39: Child Restraint And Safety Belt Maintenance
Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a crash be replaced. However, if the crash was minor and an authorized...
Page 40: Supplementary Restraints System
Supplementary Restraints System The airbags are a supplemental restraint PRINCIPLE OF OPERATION system and are designed to work with the safety belts to help protect the driver and WARNINGS right front passenger from certain upper Airbags do not inflate slowly or body injuries.
Page 41: Driver And Passenger Airbags
Supplementary Restraints System Passenger Airbag On and Off DRIVER AND PASSENGER Switch (If Equipped) AIRBAGS WARNINGS WARNINGS Even with Advanced Restraints Never place your arm or any objects Systems, children 12 and under over an airbag module. Placing your should be properly restrained in a arm over a deploying airbag can rear seating position.
Page 42 Supplementary Restraints System Switch position Passenger airbag status Passenger airbag indicator OFF: Lit Disabled ON: Unlit OFF: Unlit Enabled ON: Lit WARNINGS An infant in a rear-facing seat faces a high risk of serious or fatal injuries from a deploying passenger airbag. Rear facing infant seats should never be placed in the front seats, unless the passenger airbag is turned off.
Page 43 Supplementary Restraints System Turning the Passenger Airbag Back On WARNINGS The safety belts for the driver and right front passenger seating positions have been specifically designed to function together with the airbags in certain types of crashes. When you turn off your airbag, you not only lose E162723 the protection of the airbag, you also may Insert the ignition key and turn the...
Page 44 Supplementary Restraints System very significant risk reducing benefits of • The vehicle has no rear seat; the airbag and you are also reducing the • The vehicle has a rear seat too small effectiveness of the safety belts, because to accommodate a rear-facing infant safety belts in modern vehicles are seat;...
Page 45 Supplementary Restraints System Transport Canada Deactivation Criteria • My vehicle has no rear seat; (Canada Only) • Although children age 12 and under ride in the rear seat whenever possible, WARNING children age 12 and under have no This vehicle has special energy option but to sometimes ride in the management safety belts for the front seat because rear seat space is...
Page 46: Side Airbags
Supplementary Restraints System After all occupants have adjusted their If two adults and a child occupy a Regular seats and put on safety belts, it is very Cab, properly restrain the child in the important that they continue to sit center front unless doing so would interfere properly.
Page 47: Safety Canopy
Supplementary Restraints System The side airbags are located on the SAFETY CANOPY outboard side of the seatbacks of the front seats. In certain sideways crashes, the WARNINGS airbag on the side affected by the crash Do not place objects or mount will be inflated.
Page 48: Crash Sensors And Airbag Indicator
Supplementary Restraints System The Safety Canopy will deploy during Children 12 years old and under should significant side crashes or when a certain always be properly restrained in the rear likelihood of a rollover event is detected seats. The Safety Canopy will not interfere by the rollover sensor.
Page 49: Airbag Disposal
Supplementary Restraints System The restraints control module also The fact that the safety belt pretensioners monitors the readiness of the above safety or front airbags did not activate for both devices plus the crash and occupant front seat occupants in a crash does not sensors.
Page 50: Keys And Remote Controls
Keys and Remote Controls Note: The remote control contains sensitive GENERAL INFORMATION ON electrical components. Exposure to moisture RADIO FREQUENCIES or impact may cause permanent damage. This device complies with Part 15 of the REMOTE CONTROL FCC Rules and with Industry Canada license-exempt RSS standard(s).
Page 51: Car Finder
Keys and Remote Controls Car Finder Note: Replacing the battery will not delete the transmitter from the vehicle. The Press the button twice within transmitter should operate normally. three seconds. The horn will The remote control uses one coin-type sound and the turn signals will E138623 three-volt lithium battery CR2032 or flash.
Page 52 Keys and Remote Controls Many states and provinces have Note: If you remote start your vehicle with restrictions for the use of remote start. an integrated keyhead transmitter, you must Check your local and state or provincial switch the ignition on before driving your laws for specific requirements regarding vehicle.
Page 53: Replacing A Lost Key Or Remote Control
Keys and Remote Controls REPLACING A LOST KEY OR REMOTE CONTROL Replacement keys or remote controls can be purchased from an authorized dealer. Authorized dealers can program remote controls for your vehicle. See Passive Anti-Theft System (page 64). To re-program the passive anti-theft system see an authorized dealer.
Page 54: Mykey
MyKey Configurable Settings PRINCIPLE OF OPERATION With an admin key, you can configure MyKey allows you to program keys with certain MyKey settings when you first restricted driving modes to promote good create a MyKey and before you recycle the driving habits.
Page 55: Creating A Mykey
MyKey MyKey is successfully created. Make sure CREATING A MYKEY you label it so you can distinguish it from the admin keys. Use the information display to create a MyKey. There are two types of information You can also program configurable displays, and their controls and messaging settings for the key(s).
Page 56: Clearing All Mykeys
MyKey 3. Use the arrow buttons to get to a If You Have a Type 1 Information configurable feature. Display: 4. Press OK or > to make a selection. Press SETUP until PRESS RESET TO CLEAR MYKEY displays. Note: You can clear or change your MyKey settings at any time during the same key 2.
Page 57 MyKey Message Description MyKey Dist. Tracks the distance when drivers use a MyKey. The only way to delete the accumulated distance is by using an admin key to clear your MyKeys. If the distance does not accumulate as expected, then the intended user is not using the MyKey, or an admin key user recently cleared and then recreated a MyKey.
Page 58: Using Mykey With Remote Start Systems
Ford-approved, aftermarket remote start USING MYKEY WITH REMOTE systems. If you choose to install a remote START SYSTEMS start system, see an authorized dealer for a Ford-approved remote start system. MyKey is not compatible with non MYKEY TROUBLESHOOTING Condition Potential causes I cannot create a MyKey.
Page 59: Locks
Locks Locking the Doors LOCKING AND UNLOCKING Press the button to lock all the You can use the power door lock control doors. The turn signals will or the remote control to lock and unlock illuminate. E138623 your vehicle. Press the button again within three Power Door Locks seconds to confirm that all the doors are (If Equipped)
Page 60: Keyless Entry
Locks Battery Saver The autolock feature will unlock all the doors when: The battery saver turns off the interior • autolock has locked the doors lamps 30 minutes after you switch the • you stop the vehicle and switch the ignition off if a door is open and the dome ignition off or to accessory mode, and lamp switch is on.
Page 61 Locks Programming a Personal Entry Code Erasing a Personal Code To create your own personal entry code: Enter the factory-set 5-digit code. 2. Press and release 1·2 on the keypad Enter the factory-set code. within five seconds. 2. Press 1·2 on the keypad within five 3.
Page 62: Unlocking And Locking The Doors
Locks Unlocking and Locking the Doors Vehicles Without Intelligent Access To Unlock the Driver Door Enter the factory-set 5-digit code or your personal code. You must press each number within five seconds of each other. The interior lamps will illuminate. Note: All doors will unlock if you disable the two-stage unlocking mode.
Page 63: Tailgate
Tailgate TAILGATE LOCK The tailgate lock can help prevent theft of the tailgate. E163090 Locate and disconnect the rearview camera in-line connector. It is under the pickup box on the right-hand side of the vehicle near the spare tire. E163087 2.
Page 64: Tailgate Step
Tailgate Lift the tailgate to a 45-degree angle from horizontal. 8. Lift the right side off its hinge. 9. Lift the tailgate to an 80-degree angle from horizontal. Remove the tailgate from the left side hinge by sliding it to the right. Reverse the steps to reinstall the tailgate.
Page 65: Bed Extender
Tailgate 2. Move the yellow lever on the grab handle to the unlock position and lower the handle. BED EXTENDER (If Equipped) Note: Do not use the bed extender when driving off road. Note: Make sure to engage the locking pins and knobs fully before driving your vehicle.
Page 66: Grocery Mode
Tailgate E163099 5. Make sure to insert the latch rod into the tailgate hole. Make sure to engage both sides of the locking pins into their holes in the pick-up box. Reverse the steps to store the bed extender. Grocery mode E163100 Follow Steps 1-4 of the tailgate mode instructions by rotating the panels away...
Page 67: Security
Note: The system is not compatible with The integrated keyhead transmitter non-Ford aftermarket remote start systems. functions as a programmed ignition key. It Use of these systems may result in vehicle operates all the locks, starts the vehicle starting problems and a loss of security and acts as a remote control.
Page 68: Anti-Theft Alarm
Security Insert the first previously programmed The direction indicators flash and the horn coded key into the ignition. sounds if the system triggers while the alarm is armed. 2. Switch the ignition from off to on. Keep the ignition on for at least three Take all remote controls to an authorized seconds, but no more than 10 seconds.
Page 69: Steering Wheel
Steering Wheel ADJUSTING THE STEERING WHEEL WARNING Do not adjust the steering wheel when your vehicle is moving. Note: Make sure that you are sitting in the correct position. See Sitting in the Correct Position (page 117). E183049 3. Lock the steering column. AUDIO CONTROL (If Equipped) You can operate the following functions...
Page 70: Voice Control
Steering Wheel CRUISE CONTROL Seek down or previous. (If Equipped) Seek up or next. Media Press repeatedly to scroll through available audio modes. Seek, Next or Previous Press the seek button to: • Tune the radio to the next or previous stored preset.
Page 71: Heated Steering Wheel
Steering Wheel Type 2 E163055 See Information Displays (page 89). HEATED STEERING WHEEL Equipped) See MyFord Touch (page 374). Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 72: Pedals
Pedals ADJUSTING THE PEDALS Equipped) WARNING Never use the controls while your feet are on the accelerator and brake pedals and the vehicle is moving. You can find the control on the left side of the steering column. Press and hold the appropriate side of the control to move the pedals.
Page 73: Wipers And Washers
Wipers and Washers WINDSHIELD WIPERS WINDSHIELD WASHERS Note: Fully defrost the windshield before Note: Do not operate the wipers on a dry switching on the windshield wipers. windshield. This may scratch the glass, damage the wiper blades or cause the wiper Note: Make sure the windshield wipers are motor to burn out.
Page 74: Lighting
Lighting GENERAL INFORMATION LIGHTING CONTROL Condensation in Lamp Assemblies Exterior lamps have vents to accommodate normal changes in air pressure. Condensation can be a natural by-product of this design. When moist air enters the lamp assembly through the vents, there is a possibility that condensation can occur when the temperature is cold.
Page 75: Autolamps
Lighting Headlamp Flasher Note: If the vehicle is equipped with autolamps, it will have the headlamps on with windshield wipers feature. If the windshield wipers are turned on, the exterior lamps will turn on with the headlamp control in the autolamp position. The autolamp system also keeps the lights on for a predetermined amount of time after the ignition switch is turned to off.
Page 76: Instrument Lighting Dimmer
Lighting INSTRUMENT LIGHTING DAYTIME RUNNING LAMPS DIMMER Equipped) WARNING Always remember to switch your headlamps on in low light situations or during inclement weather. The system does not activate the tail lamps and may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 77: Direction Indicators
Lighting The headlamp control also operates the • Push the lever up or down to the first fog lamps. The fog lamps can be turned stop position and release. The direction on only when the headlamp control is in indicators flash three times and stop. the parking lamp (second) position, •...
Page 78: Rear Dome And Map Lamps
Lighting Rear Dome and Map Lamps E163274 Your vehicle may have map lamps within the rear dome lamp. Press the switches on either side of the dome lamp to turn the lamps on. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 79: Windows And Mirrors
Windows and Mirrors Note: Perform one-touch up re-calibration POWER WINDOWS (If Equipped) with the door closed. Calibrating with the door open will cause the window to WARNINGS continuously bounce back. Do not leave children unattended in To reset the function after full battery your vehicle and do not let them play power is restored: with the power windows.
Page 80: Global Opening
Windows and Mirrors Window Lock EXTERIOR MIRRORS Power Exterior Mirrors (If Equipped) WARNING Do not adjust the mirrors when your vehicle is moving. E163057 Unlock Lock Press the control to lock or unlock the rear window controls. E163059 Accessory Delay (If Equipped) Left-hand mirror You can use the window switches for...
Page 81 Windows and Mirrors Clearance Lamps Power-Folding Mirrors (If Equipped) (If Equipped) The lower, outer part of the mirror housings light when you switch the headlamps or parking lamps on. Telescoping Mirrors (If Equipped) E163060 Rotate the control so the dots line up. 2.
Page 82: Interior Mirror
Windows and Mirrors To adjust the mirrors: SLIDING WINDOWS (If Equipped) • Press and hold the control. Power Sliding Back Window • When you position the mirrors in or out, the motors will run as long as you hold Equipped) the control.
Page 83: Sun Visors
Windows and Mirrors SUN VISORS WARNINGS When closing the moonroof, you Slide-on-rod should verify that it is free of (If Equipped) obstructions and make sure that children and pets are not in the proximity of the roof opening. You can manually open or close the sliding shade when the moonroof is closed.
Page 84: Venting The Moonroof
Windows and Mirrors Bounce-Back The moonroof will stop automatically while closing. It will reverse some distance if there is an obstacle in the way. Pull and hold the SLIDE control within two seconds of a bounce-back event to override this function. While bounce-back is active, the closing force increases for each of the next three times that you close the moonroof.
Page 85: Instrument Cluster
Instrument Cluster GAUGES E163168 Engine oil pressure gauge Engine coolant temperature gauge Transmission fluid temperature gauge Fuel gauge Speedometer Information display See (page 89). Tachometer Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 86: Engine Oil Pressure Gauge
Instrument Cluster Engine Oil Pressure Gauge transmission for extended periods of time with the gauge in the higher than normal Indicates engine oil pressure. The needle area may cause internal transmission should stay in the normal operating range damage. Altering the severity of the driving (between L and H).
Page 87: Warning Lamps And Indicators
Instrument Cluster Variations: Driving type (fuel economy Fuel gauge position Distance-to-empty conditions) Highway driving 1/16th 35 miles to 80 miles (56 km to 129 km) Severe duty driving (trailer 1/16th 35 miles (56km) towing, extended idle) Anti-Lock Braking System Information Display If it illuminates when you are Odometer driving, this indicates a...
Page 88 Instrument Cluster Engine Coolant Temperature WARNING Driving your vehicle with the warning Illuminates when the engine lamp on is dangerous. A significant coolant temperature is high. decrease in braking performance Stop the vehicle as soon as may occur. It will take you longer to stop possible, switch off the engine and let cool.
Page 89 Instrument Cluster Low Fuel Level If the light is blinking, engine misfire is occurring which could damage your Illuminates when the fuel level catalytic converter. Drive in a moderate is low or the fuel tank is nearly fashion (avoid heavy acceleration and empty.
Page 90: Audible Warnings And Indicators
Instrument Cluster Stability Control Off Diesel Warning Lights Illuminates when you switch the If your vehicle is equipped with a diesel system off. It will go out when engine, it has some unique warning lights; you switch the system back on refer to your diesel supplement for detailed or when you switch the ignition off.
Page 91: Parking Brake On Warning Chime
Instrument Cluster Parking Brake On Warning Chime Sounds when you have left the parking brake on and drive your vehicle. If the warning chime remains on after you have released the parking brake, have the system checked by your authorized dealer immediately.
Page 92: Information Displays
Information Displays Information Display Controls GENERAL INFORMATION (Type 1) WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road.
Page 93 Information Displays INFO TRIP A/B XXX° (if equipped) MYKEY MILES (km) (if programmed) XXX MILES (km) TO E XX.X AVG MPG (L/100km) MPG (L/km) TIMER TBC GAIN (if equipped) EXHAUST FILTER (diesel only) This value is not the same as the average TRIP A/B fuel economy display.
Page 94 Information Displays EXHAUST FILTER Note: Some options may appear slightly different or not at all if the items are For more information, refer to the Diesel optional. supplement. Note: When returning to the SETUP menu System check and vehicle feature and you selected a non-English language, customization HOLD RESET FOR ENGLISH will display to...
Page 95 Information Displays SETUP (cont’d) REAR PARK AID On or Off REMOTE WINDOW On or Off OPEN CREATE MYKEY / MYKEY SETUP / CLEAR MYKEY RESET FOR REMOTE START press the RESET On or Off button 5, 10, 15 minutes TBC MODE Electric or EOH TBC EFFORT LOW, MED or HIGH...
Page 96 Information Displays AUTOUNLOCK Press the RESET button to set the language choice. This feature automatically unlocks all vehicle doors when the driver’s door is Information Display Controls opened within 10 minutes of the ignition (Type 2) (If Equipped) being turned off. COURTESY WIPE This feature allows for an extra swipe of the wipers after a wipe/wash cycle.
Page 97 Information Displays Gauge Mode Settings E144641 E163179 Trip A / B Information E144642 E138660 Fuel Economy Display Mode E163180 Use the arrow buttons to choose Truck Apps (If Equipped) between the following gauge options. E163179 E163181 Gauge Mode Gauges Detail Engine Oil Temperature (Diesel only) Transmission Temperature Compass...
Page 98 Information Displays Trip A / B Trip time Trip distance Fuel used Avg MPG (L/100km) Odometer Fuel used Press OK to pause the Trip A or B screen, press again to un-pause. Shows the amount of fuel used for a given Press and hold OK to reset the currently trip.
Page 99 Information Displays Fuel Hist. Truck Apps Shows fuel usage as a bar graph based on In this mode, off-road time. The graph is updated each minute information depicted with with the fuel economy that was achieved graphics and trailer towing E163181 during the prior 5, 10, 30 minutes of driving.
Page 100 Information Displays Truck Apps (cont’d) Trailer (cont’d) Press OK for options Rename Trailer Reset Trailer Mileage / Kilometers (if equipped) Connection Checklist Trailer disconnected Use the up/down arrows to highlight one Disregard this status if your vehicle is not of these choices and press OK to display equipped with a factory installed trailer the connection checklist.
Page 101 Information Displays Settings Driver Rear Park Aid On or Off Assist Rear Video Camera Camera Delay On or Off Trailer Brake Trailer Brake Mode Electric or Elect. Over Hydraulic Trailer Brake Effort Light, Medium or High Trailer Sway Control On or Off Vehicle Autolamp Delay Off or XXX seconds...
Page 102 Information Displays Settings (cont’d) MyKey Create MyKey Hold OK to Create MyKey AdvanceTrac Always On or Selectable MAX Speed 80 MPH (130 km/h) or Off Speed Warning 45, 55 or 65 MPH (75, 90 or 105 km/h), Off Volume Limiter On or Off Clear MyKey Hold OK to Clear MyKey...
Page 103: Information Messages
Information Displays Compass/Transmission indicator INFORMATION MESSAGES display (if equipped) Note: Depending on your vehicle options The compass heading will display in the and instrument cluster type, not all of the upper right corner of the information messages will display or be available. display;...
Page 104: Diesel Messages
Information Displays Diesel Messages WARNING When the CLEANING EXHAUST FILTER message appears in the information display, do not park near flammable materials, vapors or structures until filter cleaning is complete. Message Action CHECK COOLANT The coolant additive needs checking. Refer to your diesel ADDITIVE supplement for more information.
Page 105 Information Displays Message Action ENGINE TURNS OFF IN The powertrain control module will intentionally turn the XX SECONDS engine off due to your vehicle being in the final 30 seconds of a countdown. The diesel engine shutdown for extended idling is an optional feature.
Page 106 Information Displays Message Action ENGINE IDLED SOON The selective catalytic reduction system detects low exhaust EXHAUST FLUID EMPTY fluid. The engine will eventually enter into an idle only mode. You must replenish the diesel exhaust fluid to resume normal operation of your vehicle. Refer to your diesel supplement for more information.
Page 107: Doors And Locks
Information Displays Message Action You are responsible for assuring that you operate your vehicle in a manner that allows diesel particulate filter cleaning to occur. Ignoring the EXHAUST OVER LIMIT SERVICE NOW warning message could lead to reduced drivability and customer expense, including damage to the diesel particulate filter.
Page 108 Information Displays Message Action TO ENGAGE ELD RELEASE PEDAL SLOW VEHICLE TO XX The electronic locking differential requests a certain speed KM/H FOR ELD requirement to engage. SLOW VEHICLE TO XX The electronic locking differential requests a certain speed MPH FOR ELD requirement to engage.
Page 109 Information Displays Maintenance Message Action ENGINE OIL CHANGE SOON The engine oil life is nearing its end. See Engine Oil Check (page 235). OIL CHANGE REQUIRED The oil life left reaches 0%. See Engine Oil Check (page 235). BRAKE FLUID LEVEL LOW The brake fluid level is low and the brake system needs inspection immediately.
Page 110: Park Aid
Information Displays Park Aid Message Action CHECK REAR PARK AID The transmission is in R (Reverse) and the park aid is disabled. REAR PARK AID OFF The rear park aid is disabled. REAR PARK AID ON The rear park aid is enabled. Park Brake Message Action...
Page 111 Information Displays Message Action HILL DESCENT - DRIVER Hill descent control mode is no longer active and the RESUME CONTROL driver must resume control. HILL DESCENT CONTROL A hill descent system fault is present. FAULT HILL DESCENT CONTROL OFF The hill descent system is cooling due to overuse. SYSTEM COOLING HILL DESCENT CONTROL Hill descent control is active.
Page 112 Information Displays Message Action TRAILER CONNECTED A correct trailer connection (a trailer with electric trailer brakes) is sensed during a given ignition cycle. TRAILER DISCONNECTED A trailer connection becomes disconnected, either intentionally or unintentionally, and has been sensed during a given ignition cycle. Disregard this status if your vehicle is not equipped with a factory installed trailer brake controller.
Page 113: Climate Control
Climate Control MANUAL CLIMATE CONTROL E163163 Defrost: Select to distribute air through the windshield air vents. Air distribution to the instrument panel and footwell vents turns off. You can also use this setting to defrost and clear the windshield of a thin covering of ice. Heated rear window: Press the button to switch the heated rear window on and off.
Page 114: Automatic Climate Control
Climate Control MAX A/C: Press the button to maximize cooling. Recirculated air flows through the instrument panel vents, air conditioning automatically turns on, and the fan automatically adjusts to the highest speed. Note: Recirculated air may turn off automatically (or be prevented from turning on) in all airflow modes except MAX A/C to reduce risk of fogging.
Page 115: Hints On Controlling The Interior Climate
Climate Control Air distribution control: Adjust the control to turn airflow from the windshield, instrument panel, or footwell vents on or off. You can distribute air through any combination of these vents. A/C: Press the button to switch the air conditioning on or off. Air conditioning cools your vehicle using outside air.
Page 116: Heating The Interior Quickly
Climate Control Note: To improve the time to reach comfort Note: If you select AUTO during cold in hot weather, drive with the windows outside temperatures, the system directs slightly open for 2-3 minutes after start-up airflow to the windshield and side window or until your vehicle airs out.
Page 117: Recommended Settings For Heating
Climate Control Recommended Settings for Heating Vehicle with manual climate control Vehicle with automatic climate control Adjust the fan speed to the center Press the AUTO button. setting. Adjust the temperature control to the Adjust the temperature control to the midway point of the hot settings.
Page 118: Heated Windows And Mirrors
Climate Control Side Window Defogging in Cold Weather Vehicle With Manual Climate Control Vehicle With Automatic Climate Control Select the instrument panel and footwell Press the defrost button. air vents positions through the air distri- bution control. Press the A/C button. Adjust the temperature control to the desired setting.
Page 119: Remote Start
Climate Control REMOTE START (If Equipped) The remote start feature allows you to pre-condition the interior of your vehicle. The climate control system works to achieve comfort according to your previous settings. Note: You cannot adjust the system during remote start operation. Turn the ignition on to return the system to its previous settings.
Page 120: Seats
Seats We recommend that you follow these SITTING IN THE CORRECT guidelines: POSITION • Sit in an upright position with the base of your spine as far back as possible. WARNINGS • Do not recline the seatback more than Sitting improperly, out of position or 30 degrees.
Page 121 Seats Lowering the Head Restraint WARNINGS Install the head restraint properly to Press and hold button C. help minimize the risk of neck injury 2. Push the head restraint down. in the event of a crash. Removing the Head Restraint Note: Adjust the seat back to an upright Press and hold buttons C and D.
Page 122: Manual Seats
Seats Removing the Head Restraint MANUAL SEATS Press and hold buttons C. WARNING 2. Pull up the head restraint. Do not adjust the driver's seat or seat Installing the Head Restraint back when your vehicle is moving. Align the steel stems into the guide sleeves Moving the Seat Backward and and push the head restraint down until it Forward...
Page 123: Power Seats
Seats Manual Lumbar Power Recline (If Equipped) (If Equipped) E162729 E162731 The lumbar support control is located on Move the switch to recline the seatback the outboard side of the seat. Turn the forward or rearward. control to adjust your support. Power Lumbar (If Equipped) POWER SEATS...
Page 124 Seats 2. Press and release the preset button WARNINGS associated with your desired driving Do not use the memory function position. The seat and mirrors move to when your vehicle is moving. the position stored for that preset. Note: You can only recall preset memory This feature automatically recalls the positions when the ignition is off, or when position of the following:...
Page 125: Rear Seats
Seats Returning the Seat to the Seating Note: If more than one linked remote Position control or intelligent access key is in range, the memory function moves to the settings WARNING of the first key to initiate a memory recall. Make sure that cargo or any objects Easy Entry and Exit Feature are not trapped underneath the seat...
Page 126 Seats Returning the Seat to the Seating Position WARNING Make sure that cargo or any objects are not trapped underneath the seat cushion before returning the seat cushion to its original position, and that the seat cushion locks into place. Failure to do so may prevent the seat from operating properly in the event of a crash, which could increase the risk of serious injury.
Page 127: Heated Seats
Seats Rear Heated Seats HEATED SEATS (If Equipped) (If Equipped) WARNING WARNING Persons who are unable to feel pain People who are unable to feel pain to the skin because of advanced age, to their skin because of advanced chronic illness, diabetes, spinal cord age, chronic illness, diabetes, spinal injury, medication, alcohol use, exhaustion, cord injury, medication, alcohol use,...
Page 128: Climate Controlled Seats
Seats CLIMATE CONTROLLED SEATS (If Equipped) Heated Seats WARNING People who are unable to feel pain to their skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical conditions, E162742 must exercise care when using the heated seat.
Page 129: Cooled Seats
Seats To operate the heated seats, touch the heated seat symbol on the touchscreen to cycle through the various heat settings and off. More indicator lights indicate warmer settings. Cooled Seats The cooled seats will only function when the engine is running. E146319 To remove a filter: Turn the vehicle off.
Page 130: Front Seat Armrest
Seats FRONT SEAT ARMREST E162747 If your vehicle has an under-seat storage E162745 compartment in the seat cushion, lift the latch to open the lid of the compartment. Press the button on the right-hand side of You cannot open the lid when the armrest the seat and pull the seatback down to is down.
Page 131: Rear Seat Armrest
Seats REAR SEAT ARMREST (If Equipped) E162744 Fold the armrest down to use it. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 132: Universal Garage Door Opener
Universal Garage Door Opener (If Equipped) The appearance of your vehicle’s universal WARNINGS garage door opener varies according to Do not use the system with any your option package. Before programming, garage door opener that does not make sure you identify which transmitter have the safety stop and reverse you have by comparing it to the graphics feature as required by U.S.
Page 133 Universal Garage Door Opener (If Equipped) The system includes two primary features, Note: If you cannot locate the learn button, a garage door opener and a platform for see the Owner s Manual for your garage remote activation of devices within the door opener or call the toll-free help line at home.
Page 134 Universal Garage Door Opener (If Equipped) The LED lamp above the selected button will illuminate to confirm that the system is responding to the button command. To program another rolling code device, repeat Steps 1 through 6, substituting a different function button in Step 5. Fixed Code Programming E164776 Note: It may be helpful to have another...
Page 135 Universal Garage Door Opener (If Equipped) HomeLink Wireless Control The LED lamp above the selected button System will illuminate to confirm that the system (If Equipped) is responding to the button command. WARNING Erasing the Function Button Codes Do not use the system with any Note: You cannot erase individual buttons.
Page 136 Universal Garage Door Opener (If Equipped) The universal garage door opener replaces 3. Using both hands, simultaneously, the common hand-held garage door press and hold the desired HomeLink opener with a three-button transmitter, button and the hand-held transmitter integrated into the driver’s sun visor. button.
Page 137 Universal Garage Door Opener (If Equipped) E142659 To program additional buttons, repeat Steps 1 – 4. E142660 For questions or comments, please contact HomeLink at www.homelink.com or Press and hold the outer two function 1-800-355-3515. buttons simultaneously for approximately 20 seconds until the Programming Your Garage Door indicator lights above the buttons flash Opener Motor...
Page 138 Universal Garage Door Opener (If Equipped) Press and hold the previously programmed Genie button on the hand-held transmitter for 10 seconds. The indicator light will change from red to red and green. 2. Press the same button twice to confirm the change.
Page 139 Universal Garage Door Opener (If Equipped) 5. Press and hold the previously programmed button on the visor for two seconds. Repeat this step up to three times until the garage door moves. Programming is now complete. Clearing a HomeLink Device To erase programming from the three HomeLink buttons press and hold the two outer HomeLink buttons until the indicator...
Page 140: Auxiliary Power Points
Auxiliary Power Points 12 Volt DC Power Point • On the instrument panel. • Inside the center console. WARNING • On the rear of the center console. Do not plug optional electrical • Inside the front under-seat storage accessories into the cigar lighter compartment (if equipped).
Page 141 Auxiliary Power Points When the indicator light on the power point • On, the power point is working, the ignition is on and a device is plugged • Off, the power point is off, the ignition is off or no device is plugged in. •...
Page 142: Storage Compartments
Storage Compartments CENTER CONSOLE OVERHEAD CONSOLE (If Equipped) (If Equipped) Stow items in the cupholder carefully as items may become loose during hard braking, acceleration or collisions, including hot drinks which may spill. E75193 Press near the rear edge of the door to open it.
Page 143: Starting And Stopping The Engine
Starting and Stopping the Engine If your vehicle is operated in a heavy snow GENERAL INFORMATION storm or blowing snow conditions, the engine air induction may become partially WARNINGS clogged with snow and ice. If this occurs, Extended idling at high engine the engine may experience a significant speeds can produce very high reduction in power output.
Page 144: Starting A Gasoline Engine
Starting and Stopping the Engine 2. Turn the key to the off position. STARTING A GASOLINE 3. Apply the parking brake. ENGINE Stopping the Engine When Your When you start the engine, the idle speed Vehicle is Moving increases, this helps to warm up the engine.
Page 145: Engine Block Heater
Starting and Stopping the Engine Important Ventilating Information You may experience a decrease in peak performance when the engine is cold when If you stop your vehicle and then leave the operating on E85 ethanol. engine idling for long periods of time, we Do not crank the engine for more than 10 recommend that you do one of the seconds at a time as starter damage may...
Page 146: Using The Engine Block Heater
Starting and Stopping the Engine We recommend that you do the following The heater uses 0.4 to 1.0 kilowatt-hours for a safe and correct operation: of energy per hour of use. The system does not have a thermostat. It achieves •...
Page 147: Fuel And Refueling
Fuel and Refueling • Extinguish all smoking materials and SAFETY PRECAUTIONS any open flames before refueling your vehicle. WARNINGS • Automotive fuels can be harmful or Do not overfill the fuel tank. The fatal if swallowed. Fuel such as pressure in an overfilled tank may gasoline is highly toxic and if cause leakage and lead to fuel spray swallowed can cause death or...
Page 148: Fuel Quality
Fuel and Refueling Use only unleaded gasoline or unleaded FUEL QUALITY gasoline blended with a maximum of 85% ethanol (E-85) in your flex fuel vehicle Note: Do not add after-market fuel additive (FFV). products to your fuel tank. We recommend that you use only high quality fuel without Do not use: after-market additives or other engine...
Page 149: Running Out Of Fuel
Fuel and Refueling We recommend regular unleaded gasoline WARNINGS with a pump (R+M)/2 octane rating of 87. Turn off your engine when you are Some stations offer fuels posted as regular refueling. with an octane rating below 87, particularly in high altitude areas. We do not Do not smoke if you are near fuel or recommend fuels with an octane rating refueling your vehicle.
Page 150: Fuel Consumption
The usable capacity of the fuel tank is fuel tank or fuel system if the correct the amount of fuel that can be added genuine Ford, Motorcraft or other certified into the tank after the gauge indicates fuel filler cap is not used.
Page 151: Emission Control System
Fuel and Refueling Results are most accurate when the filling Conditions method is consistent. • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any Calculating Fuel Economy speed. Do not measure fuel economy during the •...
Page 152: On-Board Diagnostics (Obd-Ii)
When the service engine soon your vehicle and to its emissions system. indicator illuminates, the OBD-II If you use parts other than Ford, Motorcraft system has detected a or Ford-authorized parts for maintenance malfunction. Temporary malfunctions may...
Page 153: Transmission
Fuel and Refueling present, the service engine soon indicator If the vehicle’s engine or transmission has should stay off the next time you start the just been serviced, or the battery has engine. A driving cycle consists of a cold recently run down or been replaced, the engine startup followed by mixed OBD-II system may indicate that the...
Page 154: Transmission
Transmission Neutral (N) AUTOMATIC TRANSMISSION With the gearshift lever in neutral (N), you WARNING can start your vehicle and it is free to roll. Hold the brake pedal down while in this Always set the parking brake fully position. and make sure the gearshift is latched in park (P).
Page 155 Transmission Tow/Haul Mode Understanding the Shift Positions of a 6–Speed Automatic To activate tow/haul, press the Transmission (If Equipped) button on the gearshift lever once. The TOW HAUL indicator E161509 light illuminates in the instrument cluster. The tow/haul feature: • Delays upshifts to reduce the frequency of transmission shifting.
Page 156 Transmission M (Manual) The tow/haul feature: • Delays upshifts to reduce the frequency With the gearshift lever in manual (M), the of transmission shifting. driver can change gears up or down as desired. By moving the gearshift lever from • Provides engine braking in all forward drive position drive (D) to manual (M) you gears, which slows your vehicle and...
Page 157 Transmission Understanding your SelectShift The SelectShift Automatic transmission Automatic transmission feature has two modes: PRS and M mode. (If Equipped) PRS (Progressive Range Selection) Progressive Range Selection gives you the ability to lockout gears from the automatic shifting range. This may provide you with an improved driving experience (for example, in slippery conditions or when experiencing a steep grade).
Page 158: Brake-Shift Interlock
Transmission Upshifts when accelerating (recommended for best fuel economy) Shift from: Gasoline engines Diesel engines 1 – 2 15 mph (24 km/h) 12 mph (19 km/h) 2 – 3 25 mph (40 km/h) 19 mph (31 km/h) 3 – 4 40 mph (64 km/h) 26 mph (42 km/h) 4 –...
Page 159: Power Take-Off
Transmission 4. Place fingers into hole where you removed the gearshift lever boot and pull top half of shroud up and forward to separate it from the lower half of the shroud. There is a hinge at the forward edge of the top shroud. Roll the top half of the shroud upward on the hinge point to clear the hazard flasher button, then pull straight rearward toward the...
Page 160 Ford Super Duty Vehicles are approved for use as a stationary (including split shaft capability) or mobile power source, within limits and operating guidelines detailed in the Ford Truck Body Builders Layout Book, found at www.fleet.ford.com/truckbbas,...
Page 161: Four-Wheel Drive
Four-Wheel Drive (If Equipped) The 4WD system is engaged or disengaged USING FOUR-WHEEL DRIVE by rotating the control for both front wheel hub locks from the FREE or LOCK position, WARNING then manually engaging or disengaging the For important information regarding transfer case with the floor-mounted safe operation of this type of vehicle, shifter.
Page 162: Wd Indicator Lights
Four-Wheel Drive (If Equipped) Using a Manual Shift On Stop • provides 4x4 High engagement and (MSOS) 4WD system disengagement while the vehicle is (If Equipped) moving. Note: High shift efforts may be encountered • is operated by a rotary control located when attempting to shift into and out of 4x4 on the instrument panel that allows modes.
Page 163 Four-Wheel Drive (If Equipped) Shifting between system modes 5. If shifting to 2H (2WD) with the vehicle at a complete stop, disengage the Note: Do not perform these operations if locking hubs (optional) by rotating the the rear wheels are slipping. hub lock control from LOCK to FREE.
Page 164 Four-Wheel Drive (If Equipped) Using the Electronic Shift on the Note: Do not perform this operation if the Fly 4WD system rear wheels are slipping. (If Equipped) Note: Some noise may be heard as the system shifts or engages; this is normal. Note: 4X4 high mode is not intended for use on dry pavement.
Page 165 Four-Wheel Drive (If Equipped) If SHIFT DELAYED PULL FORWARD is Drive cautiously to avoid vehicle damage displayed in the information display, from concealed objects such as rocks and transfer case gear tooth blockage is stumps. present. To alleviate this condition, place You should either know the terrain or the transmission in a forward gear, move examine maps of the area before driving.
Page 166 Four-Wheel Drive (If Equipped) Four-wheel drive (when you select a 4WD Emergency Maneuvers mode) uses all four wheels to power the In an unavoidable emergency situation vehicle. This increases traction, enabling where a sudden sharp turn must be made, you to drive over terrain and road remember to avoid over-driving your conditions that a conventional two-wheel vehicle (i.e.
Page 167: Rear Axle
Four-Wheel Drive (If Equipped) Mud and Water Note: Avoid turning on steep slopes or hills. A danger lies in losing traction, slipping sideways and possible vehicle roll over. Whenever driving on a hill, determine Be cautious of sudden changes in vehicle beforehand the route you will use.
Page 168 Four-Wheel Drive (If Equipped) If your vehicle has anti-lock brakes, apply Make sure you allow sufficient distance the brakes steadily. Do not pump the between you and other vehicles for brakes. stopping. Drive slower than usual and consider using one of the lower gears. In Driving on Snow and Ice emergency stopping situations, apply the brake steadily.
Page 169 Four-Wheel Drive (If Equipped) On some four-wheel drive vehicles, when the transfer case is in the N (Neutral) position, the engine and transmission are disconnected from the rest of the driveline. Therefore, the vehicle is free to roll even if the automatic transmission is in P (Park) or the manual transmission is in gear.
Page 170: Rear Axle
Rear Axle • On 2WD vehicles and 4WD vehicles in LIMITED SLIP DIFFERENTIAL 2H (4X2) or 4H (4X4 High), the ELD will not engage if the vehicle speed is This axle provides added traction on above 20 mph (32 km/h). slippery surfaces, particularly when one wheel is on a poor traction surface.
Page 171 • The system has malfunctioned and is accompanied by CHECK LOCKING DIFFERENTIAL in the information display. See your authorized Ford dealer for assistance. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 172: Brakes
Brakes Anti-lock Brake System GENERAL INFORMATION This system helps you maintain steering Note: Occasional brake noise is normal. If control during emergency stops by keeping a metal-to-metal, continuous grinding or the brakes from locking. continuous squeal sound is present, the This lamp momentarily brake linings may be worn-out.
Page 173: Parking Brake
Brakes PARKING BRAKE WARNINGS You must remain in your vehicle when the system turns on. At all WARNING times, you are responsible for Always set the parking brake fully controlling your vehicle, supervising the and make sure the transmission is system and intervening, if required.
Page 174: Switching The System On And Off
Brakes 2. If the sensors detect that your vehicle is on a slope, the system activates automatically. 3. When you remove your foot from the brake pedal, your vehicle remains on the slope without rolling away for about two to three seconds. This hold time automatically extends if you are in the process of driving off.
Page 175: Traction Control
Traction Control In certain situations (for example, stuck in PRINCIPLE OF OPERATION snow or mud), it may be beneficial to turn the traction control system off. This allows The traction control system helps avoid the wheels to spin with full engine power. drive wheel spin and loss of traction.
Page 176: Stability Control
Traction Control System Indicator Lights and Messages WARNING If a failure has been detected within the AdvanceTrac system, the stability control light will illuminate steadily. Verify that the traction control system was not manually disabled using the stability control button. If the stability control light still illuminates steadily, have the system serviced by an authorized dealer immediately.
Page 177: Stability Control
Stability Control The AdvanceTrac with Roll Stability PRINCIPLE OF OPERATION Control system helps you keep control of your vehicle when on a slippery surface. WARNINGS The electronic stability control portion of Vehicle modifications involving the system helps avoid skids and lateral braking system, aftermarket roof slides and roll stability control helps avoid racks, suspension, steering system,...
Page 178 Stability Control The system automatically activates when Using Traction Control (page 172). you start your engine. The electronic You can turn off the traction stability control and roll stability control control portion of the system portions of the system can be turned off independently.
Page 179 Stability Control AdvanceTrac with RSC Features (Single rear wheels only) Button pressed Not illuminated Enabled Enabled Enabled again after deactivation Transfer case Illuminated Disabled Disabled Disabled switched to 4WD Low Electronic stability control has reduced sensitivity compared to fully active system. Lamp light starts blinking for four seconds after entering the press and hold state.
Page 180: Terrain Response
Terrain Response (If Equipped) PRINCIPLE OF OPERATION USING HILL DESCENT CONTROL WARNINGS Press and release the hill Hill descent control cannot control descent button located on the descent in all surface conditions and instrument panel. A light in the circumstances, such as ice or E163957 cluster will illuminate and a chime will extremely steep grades.
Page 181 Terrain Response (If Equipped) Refer to the Information Displays for additional Hill Descent Control messages. See Information Messages (page 100). Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 182: Parking Aids
If your vehicles has a non-Ford Rear Parking Aid approved trailer tow module the system may not correctly detect The rear sensors are only active when the objects.
Page 183: Rear View Camera
Parking Aids The system detects certain objects while WARNINGS the transmission is in reverse (R): When manual zoom is enabled • Your vehicle is moving toward a (Level 1, Level 2 or Level 3), the full stationary object at a speed of 3 mph area behind your vehicle will not be (5 km/h) or less.
Page 184 Parking Aids The system uses three types of guides to After changing a system setting, the touch help you see what is behind your vehicle: screen shows a preview of the selected features. • Active guidelines: Show the intended path of your vehicle when reversing. Guidelines and the Centerline •...
Page 185 Parking Aids Fixed guidelines are always shown in the Manual Zoom display, but the active guidelines only WARNING display when the steering wheel is turned. To use active guidelines, turn the steering When manual zoom is on, the full wheel to point the guidelines toward an area behind your vehicle is not intended path.
Page 186: Cruise Control
Cruise Control (If Equipped) Switching Cruise Control On PRINCIPLE OF OPERATION Press and release ON. Cruise control lets you maintain a set The indicator will appear in the speed without keeping your foot on the instrument cluster. accelerator pedal. You can use cruise control when your vehicle speed is greater E71340 than 20 mph (30 km/h).
Page 187: Driving Aids
Driving Aids STEERING To help prevent damage to the power steering system: • Never hold the steering wheel at its furthest turning points (until it stops) for more than three to five seconds when the engine is running. • Do not operate the vehicle with a low power steering pump fluid level (below the MIN mark on the reservoir).
Page 188: Load Carrying
Load Carrying the following terms for LOAD LIMIT determining your vehicle’s weight Vehicle Loading - with and ratings, with or without a trailer, without a Trailer from the vehicle’s Tire Label or Safety Compliance Certification This section will guide you in the Label: proper loading of your vehicle, Base Curb Weight - is the weight...
Page 189 Load Carrying Example only: WARNING The appropriate loading capacity of your vehicle can be limited either by volume capacity (how much space is available) or by payload capacity (how much weight the vehicle should carry). Once you have reached the maximum payload of your vehicle, do not add more cargo, even if there is space E210944...
Page 190: Towing
Load Carrying Cargo Weight - includes all Certification Label. The label shall weight added to the Base Curb be affixed to either the door hinge Weight, including cargo and pillar, door-latch post, or the door optional equipment. When towing, edge that meets the door-latch trailer tongue load or king pin post, next to the driver seating weight is also part of cargo weight.
Page 191 Load Carrying Example only: E198828 WARNING Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury. E143819 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 192: Towing
Load Carrying GCW (Gross Combined Weight) Tongue Load or Fifth Wheel - is the Gross Vehicle Weight plus King Pin Weight - refers to the the weight of the fully loaded amount of the weight that a trailer trailer. pushes down on a trailer hitch. GCWR (Gross Combined Examples: For a 5000 pound Weight Rating) - is the maximum...
Page 193: Towing
Load Carrying 1. Locate the statement "The *Suppose your vehicle has a combined weight of occupants 1400-pound (635-kilogram) cargo and cargo should never exceed and luggage capacity. You decide XXX kg or XXX lb." on your to go golfing. Is there enough load vehicle’s placard.
Page 194 Load Carrying be: 635 kilograms - (2 x 99 Special Loading Instructions kilograms) - (12 x 45 kilograms) = for Owners of Pick-up Trucks 635 - 198 - 540 = -103 kilograms. and Utility-type Vehicles You will need to reduce the load WARNING weight by at least 240 pounds (104 kilograms).
Page 195: Towing
Towing Load Placement TOWING A TRAILER To help minimize how trailer WARNINGS movement affects your vehicle Do not exceed the GVWR or when driving: the GAWR specified on the • Load the heaviest items closest certification label. to the trailer floor. Towing trailers beyond the •...
Page 196: Trailer Sway Control
(5.6 Turning off trailer sway control increases the risk of loss of vehicle meters ) trailer frontal area for control, serious injury or death. Ford conventional trailers. Do not does not recommend disabling this feature exceed 75 feet (6.9 meters...
Page 197 Towing Your vehicle may tow a trailer maximum trailer weight listed for provided the maximum trailer your vehicle configuration on the weight is less than or equal to the following chart. Pickup and box delete Maximum Vehicle Engine Rear axle ratio GCWR 19000 lb (8618 3.73...
Page 198 Towing Chassis cab Maximum Vehicle Engine Rear axle ratio GCWR 3.73 19000 lb (8618 6.2L gas F-350 single 4.30 22000 lb (9979 rear wheel 3.73 23500 lb (10659 6.7L diesel 3.73 19500 lb (8845 6.2L gas F-350 dual rear 4.30 22500 lb (10206 wheel 3.73, 4.10...
Page 199: Essential Towing Checks
Towing Chassis cab Maximum Vehicle Engine Rear axle ratio GCWR 26000 lb (11793 6.7L diesel 4.88 35000 lb (15875 Requires optional GCWR Package. Note: Consult an authorized dealer Calculating the Maximum to determine the maximum trailer Loaded Trailer Weight for Your weight allowed for your vehicle if Vehicle you are not sure.
Page 200: Trailer Towing Connector
Towing Dynamic Hitching Using the Rear Remember to account for the trailer View Camera System tongue weight as part of your vehicle load when calculating the total vehicle weight. Note: Active guidelines and fixed guidelines Trailer Towing Connector are only available when the transmission is in reverse (R).
Page 201 Towing Fixed guidelines are always shown in the Weight-distributing Hitches display, but the active guidelines only WARNING display when the steering wheel is turned. To use active guidelines, turn the steering Do not adjust a weight-distributing wheel to point the guidelines toward an hitch to any position where the rear intended path.
Page 202 Towing Fifth-wheel Trailer Hitch (If Equipped) the trailer and tow vehicle for turns up to 90 degrees. Failure to follow this WARNINGS recommendation could result in the trailer contacting the cab of the tow vehicle The mounting pads in the bed are during tight turns that are typical during specifically designed for certain low-speed parking and turning maneuvers.
Page 203: Integrated Trailer Brake Controller
Ford has tested the trailer brake controller to be compatible with several major brands of electric-over-hydraulic trailer brakes. Contact an authorized dealer for information on which brands you can use.
Page 204 You should change the setting as towing exactly which trailer fault has occurred. conditions change. Changes to towing However, your Ford warranty does not cover conditions include trailer load, vehicle load, this diagnosis if the fault is with the trailer.
Page 205: Trailer Lamps
Towing If the message only displays with a trailer • The controller interacts with the brake connected, the problem is with the trailer control system and powertrain control wiring. Consult your trailer dealer for system of your vehicle to provide the assistance.
Page 206 Towing • Check your hitch, electrical connections Turn the steering wheel to point your and trailer wheel lug nuts thoroughly vehicle tires away from traffic flow. after you have traveled 50 miles (80 2. Set your vehicle parking brake. kilometers). 3.
Page 207: Towing Points
Towing Replace the rear axle lubricant anytime • Only use recovery straps that have a the rear axle has been submerged in water. minimum breaking strength two to Water may have contaminated the rear three times the gross vehicle weight of axle lubricant, which is not normally the stuck vehicle.
Page 208: Transporting The Vehicle
Note: Using wheel lift equipment to tow a dollies or flatbed equipment to tow your dual rear wheel vehicle requires removing vehicle. Do not tow with a slingbelt. Ford an outer rear wheel before towing. Motor Company has not approved a slingbelt towing procedure.
Page 209: Towing The Vehicle On Four Wheels
Towing Two-wheel Drive Vehicles and TOWING THE VEHICLE ON Four-wheel Drive Vehicles Equipped FOUR WHEELS with an Electronic-shift Transfer Case Emergency Towing Do not tow your vehicle with any wheels on the ground, as vehicle or transmission If your vehicle becomes inoperable damage may occur.
Page 210: Driving Hints
Driving Hints Avoid these actions; they reduce your fuel BREAKING-IN economy: You need to break in new tires for • Sudden accelerations or hard approximately 300 miles (480 accelerations. kilometers). During this time, your vehicle • Revving the engine before turning it off. may exhibit some unusual driving •...
Page 211: Driving Through Water
Driving Hints • Transmissions give their best fuel • Lightly press the brake pedal to dry the economy when operated in the top brakes and to check that they work. cruise gear and with steady pressure • Check that the horn works. on the gas pedal.
Page 212: Snowplowing
Check attachment of floor mats on Weight limits and guidelines for selecting a regular basis. Always properly and installing the snowplow are in the Ford reinstall and secure floor mats that Truck Body Builders Layout Book, have been removed for cleaning or snowplow section, found at replacement.
Page 213 (SRS). 500 mi (800 km). Ford recommends vehicle speed does not Your vehicle is equipped with a driver and exceed 45 mph (72 km/h) when passenger airbag supplemental restraint snowplowing.
Page 214 Driving Hints • If you are driving more than 15 mi (24 km) at temperatures above freezing, angle the plow blade either full left or full right to provide maximum airflow to the radiator. • If you are driving less than 15 mi (24 km) at speeds up to 45 mph (72 km/h) in cold weather, you will not need to worry about blade position to...
Page 215: Roadside Emergencies
• Towing — independent service contractors, if not prohibited by state, Canadian customers who require roadside local or municipal law, shall tow Ford assistance, call 1-800-665-2006. eligible vehicles to an authorized dealer within 35 mi (56 km) of the Vehicles Sold in Canada: Using...
Page 216: Hazard Warning Flashers
• Press the flasher control again to turn them off. Call Ford Roadside Assistance at 1-800-665-2006 for additional information. FUEL SHUTOFF WARNING Failure to inspect and, if necessary,...
Page 217: Jump Starting The Vehicle
Roadside Emergencies In the event of a moderate to severe Note: Attempting to push-start a vehicle collision, this vehicle is equipped with a with an automatic transmission may cause fuel pump shut-off feature that stops the transmission damage. flow of fuel to the engine. Not every impact Note: Use only a 12-volt supply to start your will cause a shut-off.
Page 218 Roadside Emergencies Jump Starting Start the engine of the booster vehicle and rev the engine moderately, or press the accelerator gently to keep your engine speed between 2000 and 3000 RPM, as shown in your tachometer. 2. Start the engine of the disabled vehicle. 3.
Page 219: Post-Crash Alert System
Roadside Emergencies 2. Remove the jumper cable on the negative (-) terminal of the booster vehicle battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle battery.
Page 220: Customer Assistance
A reasonable time must be allowed to Oakville, Ontario L6K 0C8 perform a repair after taking your vehicle Telephone to the authorized dealer. Repairs will be made using Ford or Motorcraft® parts, or 1-800-565-3673 (FORD) remanufactured or other parts that are Online authorized by Ford.
Page 221: In California (U.s. Only)
2. Four or more repair attempts are made Ford in writing before pursuing remedies on the same nonconformity (a defect under your state’s warranty laws. Ford is or condition that substantially impairs also allowed a final repair attempt in some the use, value or safety of the vehicle) states.
Page 222: The Better Business Bureau (Bbb) Auto Line Program (U.s. Only)
BBB. Canadian dealers. In those cases where You are not bound by the decision, and you continue to feel that the efforts by Ford may reject the decision and proceed to of Canada and the authorized dealer to...
Page 223: Getting Assistance Outside The U.s. And Canada
CAMVAP decisions are fast, fair, FORD MOTOR COMPANY and final as the arbitrator’s award is Customer Relationship Center binding on both you and Ford of Canada. 1555 Fairlane Drive CAMVAP services are available in all Fairlane Business Park #3 Canadian territories and provinces.
Page 224: Ordering Additional Owner's Literature
(VIN) and new REPORTING SAFETY DEFECTS address with Ford Motor Company Export (U.S. ONLY) Operations & Global Growth Initiatives by emailing expcac@ford.com. If you are in another foreign country, contact the nearest authorized dealer.
Page 225: Reporting Safety Defects (Canada Only)
However, information about motor vehicle NHTSA cannot become involved safety from in individual problems between http://www.safercar.gov. you, your dealer, or Ford Motor Company. REPORTING SAFETY DEFECTS To contact NHTSA, you may call (CANADA ONLY) the Vehicle Safety Hotline...
Page 226: Fuses
Fuses The power distribution box is located in FUSE SPECIFICATION CHART the engine compartment. It has high-current fuses that protect your Power Distribution Box vehicle's main electrical systems from overloads. WARNINGS Always disconnect the battery before If you disconnect and reconnect the servicing high current fuses.
Page 227 Fuses Fuse or relay number Fuse amp rating Protected components 40A* Trailer tow — Not used 30A* Driver smart window motor — Not used — Not used Diode Fuel pump (diesel engine) — Not used 15A** Heated mirror — Not used —...
Page 228 Fuses Fuse or relay number Fuse amp rating Protected components 15A** Vehicle power 4 (diesel engine) 20A** Vehicle power 4 (gas engine) 10A** Vehicle power 5 (diesel engine) Relay Electronic control module (diesel engine) Powertrain control module (gas engine) 10A** 4x4 hub lock 15A** 4x4 electronic lock...
Page 229 Fuses Fuse or relay number Fuse amp rating Protected components — Not used — Not used — Not used — Not used — Not used — Not used — Not used 20A** Fuel pump — Not used 10A** Fuel pump relay coil —...
Page 230 Fuses Fuse or relay number Fuse amp rating Protected components 30A* Heated/cooled seats 25A* Anti-lock brake system coil feed 20A* Auxiliary power point #5 20A* Auxiliary power point #6 40A* Starter motor 25A* Trailer tow battery charge — Not used 20A* Auxiliary power point #4 20A*...
Page 231: Passenger Compartment Fuse Panel
Fuses Passenger Compartment Fuse Pull the fuse panel cover toward you to Panel remove it. When the clips of the panel disengage, let the panel fall easily. The fuse panel is in the passenger footwell. Use the provided fuse puller tool to remove Remove the panel cover to access the a fuse.
Page 232 Fuses Fuse or relay number Fuse amp rating Protected components 7.5A Driver lumbar motor Driver seat switch Power mirror switch Auxiliary switch relay #3 Customer access feed Run/accessory relay Instrument cluster Interior lighting Lighted running board lamps Right turn signals and brake lamps Left turn signals and brake lamps Backup lamps, Trailer tow backup relay High-mounted stop lamps...
Page 233 Fuses Fuse or relay number Fuse amp rating Protected components Steering wheel control module Not used (spare) Ignition switch GPS module Radio SYNC Parking lamp relay Trailer tow parking lamp relay Customer access Trailer brake controller (brake signal) Auto dimming mirror Driver and passenger door lock switch illumination Driver and passenger smart window motor...
Page 234: Changing A Fuse
Fuses Fuse or relay number Fuse amp rating Protected components Wiper relay Auxiliary switches Not used (spare) Climate control Fog lamps Fog lamp indicator (in switch) 30A Circuit breaker Power rear sliding window switch Power windows switch Moonroof switch Relay Delayed accessory CHANGING A FUSE Fuses...
Page 235: Maintenance
Maintenance Working with the Engine Off GENERAL INFORMATION Set the parking brake and shift to park Have your vehicle serviced regularly to help (P). maintain its roadworthiness and resale 2. Switch off the engine. value. There is a large network of authorized dealers that are there to help 3.
Page 236: Under Hood Overview - 6.2L
Maintenance 2. Go to the front of the vehicle and 5. To close the hood, lower the hood and locate the secondary release lever, allow it to drop the last 8 to 11 inches which is located under the front of the (20 to 30 centimeters).
Page 237: Under Hood Overview - 6.8L
Maintenance Power distribution box Air filter assembly Power steering fluid reservoir Engine oil filler cap Battery UNDER HOOD OVERVIEW - 6.8L Note: Refer to the diesel supplement for diesel engine component locations. E163635 Windshield washer fluid reservoir Battery Automatic transmission fluid dipstick Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 238: Engine Oil Dipstick
Maintenance Engine oil filler cap Engine oil dipstick Power steering fluid reservoir Brake fluid reservoir Engine coolant reservoir Air filter assembly Power distribution box 5. Locate and carefully remove the engine oil level dipstick. See the Under Hood ENGINE OIL DIPSTICK Overview in this chapter for location of dipstick.
Page 239: Oil Change Indicator Reset
2. If the engine oil level is not within the 6. Release the accelerator and brake normal range, add engine oil that pedals. meets Ford specifications. See The message confirming that the reset Capacities and Specifications for more is complete will no longer be displayed.
Page 240 Maintenance Note: For best results, coolant WARNINGS concentration should be tested with a Do not put engine coolant in the refractometer such as Robinair® Coolant windshield washer fluid container. If and Battery Refractometer 75240. We do sprayed on the windshield, engine not recommend the use of hydrometers or coolant could make it difficult to see coolant test strips for measuring coolant...
Page 241: Recycled Engine Coolant
If you drive in extremely cold climates: service location. In this instance, the • It may be necessary to have a Ford cooling system must be drained, authorized dealer increase the coolant chemically cleaned with Motorcraft concentration above 50%.
Page 242 Maintenance What You Should Know About Fail- When Fail-Safe Mode Is Activated Safe Cooling WARNINGS If the engine coolant supply is depleted, Fail-safe mode is for use during this feature allows the vehicle to be driven emergencies only. Operate the temporarily before incremental component vehicle in fail-safe mode only as long damage is incurred.
Page 243: Automatic Transmission Fluid Check
Maintenance Engine Fluid Temperature If the engine coolant temperature gauge Management (If Equipped) moves fully into the red (hot) area, or if the coolant temperature warning or service WARNINGS engine soon messages appear in your information display: To reduce the risk of collision and injury, be prepared that the vehicle Stop your vehicle as soon as safely speed may reduce and the vehicle...
Page 244 Maintenance Checking Automatic Transmission Fluid For scheduled intervals of the fluid checks and changes, See Scheduled Maintenance (page 453). Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage.
Page 245 Maintenance E163743 E163741 Type B Type B E163744 E163742 For vehicles equipped with 5-speed Fluid levels above the safe range may transmissions, check the fluid at the result in transmission failure. An overfill normal operating temperature of 151°F condition of transmission fluid may cause (66°C) to 170°F (77°C) on a level surface.
Page 246: Transfer Case Fluid Check
3. Add only enough fluid through the filler opening so that the fluid level is at the bottom of the opening. Only use fluid that meets Ford specifications. See Capacities and Specifications (page 303). Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 247: Brake Fluid Check
Only use a washer fluid that meets Check the fluid level in the reservoir. It Ford specifications. See Capacities and should be between the MIN and MAX Specifications (page 303). range. Do not add fluid if the level is State or local regulations on volatile within this range.
Page 248: Changing The 12V Battery
Maintenance Note: Electrical or electronic accessories CHANGING THE 12V BATTERY or components added to the vehicle by the dealer or the owner may adversely affect WARNINGS battery performance and durability. This vehicle may be equipped with Your vehicle is equipped with a Motorcraft more than one battery, removal of maintenance-free battery which normally cable from only one battery does not...
Page 249 When a battery replacement is required, new battery has been installed, the clock the battery should only be replaced with and radio settings must be reset once the a Ford recommended replacement battery battery is reconnected. which matches the electrical requirements Always dispose of automotive of the vehicle.
Page 250: Checking The Wiper Blades
Maintenance CHECKING THE WIPER BLADES E165794 E142463 2. Release the wiper blade lock (A) and Run the tip of your fingers over the edge of separate the wiper blade from the the blade to check for roughness. wiper arm. Clean the wiper blades with washer fluid 3.
Page 251: Horizontal Aim Adjustment
Maintenance Headlamp Aiming Target E142465 4. On the wall or screen you will observe E142592 a flat zone of high intensity light located at the top of the right hand 8 feet (2.4 meters) portion of the beam pattern. If the top Center height of lamp to ground edge of the high intensity light zone is 25 feet (7.6 meters)
Page 252: Removing A Headlamp
Maintenance 5. Depress the spring clips through the REMOVING A HEADLAMP lower inner grille access openings using a flat head screwdriver. WARNING 6. Pull the grill straight out to remove. Handle a halogen headlamp bulb carefully and keep out of children’s reach.
Page 253: Replacing Headlamp Bulbs
Maintenance Replacing Front Park and Direction 4. Remove the bulb by pulling it straight Indicator Lamp Bulbs out. Note: Do not touch the bulb glass. Note: You cannot separate the bulb from the bulb holder. Replacing Front Clearance and Identification Lamp Bulbs (If Equipped) E163824 Switch all of the lamps and the ignition...
Page 254: Replacing Brake/Tail/Turn/Reverse Lamp
Maintenance 2. Disconnect the electrical connector. Chassis Cabs 3. Turn the bulb holder counterclockwise and remove it. Note: Do not touch the bulb glass. Note: You cannot separate the bulb from the bulb holder. Replacing Brake/Tail/Turn/Reverse Lamp Bulbs Pickup Models E163828 Switch all of the lamps and the ignition off.
Page 255: Bulb Specification Chart
Maintenance 4. Remove the bulb by pulling it straight Switch all of the lamps and the ignition out. off. 2. Reach behind the rear bumper to Replacing the License Plate Lamp locate the bulb. Bulb 3. Turn the bulb holder counterclockwise Note: The license plate bulbs are located and remove it.
Page 256 Maintenance Function Number of Bulbs Trade name Dome/reading lamps Interior visor lamp 2825 Mirror turn signal 2825 Mirror clearance lamp 2825 Front clearance lamps and front identification lamps Rear fender clearance Rear identification Underhood Lamp To replace all instrument panel lights - see your authorized dealer. Dual rear wheels, if equipped.
Page 257: Changing The Engine Air Filter
Maintenance CHANGING THE ENGINE AIR FILTER WARNING To reduce the risk of vehicle damage and personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running. Note: Failure to use the correct air filter E163756 element may result in severe engine 2.
Page 258 Maintenance E163758 E163760 5. Release the three clamps that secure Reconnect the mass air flow sensor the cover to the air filter housing. Push electrical connector to the outlet the air filter cover toward the center of tube. Make sure the locking tab on the vehicle and up slightly to release it.
Page 259: Vehicle Care
Vehicle Care GENERAL INFORMATION CLEANING THE EXTERIOR Your Ford or Lincoln authorized dealer has Wash your vehicle regularly with cool or many quality products available to clean lukewarm water and a neutral pH your vehicle and protect its finishes. shampoo, we recommend Motorcraft Detail Wash.
Page 260: Waxing
Vehicle Care Note: Never use abrasive materials, for • Do not allow wax to come in contact example steel wool or plastic pads as they with any non-body (low-gloss black) can scratch the chrome surface. colored trim. The wax will discolor or stain the parts over time.
Page 261: Cleaning The Windows And Wiper Blades
Vehicle Care • Never wash or rinse any ignition coil, CLEANING THE INTERIOR spark plug wire or spark plug well, or the area in and around these locations. WARNINGS • Cover the battery, power distribution Do not use cleaning solvents, bleach box, and air filter assembly to prevent or dye on the vehicle’s safety belts, water damage when cleaning the...
Page 262: Cleaning The Instrument Panel And Instrument Cluster Lens
Vehicle Care Wipe up spilled liquid using a clean, CLEANING THE INSTRUMENT soft cloth as quickly as possible. PANEL AND INSTRUMENT 2. Use Motorcraft Premium Leather and CLUSTER LENS Vinyl Cleaner or a commercially available leather cleaning product for WARNING automotive interiors.
Page 263: With King Ranch Edition
Vehicle Care You should: • Do not spill coffee, ketchup, mustard, orange juice or oil-based products on • Remove dust and loose dirt with a the leather as they may permanently vacuum cleaner. stain the leather. • Clean and treat spills and stains as •...
Page 264: Repairing Minor Paint Damage
Vehicle Care • Clean the wheels weekly using REPAIRING MINOR PAINT Motorcraft Wheel and Tire Cleaner. DAMAGE Apply using manufacturer's instructions. Authorized dealers have touch-up paint to • Use a sponge to remove heavy match your vehicle’s color. Your vehicle deposits of dirt and brake dust color code is printed on a sticker on the accumulation.
Page 265: Removing Vehicle From Storage
Vehicle Care Battery • Touch-up exposed or primed metal to prevent rust. • Check and recharge as necessary. Keep • Cover chrome and stainless steel parts connections clean. with a thick coat of auto wax to prevent • If storing your vehicle for more than 30 discoloration.
Page 266 Vehicle Care • Check tire pressures and set tire inflation per the Tire Label. • Check brake pedal operation. Drive your vehicle 15 ft (4.5 m) back and forth to remove rust build-up. • Check fluid levels (including coolant, oil and gas) to make sure there are no leaks, and fluids are at recommended levels.
Page 267: Wheels And Tires
Ford dealer to have the system abrupt maneuvers, drive at safe speeds for reprogrammed. If you intend to change the the conditions, keep tires inflated to Ford size of the wheels from that fitted by the recommended pressures, never overload...
Page 268 Wheels and Tires Utility vehicles and trucks handle On some four-wheel drive vehicles, the differently than passenger cars in the initial shift from two-wheel to four-wheel various driving conditions that are drive while the vehicle is moving can cause encountered on streets, highways and a momentary clunk and ratcheting sound.
Page 269 Wheels and Tires E168583 E145299 • Higher - to allow higher load carrying As a result of the above dimensional capacity and to allow it to travel over differences, Sport utility vehicles and rough terrain without getting hung up trucks often will have a higher center of or damaging underbody components.
Page 270: Tire Care
U.S. Department of TIRE CARE Transportation Tire quality Information About Uniform grades: The U.S. Department of Tire Quality Grading Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 271 Wheels and Tires The traction grades, from highest Federal Motor Vehicle Safety to lowest are AA, A, B, and C. The Standard No. 139. Grades B and A grades represent the tire’s ability represent higher levels of to stop on wet pavement as performance on the laboratory measured under controlled test wheel than the minimum...
Page 272 Wheels and Tires *kPa: Kilopascal, a metric unit of Information Contained on the air pressure. Tire Sidewall *PSI: Pounds per square inch, a Both United States and Canada standard unit of air pressure. Federal regulations require tire manufacturers to place *Cold tire pressure: The tire standardized information on the pressure when the vehicle has...
Page 273 Wheels and Tires A. P: Indicates a tire, designated G. H: Indicates the tire's speed by the Tire and Rim Association, rating. The speed rating denotes that may be used for service on the speed at which a tire is cars, sport utility vehicles, designed to be driven for extended minivans and light trucks.
Page 274 Wheels and Tires J. Tire Ply Composition and Letter mph ( km/h) Material Used: Indicates the rating number of plies or the number of 168 (270) layers of rubber-coated fabric in the tire tread and sidewall. Tire 186 (299) manufacturers also must indicate Note: For tires with a maximum the ply materials in the tire and the sidewall, which include steel,...
Page 275 Wheels and Tires *Temperature: The temperature grades are A (the highest), B and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. M.
Page 276 Wheels and Tires D. Maximum Load Single lb T type tires have some additional (kg) at psi (kPa) cold: Indicates information beyond those of P the maximum load and tire type tires. These differences are pressure when the tire is used as described below: a single;...
Page 277 Inflate all tires to the appear to be flat! inflation pressure recommended by Ford Motor Company. Always inflate your tires to the Ford recommended inflation You are strongly urged to buy a...
Page 278 If you do not pressure should never be set lower maintain the inflation pressure at than the recommended pressure the levels specified by Ford, your on the Safety Compliance vehicle may experience a condition Certification Label or Tire Label.
Page 279 Wheels and Tires Note: If you have to drive a 6. Visually inspect the tires to distance to get air for your tire(s), make sure there are no nails or check and record the tire pressure other objects embedded that first and add the appropriate air could poke a hole in the tire and pressure when you get to the...
Page 280 Wheels and Tires any procedure involving tire inflation device, and ensure that inflation, the technician or all persons are clear of the individual must utilize a remote trajectory area. E161437 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 281 Wheels and Tires E161438 signs of damage or excessive WARNING wear. If internal damage to the tire Stay out of the trajectory (1) is suspected, have the tire as indicated in the illustration. demounted and inspected in case it needs to be repaired or replaced. Inspecting Your Tires and For your safety, tires that are Wheel Valve Stems...
Page 282 Wheels and Tires Tire Wear or suspected have the tire inspected by a tire professional. Tires can be damaged during off-road use, so inspection after off-road use is also recommended. WARNING Tires degrade over time depending on many factors such as weather, storage E142546 conditions, and conditions of use When the tread is worn down to...
Page 283 This begins with the letters DOT possible. Use of any tire or wheel and indicates that the tire meets not recommended by Ford can all federal standards. The next affect the safety and performance two numbers or letters are the...
Page 284 If your vehicle is stuck in than 20 psi (1.38 bar) greater than snow, mud, or sand, do not the maximum pressure, a Ford rapidly spin the tires; spinning the dealer or other tire service tires can tear the tire and cause professional should do the an explosion.
Page 285 Wheels and Tires *Avoid fast starts, stops and turns. Tire and Wheel Alignment *Avoid potholes and objects on A bad jolt from hitting a curb or the road. pothole can cause the front end of your vehicle to become *Do not run over curbs or hit the misaligned or cause damage to tire against a curb when parking.
Page 286 Wheels and Tires Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare wheel and tire assembly.
Page 287: Using Snow Chains
Snow tires must be the same size, chains or cables, please contact your load index, speed rating as those authorized dealer. originally provided by Ford. Use of any tire or wheel not recommended by TIRE PRESSURE MONITORING Ford can affect the safety and...
Page 288 Wheels and Tires Each tire, including the spare (if When the malfunction indicator is provided), should be checked illuminated, the system may not be able monthly when cold and inflated to detect or signal low tire pressure as to the inflation pressure recommended by intended.
Page 289 Wheels and Tires Changing Tires With a Tire Understanding Your Tire Pressure Pressure Monitoring System Monitoring System The tire pressure monitoring system measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The low tire pressure warning light will turn on if the tire pressure is significantly low.
Page 290 Wheels and Tires Low tire pressure Possible cause Customer action required warning light Solid warning light Tire(s) under-inflated Make sure tires are at the proper pres- sure. See Inflating your tires in this chapter. After inflating your tires to the manufacturer’s recommended pressure as shown on the Tire Label (located on the edge of driver’s door or the B-Pillar),...
Page 291 Wheels and Tires When Inflating Your Tires Tire Pressure Monitoring System Reset Procedure When putting air into your tires (such as at a gas station or in your garage), the tire WARNING pressure monitoring system may not To determine the required respond immediately to the air added to pressure(s) for your vehicle, see the your tires.
Page 292 (one meter) away from another starting with the left front tire in the Ford Motor Company vehicle following clockwise order: Left front undergoing the system reset procedure (driver's side front tire), Right front at the same time.
Page 293: Changing A Road Wheel
See Tire Pressure and wheels that were originally provided Monitoring System (page 284). by Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired. Note: If your vehicle is equipped with the...
Page 294: Location Of The Spare Tire And Tools
Wheels and Tires • Exceed 50 mph (80 km/h) • Use commercial car washing equipment. • Load the vehicle beyond maximum vehicle load rating listed on the Safety • Use snow chains on the end of the Compliance Label. vehicle with the dissimilar spare wheel and tire assembly.
Page 295 Wheels and Tires Tool Location SuperCab: Under rear bench seat on passenger side Jack handle, lug wrench, lug wrench exten- Regular cab: Fastened to floor behind driver sion (only available on dual rear wheel seat vehicles) and wheel chock (only available SuperCab: Fastened to floor under rear seat on single rear wheel vehicles equipped with Crew Cab: Fastened to floor behind rear...
Page 296: Tire Change Procedure
Wheels and Tires E162798 E162800 Attach the spare tire lock key (A) to the 5. Lift the spare tire on end to access the jack handle (B). tether attachment. 6. Use the lug wrench to remove the lug nut from the spare tire tether. If not replacing the spare or flat tire to the underbody storage area, raise the wheel retainer up into the installed...
Page 297 Wheels and Tires 4. Loosen each wheel lug nut ½ turn WARNINGS counterclockwise, but do not remove Do not attempt to change a tire on them until the wheel is raised off the the side of the vehicle close to ground.
Page 298 Wheels and Tires Rear Note: Jack at the specified locations to avoid damage to the vehicle. Jacking the Vehicle E162803 Front driver side (4x4) Note: Make sure the jack fits onto the flat area on the outboard side of the differential. E162811 Turn the jack handle clockwise until the wheel is completely off the ground...
Page 299 Wheels and Tires Stow the jack, jack handle and lug When installing the wheel center wrench. Make sure the jack is securely ornaments, make sure that the ornament fastened so it does not rattle when retention towers on the back side of the driving.
Page 300 Wheels and Tires Slide the notched end of the jack handle over the release valve and use the handle to slide the jack under the vehicle. Make sure the valve is closed by turning it clockwise. 2. Position the jack according to the following guides: E162815 Front passenger side (4x4): F-350 dual...
Page 301 Wheels and Tires 2. Use an up-and-down motion with the jack handle to raise the wheel completely off the ground. Note: Hydraulic jacks are equipped with a pressure release valve that prevents lifting loads which exceed the jack's rated capacity. 3.
Page 302 Wheels and Tires E161441 8-lug nut torque sequence 2. Hold the ornament so that all of the retention clips are sitting on the flange of the lug nuts. E169375 10-lug nut torque sequence E162824 Installing Dual Rear Wheel Ornaments 3. Use your hand or rubber mallet to tap the ornament in a star pattern.
Page 303 Wheels and Tires E162800 E162825 3. Lay the tire on the ground with the valve stem facing up. 4. Slide the wheel partially under the vehicle and install the retainer through the wheel center. Pull on the cable to align the components at the end of the cable.
Page 304: Technical Specifications
M14 x 1.5 165 lb.ft (224 Nm) Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. On vehicles equipped with single rear wheels, retighten the lug nuts to the specified torque at 100 miles (160 kilometers) after any wheel disturbance (such as tire rotation, changing a flat tire, wheel removal).
Page 305 Wheels and Tires E145950 Wheel pilot bore Inspect the wheel pilot hole and mounting surface prior to installation. Remove any visible corrosion or loose particles. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 306: Capacities And Specifications
Capacities and Specifications ENGINE SPECIFICATIONS Engine 6.2L V8 Engine 6.8L V10 Engine Cubic inches Required fuel Minimum 87 octane Minimum 87 octane Firing order 1-5-4-8-6-3-7-2 1-6-5-10-2-7-3-8-4-9 Ignition system Coil on plug Coil on plug Spark plug gap 0.041-0.047 inch (1.04-1.20 0.039-0.043 inch (1.00- 1.10mm) Compression ratio...
Page 307: Motorcraft Parts
8C3Z-7A098-D For scheduled maintenance, we recommend Motorcraft replacement parts available at your Ford dealer or at fordparts.com. These parts meet or exceed Ford Motor Company’s specifications and are engineered for your vehicle. Use of other parts may impact vehicle performance, emissions and durability. Your warranty may be void for any damage related to use of other parts.
Page 308: Vehicle Identification Number
Capacities and Specifications VEHICLE IDENTIFICATION NUMBER The vehicle identification number is located on the left-hand side of the instrument panel. E142477 World manufacturer identifier Brake system, Gross Vehicle Weight Rating, Restraint Devices and their locations Make, vehicle line, series, body type Engine type Check digit...
Page 309: Vehicle Certification Label
Capacities and Specifications VEHICLE CERTIFICATION TRANSMISSION CODE LABEL DESIGNATION E167469 E167814 The National Highway Traffic Safety The transmission code is on the Safety Administration Regulations require that a Compliance Certification Label. The Safety Compliance Certification Label be following table shows the transmission affixed to a vehicle and prescribe where code along with the transmission the Safety Compliance Certification Label...
Page 310: Capacities And Specifications - 6.2L V8
Capacities and Specifications CAPACITIES AND SPECIFICATIONS - 6.2L V8 Capacities WARNING The air conditioning refrigerant system contains refrigerant R-134a under high pressure. Opening the air conditioning refrigerant system can cause personal injury. Have the air conditioning refrigerant system serviced only by qualified personnel. Item Capacity Engine oil...
Page 311 Capacities and Specifications Specifications Materials Name Specification Recommended motor oil (U.S.): WSS-M2C946-A Motorcraft SAE 5W-30 Premium Synthetic Blend Motor XO-5W30-QSP Recommended motor oil (Canada): WSS-M2C946-A Motorcraft SAE 5W-30 Super Premium Motor Oil CXO-5W30-LSP12 Recommended motor oil (Mexico): WSS-M2C946-A Motorcraft SAE 5W-30 Synthetic Motor Oil MXO-5W30-QSP Optional motor oil (U.S.
Page 312 Capacities and Specifications Name Specification Rear axle fluid (F-250/350)(10.50 inch axle)(U.S. and WSL-M2C192-A Mexico): Motorcraft SAE 75W-140 Synthetic Rear Axle Lubricant XY-75W140-QL Rear axle fluid (F-250/350)(10.50 inch axle)(Canada): WSL-M2C192-A Motorcraft SAE 75W-140 Synthetic Rear Axle Lubricant CXY-75W140-1L Rear axle fluid (F350)(Dana M80): WSS-M2C918-A Motorcraft SAE 75W-140 Synthetic Rear Axle Lubricant XY-75W140-QL...
Page 313 Capacities and Specifications Name Specification Motorcraft Premium Quality Windshield Washer Fluid CXC-37-(A, B, D, F) A/C refrigerant (U.S.): WSH-M17B19-A Motorcraft R-134a Refrigerant YN-19 A/C refrigerant (Canada): WSH-M17B19-A Motorcraft R-134a Refrigerant CYN-16-R A/C refrigerant (Mexico): WSH-M17B19-A Motorcraft R-134a Refrigerant MYN-19 A/C refrigerant compressor oil: WSH-M1C231-B Motorcraft PAG Refrigerant Compressor Oil YN-12-D...
Page 314: Capacities And Specifications - 6.8L Triton-30V - V10
API certification mark. not be covered by your vehicle warranty. Note: Ford recommends using DOT 4 Low Viscosity (LV) High Performance Brake Fluid or equivalent meeting WSS-M6C65-A2. Use of any fluid other than the recommended...
Page 315 Capacities and Specifications Item Capacity Rear axle- F-250/350 (10.50 inch axle) 3.5 qt (3.3 L) Rear axle- F-350 (Dana M80) 4.2 qt (4 L) Rear axle- F-450/550 (Dana S110/S130) 7.0 qt (6.6 L) Automatic transmission fluid 17.5 qt (16.6 L)* Transfer case fluid 2.0 qt (1.9 L) Windshield washer fluid...
Page 316 Capacities and Specifications Name Specification XO-5W30-QFS Optional motor oil (Canada): WSS-M2C946-A Motorcraft SAE 5W-30 Synthetic Motor Oil CXO-5W30-LFS12 Engine coolant (U.S. and Mexico): WSS-M97B44-D2 Motorcraft Orange Antifreeze/Coolant Prediluted VC-3DIL-B Engine coolant (Canada): WSS-M97B44-D2 Motorcraft Orange Antifreeze/Coolant Prediluted CVC-3DIL-B Brake fluid (US): WSS-M6C65-A1 Motorcraft DOT 3 Motor Vehicle Brake Fluid PM-1-C...
Page 317 Capacities and Specifications Name Specification Rear axle fluid (F-450/550)(DanaS110/S130)(Canada): WSL-M2C192-A Motorcraft SAE 75W-140 Synthetic Rear Axle Lubricant CXY-75W140-1L Automatic transmission fluid (U.S. and Mexico): WSS-M2C938-A Motorcraft MERCON LV Automatic Transmission Fluid MERCON LV XT-10-QLVC Automatic transmission fluid (Canada): WSS-M2C938-A Motorcraft MERCON LV Automatic Transmission Fluid MERCON LV XT-10-QLVC Transfer case fluid:...
Page 318 Capacities and Specifications Name Specification Multi-purpose grease: ESB-M1C93-B Motorcraft Multi-Purpose Grease Spray XL-5-A Lock cylinders (U.S.): Penetrating and Lock Lubricant XL-1 Lock cylinders (Canada): Penetrating Fluid CXC-51-A Lock cylinders (Mexico): Penetrating and Lock Lubricant MXL-1 Transmission, parking brake linkages and pivots, brake WSD-M1C227-A pedal shift: Motorcraft Premium Long-Life Grease...
Page 319 Capacities and Specifications Note: Ford recommends using DOT 4 Low Viscosity (LV) High Performance Brake Fluid or equivalent meeting WSS-M6C65-A2. Use of any fluid other than the recommended fluid may cause degraded brake performance and not meet the Ford performance standards. Keep brake fluid clean and dry.
Page 320: Audio System
MP3 individual tracks and folder compact discs may not function correctly structures work as follows: when used in Ford CD players. • There are two different modes for MP3 disc playback: MP3 track mode Note: Do not insert CDs with homemade...
Page 321: Audio Unit - Vehicles With: Am/Fm
Audio System • MP3 folder mode represents a folder In track mode, the system displays and structure consisting of one level of plays the structure as if it were only one folders. The CD player numbers all MP3 level deep (all .mp3 files play, regardless tracks on the disc (noted by the .mp3 of being in a specific folder).
Page 322: Audio Unit - Vehicles With: Am/Fm/Cd/Sync
Audio System CLK: Press this button to switch the display between the clock and radio frequency. To set the time, press and hold the button until the hours start to flash. Press the arrow buttons (B) to adjust the hours, then repeat to set the minutes.
Page 323 Audio System E169515 Eject: Press to eject a CD. CD slot: Insert a CD. Tune: Press to search through the radio frequency band manually. Press and hold for a fast search. Phone: Press to access the phone features of the SYNC system. See SYNC (page 329).
Page 324 Audio System Track/Folder is only available on MP3 files when in CD mode. In track mode, pressing the SEEK arrows allows you to scroll through all the tracks on the disc. In folder mode, pressing the SEEK arrows allows you to scroll through all the tracks within the selected folder.
Page 325: Audio Unit - Vehicles With: Am/Fm/Cd/Touchscreen Display
Audio System AUDIO UNIT - VEHICLES WITH: WARNING AM/FM/CD/TOUCHSCREEN Driving while distracted can result in loss of vehicle control, crash and DISPLAY injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road.
Page 326: Digital Radio
Audio System Memory presets: Store your favorite radio stations. To store a radio station, tune to the station, then press and hold a preset button until sound returns. Seek, Reverse and Fast Forward: In radio mode, select a frequency band and press one of these buttons. The system stops at the first station it finds in that direction.
Page 327 Audio System Note: As with any saved radio station, you cannot access the saved station if your vehicle is outside the station s reception area. HD Radio Reception and Station Troubleshooting Potential reception issues Reception area If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute due to weak signal strength.
Page 328: Satellite Radio
SIRIUS® broadcasts a variety of music, HD Radio logos are proprietary trademarks news, sports, weather, traffic and of iBiquity Digital Corp. Ford Motor entertainment satellite radio channels. For Company and iBiquity Digital Corp. are not more information and a complete list of...
Page 329: Satellite Radio Reception Factors
Ford Motor Company shall not be of your vehicle. See an authorized dealer responsible for any such programming for availability.
Page 330 Audio System Troubleshooting Message Condition Action Acquiring… Radio requires more than No action required. This two seconds to produce message should disappear audio for the selected shortly. channel. Satellite antenna fault There is an internal module If this message does not or system failure present.
Page 331: Usb Port
Audio System USB PORT (If Equipped) WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 332: Sync
SYNC (If Equipped) GENERAL INFORMATION E198355 • Text message. SYNC is an in-vehicle communications system that works with your • Use the advanced voice recognition Bluetooth-enabled cellular phone and system. portable media player. This allows you to: • Charge your USB device (if your device •...
Page 333 SYNC (If Equipped) Monday-Saturday, 8:30am-9:00pm EST. When using SYNC: • Do not operate playing devices if the Sunday, 10:30am-7:30pm EST. power cords or cables are broken, split In the United States, call 1-800-392-3673. or damaged. Place cords and cables In Canada, call 1-800-565-3673. out of the way, so they do not interfere with the operation of pedals, seats, Times are subject to change due to...
Page 334: Using Voice Recognition
Make sure the interior of your vehicle is vehicle's SYNC module. Ford Motor as quiet as possible. Wind noise from Company and Ford of Canada will not open windows and road vibrations may access the system data for any purpose...
Page 335: System Interaction And Feedback
SYNC (If Equipped) Voice command If you want the system to carry out the following Voice Settings | Voice Adjust the level of voice interaction and feedback. Preferences Help Hear a list of voice commands available in the current mode. You can say any of the voice commands that appear within open and close brackets that are separated by |.
Page 336 SYNC (If Equipped) Confirmation prompts are short questions correct?". If turned off, the system simply the system asks when it is not sure of your makes a best guess as to what you request or when there are multiple possible requested and may ask you to confirm responses to your request.
Page 337: Using Sync With Your Phone
SYNC (If Equipped) Other features, such as text messaging USING SYNC WITH YOUR using Bluetooth and automatic phonebook PHONE download, are cell phone-dependent features. To check your cell phone's Hands-free calling is one of the main compatibility, see your cell phone's manual features of SYNC.
Page 338: Pairing Subsequent Cell Phones
SYNC (If Equipped) Pairing Subsequent Cell Phones Depending on your cell phone's capability and your market, the system may prompt Note: To scroll through the menus, press you with questions, such as setting the the up and down arrows on your audio current cell phone as the primary cell system.
Page 339 SYNC (If Equipped) Voice Command You can also say any of the following: [Phone] Settings [Message] Notification Voice Command Call ___ [Phone] Settings [Message] Notification Call ___ at Home [Phone] Settings [Set] Phone Ringer Call ___ at Work [Phone] Settings [Set] Ringer 1 Call ___ in Office [Phone] Settings [Set] Ringer 2 Call ___ on Mobile...
Page 340: Making A Call
SYNC (If Equipped) Making a Call Press the voice button and when prompted say: Voice Command Action and Description Call ___ This command is not available until your cell phone informa- tion is completely downloaded using Bluetooth. Dial Use to enter a phone number digit by digit. When the system confirms the number say one of the following commands: Dial To confirm the number and initiate the call.
Page 341 SYNC (If Equipped) Message Action and Description Press the phone button. 2. Access the desired contact through SYNC or use voice commands to place the second call. Once actively in the second call, press MENU. 3. Scroll to Join Calls, and press the OK button. Wait until the following message appears.
Page 342 SYNC (If Equipped) Press the phone button to enter the Phone Menu, then scroll to: Message Action and Description Phone Redial Press the OK button to redial the last number called. Press the OK button again to confirm. Call History Access any previously dialed, received or missed calls after you connect your Bluetooth-enabled cell phone to SYNC.
Page 343: Text Messaging
SYNC (If Equipped) Message Action and Description Vehicle Health Create and receive a diagnostic report card on your vehicle. Mobile Apps Interact with SYNC-capable mobile applications on your smartphone. Sys Settings Access Bluetooth Devices menu listings and advanced menu listings. Exit Press the OK button to exit the phone menu.
Page 344 6. Press the OK button again when the system asks if you would like to send the message. The system sends each text message with the following signature: This message was sent from my Ford. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 345: Accessing Your Phone Settings
SYNC (If Equipped) Message Action and Description Download now Allows you to download your unread messages to SYNC. To download the messages, press the OK button to select. The display indicates the system is downloading your messages. When downloading is complete, SYNC returns you to the inbox.
Page 346 SYNC (If Equipped) Message Action and Description Press the OK button then select one of the following and press the OK button again to confirm. Message Notification On Message Notification Off Modify Phone- Modify the contents of your phone book (such as add, delete, down- book load).
Page 347 SYNC (If Equipped) Press the Phone button to enter the Phone Menu, then scroll to: Message Action and Description Sys Settings Press the OK button. Bluetooth device Press the OK button. Select one of the following: See Using SYNC With Your Phone (page 334). Connect BT Connect a previously paired Bluetooth-enabled phone.
Page 348 SYNC (If Equipped) Advanced and set prompts, languages, defaults, perform a master reset, install an The Advanced menu allows you to access application and view system information. To access the advanced menu, press the phone button to enter the Phone Menu, the scroll to: Message Action and Description...
Page 349: Sync Applications And Services
SYNC (If Equipped) Message Action and Description Press the OK button and scroll to select. Press the OK button to confirm. System info Access the Auto Version number as well as the FDN number. Press the OK button to select. Return Exit the current menu.
Page 350 SYNC (If Equipped) If a crash deploys an airbag (excluding www.SYNCMyRide.ca or knee airbags and rear inflatable safety www.syncmaroute.ca. belts [if equipped]) or activates the fuel See Supplementary Restraints System pump shut-off, your SYNC-equipped (page 37). Important information about vehicle may be able to contact emergency airbag deployment is in this chapter.
Page 351 SYNC (If Equipped) In the Event of a Crash 911 Assist Privacy Notice Not all crashes will deploy an airbag or When you turn on 911 Assist, it may activate the fuel pump shut-off (the disclose to emergency services that your triggers for 911 Assist).
Page 352 Action and Description Vehicle Health (Report) The system will run a vehicle health report of your vehicle's diagnostic systems and send the results to Ford where it combines with scheduled maintenance information, open recalls, other field service actions and vehicle inspection items that still need servicing by an authorized dealer.
Page 353 Run Report Press the OK button for SYNC to run a health report of your vehicle's diagnostic systems and send the results to Ford where it combines with scheduled maintenance information, open recalls, other field service actions and vehicle inspection items that still need servicing by an authorized dealer.
Page 354 For more information, see SYNC Services Terms and Conditions at www.SYNCMyRide.com. If you do not want Ford or its service providers to collect your vehicle travel information or other information identified in the Terms and Conditions, do not subscribe or use the service.
Page 355 SYNC (If Equipped) Connecting to SYNC Services Using the Phone Menu Press the phone button, then scroll to: Message Action and Description SYNC Apps Press the OK button. Services Press the OK button. The display indicates the system is connecting. 2.
Page 356 SYNC (If Equipped) Voice command Action and Description The live operator can assist you by searching for businesses by name or by category, residential addresses by street address or by name or specific street intersections. The system may prompt you to speak with an operator when it has difficulty matching your voice request.
Page 357: Sync Applink
SYNC (If Equipped) SYNC Services quick tips You can even access your account outside your vehicle. Just use the number on your phone's call history. Traffic and Directions features do not function properly but information services and the 411 connect and text message features are available.
Page 358: Using Sync With Your Media Player
SYNC (If Equipped) Press the Menu button to the SYNC menu and scroll to: Menu item Action and description SYNC-Media Press the OK button. Mobile Apps Press the OK button and scroll through the list of available applications and select your desired app. Scroll until the app name followed by For more information, please visit: "Menu", is displayed (such as, Stitcher...
Page 359 SYNC (If Equipped) To Connect Using Voice Commands Plug the device into the USB port. See E142599 USB Port (page 328). Press the voice button and when prompted say: Voice command Action and Description USB [1] You can now play music by saying any of the appropriate voice commands.
Page 360: What's Playing
SYNC (If Equipped) What's Playing? When a track is playing, you can ask the system to tell you what is currently playing. Press the voice button and when prompted say: Voice command Action and Description Whats This? | Whats The system reads the metadata tags of the playing track, Playing? and if the metadata tags are populated, the system will tell you what track is playing.
Page 361: Media Menu Features
SYNC (If Equipped) Voice command Voice command Search The system searches all Autoplay Off Genre ___ the data from your Autoplay Turn autoplay on to listen to indexed music and, if [on] music processed during available, begins to play indexing. Turn autoplay off to the chosen type of music.
Page 362 SYNC (If Equipped) Press the AUX button, then the Menu button to enter the Media Menu. You can then scroll to: Message Action and Description Play Menu Play your music by artist, album, genre, playlists, tracks, similar music or to simply, play all.
Page 363: Accessing Your Play Menu
SYNC (If Equipped) Message Action and Description Autoplay Press the OK button to turn autoplay on to listen to music processed during indexing. Turn autoplay off to allow the indexing process to finish before the system plays any of your music. Mobile Apps Interact with SYNC-capable mobile applications on your smartphone.
Page 364 SYNC (If Equipped) Message Action and Description Play all indexed media (tracks) from your playing device in flat file mode, one at a time in numerical order. Artists Sort all indexed media by artist. Once selected, the system lists and then plays all artists and tracks alphabetically. If there are fewer than 255 indexed artists, the system lists them alphabetically in flat file mode.
Page 365: System Settings
SYNC (If Equipped) Message Action and Description Browse USB Explore all supported digital media on your media device connected to the USB port. You can only view media content which is compatible with SYNC; other files saved are not visible. Press the OK button.
Page 366 SYNC (If Equipped) Message Action and Description Press the OK button. When find SYNC appears in the display, press the OK button again. 2. Follow the directions in your phone's manual to put your phone into discovery mode. A six-digit PIN appears in the display.
Page 367 SYNC (If Equipped) You can then scroll to: Message Action and Description Sys Settings Press the OK button. Bluetooth device Press the OK button. You can then select one of the following: Confirmation Prompts Have SYNC guide you by asking questions, helpful hints or ask you for a specific action.
Page 368: Sync Troubleshooting
SYNC (If Equipped) Use the website at any time to check your SYNC TROUBLESHOOTING phone's compatibility, register your account and set preferences as well as Your SYNC system is easy to use. However, access a customer representative via an should questions arise, see the tables online chat (during certain hours).
Page 369 SYNC (If Equipped) Phone issues Issue Possible cause(s) Possible solution(s) Depending upon your phone, you may have to grant SYNC permission to access your phonebook contacts. Make sure to confirm when prompted by your phone during the phonebook download. I am having trouble This is a phone-dependent Go to the website to review connecting my phone to...
Page 370 SYNC (If Equipped) USB and media issues Issue Possible cause(s) Possible solution(s) I am having trouble This may be a possible Try turning off the device, connecting my device. device malfunction. resetting the device, removing the device's battery, then trying again. Make sure you are using the manufacturer's cable.
Page 371 SYNC (If Equipped) Vehicle Health Report and Services (Traffic, Directions and Information) issues Issue Possible cause(s) Possible solution(s) I received a text that I did You did not activate your This is a free feature, but you not activate Vehicle Health account on the website.
Page 372 SYNC (If Equipped) Voice command issues Issue Possible cause(s) Possible solution(s) SYNC does not understand You may be using the wrong Review the phone voice what I am saying. voice commands. commands and the media You may be speaking too voice commands at the soon or at the wrong time.
Page 373 SYNC (If Equipped) Voice command issues Issue Possible cause(s) Possible solution(s) The system may not be Make sure you are saying the reading the name the same contacts exactly as they are way you are saying it. listed. For example, if you Contacts in your phonebook save a contact as Joe may be very short and...
Page 374 AppLink. Also, some may have a "Ford SYNC" setting, so check the app's settings menu on the phone. My phone is connected, my Sometime apps do not...
Page 375 SYNC (If Equipped) AppLink issues Issue Possible cause(s) Possible solution(s) On an iPhone with iOS7+, to force close an app, double tab the home button then swipe up on the app to close it. Tab the home button again, then select the app again to restart it.
Page 376 SYNC phone listed in SYNC's bluetooth ports apps can to find. If the app has a "Ford Mobile Apps Menu. use to connect. If you have SYNC" setting, disable that more AppLink apps on your...
Page 377: Myford Touch
MyFord Touch (If Equipped) GENERAL INFORMATION WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 378: Myford Touch
MyFord Touch (If Equipped) This system uses a four-corner strategy to Message provide quick access to several vehicle features and settings. The touchscreen City Center provides easy interaction with your cell phone, entertainment, information and system settings. The corners display active Edit Route modes within the menus, for example;...
Page 379 MyFord Touch (If Equipped) Note: Depending on your vehicle s option Message package and software, the screens may vary in appearance from the descriptions in this Calendar section. The features may also be limited Apps depending on the market. Check with an authorized dealer for availability.
Page 380 MyFord Touch (If Equipped) Message Action and Description Midrange Set Balance and Fade EQ Mode Speed Compensated Volume Using the Steering Wheel Controls Depending on your vehicle, it may also have the following controls: Control Action and Description Adjust the volume of playing media. Voice Press to start a voice session.
Page 381 MyFord Touch (If Equipped) Safety Information • Make sure the power cables do not interfere with the safe operation of your WARNING vehicle's controls or affect your safe driving abilities. Driving while distracted can result in • Some SYNC functions are loss of vehicle control, crash and speed-dependent.
Page 382 SYNC module. Ford Motor When you connect a cell phone to SYNC, Company and Ford of Canada do not the system creates a profile within your access the system data for any purpose vehicle that links to that cell phone.
Page 383 MyFord Touch (If Equipped) When using voice commands, words and • Speak naturally, without long pauses icons may appear in the lower left status between words. bar indicating the status of the voice • At any time, you can interrupt the command session (such as Listening, system while it is speaking by pressing Success, Failed, Paused or Try Again).
Page 384 MyFord Touch (If Equipped) Menu Item Action and Description Interaction Mode Novice In this mode the system provides detailed interaction and guidance. Advanced This mode has less audible interac- tion and more tone prompts. Confirmation Prompts The system uses these short questions to confirm your voice command.
Page 385: Settings
MyFord Touch (If Equipped) SETTINGS E161968 Clock Item Message Under this menu, you can set the clock, access and adjust the display, sound and Clock vehicle settings as well as access settings Display for specific modes or the help feature. Sound Vehicle Settings...
Page 386 MyFord Touch (If Equipped) Menu Item Action and Description You can also switch the outside air temperature display off and on. It appears at the top center of the touchscreen, next to the time and date. Note: You cannot manually set the date. Your vehicle s GPS does this for you. Note: If the battery has been disconnected, your vehicle needs to acquire a GPS signal to update the clock.
Page 387 MyFord Touch (If Equipped) Note: You cannot load photos directly from your camera. You must access the photos E142599 either from your USB mass storage device or from an SD card. To make adjustments using the voice Note: Photographs with extremely large button, press the button and when dimensions (such as 2048 x 1536) may not prompted, say:...
Page 388 MyFord Touch (If Equipped) Ambient Lighting (If Equipped) Message When you switch this feature on, ambient Vehicle Health Report lighting illuminates the dashboard, footwells, doors, cupholders, and console Camera Settings with a choice of colors. Enable Valet Mode US only To make adjustments using the touchscreen, select: Menu Item Action and Description...
Page 389 MyFord Touch (If Equipped) Camera Settings To make adjustments using the touchscreen, select: Message Action and Description Settings Press the settings icon. Vehicle Camera Settings Then select from the following: Enhanced Park Aids Rear Camera Delay You can find more information on the rear view camera system in another chapter. See Parking Aids (page 179).
Page 390 MyFord Touch (If Equipped) System To make adjustments using the touchscreen, select: Message Action and Description Settings Press the settings icon. System Then select from the following: Language Select to have the touchscreen display in English, Spanish or French. Distance Select to display units in kilometers or miles.
Page 391 MyFord Touch (If Equipped) Message Action and Description Note: Even with confirmation prompts turned off, the system may occasionally ask you to confirm settings. Media Candidate Lists Candidate lists are possible results from your voice commands. The system simply makes a best guess at your request with these turned off.
Page 392 MyFord Touch (If Equipped) Navigation To make adjustments using the touchscreen, select: Message Action and Description Settings Press the settings icon. Navigation Then select from the following: Map Preferences Turn breadcrumbs on and off. Have the system display your turn list top to bottom or bottom to top.
Page 393 MyFord Touch (If Equipped) Message Action and Description Have the system display areas where road work occurs. Have the system display incident icons. Have the system display areas where difficult driving condi- tions may occur. Have the system display areas where snow and ice on the road may occur.
Page 394 MyFord Touch (If Equipped) Message Action and Description Text Message Notifica- Select the type of notification for text messages - alert tone, tion beep, text to speech, or have it be silent. Internet Data Connection If compatible with your phone, you can adjust your internet data connection.
Page 395 MyFord Touch (If Equipped) Menu Item Action and Description Gateway (Access Point) Mode Makes SYNC an access point for a phone or a computer when turned on. This forms the local area network within your vehicle for things, such as game playing, file transfer and internet browsing.
Page 396 MyFord Touch (If Equipped) The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. E142626 Help To make adjustments using the touchscreen, select: Message Action and Description Settings Press the settings icon. Help Then select from the following: System Inform- Touchscreen system serial number ation...
Page 397 MyFord Touch (If Equipped) Message Action and Description The ICE contacts you select appear at the end of the Emergency Assistance call process. Edit Select to access your phone- book and then select the desired contacts. The numbers then appear as options on this screen for the ICE 1 and ICE 2 buttons.
Page 398: Entertainment
MyFord Touch (If Equipped) ENTERTAINMENT E161892 Message Message and Description SIRIUS Touch this button to scroll down for more options, for example SD Card and USB These buttons change with the media mode you are in. Radio memory presets. Note: Some features may not be available in your area. Contact an authorized dealer for more information.
Page 399 MyFord Touch (If Equipped) Item Action and Description Touch either tab to listen to the radio. To change between AM and FM presets, just touch the AM or FM tab. Presets Save a station by pressing and holding one of the memory preset areas. There is a brief mute while the radio saves the station.
Page 400 MyFord Touch (If Equipped) Menu Item Action and Description RDS Text This allows you to view the information broadcast by FM stations. Display AST (Autostore) allows you to have the system automatically store the six strongest stations in your current location. TAG Button This feature is available when HD Radio is on, and allows you to tag a song to download later.
Page 401 MyFord Touch (If Equipped) TAG allows you to save a song to acquired HD Radio station and the feature download later when you are on an is on. To turn the feature on and use it, select AM or FM and the select: Message Action and Description Options...
Page 402 MyFord Touch (If Equipped) HD Radio Reception and Station Troubleshooting Potential reception issues Reception area If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute due to weak signal strength. If you are listening to HD1, the system switches back to the analog broadcast until the digital broadcast is available again.
Page 403 HD Radio and the HD and HD Radio logos are proprietary trademarks E142599 of iBiquity Digital Corp. Ford Motor Company and iBiquity Digital Corp. are not responsible for the content sent using HD Radio technology. Content may be changed, added or deleted at any time at the station owner's discretion.
Page 404 Touch this button to view a list of all available stations. Scroll to see more categories. Touch the station you want to listen to. Note: SIRIUS does not support the Alert feature on all channels. Ford Motor Company shall not be responsible for Alert feature variation.
Page 405 MyFord Touch (If Equipped) Browsing Controls Message Action and Description Skip Touch this button if you want to skip this channel. Lock Touch this button if you do not want anyone to listen to this channel. Title Touch this button to see song titles playing on other stations. Artist Touch this button to see artists playing on other stations.
Page 406 Canada, or call SIRIUS at at any time, with or without notice to you. 1-888-539-7474. Ford Motor Company shall not be responsible for any such programming Note: This receiver includes the eCos changes.
Page 407 MyFord Touch (If Equipped) SIRIUS Satellite Radio Reception Factors and Troubleshooting Potential reception issues Antenna obstruc- For optimal reception performance, keep the antenna clear of snow tions and ice build-up and keep luggage and other materials as far away from the antenna as possible. Terrain Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and thunderstorms can interfere...
Page 408 MyFord Touch (If Equipped) Troubleshooting tips Message Cause Action Questions? Call Your satellite service is no Contact SIRIUS at 1-888-539- longer available. 7474 to resolve subscription 1-888-539-7474 issues. None found All the channels in the selected Use the channel guide to turn category are either skipped or off the Lock or Skip function on Check Channel Guide...
Page 409 MyFord Touch (If Equipped) Insert your CD then select: Menu Item Action and Description Repeat Touch this button to repeat the currently playing track, all tracks on the disc or switch the feature off if already on. Shuffle Touch this button to play the tracks or entire albums in random order, or switch the feature off if already on.
Page 410: Sd Card Slot And Usb Port
MyFord Touch (If Equipped) Voice command Previous Track Help This applies to WMA or MP3 files only. SD Card Slot and USB Port E142620 The SD card slot and USB port are located SD logo is a trademark of SD-3C, LLC. in the Media Hub.
Page 411 MyFord Touch (If Equipped) Insert your device and select: Message Action and Description Once the system recognizes your USB or SD card you can then select from the following options: SD Card Repeat This feature replays the currently playing song or album. Shuffle Touch this button to play music on the selected album or folder in random order.
Page 412 MyFord Touch (If Equipped) Message Action and Description Device Information Displays software and firmware information about the currently connected media device. Update Media Index Indexes your device when you connect it for the first time and each time the content changes (for example adding or removing tracks) to make sure you have the latest voice commands avail- able for all media on the device.
Page 413: Bluetooth Audio
MyFord Touch (If Equipped) Voice command Play Artist ___ Play Song ___ Similar Music Help ___ is a dynamic listing, meaning that it could be the name of anything, such as a group, artist or song. For example you could say "Play artist The Beatles" or "Play song Penny Lane".
Page 414: Phone
MyFord Touch (If Equipped) PHONE E161968 At a minimum, most cell phones with Bluetooth wireless technology support the Item Message following functions: Phone • Answering an incoming call. • Ending a call. Quick Dial • Using privacy mode. Phonebook • Dialing a number.
Page 415 MyFord Touch (If Equipped) Pairing Your Cell Phone for the The first thing you must do to use the First Time phone features of SYNC is to pair your Bluetooth-enabled cell phone with SYNC. WARNING This allows you to use your cell phone in a hands-free manner.
Page 416 MyFord Touch (If Equipped) To pair a subsequent cell phone, select: Menu Item Action and Description Phone Settings Bluetooth Devices Add Device Find SYNC Follow the on-screen instructions. Make sure that Bluetooth is set to On and that your cell phone is in the correct mode.
Page 417: Phone Menu Options
MyFord Touch (If Equipped) E142632 To reject the call, select: To accept the call, select: Message Message Reject Accept Note: You can also reject the call by Note: You can also accept the call by pressing the phone button on the steering pressing the phone button on the steering wheel.
Page 418 MyFord Touch (If Equipped) Menu Item Action and Description Manage Phonebook Display Photos from Phonebook Certain smartphones may support transferring street addresses when listed with phonebook contact information. If your cell phone supports this feature, you can select and use these addresses as destinations and save them as favorites.
Page 419 MyFord Touch (If Equipped) Composing a Text Message Note: Downloading and sending text messages using Bluetooth are cell Note: This is a speed-dependent feature. phone-dependent features. It is unavailable when your vehicle is traveling at speeds over 3 mph (5 km/h). To compose and send a text message, select: Message Action and Description...
Page 420: Phone Settings
MyFord Touch (If Equipped) Phone Settings To enter the phone settings menu select: Message Action and Description Phone Settings Then any of the following: Bluetooth Devices Connect, disconnect, add or delete a device, as well as save it as a favorite. Bluetooth To turn Bluetooth off or on.
Page 421: Information
MyFord Touch (If Equipped) Phone Voice Commands Voice command Call Voicemail E142599 Listen to Message Press the voice button and when Reply to Message prompted say any of the following or a Pair Phone similar command: Help INFORMATION E188418 If your vehicle is equipped with Navigation, press the Item Message...
Page 422 SYNC Services Terms and Conditions at any future obligation. www.SYNCMyRide.com. If you do not want Ford or its service providers to collect your Note: SYNC Services requires activation vehicle travel information or other before use. Visit www.SYNCMyRide.com to...
Page 423 MyFord Touch (If Equipped) To use voice commands, press the voice button and say: Voice Command Action and Description Services This initiates an outgoing call to SYNC Services using your paired and connected Bluetooth-enabled cellular phone. Once you connect to the service, follow the voice prompts to request the desired service, for example traffic or directions.
Page 424 MyFord Touch (If Equipped) Receiving Turn-by-Turn Directions Press the voice button and say: Voice Command Action and Description Directions To receive directions to a location. Once you select your destination, the system uploads your current vehicle location, calculates a route based on current traffic conditions and sends it back to your vehicle.
Page 425 MyFord Touch (If Equipped) Disconnecting from SYNC Services To use voice commands, press the To use the steering wheel controls, press voice button and say: and hold the hang-up phone button on the steering wheel. Voice Command Good-bye SYNC Services Quick Tips Tips Personalizing You can personalize your Services feature to provide quicker...
Page 426 Sirius Travel Link. road. Your primary responsibility is the safe Note: Neither Sirius nor Ford is responsible operation of your vehicle. We recommend for any errors or inaccuracies in the Sirius against the use of any handheld device Travel Link services or its use in vehicles.
Page 427 MyFord Touch (If Equipped) Menu Item Action and Description Area Select to choose from a listing of weather locations. Sports Info Touch this button to view scores and schedules from a variety of sports. You can also save up to 10 favorite teams for easier access.
Page 428 MyFord Touch (If Equipped) 911 Assist If a crash deploys an airbag, excluding knee airbags and rear inflatable safety belts WARNINGS where fitted or activates the fuel pump shut-off, your SYNC-equipped vehicle may Unless the 911 Assist setting is set on be able to contact emergency services by before a crash, the system will not dialing 911 through a paired and connected...
Page 429 MyFord Touch (If Equipped) In the Event of a Crash You can also access 911 Assist by Not all crashes deploy an airbag or activate pressing: the fuel pump shut-off (which would trigger 911 Assist); however, SYNC tries to Message contact emergency services if 911 Assist Settings triggers.
Page 430 MyFord Touch (If Equipped) 911 Assist Privacy Notice Note: In order to allow a break-in period for your vehicle, you may not be able to create When you turn on 911 Assist, it may a Vehicle Health Report until your vehicle disclose to emergency services that your odometer has reached 200 miles.
Page 431: Climate
Vehicle Health Report Privacy Notice current location, if When you create a Vehicle Health Report, your vehicle is Ford Motor Company may collect your equipped with cellular phone number (to process your navigation. If your report request) and diagnostic information vehicle is not about your vehicle.
Page 432 MyFord Touch (If Equipped) E208904 Power: Touch the button to switch the system on and off. Switching off the climate control system prevents outside air from entering the vehicle. Passenger settings: Touch the + or – to increase or decrease the air temperature on the passenger side of the vehicle.
Page 433 MyFord Touch (If Equipped) Touch Rear Control to allow the rear seat passengers to adjust the rear climate settings. Touch it again to prevent the rear seat passengers from adjusting the settings. Rear Control automatically turns off when you use the touchscreen to adjust the rear climate settings.
Page 434: Navigation
MyFord Touch (If Equipped) Touch the + or – to increase or decrease the air temperature on the passenger side of the vehicle. Touch the heated seat icon to turn the heated seat off and on (if equipped). Touch the climate-controlled seat icon to turn the climate-controlled seat off and on (if equipped).
Page 435 MyFord Touch (If Equipped) Menu Item For an address destination entry, press: Menu Item Action and Descrip- tion Edit Route Pressing this button Cancel Route makes the address location appear on To set your destination, enter the the map. necessary information into the highlighted text fields (in any order).
Page 436: Point Of Interest (Poi) Categories
MyFord Touch (If Equipped) Note: If your vehicle is on a recognized road To expand these listings, press the + in and you do not press the Start Route front of the listing. button, the system defaults to the Fastest The system also allows you to sort Route option and begins guidance.
Page 437 MyFord Touch (If Equipped) Hotel • Laundry • Refrigerator • 24 hour room service E143884 • Fitness center Coffeehouse • Internet access • Pool E142636 • Wi-FI Food & Drink For restaurants, cityseekr can provide information such as star rating, average cost, review, handicap access, hours of E142637 operation, and website address.
Page 438 MyFord Touch (If Equipped) Menu Item Second Level Messages, Actions and Descriptions Turn List Format Have the system display your turn list Top to Bottom Bottom to Top Parking POI Notification When parking point of interest notification is on, the icons display on the map when you get close to your destination.
Page 439 MyFord Touch (If Equipped) Menu Item Second Level Messages, Actions and Descriptions Tones Only Voice and Tones Auto - Fill State/Province Have the system automatically fill in this information based on what you have already entered into the system. You can switch this feature: Menu Item Second Level Messages, Actions and Descriptions...
Page 440 MyFord Touch (If Equipped) Menu Item Second Level Messages, Actions and Descriptions Avoid Areas Choose areas which you want the system to avoid when calculating a route for you Then select any of the following: Once you make a selection, the system tries to avoid the area(s) if possible for all routes.
Page 441 MyFord Touch (If Equipped) The ETA box under the zoom buttons You can also select the following appears when a route is active and options: displays the distance and time to your destination. If the button is pressed, a pop Menu Items Description up appears with the destination listed (and...
Page 442 MyFord Touch (If Equipped) Starting point indicates the Next maneuver point indicates starting point of a planned route. the location of the next turn on the planned route. E142651 E142654 Waypoint indicates the location No GPS symbol indicates that of a waypoint on the map. The insufficient GPS satellite signals number inside the circle is are available for accurate map...
Page 443: Myford Touch Troubleshooting
MyFord Touch (If Equipped) HERE is the digital map provider for the The following commands can only be navigation application. If you find map data used when a navigation route is active: errors, you may report them directly to HERE by going to Voice command www.here.com/mapcreator.
Page 444 MyFord Touch (If Equipped) Websites Websites www.SYNCMyRide.ca www.SYNCMyRide.com www.syncmaroute.ca Phone issues Issue Possible cause(s) Possible solution(s) There is excessive back- The audio control settings Review your phone's manual ground noise during a phone on your phone may be about audio adjustments. call.
Page 445 MyFord Touch (If Equipped) Phone issues Issue Possible cause(s) Possible solution(s) Depending upon your phone, you may have to grant SYNC permission to access your phonebook contacts. Make sure to confirm when prompted by your phone during the phonebook download. I am having trouble This is a phone-dependent Go to the website to review...
Page 446 MyFord Touch (If Equipped) USB and media issues Issue Possible cause(s) Possible solution(s) I am having trouble This may be a possible Try turning off the device, connecting my device. device malfunction. resetting the device, removing the device's battery, then trying again. Make sure you are using the manufacturer's cable.
Page 447 MyFord Touch (If Equipped) Vehicle Health Report and Services (Traffic, Directions and Information) issues Issue Possible cause(s) Possible solution(s) I received a text that I did You did not activate your This is a free feature, but you not activate Vehicle Health account on the website.
Page 448 MyFord Touch (If Equipped) Voice command issues Issue Possible cause(s) Possible solution(s) SYNC does not understand You may be using the wrong Review the phone voice what I am saying. voice commands. commands and the media You may be speaking too voice commands at the soon or at the wrong time.
Page 449 MyFord Touch (If Equipped) Voice command issues Issue Possible cause(s) Possible solution(s) Contacts in your phonebook Using the SYNC phone may be very short and menu, open the phonebook similar, or they may contain and scroll to the name special characters. SYNC is having trouble Your phonebook contacts understanding.
Page 450: Accessories
Ford Accessories are available for your • Bedliners and bedmats. vehicle through an authorized Ford dealer. • Racks and carriers.* Ford Motor Company will repair or replace • Rear-seat entertainment.* any properly authorized dealer-installed Ford Original Accessory found to be •...
Page 451: Auxiliary Switches
Contact an authorized Ford dealer for the mobile communication system manufacturer’s limited warranty details, specifically for automotive use. and request a copy of the Ford Licensed • If you or an authorized Ford dealer add Accessories product limited warranty from any non-Ford electrical or electronic the accessory manufacturer.
Page 452 See your authorized dealer for • If you or an authorized Ford dealer add service. any non-Ford electrical or electronic The relays are coded as shown:...
Page 453 AUX 1 CAC05 Yellow AUX 2 CAC06 Green with Brown Trace AUX 3 CAC07 Violet with Green Trace AUX 4 CAC08 Brown Learn more about auxiliary switches by visiting https://www.fleet.ford.com/truckbbas/. Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 454: Extended Service Plan (Esp)
3. BaseCARE - Covers 84 components. Transferable Coverage 4. PowertrainCARE - Covers 29 critical If you sell your vehicle before your Ford components. Extended Service Plan coverage expires, Ford Extended Service Plan is honored by you can transfer any remaining coverage all authorized Ford dealers in the U.S.,...
Page 455: Scheduled Maintenance
Premium Maintenance Plan that covers all Service Plan. Ford Extended Service Plan scheduled maintenance, and selected is the only service contract backed by Ford wear items. The coverage is prepaid, so Motor Company of Canada, Limited. you never have to worry about affording Depending on the plan you purchase, Ford your vehicle’s maintenance.
Page 456: Scheduled Maintenance
If you do not use Ford authorized parts they you sell or trade it. Keep all receipts for may not meet our specifications and completed maintenance with your vehicle.
Page 457: Owner Checks And Services
It is critical that systems are Additives and Chemicals flushed only with new fluid that is the same This owner's manual and the Ford as that required to fill and operate the Workshop Manual list the recommended system or using a Ford-approved flushing additives and chemicals for your vehicle.
Page 458: Multi-Point Inspection
Scheduled Maintenance Tightening lug nuts Tighten the lug nuts to the specified torque at 500 miles Vehicles with single rear (800 km) after any wheel disturbance (such as tire rota- wheels tion, changing a flat tire or wheel removal). Tighten the wheel lug nuts to the specified torque at 100 Vehicles with dual rear miles (160 km), and again at 500 miles (800 km) of new wheels...
Page 459: Normal Scheduled Maintenance
Scheduled Maintenance Be sure to ask your dealership service your vehicle. Your checklist gives you advisor or technician about the multi-point immediate feedback on the overall vehicle inspection. It is a comprehensive condition of your vehicle. way to perform a thorough inspection of NORMAL SCHEDULED MAINTENANCE 6.2L and 6.8L Gasoline Engines Every 7500 miles (12000 km) or six months (whichever comes first)
Page 460: Special Operating Conditions Scheduled Maintenance
Scheduled Maintenance Other maintenance items Replace front wheel bearing grease and grease seal if non- sealed bearings are used. Every 97500 miles (156000 Replace spark plugs. Change engine coolant. Every 105000 miles Replace rear axle fluid. (168000 km) Inspect accessory drive belt(s). Change automatic transmission fluid and filter on 6-speed transmission.
Page 461 Scheduled Maintenance Towing a trailer or using a car-top carrier Inspect frequently, service Inspect and lubricate U-joints. as required See axle maintenance items under Exceptions. Every 5000 miles (8000 Inspect the wheels and related components for abnormal noise, wear, looseness or drag. Rotate tires , inspect tires for wear and measure tread depth.
Page 462 Scheduled Maintenance Extensive idling or low-speed driving for long distances, as in heavy commercial use (such as delivery, taxi, patrol car or livery) Every 30000 miles (48000 Change transfer case fluid (Four-wheel drive vehicles). Replace front wheel bearing grease and grease seals if non-sealed bearings are used.
Page 463: L Diesel Engine
Rear axles and power take-off units with 6.7L Diesel Engine synthetic fluid and light-duty trucks equipped with Ford-design axles are See the diesel supplement for special lubricated for life; do not check or change operating condition information. fluid unless a leak is suspected, service is...
Page 464 (wrench icon) to inform you to bring before the completion of your vehicle's your vehicle to the dealer for service. If useful life. Ford Motor Company, however, there are any issues with the oxidation urges you to have all recommended...
Page 465: Scheduled Maintenance Record
Scheduled Maintenance SCHEDULED MAINTENANCE RECORD Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 466 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 467 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 468 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 469 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 470 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 471 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 472 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 473 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 474 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 475: Appendices
The • You have acquired a device ("DEVICE") additional software and services of that includes software licensed by Ford third party origin, as well as associated Motor Company and its affiliates media, printed materials, and "online"...
Page 476 Certificate(s) of Authenticity), and the the process. Neither FORD MOTOR recipient agrees to the terms of this COMPANY nor its suppliers shall be EULA. If the SOFTWARE is an upgrade,...
Page 477 SOFTWARE ("Supplemental may collect and use technical Components"). information gathered in any manner as If FORD MOTOR COMPANY or third party part of product support services related software and services suppliers provide or to the SOFTWARE or related services. make available to you Supplemental...
Page 478 DEVICE. electronic form, you may print one copy of UPGRADES AND RECOVERY MEDIA: such electronic documentation. If the SOFTWARE is provided by FORD EXPORT RESTRICTIONS: You MOTOR COMPANY separate from the acknowledge that the SOFTWARE is DEVICE on media such as a ROM chip, CD subject to U.S.
Page 479 Adobe TRADEMARKS: This EULA does not grant you any rights in connection with any Contains Adobe® [Flash® Player] or trademarks or service marks of FORD [AIR®] technology by Adobe Systems MOTOR COMPANY, MS, Microsoft Incorporated. This [Licensee Product] Corporation, third party software or service contains [Adobe®...
Page 480 Appendices Use of Speech Recognition Functions: WARNING Speech recognition software is inherently Operating certain parts of this a statistical process which is subject to system while driving can distract errors. It is your responsibility to monitor your attention away from the road, any speech recognition functions included and possibly cause an accident or other in the system and address any errors.
Page 481 Appendices Potential Map Inaccuracy: Maps used Telenav may revise this Agreement and by this system may be inaccurate because the privacy policy at any time, with or of changes in roads, traffic controls or without notice to you. You agree to visit driving conditions.
Page 482 Appendices 2. Account Information or proprietary rights, rights of publicity or privacy or other rights of any party, (ii) You agree: (a) when registering the violates any law, statute, ordinance or Telenav Software, to provide Telenav with regulation, including but not limited to laws true, accurate, current, and complete and regulations related to spamming, information about yourself, and (b) to...
Page 483 Appendices COURSE OF DEALING, CUSTOM OR STATES AND/OR JURISDICTIONS DO NOT TRADE AND INCLUDING, BUT NOT ALLOW THE EXCLUSION OR LIMITATION LIMITED TO, THE IMPLIED WARRANTIES OF INCIDENTAL OR CONSEQUENTIAL OF MERCHANTABILITY, FITNESS FOR A DAMAGES, SO THE ABOVE LIMITATIONS PARTICULAR PURPOSE AND OR EXCLUSIONS MAY NOT APPLY TO NON-INFRINGEMENT OF THIRD PARTY...
Page 484 Appendices the terms and conditions of this Notices by posting them on Telenav’s Agreement. Any such sale, assignment or Website or by downloading such Notices transfer that is not expressly permitted to your wireless device. If you desire to under this paragraph will result in withdraw your consent to receive Notices immediate termination of this Agreement, electronically, you must discontinue your...
Page 485 Appendices Agreement), and thus your use of the 9.2 End User Terms Required by NAV2 Telenav Software is also subject to such (Shanghai) Co., Ltd terms. You agree to comply with the The data (“Data”) is provided for your following additional terms and conditions, personal, internal use only and not for which are applicable to Telenav’s third resale.
Page 486 Appendices Disclaimer of Liability: positioning devices or any mobile or wireless-connected electronic or computer TELENAV AND ITS LICENSORS devices, including without limitation (INCLUDING THEIR LICENSORS AND cellular phones, palmtop and handheld SUPPLIERS) SHALL NOT BE LIABLE TO computers, pagers, and personal digital YOU: IN RESPECT OF ANY CLAIM, assistants or PDAs.
Page 487 Appendices that any such export laws, rules or regulations prohibit HERE from complying NOTICE OF USE with any of its obligations hereunder to CONTRACTOR (MANUFACTURER/ deliver or distribute Data, such failure shall SUPPLIER) NAME: HERE be excused and shall not constitute a breach of this Agreement.
Page 488 Appendices 2. Copyright Notice: In connection with B. Canada Data. The following provi- each copy of all or any portion of the sions apply to the Data for Canada, Data for the Territory of Canada, Client which may include or reflect data from shall affix in a conspicuous manner the third party licensors (“Third Party following copyright notice on at least...
Page 489 Appendices either express or implied, arising by II. Mexico. The following provision applies law or otherwise, including but not to the Data for Mexico, which includes limited to, effectiveness, complete- certain data from the Instituto Nacional ness, accuracy or fitness for a de Estadística y Geografía (“INEGI”): particular purpose.
Page 490 Appendices A. Third Party Notices. Any and all copies V. Europe Territory of the Data and/or packaging relating thereto shall include the respective Third A. Use of Certain Traffic Codes in Europe Party Notices set forth below and used as described below corresponding to 1.
Page 491 Appendices is conditioned on Client’s obtaining prior Austria “© Bundesamt für Eich- und written consent from Kartografie a.s.; Vermessungswesen” (c) such license for selling or distributing Croatia with respect to Data for the Territory of Cyprus, Switzerland is conditioned on Client’s Estonia, obtaining a permit from Bundesamt für Latvia,...
Page 492 Appendices Sweden “Based upon electronic data Product incorporates data which is © © National Land Survey 20XX Telstra Corporation Limited, GM Sweden.” Holden Limited, Intelematics Australia Pty Ltd and Continental Pty Ltd. Switzer- “Topografische Grundlage: © land Bundesamt für Landestopo- B.
Page 493 Appendices No Other Warranty: with or in communication with any positioning devices or any mobile or EXCEPT FOR THE LMITED WARRANTY wireless-connected electronic or computer SET FORTH ABOVE AND TO THE EXTENT devices, including without limitation PERMITTED BY APPLICABLE LAW, NAV2 cellular phones, palmtop and handheld AND ITS LICENSORS (INCLUDING THEIR computers, pagers, and personal digital...
Page 494 Appendices Export Control Gracenote® Copyright You agree not to export to anywhere any CD and music-related data from part of the Data provided to you or any Gracenote, Inc., copyright© 2000-2007 direct product thereof except in Gracenote. Gracenote Software, copyright compliance with, and with all licenses and ©...
Page 495 Appendices You agree that you will use the content THE GRACENOTE SOFTWARE, EACH ITEM from Gracenote ("Gracenote Content") , OF GRACENOTE DATA AND THE Gracenote Data, the Gracenote Software, GRACENOTE CONTENT ARE LICENSED and Gracenote Servers for your own TO YOU "AS IS". NEITHER GRACENOTE personal, non-commercial use only.
Page 496 Appendices Vehicle with SYNC only United States and Mexico FCC ID: KMHSG1G1 IC: 1422A-SG1G1 Mexico Model: KMHSG1P1 NOM-121-SCT1-2009 The operation of this equipment is subject to the following two conditions: (1) This equipment or device may not cause harmful interference, and (2) this equipment or device must accept any interference, including interference that may cause undesired operation.
Page 497 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 498 Index Audio Unit - Vehicles With: AM/FM/CD/ Touchscreen Display........322 Audio Unit - Vehicles With: AM/FM..318 Autolamps............72 See: Four-Wheel Drive........158 Autolamps - Programmable Exit Delay..............72 Automatic Climate Control......111 Automatic Transmission......151 Brake-Shift Interlock.........155 See: Climate Control..........110 If Your Vehicle Gets Stuck In Mud or About This Manual...........7 Snow..............156 Understanding the Shift Positions of a...
Page 499 Index Capacities and Specifications - 6.8L Cleaning the Engine........257 Triton-30V - V10..........311 Cleaning the Exterior........256 Specifications............312 Exterior Chrome Parts........256 Capacities and Specifications....303 Exterior Plastic Parts.........257 Car Wash Stripes or Graphics..........257 See: Cleaning the Exterior......256 Underbody............257 Center Console..........139 Cleaning the Instrument Panel and Instrument Cluster Lens......259 Removable Front Cupholders......139 Changing a Bulb...........249...
Page 500 Supported Media Players, Formats and See: Front Fog Lamps.........73 Foot Pedals Metadata Information.........410 Environment............14 See: Adjusting the Pedals.........69 Ford Credit............11 (U.S. Only)..............11 Four-Wheel Drive.........158 Front Fog Lamps..........73 Front Seat Armrest........127 Fuel and Refueling........144 Super Duty (TFA) Canada/United States of America, enUSA, First Printing...
Page 501 Index Fuel Consumption........147 Hazard Warning Flashers......213 Calculating Fuel Economy......148 Filling the Tank.............147 See: Using Hill Descent Control.....177 Fuel Filter............244 Head Restraints..........117 Fuel Quality.............145 Adjusting the Head Restraint......118 Heated Seats..........124 Choosing the Right Fuel........145 Choosing the Right Fuel With a Flex Fuel Rear Heated Seats ..........124 Heated Steering Wheel.......68 Vehicle (If Equipped)........145...
Page 502 Index Information Messages.......100 4WD................109 AdvanceTrac ...........100 Keyless Entry............57 Alarm..............100 SECURICODE KEYLESS ENTRY Diesel Messages..........101 KEYPAD...............57 Doors and Locks..........104 Unlocking and Locking the Doors....59 Drivetrain...............104 Keys and Remote Controls......47 Engine..............105 Fuel................105 Key................105 Maintenance............106 Lighting Control..........71 MyKey®..............106 Headlamp Flasher..........72 Off Road..............107 High Beams..............71 Park Aid..............107 Lighting..............71 Park Brake..............107...
Page 503 Index Memory Function.........120 Ordering Additional Owner's Literature............221 Easy Entry and Exit Feature......122 Linking a PreSet Position to your Remote Obtaining a French Owner’s Manual...221 Overhead Console........139 Control or Intelligent Access Key Fob ................121 Recalling a Preset Position.......121 Saving a Preset Position........121 Message Center Parking Aid............179 See: Information Displays.........89...
Page 504 Index Rear Seats............122 Roadside Assistance........212 Folding the Rear Seat Back (Crew Cab) Vehicles Sold in Canada: Getting Roadside ................122 Assistance............212 Folding up the Rear Seat Cushion....122 Vehicles Sold in Canada: Using Roadside Rear Under Seat Storage (Crew Cab)..123 Assistance............212 Returning the Seat to the Seating Vehicles Sold in the United States: Getting Position..............122 Roadside Assistance........212...
Page 505 Index Snowplowing..........209 Supplementary Restraints System..37 Engine temperature while plowing....210 Principle of Operation.........37 Symbols Glossary..........7 Installing the Snowplow.........209 SYNC Applications and Operating the Vehicle with the Snowplow Services............346 Attached............210 Snowplowing with your Airbag Equipped 911 Assist...............346 Vehicle...............210 SYNC Services: Traffic, Directions & Transmission operation while Information (TDI) (If Equipped, United plowing...............211...
Page 506 Index Towing Points..........204 Using Stability Control........174 Towing the Vehicle on Four AdvanceTrac® with Roll Stability Control Wheels............206 (RSC®)...............174 Using SYNC With Your Media Emergency Towing...........206 Player............355 Recreational Towing........206 Towing..............192 Accessing Your Play Menu......360 Traction Control..........172 Connecting Your Digital Media Player to the Principle of Operation........172 USB Port............355 Trailer Sway Control........193...
Page 507 Index Vehicle Storage..........261 Washers Battery..............262 See: Cleaning the Exterior......256 Body.................261 See: Wipers and Washers.........70 Waxing..............257 Brakes..............262 Wheel Nuts Cooling system...........262 Engine..............262 See: Changing a Road Wheel.......290 Wheels and Tires.........264 Fuel system............262 General..............261 General Information.........264 Miscellaneous.............262 Technical Specifications........301 Windows and Mirrors........76 Removing Vehicle From Storage....262 Windshield Washers........70 Tires................262...

Ford 2016 SUPER DUTY Owner's Manual

Introduction

Environment

Child Safety

Safety Belts

Supplementary Restraints System

Keys and Remote Controls

Mykey

Locks

Tailgate

Security

Steering Wheel

Pedals

Wipers and Washers

Lighting

Windows and Mirrors

Instrument Cluster

Information Displays

Climate Control

Seats

Universal Garage Door Opener

Auxiliary Power Points

Storage Compartments

Starting and Stopping the Engine

Fuel and Refueling

Transmission

Four-Wheel Drive

Rear Axle

Brakes

Traction Control

Stability Control

Terrain Response

Parking Aids

Cruise Control

Driving Aids

Load Carrying

Towing

Driving Hints

Roadside Emergencies

Customer Assistance

Fuses

Maintenance

Quick Links

Troubleshooting

Related Manuals for Ford 2016 SUPER DUTY

Summary of Contents for Ford 2016 SUPER DUTY
