3. LIST OF COMPONENTS

3.1 Table of Components – Driver Board
Circuit Designation
Resistors
R1
R2 – R7
R8 – R11
R12 – R14
R15
R16
R17 – R19
R20
RN1 – RN6
Capacitors
C1, C2
C3
C4
C5
C6
C7 – C9
Transistors
Q1
Q2 – Q4
Q15
Diodes
D1 – D3
D4
D5
D6
RGB1 – RGB8
Integrated Circuits
IC1
IC2
IC3, IC4
IC5
Miscellaneous
L1
AM1, PM1, AM2, PM2
ALARM, SET, ADJ, DST
IC2 Socket
IC3, IC4 Socket
J1
GPS / RFT and GPS2
PIR and PIR2
LS1
FUSE
VR1
X1
HV Module
Nixie Tube Clock 'Spectrum 18'
Issue 2 (15 February 2015)
www.pvelectronics.co.uk
Part Description
6.8 KΩ, ¼ Watt
10 KΩ, ¼ Watt
270 KΩ, ¼ Watt
270 Ω, ¼ Watt
6.8 KΩ, ¼ Watt
15 KΩ, ¼ Watt
270 Ω, ¼ Watt
6.8 KΩ, ¼ Watt
Quad Resistor Network, 220Ω
220uF Electrolytic 16-25V
10pF Ceramic
15pF Ceramic
100nF Ceramic
0.1F or 0.22F Supercapacitor
100nF
MPSA42
2N7000 MOSFET
MPSA42
1N5819
5mm Yellow LED
5mm Green LED
5mm Yellow LED
RGB 5mm LED, common anode
LM2576 5V voltage regulator
PIC16F1938 in socket
HV5622 in socket
DS18B20
100uH inductor
6mm wire ended neon lamp
Miniature push button
28 Way narrow IC socket for IC2
PLCC44 IC socket for IC3
2.1mm PCB power socket
Surface mount 3.5mm jack socket
Surface mount 3.5mm jack socket
Piezo sounder
500mA fuse
1KΩ Potentiometer
32.768KHz watch crystal
High Voltage Module in header
