Audio Enancement CA-50A Quick Start Manual

IR-Satelite (TLD100)
Dome Sensor LED Indicators
Teacher
Microphone System Power ON
Active
Turn power on to
activate classroom
sound system
UP Volume
control button
DOWN Volume
control button
Press and hold PWR button
to turn microphone On/O
A momentary press of PWR button
will Mute/Unmute microphone
audio. If muted for more than
5 minutes, the microphone will
automatically turn o .
Student
Microphone
Active
Teacher and Student Volumes are
remotely controlled from the
Teacher Microphone and not from
the front panel of the ampli er.
See page 3 for detailed remote
volume control information.
Press and hold for
Step 1.
more than 2 seconds
the black back of the microphone facing towards you.
to activate SAFE
alert system.
Step 2.
shaped arrow on the charging connector is facing you.
See page 3 for detailed
SAFE System
information Step 3.
www.AudioEnhancement.com • 800.383.9362
Front Panel Controls
Front panel line level
output for Assistive
Listening Device (ALD) such
as a student FM transmitter
Charging the Microphone
Position the Micro Teardrop Teacher Microphone with
Align the charger connector so that the small triangle
Insert the connector into the microphone.
CA-50A Ampli er
Quick-Start Manual
DVD
Level controls for
Multimedia (Line) Sources
Front panel line
portable device
Bass, Mid, Treble
Tone Controls
input for a
