Receiver
LED Status Indicators
Microphone 1
Active
System Power ON
Note: Individual
volume levels of the
Teacher Microphone
can be adjusted with
the UP and DOWN
volume buttons.
Press & hold the
PWR button to turn
the mic on or o .
A momentary press of the PWR button will mute or unmute
the microphone audio. If muted for more than 5 minutes,
the microphone will turn o automatically.
CAT6
Microphone 2
Line Output
Active
DC Power Input
Reset Button
USB Port
Note: Volume levels on line
inputs can only be adjusted
via USB or in a browser if
connected to the network.
UP
Install and run the MS-450
Volume
software before connecting
the USB.
Step 1. Connect the micro-USB plug of
the charger to the DC input terminal of
the microphone.
DOWN
Volume
Step 2. The charger indicator light will
blink at 2-second intervals
Step 3. The charger indicator light will
remain on once fully charged.
www.AudioEnhancement.com • 800.383.9362
www.AudioEnhancement.com • 800.383.9362
XD MS-450 Ampli er
Quick Start Manual
Front Panel Terminals
Microphone and I/O Connections
Power/Status
RS-232
Indicator LED
Remote Control Ports
Charging the XD Teacher Microphone
PoE Network
Connection
XD
Receiver
Balanced
Unbalanced
Line Input
Summed
Stereo Inputs
1
