the wind speed, or select a lower number to decrease the
responsiveness.
• Select Auto to automatically adjust the filter settings
based on wind conditions.
4
Select Done.
Maintenance and Storage
• If needed, use a mild soap solution to clean the wind
transducer, and rinse it with water. Do not use detergents or
high-pressure water.
• It is recommended to remove the wind transducer and store it
in a dry location if it will not be used for long periods of time.

Specifications

Specification
Dimensions when mounted (H×L)
Weight
Cable length
Operating temperature
Storage temperature
Water resistance rating
Power usage (wind transducer)
Power usage (wind transducer and
GND 10)
Typical current draw at 12 VDC
(wind transducer)
Typical current draw at 12 VDC
(wind transducer and GND 10)
Wind speed range
4
Value
345 mm (13.58 in.) × 610 mm
(24 in.)
260 g (9.17 oz.)
25 m (82 ft.)
From -15° to 70°C (5° to 158°F)
From -20° to 80°C (-4° to 176°F)
IEC 60529 IPX-6 (protected
against heavy seas)
0.33 W
0.85 W
28 mA
71 mA
From 0.8 to 90 knots (From 0.4
to 50 m/s)
