Service Manual
Refrigerator
Model: FR-510M
Caution

: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : FR510P0010
FR-540M
FR-510P
FR-540P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-510M and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo FR-510M

Summary of Contents for Daewoo FR-510M

  • Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.

  • Page 2: Table Of Contents

    CONTENTS 1. Specification -----------------------------------------------------------------------------------------------1 2. External view-----------------------------------------------------------------------------------------------2 3. Wire diagram --------------------------------------------------------------------------------------------- 3 4. Name of parts--------------------------------------------------------------------------------------------- 4 5. Air flow diagram----------------------------------------------------------------------------------------- 5 6. Refrigerant cycle diagram ---------------------------------------------------------------------------- 6 7. Machine room view and part list--------------------------------------------------------------------7 8. Main components----------------------------------------------------------------------------------------- 8 9. Door color specification--------------------------------------------------------------------------------- 9 10.

  • Page 3: Specification

    1. SPECIFICATION MODEL NAME FR-510M FR-540M FR-510P FR-540P 200g 200g 200g 200g Refirgerant R134a 170g 170g 170g 170g Cooling System Fan Cooling Convection Refrigeration System Air Forced Convection Defrost System Fin Evaporator Forced Defrost Operation Automatic Start & Stop Cold Control...

  • Page 4: External View

    2. EXTERNAL VIEWS 1. FR-510M 2. FR-540M...

  • Page 5: Wire Diagram

    3. WIRE DIAGRAM 1. FR-510M, 540M TEMP FUSE BLACK GRAY COMPRESSOR BLUE DEFROST PINK HEATER L/BLUE WHITE P-RELAY GN/YW R-LAMP BIMETAL PLUG WHITE R-LAMP BROWN BROWN F-LAMP 4 RED BLACK WHITE/BLUE YELLOW TEMP CONTROLLER 2. FR-510P, 540P M-PCB YELLOW YELLOW...

  • Page 6: Name Of Parts

    4. NAME OF PARTS 1. FR-510M, 540M 1 Freezer Compartment Lamp 2 Shelf Freezer & Ice Tray Guide 3 Case Icing 4 Case Ice 5 Case Child 6 Temperature Controller (Refrigerator Compartment) 7 Shelf Refrigerator 8 Window Refrigerator 9 Lever Moisture Control...
  • Page 7 3. FR-510P 4. FR-540P...

  • Page 8: Air Flow Diagram

    5. AIR FLOW DIAGRAM Freezer door pocket Do not put ice cream or frozen Freezer room food in freezer door pocket to Do not put any bottle such as store for a long term. Opening beer or beverage because it can and shutting the door can rise up -16~-18 -16~-18...

  • Page 9: Refrigerant Cycle Diagram

    6. REFRIGERANT CYCLE DIAGRAM ACCUM SUC-PIPE COOLING PIPE...

  • Page 10: Machine Room View And Part List

    7. MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME PART NAME BASE COMPRESSOR DRYER BIND WIRE COMPRESSOR PIPE CON (SUC) PLUG POWER AS ABSORBER COMPRESSOR VIBRATIONPROOF GUM SCREW MACHINE WASHER COMP. *T PIPE CON (AUX) PIPE CON (HOT) SWITCH P-RELAY AS HOSE DRAIN (B) TAPE OPP...

  • Page 11: Main Components

    8. MAIN COMPONENTS 1. COMPRESSOR Refrigerant Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Comp. model BL25YE-2-C SL28YE-5-C PL25YE-4-C SL28YE-5-C Part code 3952125C20 3954128C50 3956125C40 3954128C50 Strating type RSIR RSCR RSIR Refrigerant R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz...
  • Page 12 Refrigerant R12, R134a Voltage 110V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Spec. Part code 3013600050 3013600020 8. DEFROST TIMER (FR-510M, 540M) Refrigerant R12, R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Spec. TMDEX09UM1 Part code...
  • Page 13 POWER CORD SPECIFICATION SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK 3011315000 CP-2PIN FOR EUROPEAN COUNTRY 401RA17200 CP-2PIN FOR OTHER COUNTRY 4006D17101 KP-30 FOR AMERICA 401PD17101 KP-211 FOR JAPAN & TAIWAN 3011300801 BP-3PIN 3011303010 #267 FOR CHILE 3011315310 FOR ISRAEL FOR U.K, MIDDLE ASIA 3011303050 BS-1363A...

  • Page 14: Door Color Specification

    9. DOOR COLOR SPECIFICATION 1. FR-510M, 510P 1. ASSEMBLY URETHAN FREEZER DOOR 1) FR-510M Refrigerant R134a Color type Dull lamina High glossy High glossy Dull lamina High glossy High glossy Normal PCM Normal PCM sheet lamina sheet bright PCM sheet...
  • Page 15 COLOR TABLE 1. PCM type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) '97 BEIGE (BE215)
  • Page 16 2. Lamina sheet type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) S/GOLD G/GREEN...

  • Page 17: Exploded View And Parts List

    10. EXPLODED VIEWS AND PARTS LIST 1. FR-510M, 540M 1.Exploded view...
  • Page 18 2. Parts list CONTENTS PART CODE PART NAME DESCRIPTION QUANTITY REMARK ASSY URT CAB HEATER GLAS TUBE AS REFER TO # 10 3011408100 COVER HTR *U 3011408200 COVER HTR *T 4010G19010 FIXTURE DEFR HTR 3017000502 EVAPORATOR SAS 400EL21213 FUSE TEMP AS 3018111100 SWITCH BIMTL AS 3014502101...
  • Page 19 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 3012300600 GASKET F DR AS PVC-S 3019002100 POCKET F *T GPPS T3.0 3014202610 PANEL F CONTL ABS T2.3 3012901400 HINGE *T AS 3016001800 SPECIAL BOLT M6 x L16 3011408700 COVER *T HI ASSY URT *U DOOR REFER TO # 12 3017402301 LINER R DR...
  • Page 20 FR-540M PART CODE PART NAME DESCRIPTION QUANTITY REMARK ASSY URT CAB HEATER GLAS TUBE AS REFER TO # 10 3011408100 COVER HTR *U 3011408200 COVER HTR *T 4010G19010 FIXTURE DEFR HTR 3017000502 EVAPORATOR SAS 400EL21213 FUSE TEMP AS 3018111100 SWITCH BIMTL AS 3014502101 PLATE DV AS 3018100010...
  • Page 21 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 3012300600 GASKET F DR AS PVC-S 3019002100 POCKET F *T GPPS T3.0 3014202610 PANEL F CONTL ABS T2.3 3012901400 HINGE *T AS 3016001800 SPECIAL BOLT M6¡¿L16 3011408700 COVER *T HI ASSY URT *U DOOR REFER TO # 12 3017402501 LINER R DR...
  • Page 22 2. FR-510P, 540P 1. Exploded view...
  • Page 23 2. Parts list FR-510P  Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr) PART CODE PART NAME...
  • Page 24 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 3014302300 PCB *F AS 3012901400 HINGE *T AS 3016001800 SPECIAL BOLT M6 x L16 3011408700 COVER *T HI ASSY URT *U DOOR REFER TO # 12 3017402301 LINER R DR ABS 1.4 x 785 x 1060 3012301600 GASKET R DR AS PVC-S+MAGNET...
  • Page 25 FR-540P  Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr) PART CODE PART NAME...
  • Page 26 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 3014302300 PCB *F AS 3012901400 HINGE *T AS 3016001800 SPECIAL BOLT M6 x L16 3011408700 COVER *T HI ASSY URT *U DOOR REFER TO # 12 3017402501 LINER R DR ABS 1.4 x 785 x 1085 3012300500 GASKET R DR AS PVC-S...

  • Page 27: Electronic Function

    11. ELECTRONIC FUNCTION 1. FR-510P, 540P 1) How to use the panel • When you press the Time Set button, "HOUR" blinks, and the time can be set by pressing the time adjust button( , • By pressing time set button again, "MINUTE"...
  • Page 28 2) Function table Control Control Contents Remark Function Objects Initial Time 1. In the initial operation, the temperature is automatically set at operation Temperature normal position and the clock is set at 12:00 AM. control QUICK FREEZER TEMP. CONTROL ECONOMIC TIME SET FREEZING TIME ADJUSTER...
  • Page 29 Control Control Contents Remark Function Objects QUICK FREEZER TEMP. CONTROL ECONOMIC TIME SET FREEZING TIME ADJUSTER FREEZING FRESH F R Z . CLEAN 2. 1) LED displays the temperature set by the temperature control button, and the bar LED lights in sequence until set temperature.
  • Page 30 Control Control Contents Remark Function Objects Economic COMP. 1. When the economic freezing button is pressed the LED lights F-fan and the operation is started. freezing C-fan QUICK FREEZER TEMP. CONTROL ECONOMIC TIME SET FREEZING TIME ADJUSTER FREEZING FRESH F R Z . CLEAN 2.
  • Page 31 Control Control Contents Remark Function Objects Forced COMP. 1. Press the quick freezing button 5 times, when press time set defrost F-fan button and then forced defrost mode is started. QUICK FREEZER TEMP. CONTROL ECONOMIC TIME SET TIME ADJUSTER FREEZING FREEZING FRESH F R Z .
  • Page 32 3) Self-diagnosis table Code Content Perception method Refrigerator operation state F-sensor - Short circuit - The refrigerator is run at 60% power with a malfunction 40 minute period. - Wire disconnection - When the refrigerator compartment is over frosted. the operation is forcibly stopped, then returns to a 40 minute period operation.
  • Page 33 4) circuit and wiring diagram M - PCB 5267-14A 5273-02A TIME Quick Freezing 5265-13A Economic ESTABLISHMENT POWER CORD KEY INPUT AIN1 R-SENSOR IN4145x5 SCAN B-4P-YH D-SENSOR 4051 AIN2 SCAN AIN0 SCAN F-SENSOR VAREF 25.5K IC10 1000mf 5231-04A DATA VASS 7812 37.4K WHRED C1 ERROR...
