PARTS

1. Hopper
2. Juicing Bowl
3. Pulp
Container
7. Rotation Wiper 8. Strainer
10. Pusher 11. Cleaning Brush
6
4. Smart Cap
Detachable
5. Base
6. Juice
Container
9. UltraSqueezer™
* The products illustrated/photographed in this booklet may vary slightly from the actual product.
Pusher
Align
+
Align the dots
the pusher in.
+
STEP 1
Top-set Assembly
Align the red dots
assemble in the order shown. Once
+
assembled, turn the hopper clockwise to
close.
+
+ +
STEP 2
Top-set and base assembly
Assemble the entire top-set onto the
base ensuring the arrow symbol ▼on the
+ +
hopper is aligned with the arrow symbol
on the base. Turn the top-set clockwise
ensuring the arrow symbol ▼ is aligned
with the arrow symbol .
●
and slide
●
on each part and
7
