- Page 1 Business Networking Solution Installation Guide JetStream Gigabit Smart Switch T1600G-28TS (TL-SG2424) T1600G-52TS (TL-SG2452)
-
Page 2: Fcc Statement
Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. - Page 3 Conventions Due to the similarity in structure of the Gigabit Smart Switch series, in this Installation Guide we take T1600G-28TS as an example to illustrate Chapter 2 Installation, Chapter 3 Lightning Protection and Chapter 4 Connection. This Guide uses the specific formats to highlight special messages. The following table lists the notice icons that are used throughout this guide.
-
Page 4: Table Of Contents
Contents Chapter 1 Introduction ———————————— 01 Product Overview ........01 Appearance ........... 0 Chapter 2 Installation ———————————— 05 Package Contents ........05 Safety Precautions ........05 Installation Tools ........07 Product Installation ........08 Chapter 3 Lightning Protection ———————— 10 Cabling Reasonably ........10 Connect to Ground ........12 Equipotential Bonding .......13 Use Lightning Arrester ......14 Chapter 4 Connection ————————————... -
Page 5: Chapter 1 Introduction
Appearance Front Panel ■ The front panel of T1600G-28TS is shown as the following figure. LEDs Reset 10/100/1000Mbps RJ45 Port SFP Port... - Page 6 1000Mbps. Each has a corresponding Link/Act LED and a 1000Mbps LED. SFP Port Designed to install the SFP module. T1600G-28TS features 4 individual SFP ports and supports 1000M SFP module connection only. The front panel of T1600G-52TS is shown as the following figure.
-
Page 7: Rear Panel
T1600G-28TS T1600G-52TS Rear Panel ■ The rear panel of T1600G-28TS/T1600G-52TS features a Kensington security slot, a grounding terminal and a power socket. Here we take T1600G-28TS for example. Power Socket Grounding Terminal Kensington Security Slot Figure 1-3 Rear Panel Kensington Security Slot Secure the lock (not provided) into the security slot to prevent the device from being stolen. - Page 8 JetStream Gigabit Smart Switch Grounding Terminal The switch already comes with lightning protection mechanism. You can also ground the switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed information, please refer to Chapter 3 Lightning Protection. Power Socket Connect the female connector of the power cord here, and the male connector to the AC (Alternating Current) power outlet.
-
Page 9: Chapter 2 Installation
JetStream Gigabit Smart Switch Chapter 2 Installation Package Contents Make sure that the package contains the following items. If any of the listed items is damaged or missing, please contact your distributor. This Installation Guide One Switch One Power Cord Two Mounting Brackets and the One Resource CD Fittings... -
Page 10: Site Requirements
JetStream Gigabit Smart Switch Site Requirements ■ Temperature/Humidity Please keep a proper temperature and humidity in the equipment room. Too high/low humidity may lead to bad insulation, electricity leakage, mechanical property changes and corrosions. Too high temperature may accelerate aging of the insulation materials and can thus significantly shorten the service life of the device. -
Page 11: Installation Tools
JetStream Gigabit Smart Switch Lightning Protection Extremely high voltage currents can be produced instantly when lightning occurs and the air in the electric discharge path can be instantly heated up to 20,000℃. As this instant current is strong enough to damage electronic devices, more effective lightning protection measures should be taken. -
Page 12: Product Installation
JetStream Gigabit Smart Switch 2.4 Product Installation Desktop Installation ■ To install the device on the desktop, please follow the steps: 1. Set the device on a flat surface strong enough to support the entire weight of the device with all fittings. 2. - Page 13 JetStream Gigabit Smart Switch Rack Figure 2-3 Rack Installation Caution: Please set 5~10cm gaps around the device for air circulation. ■ Please avoid any heavy thing placed on the device. ■ Please mount devices in sequence from the bottom to top of the rack and ensure a ■...
-
Page 14: Chapter 3 Lightning Protection
JetStream Gigabit Smart Switch Chapter 3 Lightning Protection Cabling Reasonably In the actual network environment, you may need cable outdoors and indoors, and the requirements for cabling outdoors and indoors are different. A reasonable cabling system can decrease the damage of induced lightning to devices. Note: It's not recommended using Ethernet cables outdoors. -
Page 15: Requirements For Cabling Indoors
JetStream Gigabit Smart Switch Requirements for Cabling Indoors ■ When cabling indoors, keep a certain distance away from the devices that may cause high-frequency interferences, such as down-conductor cable, powerline, power transformer and electromotor. The main cable should be paved in the metal raceway of the access shaft. When ■... -
Page 16: Connect To Ground
JetStream Gigabit Smart Switch Min Parallel Cable Pave Way Length (mm) Parallel cabling 2~5kVA One is in the grounded metal raceway or metal pipe powerline The both are in the grounded metal raceway or metal pipe Parallel cabling >5kVA One is in the grounded metal raceway or metal pipe powerline The both are in the grounded metal raceway or metal pipe... -
Page 17: Equipotential Bonding
JetStream Gigabit Smart Switch Note: The grounding bar and the ground cable are not provided with our product. If needed, please self purchase them. Connecting to the Ground via the Power Supply ■ If the device is installed in the normal environment, the device can be grounded via the PE (Protecting Earth) cable of the AC power supply as shown in the following figure. -
Page 18: Use Lightning Arrester
JetStream Gigabit Smart Switch Grounding Terminal Equipotential Bonding Cable Ground Cable Grounding Bar Figure 3-3 Equipotential Bonding When equipotential bonding, please note that the cable should be copper conductor with a sectional area of 6mm at least, wrapped green with yellow stripe. The shorter cable the better, and use a grounding bar to establish an equipotential bonding point. - Page 19 JetStream Gigabit Smart Switch When purchasing or using a signal lightning arrester, please observe the following rules: The port rate of the signal lightning arrester should match the rate of the desired ■ port on the device. If it is not matched, this signal lighting arrester will not work. Purchase a standard lightning arrester.
-
Page 20: Chapter 4 Connection
JetStream Gigabit Smart Switch Chapter 4 Connection Ethernet Port Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shown. RJ45 Port RJ45 Cable Figure 4-1 Connecting the RJ45 Port 4.2 SFP Port Connect the SFP port to a SFP module as shown below. -
Page 21: Power On
JetStream Gigabit Smart Switch 4.4 Power On Plug in the negative connector of the provided power cord into the power socket of the device, and the positive connector into a power outlet as the following figure shown. Figure 4-3 Connecting to Power Supply Note: The figure is to illustrate the application and principle. -
Page 22: Chapter 5 Configuration
JetStream Gigabit Smart Switch Chapter 5 Configuration Configure the Switch via GUI 1. To access the GUI of the switch, open a web browser and type the default management address http://192.168.0.1 in the address field of the browser, then press the Enter key. Figure 5-1 Web Browser Note: To log on to the GUI of the switch, the IP address of your PC should be set in the same subnet addresses of the switch. -
Page 23: Configure The Switch Using Cli
JetStream Gigabit Smart Switch Figure 5-3 Main Page of the Switch 5.2 Configure the Switch Using CLI You can log on to the switch and access the CLI by Logging on to the switch remotely by a Telnet connection through an Ethernet port. To log on to the switch by a Telnet connection, please take the following steps: 1. - Page 24 JetStream Gigabit Smart Switch 3. Type cmd in the prompt Run window as Figure 5-5 shows and click OK. Figure 5-5 Run Window 4. Type telnet 192.168.0.1 in the command prompt shown as Figure 5-6, and press the Enter button. Figure 5-6 Connecting to the Switch Configuration...
-
Page 25: Appendix A Troubleshooting
JetStream Gigabit Smart Switch Appendix A Troubleshooting Q1. What could I do if I forgot the username and password of the switch? Press the RESET button for at least 5 seconds to reset the system. The system will be reset to the factory default settings, and the default login user name and password are both admin. -
Page 26: Appendix B Hardware Specifications
1000Base-T: 4-pair UTP/STP of Cat. 5e and Cat. 6 or above (maximum 100m) 1000Base-X: MMF or SMF SFP Module (Optional) LEDs T1600G-28TS: PWR, SYS, Reset, 1000Mbps, Link/Act T1600G-52TS: PWR, SYS, Reset, 10/100/1000Mbps (port 1-48), Link/Act (port 49-52) Operating Temperature 0℃~40℃... - Page 28 Website: http://www.tp-link.com E-mail: support@tp-link.com 7106505040 REV1.0.0...
