Braemar ECOSTAR SH18 Operating Instructions Manual

Gas space heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

LAYOUT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECOSTAR SH18 and is the answer not in the manual?

Questions and answers

Related Manuals for Braemar ECOSTAR SH18

Summary of Contents for Braemar ECOSTAR SH18

  • Page 1 LAYOUT...

  • Page 2: Table Of Contents

    Contents Section Page Operating the heater Heater control panel functions Turning the heater ON Turning the heater OFF Adjusting the room temperature Selecting ECO mode Locking the controls Normal heater operation Caring for your heater Cleaning Maintenance If your heater stops working Problem - potential cause/check Fault messages Important safety information...

  • Page 3: Operating The Heater

    Operating the heater HEATER CONTROL PANEL FUNCTIONS Child lock Eco mode indicator indicator Set temperature On/off Up button indicators button Down button Turning the heater ON Press the ON/OFF button. The set temperature indicators illuminate red to show the set temperature. If the room temperature is below the set temperature the heater will start.

  • Page 4: Adjusting The Room Temperature

    Operating the heater Adjusting the room Increase set temperature: Press the UP temperature with button to increase by 1 step. the heater turned Decrease set temperature: Press the DOWN button - each press drops the temperature setting by 1 step. Approximate temperature settings are: - Minimum: - Maximum: 28...

  • Page 5: Normal Heater Operation

    Normal heater operation Start - Heater turned on. - Heater performs check of safety systems. - Combustion fan starts. - Igniter sparks and gas valve opens. - Burners ignite at low gas rate. - Room fan starts approximately 15s after ignition. - Heater continuously checks room and set temperatures, and monitors all safety systems.
  • Page 6 Seeley International does not assume any liability for errors and/or omissions. Braemar is a registered trademark of Braemar Industries Pty Ltd. Seeley International Pty Ltd ACN 23 054 687 035...

  • Page 7: Caring For Your Heater

    Energy Safe Victoria recommend annual servicing/maintenance of all gas appliances. To arrange routine seasonal maintenance, please contact an authorised Braemar service agent on 1300 650 644. If your heater stops working If your heater stops working, it is recommended that the following simple checks be carried out prior to requesting a service call - this may avoid an un-necessary service charge.

  • Page 8: Fault Messages

    Fault messages Your Braemar Ecostar space heater uses inbuilt fault diagnosis software to help determine the source of a fault. If the heater detects a fault the heater will turn off and the control panel indicators will flash to indicate the fault code (FC) and the reset action required. Please quote this fault code if requesting a service call - this may enable the problem to be fixed over the phone.
  • Page 9 BRAEMAR ECOSTAR GAS SPACE HEATER OPERATING INSTRUCTIONS FOR MODELS SH18 AND SH25 ROOM AIR INLET HEATER CONTROL PANEL HEATED AIR OUTLET...

This manual is also suitable for:

Ecostar sh25
