Page 1: Operation Manual
Installation and Operation Manual POWER EJECT ELAPSE LOUD 4 X 50W AS/PS PULL OPEN MARINE CD RECEIVER SHIFT MODE SCAN SHIFT BAND DISP MUTE TUNE TUNE M6100CD Waterproof AM/FM/WB and CD Stereo Receiver A Registered Trademark of Magnadyne Corporation... - Page 2 Introduction Your new M6100CD entertainment system has been designed to give you many years of listening pleasure. Take a moment to read through this manual and become familiar with the operations and features of this outstanding product. It is advisable to keep this manual in your vehicle so it is readily available for reference. Be sure to fill out and send in your warranty card to ensure that you receive the full benefits of warranty repair in the unlikely event that your system will need service.
- Page 3 Location and Function of Controls at a Glance 8. Multi-Function Button 3/RPT: Radio: Recalls a memorized radio station, and programs a radio station into memory (See Radio Operation for more information). Continuously repeats the same track (See CD Operation for more information). 9.
-
Page 4: Radio Operation
Radio Operation Listening to the Radio 1. Push the “POWER” button (1) once to turn the unit on. 2. Press the “BAND” button (11) to select a radio band: FM1, FM2, FM3, AM or WX (weather band). 3. AM or FM Station Selection Automatic Seek Station Selection: Press the TRK/TUNE DN or TRK/TUNE UP button (5) to automatically seek the next strong station. -
Page 5: General Operations
General Operations Setting the Clock 1. Press DISP button (12) for more than 3 seconds until the clock shown in the display area is flashing. 2. Press the TRK/TUNE DN button to adjust the hours 3. Press the TRK/TUNE UP button to adjust the minutes. -
Page 6: Cd Player Operation
CD Player Operation Inserting and Ejecting a Disc Pull the tab at the top of the CD Door, and the door will open. Push a disc into the CD Slot (18), label side up, and the disc will begin to play. The disc will eject automatically when the CD Door is opened. - Page 7 Waterproof Wired Remote General Operations (Optional) POWER 1. Power Button: Press and release the button (1) to turn on/off the unit. To program the initial volume level, adjust the volume to the desired level, then press the POWER button for more than 3 seconds. The next time the unit is turned on, the volume will be at this initial level.
-
Page 8: Installation Procedures
This unit is a wired remote control made using a modified controller or similar layout. It is capable of operating the specified functions on the M6100CD receiver. The body, buttons, controls and display are UV and water-resistant. It includes a LCD and an illumination circuit. - Page 9 Wiring Step 1: The radio chassis is designed to be “Panel Mounted” through a opening in the mounting panel. See the installation part of this manual for panel mounting. Step 2: Bring all wiring for the connection of the unit (including the antenna) through the mounting hole.
-
Page 10: Wiring Diagram
Main Speaker White Wire with Black Stripe Left Green Wire Remote Speaker Green Wire with Black Stripe M6100CD RCA Connectors Set 1 Connect to Line Input of Optional Amplifier RCA Connectors Set 2 Connect to Line Input of Optional Amplifier... -
Page 11: Auxiliary Connection
CD Changer Connection M6100CD 8-Pin Din Connector Auxiliary Connection M6100CD Auxiliary Audio Input RCA with Yellow Cables Wired Remote Connection M6100CD Female 8-Pin Mini Din Connector Male to Male 8-Pin Din Cable (Supplied with CD changer) Audio Out From VCR / TV /... -
Page 12: Installation
Installation Remove Transportation Screws Before installing the unit, remove the two screws shown in the illustration below. Remove screws before installation Note: If this unit is to be installed in a boat or a spa, you should use the two pieces of plastic film (30 mm X 20 mm) supplied to seal the two holes after removing the screws. -
Page 13: Troubleshooting
Installation Trouble Shooting Before going through the trouble shooting table below, check the wiring connection. If the problem persist, consult your nearest service dealer. SYMPTOM CAUSE No power The ACC Power Supply is not connected. The fuse is blown. Disc cannot be loaded, Presence of disc inside the player. -
Page 14: Specifications
ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within one year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of... - Page 15 A Registered Trademark of Magnadyne Corporation © Copyright 2003 Magnadyne Corporation M6100CDUM Rev. A 11-03...
